Stephen SVG400S User Manual

4 fxs port voip ata
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SVG400S 4 FXS Port VoIP ATA User Manual
For DC24V Only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVG400S and is the answer not in the manual?

Questions and answers

Summary of Contents for Stephen SVG400S

  • Page 1 SVG400S 4 FXS Port VoIP ATA User Manual For DC24V Only...

  • Page 2: Table Of Contents

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual Contents 1.1 General Information......................3 1.2 Protocol ..........................3 1.3 Hardware Specification.......................4 1.4 Software Specification ......................4 1.5 List of the Package......................4 1.6 View of the Appearance ......................4 2.1 Installation Steps .........................5 2.2 Connection Diagram ......................5 "...
  • Page 3 Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 4.4.1.1 Single Configuration ...................16 4.4.1.2 Configuration by Line .................17 4.4.1.3 Configuration by Group ................17 4.4.1.4 Advance Settings..................18 4.4.1.5 H.323 Direct Mode..................19 4.4.2 SIP Phone......................19 4.4.2.1 Single Configuration ...................20 4.4.2.2 Configuration by Line .................21 4.4.2.3 Advance Settings..................22...

  • Page 4: General Information

    DHCP, LAN Phone System. The SVG400S IP ADAPTOR is an all-in-one VoIP integrated device, which is designed to be a total solution for network’s providing VoIP services. Its functions are available via a regular analog telephone.

  • Page 5: Hardware Specification

    DHCP Server Firmware On-line upgrade Phone Book Memory Dial Caller ID Multiple Language Support With Accounting Function 1.5 List of the Package One SVG400S IP ADAPTOR One universal power adaptor DC24V/500mA One Ethernet cable (3m) 1.6 View of the Appearance...

  • Page 6: Installation Steps

    2 Installation 2.1 Installation Steps The SVG400S IP ADAPTOR has four PHONE ports ˜Phone1 to 4 ¯ ¨ one NETWORK port and one PC port. The PHONE ports can register to the same SIP or H.323 account or two different SIP or H.323 accounts.

  • Page 7: Star Command

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 3 Basic Operations 3.1 Star Command There are two types of Star Commands. One is factory predefined star command for phone setup and information purpose. The other is for phone operation. The first digit of a command must be “*”...

  • Page 8: Star Commands For Phone Operation

    Local setup is supported via built-in web pages. To access the web pages, the LAN or PC port IP address is required. The SVG400S IP ADAPTOR is equipped with voice prompts to read LAN port and PC port IP addresses via the Phone port.

  • Page 9: Make Phone Calls

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual port to the factory default IP. By the new firmware, the default setting was the LAN port is DHCP mode, the PC port is bridge mode. The star command *11983185922 can be dialed to reset the system configuration or return to the default configuration.

  • Page 10: Call-Forward

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual transfer. If the third party agrees, you hang up your phone. Unattended Transfer When a call is in progress and you agree with him/her to have a call transfer, press “*41”, and when you hear dial tone, dial another phone number. When you hear ring tone, just hung up your phone without a conversation with the third party.
  • Page 11 Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual with the network, the LAN LED will light up continuously. ( The LED will not light network connection unavailable ) If there is data transmitting through the ATA, the LAN LED will blink. (Example: During a VoIP call, the LED will keep blinking.)

  • Page 12: Access The Web Configuration Menu

    The SVG400S IP ADAPTOR HTML configuration menu can be accessed via LAN or PC port: With the LAN access is enabled, get the LAN IP address of the SVG400S IP ADAPTOR as described in section 3.1.1. The SVG400S IP ADAPTOR’s Web Configuration page can then be accessed by entering the URI into a web browser.
  • Page 13 “dbl#admin” (default) in the Password field and then click on the OK button. The PC Browser then shows the window below and you have successfully entered the SVG400S IP ADAPTOR HTTP WEB Interface. Administration configuration includes not only the end user configuration, but also advanced configuration such as SIP configuration, and other miscellaneous configurations.

