Summary of Contents for Frontier TV Receiver

  • Page 1 SELF-INSTALLATION GUIDE...
  • Page 2 HD channels and thousands of On Demand titles at your fingertips. All in crystal clear lifelike clarity. This guide will make it quick and easy to replace your Wireless Router and add or replace a Wireless TV Receiver. WIRELESS ROUTER REPLACEMENT ..............
  • Page 3 WIRELESS ROUTER REPLACEMENT...
  • Page 4 Let’s Get Started These instructions will guide you through the process of replacing your Wireless Router. Approximate installation time: 35 minutes In the box: Voice Line Splitter Battery Backup Unit (BBU) Wireless Router SET UP Approximate time: ten minutes Begin by setting up the Wireless Router and then establishing each service.
  • Page 5 SET UP cont. • Stand the new Router next to the existing Router. • Disconnect the data cable from the existing Wireless Router’s green phone line port and plug it into the green data port on the new Router. • Remove one connection at a time from the Ethernet (yellow) ports of the existing Router. •...
  • Page 6 SET UP cont. • Disconnect the phone cord that is connected to the existing Router’s Phone Lines 1 & 2 port. • Connect the phone cord to the new Router’s Phone Lines 1 & 2 port. • Connect the new BBU to the new Router’s power port. •...
  • Page 7 Write down your new Network Name (SSID) and new Wireless Network Key (WPA) to configure a Wi-Fi device. This information is on the side of your Wireless Router. The Network Name consists of “2WIRE” and/or “Frontier” plus the last three digits of the Wireless Router’s serial number. Be sure to record this information in the form on this page.
  • Page 8 HAVING TROUBLE? cont. SPECIFIC ISSUES My Power indicator light turns orange during the power up sequence. Don’t worry. This is a normal part of the power up sequence—just remember not to unplug the power cord or data cable depicted in green in this guide when the light is still orange. At the end of the sequence, the Broadband and Service indicator lights will be solid green.
  • Page 9 WIRELESS TV RECEIVER...
  • Page 10 Ready to install your Wireless TV Receiver? Let’s Get Started Approximate installation time: 20 minutes What’s in the box? To install your Receiver, you will need: POWER Wireless TV Receiver Wireless Access Point Remote control Wireless TV Receiver power cord (two parts)
  • Page 11 First, you need to connect your existing Wi-Fi Router to the Wireless Access Point. NOTE: If you are adding a Second Wireless TV Receiver, skip this step and go to Power Up. Connect the Wireless Access Point to your existing Wi-Fi Router using the yellow Ethernet cable.
  • Page 12 PAIR UP Now let’s get your Wireless TV Receiver and Wireless Access Point talking to each other. Follow the instructions on your TV screen. On the front of your new receiver, press the button. Your TV screen should look like this.
  • Page 13 3. Give it a minute and then repeat the last two steps on “Pair Up.” REMOTE CONTROL INFORMATION New Frontier customers or current customers adding a new receiver will need to program the new remote control. Programming instructions are available online at Frontier.com/HelpCenter...
  • Page 14 ADDING A SECOND WIRELESS TV RECEIVER Complete the installation of the first TV Receiver. Repeat steps in the instructions for Power Up and Pair Up sections in this guide with the second TV Receiver.
  • Page 15 WIRELESS RECEIVER REPLACEMENT...
  • Page 16 Let’s Get Started These instructions will guide you through the process of replacing your wireless TV receiver. Approximate installation time: 15 minutes Gather materials needed for set up: POWER Replacement Frontier receiver Replacement power cord (two parts) The appearance of your receiver and power cord may differ from above pictures.
  • Page 17 Do not reuse the power cord from your old receiver. POWER UP Now let’s get your Wireless TV Receiver and Wireless Access Point talking to each other. Follow the instructions on your TV screen. On the front of your new receiver, press the button.
  • Page 18 HAVING TROUBLE? If you see a red antenna: 1. Disconnect your Wireless TV Receiver from its current location. 2. Move the Receiver closer to the Wireless Access Point. Now reconnect it to another power outlet.
  • Page 19 RECEIVER RETURN Using the packing label that came with your order, return the receiver you replaced and the old two-part power cord as-is in the box provided to The UPS Store . Find the location nearest ® you by visiting www.theupsstore.com or by calling 800.789.4623. Do not return your remote control.
  • Page 20 WIRED RECEIVER REPLACEMENT...
  • Page 21 These instructions will guide you through the process of replacing your FrontierTV receiver with a new receiver. Approximate installation time: 15 minutes Gather materials needed for set up: Replacement Frontier receiver Replacement power cord (two parts) Not included: wrench You may also need a 7/16-inch wrench to loosen the existing coaxial cable connection on the back of the receiver.
  • Page 22 SET UP cont. The back of your receiver and the connections may vary depending upon the model. If the connectors are in different places, just follow the names, shapes and colors, as they will all be the same. This illustration of the existing receiver shows various connection possibilities. You will only need to use one of the connections (HDMI, Component, Composite or Coaxial) to connect your receiver to the TV.
  • Page 23 RECEIVER RETURN Using the packing label that came with your order, return the receiver you replaced and the old two-part power cord as-is in the box provided to The UPS Store . Find the location nearest ® you by visiting www.theupsstore.com or by calling 800.789.4623.
