- Page 1 NX-SERIES USER MANUAL NX-series User Manual http://www.iviewtech.com iView Technology...
-
Page 2: Table Of Contents
6 CONFIGURE RECORDING ..............16 6.1. Initializing Record Settings 6.2. Scheduling a Recording 7 PLAYBACK AND BACKUP ..............19 7.1. Playback files from a video search 7.2. Understanding the Playback Interface 7.3. Backup the recorded file 8 CONFIGURE NETWORK ..............23 http://www.iviewtech.com iView Technology... - Page 3 9.2 Detecting Video Loss 9.3 Detecting Exception CONFIGURE DEVICES ............... 32 10.1 Managing HDDs 10.2 Configuring PTZ Settings CONFIGURE SYSTEM ................ 35 11.1 General 11.2 User 11.2.1 Adding a New User ..........................37 11.3 System Information 11.4 Maintenance http://www.iviewtech.com iView Technology...
-
Page 4: Nx-Series Overview
NX-SERIES USER MANUAL 1 NX-Series OVERVIEW This User Manual is to provide a comprehensive operational guide to iView Technology NX-Series NVR and Hybrid NVR. As we are constantly upgrading and updating our software and firmware features for our products, please check http://www.iviewtech.com... -
Page 5: Nvr Control Panel
LAN interface Connector for LAN (Local Area Network). USB interface Connector for USB device. LAN interface 4 ports LAN interface for IPCam connections DC POWER IN 12V DC power input for non-PoE or 48V for PoE Ground Ground http://www.iviewtech.com iView Technology... - Page 6 DB9 connector for VGA output. Display local video output and menu. HDMI OUTPUT HDMI output, Display local video/Audio output and menu. eSATA2 eSATA port, connect eSATA HDD for recording USB/eSATA1 USB/eSATA port, connect eSATA HDD for backup Alarm IO alarm, 8CH input and 4CHoutput http://www.iviewtech.com iView Technology...
- Page 7 NX-SERIES USER MANUAL LAN interface Connector for LAN (Local Area Network). DC POWER IN 12V DC power input Power switch Power switch http://www.iviewtech.com iView Technology...
-
Page 8: Getting Started
Unplug the power supply on the rear panel to safely shutting down the system. Rebooting and Locking Your NVR In the Shutdown menu, you may also reboot or lock your DVR. Locking your NVR will return you to the http://www.iviewtech.com iView Technology... - Page 9 Live Preview mode, which will require user name and password to exit out of it. The Reboot button will reboot your NVR. To reboot or lock your NVR: Enter the Shutdown menu by clicking Menu > Shutdown. Select the Lock button to lock the NVR or the Reboot button to reboot the NVR. http://www.iviewtech.com iView Technology...
-
Page 10: Live View
Click any channel in live view mode, a toolbar will be pop up: 1. Playback: click this icon, enter the menu of playback; 2. Audio: mute/unmute this channel; 3. PTZ: control the PTZ of this channel 4. Digital Zoom 5. Image parameter control: change the parameter of this camera http://www.iviewtech.com iView Technology... -
Page 11: Understanding Home Menu
: To enlarge the picture 2 times for each click. 6 times at most; : To shrink the enlarged picture till normal one; : To enlarge the selected area to full screen; : To turn the picture into normal size; : Exit. http://www.iviewtech.com iView Technology... -
Page 12: Ip Camera Channel
To delete an IP camera from your NVR, please select that IP camera and select none from the channel drop-down list. When you’re finished, click the Apply button to save the new configuration. Detail: if one IP camera is connected with your NVR, you can click this button to show this IP camera’s status: http://www.iviewtech.com iView Technology... - Page 13 NX-SERIES USER MANUAL Scan: Click this button, all the IP cameras in your local area network will be listed. http://www.iviewtech.com iView Technology...
-
Page 14: Configure Display
Save and Exit. To exit without saving, simply choose Exit. If you want to save your changes, choose Save first. Disable Preview: When checked, the live view of the channel you’ve selected will be disabled. http://www.iviewtech.com iView Technology... -
Page 15: Displays Output Settings
The settings available in this menu include: Display resolution Transparency: To adjust the menu transparency. Mouse Sensitivity Border Adjustment: To adjust the border of video output. Audio: Enables/disable audio output for the selected video output. http://www.iviewtech.com iView Technology... -
Page 16: Configure Recording
Select the camera you would to configure the settings for. Configure settings for: Encoding Parameters: Select main stream or sub stream. Record Audio: Select to record audio of the camera. Resolution. Frame Rate: Select recordings frame rate. http://www.iviewtech.com iView Technology... -
Page 17: Scheduling A Recording
Pack Duration: set the time in seconds for how long the NVR will be recording before splitting the output file. 6.2. Scheduling a Recording Scheduling a recording allows you to setup the NVR to only record when you want it to. To setup a recording schedule: http://www.iviewtech.com iView Technology... - Page 18 Motion detected and alarm triggered recordings are further explained in Configuring Alarms. Repeat the steps for other cameras or copy settings from one channel to others by Copy To; Click OK to finish and save the schedule settings. http://www.iviewtech.com iView Technology...
