DSM Computer AG 96M4011o User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
96M4011o
Single Board Computer
User's Manual
P/N: B8980850
Version 1.4
Copyright © DSM Computer AG, 2004. All rights reserved.
All other brand names are registered trademarks of their respective owners.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 96M4011o and is the answer not in the manual?

Questions and answers

Summary of Contents for DSM Computer AG 96M4011o

  • Page 1 96M4011o Single Board Computer User's Manual P/N: B8980850 Version 1.4 Copyright © DSM Computer AG, 2004. All rights reserved. All other brand names are registered trademarks of their respective owners.

  • Page 2: Table Of Contents

    Preface Table of Contents How to Use This Manual Chapter 1 System Overview.......................1-1 1.1 Introduction..........................1-1 1.2 Check List ............................. 1-2 1.3 Product Specification ........................1-2 1.3.1 Mechanical Drawing......................1-6 1.4 System Architecture ........................1-6 Chapter 2 Hardware Configuration ...................2-1 2.1 Jumper Setting ..........................

  • Page 3: How To Use This Manual

    BIOS. In addition, POST checkpoint list will give you a guide of trouble-shooting. Chapter 5: Troubleshooting. This chapter provides you a few useful tips to quickly get your 96M4011o running with no failure. As basic hardware installation has been addressed in Chapter 3, this chapter will basically focus on system integration issues, in terms of backplane setup, BIOS setting, and OS diagnostics.
  • Page 4 Preface WARNING Remove Processor Caution: Do not pull out processor without opening socket handle! High viscosity thermal grease between processor and cooler will lead the processor be pulled out from socket when taking cooler off. This action may damage processor socket, which will cause poor contact between CPU &...

  • Page 5: Chapter 1 System Overview

    Chapter 1 System Overview Introduction 96M4011o is a cost effective and high integration Pentium 4 applied computing platform. It provides innovative, high integration, high quality Single Board Computers in the applied computing market. The board is based on Intel 845GV chipset and support Intel latest high performance processor, Intel Socket 478 Pentium®...

  • Page 6: Check List

    System Overview Check List The 96M4011o package should cover the following basic items: One 96M4011o single board computer One serial port kit with two COM ports One Parallel port cable kit One FDC cable One IDE cable One Y-cable cable for PS/2 keyboard and mouse...
  • Page 7 - Parallel Port Support one parallel port with SPP, EPP and ECP modes - USB Interface USB 2.0 compliant Support three USB (Universal Serial Bus) ports for high-speed I/O peripheral devices One on bracket; two with pin header 96M4011o User’s Manual...
  • Page 8 Auxiliary I/O Interfaces System reset switch, external speaker, Keyboard lock and HDD active LED, etc. Power Good On-Board power good generator with 200 ms to 300 ms reset duration CPU Cooling Fan Support one 3-pin header with wafer 96M4011o User’s Manual...
  • Page 9 . +12V (System) @0.8A . +5V @2.8A - Test configuration: . CPU: Intel P4 2.4GHz/533MHz FSB/512KB L2 Cache . Memory: DDR SDRAM 512MBx2 . Primary Master IDE HDD: Samsung SV2042H (20GB) . OS: Microsoft Windows 2000 + SP2 96M4011o User’s Manual...

  • Page 10: Mechanical Drawing

    CPU provides better performance to many applications. The PCI-to-ISA bridge supports a standard 16-bit ISA bus interface which is applied for all slower I/O operations. In 96M4011o, it supports DiskOnChip (DOC) for M-systems Flash disk. 96M4011o User’s Manual...

  • Page 11: System Block Diagram

    System Overview There is one on-board PCI Fast Ethernet via RJ-45 Ports to support full functionality of 96M4011o AIO SBC (All-In-One Single Board Computer). The on-board 68-pin PCI connector supports one additional PCI daughter board for further extension. Intel Pentium...

  • Page 12: Chapter 2 Hardware Configuration

    ( ). Jumper Setting For users to customize 96M4011o’s features. In the following sections, Short means covering a jumper cap over jumper pins; Open or N/C (Not Connected) means removing a jumper cap from jumper pins.

