Summary of Contents for Customidea GeoPic II
- Page 1 Geotagging Device With three intelligent modes of operation including low-power and freeze mode Suitable for: Nikon D200/D2HS/D2X/D2XS Fuji S5 Pro...
-
Page 2: Table Of Contents
Contents Contents Introducing the GeoPic II ………………………………… 2 Quick start guide ……………………………….………… 3 GeoPic II overview ……………………………….………. 4 GeoPic II basic operation ………………………….…….. 5 Continuous mode (red) ………………………….………. 7 Low power mode (green) ………………………….…….. 8 Freeze mode (blue) ………………………….…...…….. 10 Remote shutter release …………………….…...……. -
Page 3: Introducing The Geopic Ii
This handy booklet contains everything you need to know about your GeoPic II, but if you want to jump right in, then a quick start guide has been included on page 2. -
Page 4: Quick Start Guide
Quick start guide Quick start guide The GeoPic II is powered up or down by pressing and holding the function button and it starts up in the mode you last used. The three modes of operation are called continuous, low... -
Page 5: Geopic Ii Overview
GeoPic II overview GeoPic II overview The GeoPic II is designed to be extremely compact and very simple to use, so you can spend time on your photography instead of being confused by a new gadget. A function button is used... -
Page 6: Geopic Ii Basic Operation
There are a number of different ways that the GeoPic II can be powered up and powered down. When the GeoPic II powers up, the status light will slowly turn on in the colour corresponding to the last used mode. When the GeoPic II powers down, the status light will slowly turn off in the colour of the currently used mode. - Page 7 To save you time, the GeoPic II remembers the mode you last used and when you power it up will automatically enter that mode.
-
Page 8: Continuous Mode (Red)
The time that the GeoPic II takes to achieve a good lock on the satellites will depend on a number of factors. Typical lock times are given in the technical details at the end of this manual. -
Page 9: Low Power Mode (Green)
Low power mode (green) Low power mode (green) This section explains how the GeoPic II behaves in its low power mode of operation. In this mode, the status light will always be a green colour. The low power mode of operation ensures that GPS data is only sent to the camera when the user is getting ready to take a picture. - Page 10 Note that the GPS module within the GeoPic II is constantly on during the low power mode, so the power consumed by the GeoPic II does not change. Power is reduced by allowing the camera to enter standby state.
-
Page 11: Freeze Mode (Blue)
Freeze mode (blue) Freeze mode (blue) This section explains how the GeoPic II behaves in its freeze mode of operation. In this mode, the status light will always be a blue colour. The freeze mode of operation keeps the last locked GPS location in a buffer and uses this to send to the camera, instead of live data. - Page 12 To start a search for a new position, press the function button on the GeoPic II. This will cause the GPS module inside the GeoPic II to be powered up, until a new lock is achieved. The new GPS location will be buffered and the internal GPS module will switch off once more.
- Page 13 Unlike the low power (green) mode, the GPS module within the GeoPic II is turned off during freeze mode (unless searching for a new position). The power consumed by the GeoPic II in freeze mode is therefore much lower than both the other modes of operation.
- Page 14 (red) or low power (green) modes. Consider the scenario when the GeoPic II is in low power (green) mode and locked, then you subsequently change to freeze mode. The GPS data from low power mode will not be used in freeze mode.
-
Page 15: Remote Shutter Release
Remote shutter release Remote shutter release Every GeoPic II is provided with a fully functional remote shutter release socket. The socket is a 2.5mm jack socket which is compatible with standard remote shutter release cords available in shops and online. Custom Idea sells a suitable remote shutter release cord on our website at a very reasonable price. -
Page 16: Geopic Ii User Settings
GeoPic II user settings GeoPic II user settings The GeoPic II has a total of eight user settings, each with different options that can be configured to suit your needs. The settings menu is accessed from any mode by holding the shutter release button half way and pressing the function button on the GeoPic II for around 5 seconds. - Page 17 5 mins 10 mins Disabled If enabled, the function button Enabled † 3 Button will power up the GeoPic II. Disabled If enabled, the GeoPic II powers Enabled † 4 Meter up when camera wakes up. Disabled Enables the green/blue blink in...
- Page 18 GeoPic II user settings 2) Half press the shutter release button once to move from the current setting (setting 1) to setting 2. Two blue flashes confirm setting 2 is selected. Press the function button to enter the option menu for setting 2. A single red flash confirms you are at the first option for setting 2.
-
Page 19: Technical Information
Lens 50mm f/1.8 Nikon Error warnings: Slow RGB flash Settings are corrupt so GeoPic II has automatically reloaded the default options. To continue, reset the unit by disconnecting from the camera and reconnecting after a few minutes. Nikon D200, D2HS, D2X and D2XS and Fuji S5 Pro are registered... - Page 20 GeoPic II, this problem has now been solved. In total the GeoPic II has three modes of operation, including a low power and freeze mode. Freeze mode keeps the GPS position in an internal buffer, allowing you to geotag photos even when out of sight of the satellites, for example when indoors.
