45A00-1

Document Number: 45I00-1

Installation Instructions

DESCRIPTION

The Model 45A00-1 Supervised Wireless Receiver allows up to 64 unique wireless

security transmitters to report information to an HAI controller.

The wireless

transmitters replace wired door and window sensors, as well as wired smoke, motion,

glassbreak detectors, and handheld keyfobs.

These transmitters report status

information to the 45A00-1 Receiver which, in turn, processes the information and

reports it to the HAI controller.

COMPATIBLE TRANSMITTERS

The Model 45A00-1 Supervised Wireless Receiver is compatible with HAI Wireless

Transmitters. These transmitters include the 46A00-1 Door/Window Transmitter,

47A00-1 Quad Pet Immune Motion Detector, 48A00-1 4 Button Keyfob, 49A00-1

Smoke and Carbon Monoxide Detector, and 50A00-1 Panic/Alert Pendant.

Table of Contents

Need help?

Do you have a question about the 45A00-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for HAI 45A00-1

Page 1 Document Number: 45I00-1 Installation Instructions DESCRIPTION The Model 45A00-1 Supervised Wireless Receiver allows up to 64 unique wireless security transmitters to report information to an HAI controller. The wireless transmitters replace wired door and window sensors, as well as wired smoke, motion, glassbreak detectors, and handheld keyfobs.
Page 2: Installation
Install the receiver in a central area of the premises, as high above ground as practical. The receiver may be mounted up to 1000 feet from the HAI controller. The receiver should be at least 5 feet from the controller or any other electronic device.
Page 3: Specifications
ANTENNA MODE TYPE DISPLAY MODE +12V B GND SWITCH MODE/ADVANCE SWITCH SPECIFICATIONS Dimensions: 2.5W x 3.75H x 1.0D, excluding antenna Current Consumption: 30mA maximum Operating Temperature: F - 140 F (0 C - 60 Maximum Humidity: 90% relative humidity, non-condensing...
Page 4: Operation
OPERATION The two operating modes of the receiver are "Run" and "Setup". In Run Mode, with the receiver connected to and communicating with the controller, the Mode LED (see Figure 2) should blink once per second. The receiver monitors the status of each transmitter.
Page 5: Setup Mode
Next, you are prompted to enter the “number of addresses” (see the Setup information in this document for configuration of each HAI controller). The letter "n" is shown on the left of the display and the digit for the current number of addresses is shown on the right of the display.
Page 6: Teaching The Receiver A Transmitter Address
If no transmitter is programmed in an address location, neither the Mode LED nor the Type LED will be lit. If a transmitter is programmed in an address location: 1. The Mode LED indicates whether the transmitter sends restore transmissions The Mode LED is on if the transmitter sends restore transmissions, and off if it doesn't.
Page 7: Transmitter Setup
SET button until there are no dots (blinking or otherwise) on either side of the address number. The transmitter in now removed. To replace the transmitter, simply trip the new transmitter. When the 45A00-1 receives the transmission, the 45A00-1 will display the digit (transmitter address...
Page 8: Reset Memory
Connect the receiver to the OmniLT controller using 4-conductor, 22-gauge or larger wire as follows: Connect the "A" and "B" terminals of the 45A00-1 to the “YEL” (Yellow) and “GRN” (Green) terminals under the section marked “CONSOLE” on the OmniLT controller (Yellow = A and Green = B).
Page 10: Omnilt Setup
“Zones”, and then press 1 # (“Wireless Receiver?” Yes = 1). B. When connected to OmniLT, Zones 9-24 are the wireless receiver zones. C. When connected to OmniLT, the receiver address on the 45A00-1 must be set to "A1" and the number of addresses must be set to "n1".
Page 11 B. When connected to Omni II / Lumina, Zones 33-48 are the wireless receiver zones. C. When connected to Omni II / Lumina, the receiver address on the 45A00-1 must be set to "A1" and the number of addresses must be set to "n1".
Page 13 A. OmniPro II and Lumina Pro can have two 45A00-1 Wireless Receivers connected. When connected, the 45A00-1 is recognized as an Expansion Enclosure. Each 45A00-1 can handle up to 64 wireless zones, in groups of 16. Each group of 16 zones is considered 1 Expansion Enclosure (8 Expansion Enclosures maximum).
Page 14 The charts below describe where each group of wireless transmitters (groups of 16) on the 45A00-1 Wireless Receiver relates to each group of zones (groups of 16) on the OmniPro II / Lumina Pro in accordance with the number of addresses assigned (n1-4).
Page 15: Hai Controller Indications
HAI CONTROLLER INDICATIONS When the condition of a transmitter changes state, the HAI console will display that condition as follows: Transmitter Condition HAI Console Display When a transmitter (zone) is violated Zone Name "NOT RDY" When a cover is removed from a transmitter Zone Name "NOT RDY"...
Page 16: Display Description
To enter Setup Mode, press and hold the Mode/Advance switch for 2 seconds. DISPLAY DESCRIPTION SET SWITCH MODE/ADVANCE SWITCH Enter the receiver Changes the current Advances to the next address address (1-8) item Enter number of Changes number of Advances to the next addresses addresses (1-4) item...