  • Page 13: Connector Allocation

    Connect to Chassis Standalone Power Connector Only for standard one ATX Power Button Interface Connect to Chassis Reset Button Connector Connect to Chassis DVO Power Connector Optional DVO Connector -1 Optional DVO Connector -2 Optional Front SMBus Connector 96M4011o User’s Manual...
  • Page 14 Ground Ground Density Select 1 Ground Index# Ground Motor ENA# Ground Drive Select B# Ground Drive Select A# Ground Motor ENB# Ground Direction# Ground Step# Ground Write Data# Ground Write Gate# Ground Track 0# Ground Write Protect# 96M4011o User’s Manual...
  • Page 15 RI (Ring Indicator) Notes: 1) J8 is fixed as RS-232 2) J9 is configurable as RS-232/422/485 with jumper JP2 J10: External Wake On LAN Connector PIN No. Signal Description 5VSB Ground External WOL Signal Input (Active low) 96M4011o User’s Manual...
  • Page 16 Ground Busy Ground Paper Empty Ground Printer Select J12: IrDA Connector PIN No. Signal Description IRRX Ground IRTX J13: PS/2 Keyboard/Mouse Connector PIN No. Signal Description Mouse Data Keyboard Data Ground 5V Dual Mouse Clock Keyboard Clock 96M4011o User’s Manual...
  • Page 17 Signal Description MIC with Reference Voltage Analog Ground Line-in Left Channel Analog Ground Line-in Right Channel Analog Ground Line-out Left Channel Analog Ground Line-out Right Channel Note: The Reference Voltage on MIC signal offers 2.25V~2.75V with 5mA drive 96M4011o User’s Manual...
  • Page 18 Green Blue Monitor ID0 (MONID0) (5V I/F) Ground Ground Ground Ground Ground Monitor ID1 (MONID1) (5V I/F) VGA DDC Data (5V I/F) Horizontal Sync. (HSYNC) (5V I/F) Vertical Sync. (VSYNC) (5V I/F) VGA DDC Clock (5V I/F) 96M4011o User’s Manual...
  • Page 19 Ground AD24 AD25 AD26 AD27 AD28 AD29 AD30 AD31 Ground C/BE#0 C/BE#1 C/BE#2 C/BE#3 FRAME# TRDY# IRDY# Ground STOP# DEVSEL# PERR# SERR# REQ#4 GNT#4 REQ#5 GNT#5 Ground PCI Clock1 PCI Clock2 PCIRST# LOCK# IRQ#A IRQ#B IRQ#C IRQ#D 96M4011o User’s Manual...
  • Page 20 Through invert amplitude respected to GPIO port, each open-drain DO port can stand maximum fan out for up to 100mA, rather than 12mA direct driven by GPIO port. J26: 12V CPU Supplementary Connector PIN No. Signal Description Ground Ground +12V +12V 96M4011o User’s Manual...
  • Page 21 ATX 5V Stand-by (5VSB) ATX Power On Control (PS-ON) Ground J30: Power LED and Keyboard Lock Connector PIN No. Signal Description +5V (470 Ohm pull-up for power LED+) Ground (For Power LED-) Keyboard Lock Signal Input (Active low) Ground 96M4011o User’s Manual 2-10...
  • Page 22 Pull-high 1K Ohm to +5V Power Button Signal Input (Active high) J33: Reset Button Connector PIN No Signal Description Reset Signal Input (Active low) Ground J34: DVO Power Connector PIN No. Signal Description +12V +3.3V Ground Ground 96M4011o User’s Manual 2-11...
  • Page 23 J36: DVO Connector-2 (Factory Optional for Panel Display Kit only); not populated on the standard module PIN No. Signal Description PIN No. Signal Description DVOBD0 DVOBD1 DVOBD2 DVOBD3 DVOBD4 DVOBD5 DVOBD6 DVOBD7 DVOBD8 DVOBD9 DVOBD10 DVOBD11 DVOBCLK DVOBCLK# DVOBVSYNC DVOBHSYNC DVOBFLDSTL DVOBCCLKINT Ground +3.3V 96M4011o User’s Manual 2-12...
  • Page 24 Hardware Configuration J38: Front SMBus Connector PIN No. Signal Description SMBCLK Ground SMBDATA 96M4011o User’s Manual 2-13...

