- Page 1 ASSEMBLY & OPERATING INSTRUCTIONS FOR OUTDOOR USE ONLY Model: 730-0439 natural Gas Use only J23Y06N-1 PLEASE CONTACT 1-800–984-7455 FOR ASSISTANCE ABOUT ASSEMBLY OR GRILL OPERATION DO NOT RETURN TO THE PLACE OF PURCHASE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION FOUR: SECTION ONE: Cleaning & Maintenance-----------------------------16 Table of Contents & Importance -----------------1 Trouble Shooting---------------------------------------17-20 Precautions--------------------------------------------2-5 SECTION TWO: SECTION FIVE: Assembly Instruction-------------------------------6-10 Exploded View------------------------------------------21 Grill Parts List -------------------------------------------22 To Match Light the Grill-----------------------------11 SECTION SIX: Operating Instructions-------------------------------12 Grilling Hints---------------------------------------------23 SECTION THREE: Grill Cooking Chart----------------------------------24-25... -
Page 3: Precautions
PRECAUTIONS WARNING CAUTION: Beware of Flashback Do not try lighting this appliance without reading the “LIGHTING INSTRUCTIONS” section of this manual. CAUTION: Spiders and small insects occasionally spin webs or make nests in the TESTED IN ACCORDANCE WITH ANSI grill burner tubes during transit and Z21.58 CSA 1.6 STANDARD FOR OUTDOOR warehousing. - Page 4 PRECAUTIONS PROPER PLACEMENT AND CLEARANCE WARNING OF GRILL Your grill will get very hot. Never lean over the •Never use your gas grill in a garage, porch, shed, breezeway or any other enclosed area. Your gas grill is to be cooking area while using your grill.
- Page 5 PRECAUTIONS WHEN LIGHTING A BURNER, ALWAYS PAY SAFETY PRACTICES TO AVOID CLOSE ATTENTION TO WHAT YOU ARE DOING. PERSONAL INJURY BE CERTAIN YOU ARE TURNING THE IGNITER When properly cared for, your grill will give safe, LABELED FOR THE BURNER YOU INTEND ON reliable service for many years.
- Page 6 PRECAUTIONS CHECKING FOR GAS LEAKS Never test for leaks with a flame. Prior to 3. Apply the soap solution to all gas connections. first use and at the beginning of each new Bubbles will appear in the soap solution if season, you must check for gas leaks.
-
Page 7: Assembly Instruction
ASSEMBLY INSTRUCTIONS PLEASE READ THE INSTRUCTIONS CAREFULLY AND FOLLOW STEP BY STEP. TOOLS REQUIRED: (1) PHILIPS HEAD SCREWDRIVER – NOT PROVIDED STEP 1: A. The screws used to attach the side shelf are already screwed into the left panel (see the figure below). Remove the screws from the left panel, align with the holes in the side shelf, and then re-screw into the holes on the left panel of the grill. - Page 8 ASSEMBLY INSTRUCTIONS STEP 2: Side Burner Assembly A. Push valve into side burner control panel. Insert screws from the front side of control panel and tighten. 3 0 0 4 0 0 5 0 0 2 0 0 6 0 0 1 0 0 8 0 0 7 0 0...
- Page 9 ASSEMBLY INSTRUCTIONS STEP 3: Battery is inserted for the rotisserie burner . To install the battery, turn the ignition button cap counterclockwise and remove it. Replace the ignition button cap after the battery is installed. J23Y06N-1...
- Page 10 ASSEMBLY INSTRUCTIONS STEP 4: The screws for rotisserie drive motor bracket are attached to the motor bracket. Remove the screws and install the rotisserie motor bracket as shown in the figure below. Assemble the rotisserie skewer as shown in the figure below. J23Y06N-1...
-
Page 11: Assembly Instruction
ASSEMBLY INSTRUCTIONS STEP 5: The Nature Gas regulator has been installed on the unit. Attach the PVC Gas Hose to the regulator (See drawing below). Connect the other end of the PVC Gas Hose to the house gas line. J23Y06N-1... -
Page 12: To Match Light The Grill
TO MATCH LIGHT THE GRILL 1.If the burner will not light after several attempts then the burner can be match lit. 2.If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. Keep your face and hands as far away from the grill as possible. Insert a lit extended match or lighter through the cooking grids to the burner. -
Page 13: Operating Instructions
OPERATING INSTRUCTIONS WARNING: IMPORTANT! GENERAL USE OF THE GRILL AND USING THE SIDE BURNER: ROTISSERIE Inspect the gas supply hose prior to Each main burner is rated at 10,000 turning the gas “ON”. If there is evidence Btu/hr. The main grill burners encompass of cuts, wear or abrasion, it must be the entire cooking area and are side replaced prior to use. -
Page 14: Lighting Instructions
GRILL LIGHTING INSTRUCTIONS WARNING: Always keep your face and body If you’ve just attempted to light the burner as far away from the burner as possible with the igniter, allow 5 minutes for any when lighting. accumulated gas to dissipate. Keep your TO LIGHT THE SIDE BURNER face and hands as far away from the grill To light the side burner, remove any... -
Page 15: Lighting Instructions
GRILL LIGHTING INSTRUCTIONS FLAME CHARACTERISTICS flame is noisy and tends to lift away from the burner, it indicates too much air. Check for proper burner flame characteristics. Burner flames should be blue and stable Each burner is adjusted prior to with no yellow tips, excessive noise, or shipment;... -
Page 16: Lighting Illustrations
LIGHTING ILLUSTRATION Main & Side Burner Lighting illustration Rotisserie Burner Lighting Illustration Step 1. Step to light the Rotisserie Burner: Make sure the Lid is open Push and turn the rear burner knob to “IGNITE/HI” position and hold for 3-4 seconds and push electronic ignition button, until burner is lit. -
Page 17: Cleaning & Maintenance
CLEANING & MAINTENANCE CLEANING THE COOKING GRIDS BURNER CLEANING 1. Wire brush entire surface of burner to remove After cooking, turn control knobs to “OFF” and let grill cool before attempting to clean your cooking food residue and dirt. grids. 2. -
Page 18: Trouble Shooting
TROUBLE SHOOTING SPIDER AND INSECT WARNING!!! WHEN TO LOOK FOR SPIDERS Spiders and small insects occasionally You should inspect the burners at least spin webs or make nests in the grill burner once a year or immediately after any of the tubes during transit and warehousing. - Page 19 TROUBLE SHOOTING PREHEATING: The grill lid should be in a closed position during the preheat time period. It is necessary to preheat the grill for a short time before cooking certain foods, depending on the type of food and the cooking temperature. Food that requires a high cooking temperature needs a pre-heat period of five minutes;...
