Jensen AL7000AC Installation Manual

WPS LED
2.4GHz LED
WPS status LED.
LED that show status
WPS LED is
for the 2.4GHz network.
flashing when
The LED will flash when
setting up a WPS
active.
connection.
5GHz LED
Network ports LED
LED that show status
Show status for devices
for the 5GHz network.
that are connected to
The LED's will flash
the router by cable.
when active.
Sys Led
Internet LED
Displays a
LED that show
blinking light
status for the
when functioning
Internet port.
correctly
The LED will flash
when active.
USB LED
Indicates if the
USB port is
correctly
connected.
Declaration of Conformity with Regard to EU Directive 1999/5/EC (R&TTE Directive):
Hereby, Jensen Scandinavia AS, declares that this wireless router is in compliance with
the essential requirements and other relevant provisions of Directive 1999/5/EC.
The declaration of confirmity may be consulted at www.jensenscandinavia.com/rtte/

Installation Guide

Power connector
USB port
USB port for connecting
a printer or USB hard disk drive.
Power LED
Displays a solid light
upon powerup
This equipment may be operated in all EU and EFTA countries: AT, BE, BG, CY, CZ, DK, EE, FI,
FR, DE, GR, HU, IS, IE, IT, LV,LI, LT, LU, MT, NL, NO, PL, PT, RO, SK, SI, ES, SE, CH, TR, GB
PRODUCT USAGE RESTRICTIONS: This product is intended for indoor use only.
Modelno: AL7000AC
Network ports
Ports for connecting network
devices by cable, such as computer,
Media Server, Network printer
VOIP adapter etc.
Internet port
Please connect your
broadband modem
to the internet port.
Reset / WPS*
Reset: Hold for about 10 seconds to
reset AL5000ac to factory default.
WPS: Hold for about to 2-5 seconds
to initiate WPS connection.
* WPS is disabled as default
and needed to be activated in
router GUI (http://192.168.38.1)
beforeuse.