  • Page 25: Chapter 3 System Installation

    4) Follow the steps of installing a CPU to change to another one or place handling bar to close the opened socket. Configuring System Bus 96M4011o will automatically detect the CPU used. CPU speed of Intel P4 can be detected automatically. 96M4011o User’s Manual...

  • Page 26: Main Memory

    M-systems Flash Disk 96M4011o reserves one 32-pin DIP sockets for installing M-systems Flash disk from 2MB to 288MB. This operation structure is running with pure ISA-bus without PnP (Plug and Play) function. Before installing, make sure that I/O address jumper setting is set on right position to prevent unworkable system due to I/O resource conflict.

  • Page 27: Installing The Single Board Computer

    3.4.1 Chipset Component Driver The chipset on 96M4011o is a new chipset that a few old operating systems might not be able to recognize. To overcome this compatibility issue, for Windows Operating Systems such as Windows-95/98/98SE/2000, please install its INF before any of other Drivers are installed.

  • Page 28: On-Board Fast Ethernet Controller

    3.4.3 On-board Fast Ethernet Controller Drivers Support Please find Intel ICH4 LAN driver in /Ethernet directory of 96M4011o CD- title. The drivers support Windows-NT 4.0, Windows-98/98SE/ME, Windows-2000, Windows-XP, and Linux. LED Indicator (for LAN status) 96M4011o provides three LED indicators to report 82801BA MAC Fast Ethernet interfaces status.

  • Page 29: Clear Cmos Operation

    Additionally, there are maximum 2 seconds of counting tolerance that should be considered into user’ application program. For more information about WDT, please refer to Winbond W83627HF data sheet. 96M4011o User’s Manual...

  • Page 30: On-Board Usb 2.0 Controller

    Time-out Value Register 1) 0x00 -- Time-out Disable 2) 0x01~0xFF -- Value for counting down On-Board USB 2.0 Controller Drivers Support Please find Intel ICH4 USB driver in /USB20 directory of 96M4011o CD-title. The drivers support Windows-2000 and Windows-XP. 96M4011o User’s Manual...

  • Page 31: Panel Display Output (Factory Optional Only)

    The selection will be made base on the different impedances combinations. GPIO The 96M4011o provides 4 input/output ports that can be individually configured to perform a simple basic I/O function. Users can configure each individual port to become an input or output port by programming register bit of I/O Selection.
  • Page 32 If a port is assigned to be an input port, then its respective bit can be read only. Notes: 1) All the Buffered Digital Outputs are open-drain amplified form corresponding GPIO ports. 2) Some other functions may occupy the lower nibble of the registers. Altering any content in lower nibble will be undesired. 96M4011o User’s Manual...

  • Page 33: Chapter 4 Bios Setup Information

    Chapter 4 BIOS Setup Information 96M4011o is equipped with the AWARD BIOS stored in Flash ROM. This BIOS has a built-in Setup program that allows users to modify the basic system configuration easily. This type of information is stored in CMOS RAM so that it is retained during power-off periods.

  • Page 34: Main Menu

    BIOS Setup Information Main Menu Once you enter 96M4011o AWARD BIOS CMOS Setup Utility, you should start with the Main Menu. The Main Menu allows you to select from eleven setup functions and two exit choices. Use arrow keys to switch among items and press <Enter>...

  • Page 35: Standard Cmos Setup Menu

    Press <Enter> to enter the sub menu of Master menu (described in 4.4 detailed options Table) IDE Primary Options are in its sub Press <Enter> to enter the next page Slave menu for detail hard drive settings (described in 4.4 Table) 96M4011o User’s Manual...
  • Page 36 All, but Disk/Key Base Memory Displays the amount of conventional memory detected during boot up Extended Displays the amount of extended Memory memory detected during boot up Total Memory Displays the total memory available in the system 96M4011o User’s Manual...

  • Page 37: Ide Adaptors Setup Menu

    Choose the access mode for this hard disk Large Auto Capacity Auto Display your disk Disk drive capacity (Approximated). drive size Note that this size is usually slightly greater than the size of a formatted disk given by a disk checking program. 96M4011o User’s Manual...