-
Page 19: Playback And Backup
7.1. Playback files from a video search To initiate playback: Select the channel you’d like to playback.. From the Video Type menu, select the type of video you’d like to playback. The options are Manual, Schedule, Motion and All. http://www.iviewtech.com iView Technology... -
Page 20: Understanding The Playback Interface
Pause / Single Frame: Select to pause or play in single frame; Fast Forwards: Select to play the recording files forward at the speed of x2, x4, x8, and x16; Slow Forwards: Select to play the recording files forward at the speed of x1/2, 1/4, 1/8, 1/16; http://www.iviewtech.com iView Technology... -
Page 21: Backup The Recorded File
Select the channel you’d like to backup. From the Video Type menu, select the type of video you’d like to playback. The options are Manual, Schedule, Motion and All. Set your Start Date/Time and your End Date/Time http://www.iviewtech.com iView Technology... - Page 22 Select Backup, the backup file list will be shown. Select the file(s) to be backup, and click Next; Click Refresh to look for USB devices to which recorded files can be backed up; Click start to begin the backup. http://www.iviewtech.com iView Technology...
-
Page 23: Configure Network
3) PPPoE: An advanced protocol that allows the NVR to be more directly connected via a DSL modem. This is an option for advanced users only. If you select Static in Network Access, you will need to input IP Address, Subnet Mask, Default Gateway and DNS information. http://www.iviewtech.com iView Technology... -
Page 24: Configuring Advanced Settings
HTTP Port: This is the port through which you will be able to log in to the NVR via web browser. RTSP Port: This is the port through which you will be able to live-view the NVR via RTSP client software. http://www.iviewtech.com iView Technology... -
Page 25: Ddns
Check the DDNS checkbox to enable feature. Select DDNS Type. Input the user name and password 8.2.2 NTP A Network Time Protocol (NTP) Server may also be setup on your DVR to keep the date and time current and accurate. http://www.iviewtech.com iView Technology... -
Page 26: E-Mail Settings
2. Synchronize Every: When you enable Auto Sync, here you can define the time in minutes of how often the synchronization should be. 3. NTP Server and NTP Port: NTP server IP address and port. 8.2.3 E-mail Settings To configure E-mail settings: http://www.iviewtech.com iView Technology... - Page 27 NX-SERIES USER MANUAL 1. Enter e-mail settings. 2. Click the Test button to test e-mail settings. 3. Select Attached Picture if you want to send email with alarm images, the interval of two adjacent pictures is configurable. http://www.iviewtech.com iView Technology...
-
Page 28: Configure Alarms
Check the checkbox of Enable to enable Motion Detection. Click the applicable Set button of Motion Detection to setup the motion detection area and sensitivity for that channel. Configure the schedule for motion detection. User can define when it’s armed or disarmed during 7x24. http://www.iviewtech.com iView Technology... -
Page 29: Detecting Video Loss
The default behavior of the NVR, when a channel has no incoming video signal, is simply to display “Video Loss” on a black background over the http://www.iviewtech.com iView Technology... -
Page 30: Detecting Exception
Action: The action you’d like the NVR to take when this event occurs. It’s set in the same way as the Action for any other event. 9.3 Detecting Exception Setting exceptions allow the NVR to alert you when irregular events occur. These events include: http://www.iviewtech.com iView Technology... - Page 31 HDD Full: All installed HDD are full. HDD Error: Errors occurred during writing of the HDD, no HDD installed or HDD had failed to initialize. Net Disconnected: Disconnected network cable. IP Conflict: Conflict in IP addresses setting. http://www.iviewtech.com iView Technology...
-
Page 32: Configure Devices
Initializing the HDD will erase all data on it. To initialize a HDD: Select HDD to initialize. Click the Init button. Select OK button to begin initialization. After the HDD has been initialized, the status of the HDD will change from No to Yes. http://www.iviewtech.com iView Technology... -
Page 33: Configuring Ptz Settings
You can see the detail S.M.A.R.T information of the HDD. 10.2 Configuring PTZ Settings Settings for a PTZ camera must be configured before it can be used. Before proceeding, verify that the PTZ and RS-485 of the NVR are connected properly. To configure PTZ settings: http://www.iviewtech.com iView Technology... - Page 34 NX-SERIES USER MANUAL Select channel where PTZ camera is installed next to Camera label. Enter PTZ settings according to the camera. Click OK button to save and exit menu. http://www.iviewtech.com iView Technology...
-
Page 35: Configure System
First, turn DST on. We suggest setting the Daylight Saving Time Mode to Date, and manually entering the dates and times that daylight savings time applies to and from, in your locality. Device Mode: NX-8X Hybrid NVR supports several modes, including 8CH analog mode, 4Ch http://www.iviewtech.com iView Technology... -
Page 36: User
12345. The default password for Administrator should be changed right away for security reasons. The Administrator has the authority to add, delete or configure parameters for many of the system functions. To add additional users, choose Add. To remove a user, choose Delete. http://www.iviewtech.com iView Technology... -
Page 37: Adding A New User
4. Configure privileges for local settings under Configuration tab. The configuration page specifies which menu(s) the user can access. There is no hierarchy and any combination of menus can be selected (although some combinations would make little sense in practice). http://www.iviewtech.com iView Technology... -
Page 38: System Information
2 and 4. 11.3 System Information System information is for use by technical support. When you call for technical support, you need to provide the information here. http://www.iviewtech.com iView Technology... -
Page 39: Maintenance
NX-SERIES USER MANUAL 11.4 Maintenance Enable auto reboot: Will automatically shut the NVR down and restart it at a certain time of the day or http://www.iviewtech.com iView Technology... - Page 40 Locate the file you want on your flash drive - it will be called config(time & date).tgz. For example, config20120404110829.tgz would be the config file from April 4, 2012 at 11:08AM. Loading the file will cause the NVR to automatically reboot. http://www.iviewtech.com iView Technology...
