Rev 1.7

MXS-EVO

Disciplined RF Generator

Table of Contents

Need help?

Do you have a question about the MXS-EVO and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Instruments MXS-EVO

Page 1 ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO Disciplined RF Generator Rev 1.7...
Page 2: Declaration Of Conformity
Safety of machinery - Electrical equipment of machines - Part 1: General CEI EN 60204-1:2006+A1:2010 requirements DIGITAL INSTRUMENTS S.r.l. Bresso, October 2012 Via Parco degli Scout, 13 20091 BRESSO (MI) ITALY Marco Genova Quality Assurance Manager ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 2 -...
Page 3 Any adjustments, replacements of parts, maintenance or repair may be carried out only by authorized Digital Instruments technical personnel. Assicurarsi che ogni collegamento con dispositivi informatici sia eseguito secondo IEA950/EN60950 Ensure that the connections with information technology equipment comply with IEC950/EN60950 ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 3 -...
Page 4 11/04/2012 Added note about the internal NTP server 18/04/2012 Added section about Custom Settings 30/10/2012 Updated changelog 02/05/2013 Added notes about the NTP server timestamping 14/10/2013 Added FAQ section 31/10/2013 ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 4 -...
Page 5: Table Of Contents
35 Quality Factor ................................36 Statistics..................................37 Automatic Site Survey .............................. 37 Appendix B: FAQ ............................... 38 Appendix C: Changelog ............................. 41 Assistance ..................................43 Technical Data ................................44 ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 5 -...
Page 6: Summary
When an error on the selected source is observed an error condition is generated via SNMP and dry contacts and a new source is selected between the available ones as per user configured priority. MXS-EVO is quite simple to use and to set-up. Every function can be accessed locally from the LCD panel and remotely via WEB or SNMP.
Page 7: Front View
Date and time By pushing the right keyboard button it’s possible to enter the main menu of the MXS-EVO. Rear View In the following feature is depicted the back of the apparatus MXS-EVO with the position of connectors. Programmable TNC Antenna...
Page 8: Connectors Details
A tecnhical sheet about the programmable outputs is given alongside the device. The following table can be taken as reference to understand it. J10A J11A J12A J13A J14A J15A J10B J11B J12B J13B J14B J15B ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 8 -...
Page 9 Twelve connectors have instead customizable functions by means of a DIP switch matrix placed on the PCB inside the device: Even if modifying the outputs is simple is suggested to first contact the factory in order to avoid voiding the warranty by opening the device. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 9 -...
Page 10: Main Operation
MXS-EVO - MANUAL Main Operation The main purpose of the MXS-EVO is to provide stable output signals of Time (PPS, E1, IRIG code, NTP/PTP) and Frequency (10 MHz, 2.048MHz), and to enable the synchronization of the network. This is allowed by the application of algorithms, tuning an high-stability internal oscillator.
Page 11 Rec G.812 (ITU-T) MXS-EVO allows to choose on which of the 30 (from 2 to 32, excluding 17) timeslots of the E1 frame transmit the PPS signal. As default, the signal is sent and received on timeslot 32. The timeslots 1 and 17 are used to send sync and control data by E1.
Page 12: Ntp
• X6 from 0 to 1 when there is loss of synchronization; MXS-EVO allows to choose which "column" (from 4 to 8) of bits use to transmit the value of the signal quality. By default this value is sent and received on the column 8.
Page 13: Ptp (Ieee 1588)
PTP (IEEE 1588) The MXS-EVO supports the IEEE 1588-2008 (version 2), also known as Precision Time Protocol, both as master and slave. When connected to an appropriate device compatible to the IEEE 1588 standard is able to synchronize the slave apparatus with a precision well below the micro-second.
Page 14: Irig-B
MXS-EVO - MANUAL IRIG-B The device can accept in input and provide in output (on BNC and optical connectors) an IRIG-B stream of type 006, compliant with following code: ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 14 -...
Page 15: Date And Time
The device disciplines its internal clock from the selected reference (GPS, PTP, IRIG-B, NTP) and distributes it with the following rules: NTP (UTC timebase as per standard) • PTP (TAI timebase as per standard) • ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 15 -...
Page 16: Switchover Function
IRIG-B signal Switch Policies The MXS-EVO permits to chose the priorità of the various sources. Priorità is bigger when the value is bigger. 0 inhibits the source. When the device is configured for automatic switchover two different policies can be used: Switch &...
Page 17 Characterization of Sources MXS-EVO was also designed to compare the quality of the different sources provided to apparatus, analyzing the ratio ∆f / f (variation of the frequency value on the nominal frequency) of each source. This analysis is supported by a graph (that can be generated by the Stability Chart button in the Main Panel) which shows the trend of these ratios over time.
Page 18 MXS-EVO - MANUAL It is also possible display the progress of these distances over time (using the button Distance Chart in the Main Panel). ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 18 -...
Page 19: Graph Menu
The changing of parameters from front panel is only supported in local mode. From the level 0 (ROOT) it is possible to change the contrast of the LCD screen by pushing the UP and DOWN keys. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 19 -...
Page 20 0 ÷ 10000 ns T-Raim Alarm 300 ÷ 1000000 ns Restore Defaults Restore Show Ch Status Ch, S/N, Elevation, Azimuth Show Global Info Tracked Sats, Visibile Sats, PPS Signal, Antenna ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 20 -...
Page 21 IRIG-B <value> [ns] IRIG-B Mux In Optical / Electrical Date & Time 00:00:00 01/01/01 ÷ 23:59:59 31/12/99 Timezone -12 ÷ 12 Setup Clear Log Clear Restore Defaults Restore Reboot Reboot ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 21 -...
Page 22: Web Interface