  • Page 38: Advanced Bios Feature

    OS Select For DRAM > 64MB [Non-OS2] Report No FDD For WIN 95 [No] Small Logo(EPA) Show [Disabled] ↑↓→←: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 96M4011o User’s Manual...
  • Page 39 The choice: Enabled, Disabled. Boot Up Floppy Seek Enabled tests floppy drives to determine whether they have 40 or 80 tracks The choice: Enabled, Disabled. Boot Up NumLock Status Select power on state for NumLock. The choice: Off, On. 96M4011o User’s Manual...
  • Page 40 Select OS/2 only if you are running SO/2 operating system with greater than 64MB of RAM on the system. The choice: Non-OS2, OS2. Report No FDD for WIN 95 The choice: No, Yes. Small Logo (EPA) Show The choice: Enabled, Disabled. 96M4011o User’s Manual...

  • Page 41: Advanced Chipset Feature

    Such a scenario might well occur if your system had mixed speed DRAM chips installed so that greater delays may be required to preserve the integrity of the data held in the slower memory chips. 96M4011o User’s Manual...
  • Page 42 System BIOS Cacheable Selecting Enabled allows caching of the system BIOS ROM at F0000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result. The choice: Enabled, Disabled. 96M4011o User’s Manual 4-10...
  • Page 43 Users can set the display memory size that shared from main memory. The choice: 1MB, 8MB. Boot Display The choice: Auto, CRT, TV, EFP. On board LAN Control Users can disable on board LAN function. The choice: Enabled, Disabled. 96M4011o User’s Manual 4-11...

  • Page 44: Integrated Peripherals

    Midi Port IRQ [10] Watch Dog Timer Select [Disabled] DOC Memory Address Range [D8000-D9FFF] ↑↓→←: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 96M4011o User’s Manual 4-12...
  • Page 45 DOS, or Windows-NT with no USB driver loaded. The choice: Enabled, Disabled. USB Mouse Support This item allows you to enabled USB Mouse function under POST, BIOS Setup menu, DOS, or Window-NT with no USB driver loaded. The choice: Enabled, Disabled. 96M4011o User’s Manual 4-13...
  • Page 46 In the event of “Power On Function” being configured as “Hot Key”, this item will be enabled for tuning. The choice: Ctrl-F1 to Ctrl-F12. Onboard FDC Controller This item allows you to enable/disable onboard Floppy disk controller. The choice: Enabled, Disabled. 96M4011o User’s Manual 4-14...
  • Page 47 Use IR Pins The available choices are IR-Rx2Tx2/ RxD2, TxD2. The choice: IR-Rx2Tx2 / RxD2, TxD2. Onboard Parallel Port This item allows you to configure I/O address of the onboard parallel port. The choice: Disabled, 378/IRQ7, 278/IRQ5, 3BC/IRQ7. 96M4011o User’s Manual 4-15...
  • Page 48 Watch Dog Timer Select This BIOS testing option is able to reset the system according to the selected table. The choice: Disabled, 10 Sec, 20 Sec, 30 Sec, 40 Sec, 1 Min, 2 Min, 4 Min. 96M4011o User’s Manual 4-16...

  • Page 49: Power Management Setup

    Secondary IDE 0 [Disabled] Secondary IDE 1 [Disabled] FDD,COM,LPT Port [Disabled] PCI PIRQ[A-D]# [Disabled] ↑↓→←: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 96M4011o User’s Manual 4-17...
  • Page 50 Blank Screen This option only writes blanks to the video buffer. DPMS Initial display power management signaling. Video Off In Suspend This allows user to enable/disable video off in Suspend Mode. The choice: Yes, No. 96M4011o User’s Manual 4-18...
  • Page 51 The choice: Disabled, Enabled. Power On by Ring When select “Enabled”, a system that is at soft-off mode will be alert to Wake-On- Modem signal. The choice: Enabled, Disabled. USB KB Wake-up From S3 The choice: Enabled, Disabled. 96M4011o User’s Manual 4-19...
  • Page 52 The choice: Enabled, Disabled. PCI PIRQ[A-D]# This option can be used to detect PCI device activities. If they are activities, the system will go into sleep mode. The choice: Enabled, Disabled. 96M4011o User’s Manual 4-20...