  • Page 14: Status

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 4.2 Status As shown in the figure above, there are four main fields to be configured on the Status page. 4.2.1 Phone Information A. Serial Number Each ATA has a unique serial number assigned by the factory such as SVG400S05600082.

  • Page 15: Configurations Options

    This field shows the NTP server IP address such as timekeeper.isi.edu. 4.3.3 Auto-provision Allow central provisioning of SVG400S. Auto-provision is the automatic configuration of devices without manual intervention and without any need for software configuration programs or jumpers. Ideally, auto-provision devices should just "Plug and Play".

  • Page 16: Pound(#)Key And Auto-Dial Timeout

    SVG400S IP ADAPTOR User Manual other embedded controller devices. It includes Auto-provision Server and Auto-update. This is the special service only. It must support by Stephen Technologies’ Auto-provision Server. 4.3.4 Pound(#)Key and Auto-dial Timeout If you want the terminal send out your telephone number shortly, please click the Pound(#)Key enable.

  • Page 17: Phone

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 4.4.1 H.323 Phone H.323 is the international standard for multimedia communication over packet-switched networks, including LANs, and the Internet. There are three kinds of FXS mode to configure: 1 ¯ Single Configuration; 2 ¯ Configuration by line ; 3 ¯ Configuration by Group .

  • Page 18: Configuration By Line

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual screen, enter the gatekeeper address in the Gatekeeper Address field.If your gatekeeper used nonstandard signaling port ˜The default port is 1719 ¯, you can config it with gatekeeper address field such as 192.168.2.197:2000 or gk.your.com:2000 ( the 2000 is your gatekeeper’s signaling port ).

  • Page 19: Advance Settings

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 4.4.1.4 Advance Settings Click on “Advance Settings” in the H.323 menu, the configuration screen of advance settings will be displayed as follows. In this part, you will have more advance control over the H.323 signaling.

  • Page 20: Direct Mode

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual Media control port is the port or port range used by the H.245 media control protocol. Note: the H.245 media control protocol uses TCP D ¯ ¯ ¯ ¯ Fast Start Enable or disable the Fast Start procedure described in H.225.0. This option is mainly used for testing and solving compatibility problems.

  • Page 21: Single Configuration

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 4.4.2.1 Single Configuration In this FXS mode, you can give the two phones connected to the ATA the same configurations in the following items. A ¯ ¯ ¯ ¯Phone Number This field use fill in the SIP client authentication ID. It is the telephone number (or extension) you assigned to the VoIP SIP Phone such as 123456.

  • Page 22: Configuration By Line

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual the problem, Internet defines the Domain Name System (DNS) by using ASCII string. E ¯ ¯ ¯ ¯Authentication ID This field use fill in the SIP client authentication ID. Authentication mainly is the identification of the user.

  • Page 23: Advance Settings

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 4.4.2.3 Advance Settings Click on “Advance Settings” in the SIP menu, the configuration screen of advance settings will be displayed as follows. In this part, you will have more advance control over the SIP signaling.
  • Page 24 Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual proxy server or other SIP user. B ¯ ¯ ¯ ¯ Outbound Proxy This field shows the SIP outbound proxy IP address. In most cases, the SIP outbound proxy is placed alongside the firewall and is the way to let SIP traffic pass from the internal network to the Internet.

  • Page 25: Media Setting

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual G ¯ ¯ ¯ ¯ Signaling Qos C. SIP Local Port SIP Local Port is the local UDP port used by the SIP client to communicate with SIP proxy and other SIP user agents.

  • Page 26: Codec Preference

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual D ¯ ¯ ¯ ¯ Media Qos RTP TOS is a service field in UDP IP packets carrying a RTP data. Enter RTP TOS if your network supports DiffServ and can prioritize the packets to maintain voice quality.