MXS-EVO - MANUAL WEB Interface The MXS-EVO is managed by the network using a common browser by simply connecting to the associated IP address. Mode Menu Local/Remote In local mode is only possible to modify operative parameters from the front panel display. In remote mode it can be done from WEB, SNMP and REMOTE CONTROLS.
Page 23 IRIG-B OUT Allows to choose which signal to spread on the IRIG-B BNC connectors (default is IRIG-B). Positioning Permits to change the position of the device (retrieved from GPS if available). ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 23 -...
Page 24 TLC active Shows the status of the 7 TLS TLS inactive TLS active Supply Shows the status of the 2 power supplies (left and right). power supply inactive power supply active ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 24 -...
Page 25 All these variables are reported in the GPS status window. Cable Delay can be set in the GPS Configuration, whilst Latitude, Longitude and Height cannot be set by WEB, but only from SNMP or front panel. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 25 -...
Page 26 These values are displayed in the EXT tab of Main Panel. Settings Allows to set the eligible values for the time and frequency reference between the pre-set. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 26 -...
Page 27 In the web interface it’s possible view the values of state variables of the settings in Tab E1 of the Main Panel, while is possible change the settings on the E1 Config Panel. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 27 -...
Page 28 Sources Panel. Enable Allows to switch on or off the PTP. Type Allows to choose to configure the device as a Grandmaster or a Slave. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 28 -...
Page 29 This setting is for additional safety. Hardware Enable NTP hardware timestamping support for improved performance (disables PTP) Broadcast Periodically send broadcast NTP server packets (without authentication) Poll Specify the interval between broadcast packets ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 29 -...
Page 30: Event Log
Event Code 018 PTP PPS Change in the status of the PPS rebuilt by PTP Event Code 019 IRIG-B Change in the status of the presence of the IRIG-B signal ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 30 -...
Page 31: Snmp Trap Management
The username and password for this guest account can be set by the administrator under Guest Account Settings. The default credentials are: admin admin / admin guest / guest guest About SNMP: Read community string public public Write community string ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 31 -...
Page 32: Custom Settings
The device is able to generate two distinct programmable square wave clocks by dividing two different sources with integer dividers: 10 MHz • 16.384 MHz • Please note that the rising edge of the resulting clock is synchronous to the internal PPS, if the frequency is integer. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 32 -...
Page 33: First Run
• input in the IRIG-B Mux selection) Connect the MXS-EVO to the power grid. After a few seconds the LCD display should light up (without an ethernet cable it would take a little more) and the leds under the keyboard should start blinking.
Page 34 Automatic switchover • To finally enable the automatic switchover is possible to operate from the front panel (Board Settings Manual/Auto), from SNMP (switchMode) or from WEB in the Board Configuratio page. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 34 -...
Page 35: Appendix A: Quality Factor
3. checking that the PPS generated by the radio (PPS Status) is valid (green LED) Se così non fosse l’algoritmo di disciplinamento potrebbe non comportarsi in maniera ottimale e la short term stability dei riferimenti PPS e 10 MHz ne potrebbe venire inficiata. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 35 -...
Page 36: Quality Factor
The value of the Quality Factor is shown in GPS tab of Main Panel Page. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 36 -...
Page 37: Statistics
GPS menu. Should be also necessary to reset the device in Automatic Site Survey mode, since the radio, after completing the survey - which takes about 3 hours - automatically returns to Position Hold mode. POSITION HOLD ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 37 -...
Page 38: Appendix B: Faq
To do so is simply necessary to launch the utility and specify the correct IP address of the device. Is better to configure the utility with the following settings. Add date an time OFF Verbose debug Continuous save ON ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 38 -...
Page 39 127.127.20.1 minpoll 4 maxpoll 4 mode 24 # NMEA @ 9600 bps, $GPZDA fudge 127.127.20.1 time2 0.0110185 # time correction A NULL modem cable should be used to connect with the device on the serial port. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 39 -...
Page 40 MXS-EVO - MANUAL The schematic is depicted here: ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 40 -...
Page 41: Appendix C: Changelog
Added support for NMEA GPS radio • Release 2.5 (april 2013) Updated GUI to fix some problems in the E1 panel • Release 2.6 (august 2013) Updated PTP settings • ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 41 -...
Page 42 Release 2.7 (september 2013) Added multiple VLAN support • Release 2.8 (october 2013) Added support for NTP hardware timestamping • Release 2.9 (october 2013) Added support for PPS over serial line • ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 42 -...
Page 43: Assistance
You can then send the form to riparazioni@digital-instruments.com, via fax to +39.02.66506103, or enter it directly into the box when sending goods for repair. You can also contact us at +39.02.66506250 Monday to Friday from 9 to 13 and from 14 to 17 (GMT+1 Time). ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 43 -...
Page 44: Technical Data
Grandmaster clock source (GPS) or slave Time stamping Hardware Precision < 1 µs NTP Section Protocol NTP version 4 Role Grandmaster clock source (GPS) Stratum Precision < 10 ms with software timestamping ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 44 -...
Page 45 Depth 300 mm without connectors Weight 1.5 Kg Accessories 1 x GPS Antenna 1 x 30 m Belden PRG 7 Cable 2 m Cordon for network supply Handbook in English/Italian ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- MXS-EVO – Manual – Rev 1.7 - 45 -...