- Page 20 TROUBLE SHOOTING --Cover may be incorrect for your grill. It may be a tight fit. Ensure the cover correct length for your gril Measure it left to right. Compare to the grill’s measurement. --Compare the location and size of the hood portion of the cover to your grill. --Spread the cover and allow it to relax, preferably in warm sunlight or in a warm room.
-
Page 21: Trouble Shooting
TROUBLE SHOOTING Rotisserie motor will not turn --Check the voltage at the outlet. --If an extension cord is required, ensure it is a 16 gauges, grounded cord. --Ensure the on/off switch is on. --Ensure the load does not exceed the 40 pounds operational capacity. -
Page 22: Exploded View
EXPLODED VIEW J23Y06N-1... - Page 23 PARTS LIST REF# DESCRIPTION REF# DESCRIPTION Main Lid Utility Drawer Slide, Right Utility Drawer Slide Main Lid Screw Bracket right Main Lid screw cover Side Shelf, Left B Logo Side Shelf, Left A Main Lid Handle Heat Side Shelf Trim Insulating Spacer Panel,Left Temperature Gauge...
- Page 24 PARTS LIST REF# DESCRIPTION REF# DESCRIPTION Side Burner Pipe Rotisserie Handle Side Burner Ring Key Washer Side Burner Igniter wire Shaft Collar Side Burner bowl Rotisserie Burner Flex Assembly Frame A Gas line Side Burner Bowl Rotisserie Orifice Assembly Frame B w/Brass Elbow Side Burner Bowl Rear Baffle...
-
Page 25: Grilling Hints
GRILLING HINTS The doneness of meat, whether rare, To get the juiciest meats, add medium, or well done, is affected to a large seasoning or salt after the cooking is degree by the thickness of the cut. Expert finished on each side and turn the chefs say it is impossible to have a rare meat only once (juices are lost when doneness with a thin cut of meat. -
Page 26: Grill Cooking Chart
GRILL COOKING CHART WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS AND FOOD THICKNESS FLAME SIZE TIME TIPS VEGETABLES Slice.Dot with butter or margarine Wrap in heavy-duty foil.Grill,turning occasionally Fresh Beets Medium 12 to 20 minutes Carrots Grill,turning once.Brush Occasionally Turnips With melted butter or margarine Onion 1/2 inch slices Medium... - Page 27 GRILL COOKING CHART WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FLAME SIZE FOOD THICKNESS TIME AND TIPS FISH AND SEAFOOD Grill,turning once.Brush with melted butter,margarine or oil Steaks To keep moist. Halibut 3/4 to 1 inch Medium to 8 to 15 minutes Salmon High Swordfish...
- Page 28 GRILL RECIPE SUGGESTIONS BBQ SALMON Half hour before cooking, turn the TANGY SEAFOOD KABOBS burner to the grill on full. Drain 1 lb. Large shrimp, shelled & 2 large salmon steaks seafood reserving marinade. On deveined 2 tbs. Oil each of twelve 10” skewers, ¾...
-
Page 29: Grill Recipe Suggestions
GRILL RECIPE SUGGESTIONS Preheat grill. Combine cheese, Pound flank steak to ¼ inch In blender, process 1/3 c. water, condensed soup, milk, BBQ thickness or flatten chicken onion, soy sauce, 2 tsp. oil and sauce, oregano, salt and pepper breasts. Mix oil, lime juice and the next 8 ingredients until in a large mixing bowl. - Page 30 GRILL RECIPE SUGGESTIONS CHICKEN TANDOORI STYLE Marinade ribs for 3 hours. Use TURKEY marinade for basting by adding 8 large chicken thighs or 12 lb. turkey drumsticks beer to it. Place pan under the Beer basting sauce: ribs and baste frequently. To 1 c.
-
Page 31: Limited Warranty
Our obligation under this warranty is limited to repair or replacement, at our option, of the product during the warranty period. The extent of any liability of Nexgrill Industries, Inc. under this warranty is limited to repair or replacement. This warranty does not cover normal wear of parts, damage...
