Summary of Contents for Skypatrol ST8050
- Page 1 ST8050 User Guide ST8050UG001 ST8050 User Guide Revision 2.00 5/4/2013 Confidential and Proprietary Information – © 2013 Skypatrol, LLC. Do not duplicate without express permission from Skypatrol, LLC...
- Page 2 All specifications are subject to change without notice and do not represent a commitment on the part of SkyPatrol LLC. SkyPatrol LLC., will not be responsible for any loss or damages incurred related to the use of information contained in this document.
-
Page 3: Warranty Information
SkyPatrol will not be required to repair or replace the product, but may instead reship the product to the purchaser, in which case purchaser shall be responsible for paying SkyPatrol’s usual charges for unpacking, testing, and repacking the product for reshipment to purchaser. - Page 4 EXEMPLARY, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING WITHOUT LIMITATION LOSS OR INTERRUPTION OF USE, DATA, REVENUES OR PROFITS) RESULTING FROM A BREACH OF THIS WARRANTY OR BASED ON ANY OTHER LEGAL THEORY, EVEN IF SKYPATROL HAS BEEN ADVISED OF THE POSSIBILITY OR LIKELIHOOD OF SUCH DAMAGES.
-
Page 5: Table Of Contents
Sequence of events: Mobile Originated–Short Burst Data message (MO-SBD)........22 5.1.1.2 Sequence of events: Mobile Terminated–Short Burst Data message (MT-SBD) ....... 23 GSM ..........................23 APPENDIX A – GLOSSARY OF TERMS ..................24 APPENDIX B – ST8050 CONNECTOR DESCRIPTION ..............26 ST8050UG001 – User Guide Revision 2.0... - Page 6 User Guide to ST8050 List of Figures Figure 2-1: ST8050 assembly data cable ....................2 Figure 2-2: ST8050 assembly data cable components ................2 Figure 2-3: ST8050 locking connector ......................3 Figure 2-4: ST8050 antenna connections ....................3 Figure 2-5: SCT – Initial screen........................9 Figure 2-6: SCT –...
-
Page 7: Introduction
Introduction 1.1 Overview The SKYPATROL ST8050 is a highly configurable, dual mode solution that is ready for global use. The ST8050 is designed to communicate with terrestrial GSM cellular network systems when a cellular signal is available, and to slide seamlessly into its back-up mode to communicate with a satellite system when a cellular signal is not available. -
Page 8: Quick Start Guide
User Guide to ST8050 Quick Start Guide The ST8050 operates from 6VDC to 32VDC. For satellite applications, optimal performance requires at least 10.5 VDC. In order to communicate with the ST8050 the following is required: - a computer with at least one available serial port or a USB-to-serial adapter (Keyspan, part... -
Page 9: Figure 2-3: St8050 Locking Connector
Plug the locking connector into the modem. The connector can only fit one way as shown below. Figure 2-3: ST8050 locking connector On the opposite side of the modem, attach the antenna cable to the appropriate connector (Figure 2-4). -
Page 10: Inserting The Sim Card
User Guide to ST8050 2.1.1.1 Inserting the SIM card One of two types of screw is used to attach the SIM card to the modem. The screw will be a round head screw, Phillips, 0-80 X 3/16, SS, or a hex screw, size 0-80, 50 1. -
Page 11: Serial Port Connections
Stop bits: Flow control: None 2.3.1 GRPS configuration The ST8050 uses the GRPS network or Iridium network (if GPRS is not available) to send the message. Use AT&STGPRS command to setup all parameters related with the GPRS network. AT&STGPRS=<apn>,<user>,<password>,<protocol>,<ip>, <port>... -
Page 12: Periodic Report Configuration
User Guide to ST8050 2.3.2 Periodic report configuration The ST8050 will send messages, depending on message format, using GRPS network or Iridium network. The periodic report timers are defined bases in the state of IO 1 (ignition). Use AT&STREPORT command to setup those timers AT&STREPORT=<mode>,<format>, <GPRS mask>, <Iridium mask>, <GPRS time On>, <... -
Page 13: Io Alarms
AT&STREPORT=0,1,127,127,300,3600,900,14400,0,0 2.3.3 IO alarms The ST8050 uses the IO alarms to notify the end user of all events which are triggered by external sensors connected to the device. IO alarms can be used for ignition, open doors, panic buttons, etc. -
Page 14: Downloading Code To The Modem
Example: AT&STIOALARM=1,1,2,2 2.4 Downloading code to the modem The ST8050 uses two separate code packages: the foundation and the application. The foundation and application are supplied by Skypatrol. Either can be loaded into the modem using the SKYPATROL Configuration Tool (SCT). -
Page 15: Skypatrol Configuration Tool (Sct)
2.4.1 SKYPATROL Configuration Tool (SCT) The SKYPATROL Configuration Tool (SCT) provides a Graphical User Interface (GUI) to download code and modify configuration parameters in the modem. SCT is available on the SkyPatrol’s ftp at ftp://ftp.skypatrol.com. To download code or modify configuration parameters, first load and run SCT on a PC connected to the modem’s MTS serial port. -
Page 16: Figure 2-6: Sct - Update The Firmware (1)
User Guide to ST8050 Figure 2-6: SCT – Update the firmware (1) 2. Enter the foundation file’s address and select Figure 2-7: SCT – Update the firmware (2) 3. SCT starts the firmware update. Power cycle the modem. Figure 2-5: SCT – Update the firmware (3) 4. -
Page 17: Downloading Application Code
2.4.1.2 Downloading application code 2.4.2 Downloading Download the latest ST8050 .bin file from the SkyPatrol’s ftp. After unzipping the file, there should be a Turnkey file with the name format of ST8050_9,9.99.bin. 1. On the QCT screen, select Flash Load Application. -
Page 18: Provisioning And Activation
Figure 2-6: Completion of successful download (using SCT) 2.5 Provisioning and activation Upon receipt of the ST8050, it is necessary to activate and provision the GSM/GPRS service and/or the satellite service before using the modem to transmit messages. GSM/GPRS customers must obtain a SIM card from their carrier and place it into the SIM slot ... -
Page 19: Configuration Parameters
Stop bits: Flow control: None 2.6.1 GRPS configuration The ST8050 uses the GRPS network or Iridium network (if GPRS is not available) to send the message. Use AT&STGPRS command to setup all parameters related with the GPRS network. AT&STGPRS=<apn>,<user>,<password>,<protocol>,<ip>, <port>... - Page 20 Bit 3 – GSM Strength Bit 4 – Iridium Strength Bit 5 – GSM Network Information Bit 6 – GSM SIMCARD information Bit 7 – Used by the ST8050 to indicate that an alarm was triggered. <Iridium mask> Same as GPRS Mask <GPRS time On>...