  • Page 53: Pnp/Pci Configurations

    Default is Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the OS cannot boot. The choice: Enabled, Disabled. 96M4011o User’s Manual 4-21...
  • Page 54 Devices (S) using this INT: Display Cntrlr – Bus 0 Dev 2 Func 0 USB 1.0/1.1 UHCI Cntrlr – Bus 0 Dev29 Func 0. The choice: Auto, 3, 4, 5, 7, 9, 10, 11, 12, 14, 15. 96M4011o User’s Manual 4-22...
  • Page 55 The choice: Auto, 3, 4, 5, 7, 9, 10, 11, 12, 14, 15. INT Pin 8 Assignment Devices (S) using this INT: USB 2.0 EHCI Cntrlr – Bus 0 Dev 29 Func 7. The choice: Auto, 3, 4, 5, 7, 9, 10, 11, 12, 14, 15. 96M4011o User’s Manual 4-23...

  • Page 56: Pc Health Status

    This item allows you to set a temperature above which the system will operate in lower speed immediately. Default setting is Disabled. This function will only with “ACPI” power management and “S3 (STR)” suspend type. The choice: Disabled, 60℃/140℉, 65℃/149℉, 70℃/158℉, 75℃/167℉. 96M4011o User’s Manual 4-24...

  • Page 57: Frequency/Voltage Control

    When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Optimized Defaults (Y/N) ? N Pressing ‘Y’ loads the default values that are factory settings for optimal performance system operations. 96M4011o User’s Manual 4-25...

  • Page 58: Supervisor/User Password Setting

    Security option (see Section 3). If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup. 96M4011o User’s Manual 4-26...

  • Page 59: Exiting Selection

    Pressing <Enter> on this item asks for confirmation: Quit Without Saving (Y/N)? N This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your computer. 96M4011o User’s Manual 4-27...

  • Page 60: Chapter 5 Troubleshooting

    BIOS setting, and OS diagnostics. Backplane Setup Backplane 96M4011o is a full-sized SBC, and therefore is only able to run on PICMG PCI/ISA Backplane. P4 Power connector 96M4011o requires power drawing from at least two connectors. The CPU supplementary power connector (J26) should be connected at all time for this P4 system to run properly.
  • Page 61 Step4: Please find the J29 4-pin ATX Power Control Connector on the right part of 96M4011o in white color. You will also see a mark with “J29” on the lower side of J29 header. Connect the 4-pin ATX power control cable with this J29 header.
  • Page 62 Q: In addition to the above description, is there anything to do to finish up an ATX system? A: Yes. 96M4011o needs to be configured to support ATX function for the above cabling. Please move jumper JP3 to 3-5 short and 4-6 short (support ATX function).

  • Page 63: Onboard Hardware Installation

    Troubleshooting Q: How can I build up an AT system using ATX power supply A: Do not forget to move JP3 of 96M4011o back to 1-3 short and 2-4 short (support AT function). If the ATX power supply has a switch, such as ORION-300ATX, do not remove the jumper of backplane connector in step 1, and use the power supply switch as the system power on switch.
  • Page 64 BIOS optimal default, thank you for doing so. However, this will force the BIOS to pick up the default CPU core/bus ratio as well. It needs to be emphasized again that 96M4011o does not have switch or jumper to configure CPU core/bus ratio. This is done through BIOS automatically. Please check in the “Frequency/Voltage Control”...

  • Page 65: Bios Setting

    To make sure that you have a successful start with 96M4011o, it is recommended, when going with the boot-up sequence, to hit “DEL” key and enter the BIOS setup menu to tune up a stable BIOS configuration so that you can wake up your system far well.

  • Page 66: Os Diagnostics

    Please proceed to do so and restart your Windows. Devices with removed drivers will be automatically detected again. The drivers will be loaded automatically, if drivers have been included in the system database, else you will be asked to provide driver source for installation. 96M4011o User’s Manual...
  • Page 67 By default, any Windows OS starts with 640 x 480 with 16 colors display. The display driver provided in 96M4011o product CDROM can be installed into operating system to maximize the VGA performance. If you are using a monitor that Microsoft®...
  • Page 68 7. Network setup within Windows-NT 4.0 is not as easy as within Windows-95/98. Special familiarity and care are required for a successful installation. Note: Please visit our technical web site at http://www.DSM.AG For additional technical information, which is not covered in this manual. 96M4011o User’s Manual...