  • Page 27: Media Nat Traversal

    It includes address, ports, user name, and password. Note: This RELAY proxy is only compatible with the RELAY Server software developed by Stephen Technologies independently. It was free software, you can come down on us. 4.4.5.2 Media NAT Traversal Click on the “Media NAT Traversal”...

  • Page 28: Billing Support

    The terminal can support billing by normal Reverse Signal. It was without config. About the Stephen Technologies’ billing software can download by www.stephen-tele.com, it is free. 4.4.7 Dial Plan SVG400S apply to the rule dialing out the telephone number ,user can set the rule in the panel of Call Settings.

  • Page 29: Basic Dial Rule

    "013044557766"; or input "13644557766", output "013644557766" C. input "23185700", output "075523185700". or input "73185700", output "075573185700" 4.4.7.2 How to limit code bit If you want to limit the bit of every telephone number in the SVG400S,you could set the...

  • Page 30: User Command

    We dial out the number "88990011" or "8899001133", and the really we dial is the same one, which is "075588990011". 4. 5 User Command The SVG400S have four User Commands, in the “Phone setting” web like below screen: You can change the VoIP and PSTN switch command. The other two commands: The Hold Key command:*42 The Transfer Key command;*41...

  • Page 31: Switch To Pstn

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 4.5.2 Switch to PSTN The default number is *21. If the line default is VoIP, press *21 and you will switch to PSTN line. 3 Hold Key The default number is *42. If you are in the process of a call, press *42 and you will put the call on hold.

  • Page 32: Network Configurations

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual Note: The range of the Input Gain can induce the terminal can not dial the phone number. If you meet this phenomenon and you adjusted it, Please resume or lessen the range of the Input Gain.

  • Page 33: Lan Port Configurations

    PC port configurations. 4.7.1 LAN Port configurations The SVG400S LAN port can be configured to obtain its IP address by DHCP or the IP address can be set statically (used mainly when using the ATA with a DSL line). There are three modes to configure LAN port: 1 ¯...

  • Page 34: Pc Port Configurations

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual PPPoE, point-to-point protocol over Ethernet, is a network protocol for encapsulating PPP frames in Ethernet frames. It is used mainly with cable modem and DSL (Digital Subscriber Line) services. Click PPPOE, and you can set user name and user password.

  • Page 35: Primary Dns

    To Enable DHCP Service, you have to know the starting address, which is used to start the service; and the ending address, which is used to end this service. The SVG400S’s DHCP server must running by PC Port using Static IP mode.

  • Page 36: Secondary Dns

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 4.7.4 Secondary DNS It is the secondary DNS server IP address that will be used in the event that the primary DNS server IP address fails or is not available. You can obtain this from your ISP (For example: 202.67.156.222).

  • Page 37: Online Upgrade

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 4.10.1 Online Upgrade WARNING! Performing an online upgrade is for experienced users or administrators only! Click Online Upgrade. Enter the IP address or domain name of the upgrade server and package name: http://202.96.136.145/update/A34HS-3.07-18.pkg ¨ And then click Start.

  • Page 38: Reset Configuration

    Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual B ¯ ¯ ¯ ¯Administrator Password The administrator password is set to allow you to modify all configuration items assigned to the ATA. The default is admin. You can change it according to your own wish..
  • Page 39 Stephen Technologies Co.,Limited SVG400S IP ADAPTOR User Manual 5 Products Parameter Characteristics of the Parameter Remarks hardware Type SVG400S Can be customized Processor ARM9E 133MHz VDS924PM4 200MHz FLASH Power DC24V/500mA Consumption The maximum 10 W Operate, network , circuit Network card 100/10BASE-T ×2...

  • Page 40: Copyright Notice

    Co.,Limited. Disclaimer Notice: No license is granted, implied or otherwise, under any patent or patent rights of Stephen Technologies Co.,LTD. Stephen Technologies Co.,LTD, makes no warranties, implied or otherwise, in regard to this document and to the products described in this document. The information provided by this document is believed to be accurate and reliable to the publication date of this document.