-
Page 21: Io Alarms
AT&STREPORT=0,1,127,127,300,3600,900,14400,0,0 2.6.3 IO alarms The ST8050 uses the IO alarms to notify the end user of all events which are triggered by external sensors connected to the device. IO alarms can be used for ignition, open doors, panic buttons, etc. - Page 22 User Guide to ST8050 Condition Define the condition to trigger the alarm. 0: When the port level goes UP. 1: When the port level goes DOWN. 2: When the port level changes, UP or DOWN, this condition is not valid if the trigger type is 2.
-
Page 23: Antenna Setup
User Guide to ST8050 Antenna setup 3.1 Antenna recommendations 3.1.1 GPS The GPS antenna should be 3.3 VDC active. The recommended active antenna gain should be in the range of 17dB to 42 dB in the Low Noise Amplifier (LNA). Ensure that the GPS antenna is located where it has an unobstructed view of the sky. -
Page 24: Figure 3-1: Antennas With Blocked View Of Sky
User Guide to ST8050 Beware of high power antennas, urban canyons and other structures that block the line of sight (LOS) to the satellite. Below are some antenna installation mishaps: Figure 3-1: Antennas with blocked view of sky Figure 3-2: Tipped over antenna ST8050UG001 –... -
Page 25: Noise Problems
User Guide to ST8050 3.3 Noise problems To locate noise problems, start with a visual inspection of RF connectors. Look for water leakage or corrosion. A spectrum analyzer, VSWR meter or noise detector is helpful for locating problems. Noise sources for broadband may be electric power lines, electric motors or generators, switching power sources or microprocessors. -
Page 26: Activating And Provisioning The Modem
User Guide to ST8050 Activating and provisioning the modem Each ST8050 must be provisioned and activated on the network(s) supported by the modem. The customer is responsible for activating and provisioning the modem(s). The following information is required for provisioning and activation. - Page 27 User Guide to ST8050 For modems utilizing the Direct IP gateway, the user’s IP gateway and port number must be added to the Iridium firewall. This may require an extra day or two to be provisioned. The above mechanisms can also be combined so that a modem can do both Direct IP and email- based message sending.
-
Page 28: Networks
5.1.1.1 Sequence of events: Mobile Originated–Short Burst Data message (MO-SBD) 1. User’s application creates the mobile-originated-SBD message in the ST8050. 2. Application instructs the ST8050 to send the SBD message to the Iridium Gateway. 3. Iridium Gateway SBD equipment: Receives the SBD message ... -
Page 29: Sequence Of Events: Mobile Terminated-Short Burst Data Message (Mt-Sbd)
User Guide to ST8050 5.1.1.2 Sequence of events: Mobile Terminated–Short Burst Data message (MT-SBD) 1. The message is sent to the Iridium Gateway server by the Value Added Reseller’s host server via email or a DirectIP connection. 2. Iridium Gateway SBD equipment receives the message and stores it in a database. -
Page 30: Appendix A - Glossary Of Terms
User Guide to ST8050 Appendix A – Glossary of terms Analog to Digital Converter Application Programming Interface Bits per Second Controller Area Network Carrier Detect Signal Carriage Return Digital Input/Output Data Terminal Equipment Data Terminal Ready signal Event Driven Architecture... - Page 31 User Guide to ST8050 QRTOS SKYPATROL Real-time Operating System Revolutions Per Minute Real-time Clock RTOS Real-time Operating System Society of Automotive Engineers Short Burst Data Subscriber Communicator (modem) [ORBCOMM] Subscriber Communicator Originated message Subscriber Communicator Terminated message SMTP Simple Mail Transfer Protocol...
-
Page 32: Appendix B - St8050 Connector Description
User Guide to ST8050 Appendix B – ST8050 Connector Description The ST8050 connector has 40 pins connector. Each pin has the following function: Pin Signal Type Voltage Notes (Min/Max/ Nominal) VDC UBATT (+) Power 6/32/12 UBATT (+) Power 6/32/12 UBATT (-) - Page 33 User Guide to ST8050 32 DIG_1 Input 3.5V CMOS/TTL Used to monitor the vehicle ignition state 33 DIG_2 Input 3.5V CMOS/TTL Used to monitor the SOS button 34 DIG_3 Input 3.5V CMOS/TTL 35 DIG_4 Input 3.5V CMOS/TTL 36 DIG_5 Input 3.5V CMOS/TTL...
