EzwatchPro M4229RGDDT User Manual

4, 8, 16 channel premium standalone digital video recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Standalone Digital Video Recorder
Premium DVR
4, 8, 16 Channel Models
User`s Manual
MADE IN KOREA
M4229RGDDT
RGD4
This document contains preliminary information and is subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M4229RGDDT and is the answer not in the manual?

Questions and answers

Summary of Contents for EzwatchPro M4229RGDDT

  • Page 1 Standalone Digital Video Recorder Premium DVR 4, 8, 16 Channel Models User`s Manual MADE IN KOREA M4229RGDDT RGD4 This document contains preliminary information and is subject to change without notice.
  • Page 2 FCC Compliance Statement Notice to Users This equipment has been tested and found to comply with the limits for a Class A digital device. Pursuant to Part 15 of the FCC Rules, these limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 3 Cautions  This product has multiple-rated voltages (110V and 220V). See installation instructions before connecting to the power supply.  This product uses a Lithium battery.  To avoid any risk of explosion, do not replace the battery on the main board by anything other than a Lithium battery. ...
  • Page 4 11. Objects and Liquids  Never push objects of any kind through openings of this equipment as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock.  Never spill liquid of any kind on the equipment. 12.
  • Page 5 The List of Configuration A Type : 4 / 8 / 16CH B and D Type : 4 / 8 / 16CH DVR Set C, E, F and G Type : 4 / 8 / 16CH CD (CMS Software/Manual) Remote Controller Manual Screws HDD Brackets...

  • Page 6: Operation Precautions

    Operation Precautions  Power Off  Do not turn DVR off, or plug off the power adapter while DVR is in operation (record/playback). Otherwise, it may cause permanent damage to the equipment. Please click ( ) SETUP>SYSTEM>Shutdown sequentially and then remove the power after DVR is shutdown completely.

  • Page 7: Table Of Contents

    Table of Contents Server 4.4.3 Audio ................45 4.4.4 Alarm In ............... 45 PRODUCT FEATURES .............9 4.4.5 Alarm Out ..............46 4.4.6 Serial In ............... 46 Unpacking ................9 RECORD ................47 4.5.1 Setting ................. 47 Service ...................9 4.5.2 Schedule ..............52 4.5.3 Pre Alarm ..............
  • Page 8 8.2.1 System Setup...............74 12.2.1 System Requirements ..........104 8.2.2 Remote Site ..............75 12.2.2 Installation ..............104 12.2.3 Site Registration ............105 12.2.4 Connection ..............106 Live Video ................77 12.2.5 PTZ Control ............... 106 8.3.1 Network Connection.............77 12.2.6 Disconnection............107 8.3.2 Watch Mode..............78 12.2.7 Uninstall..............

  • Page 9: Product Features

    1. Product Features 1.1 Unpacking  This equipment is an electronic appliance, so it should be handled with special care.  After unpacking, please check if all the following items are included. - DVR Main body A Type : Power Supply Adapter (DC 12V, 3.33A) and Power Supply Cable B, C and D Type : Power Supply Adapter (DC 12V, 5A) and Power Supply Cable E Type...
  • Page 10 B Type – 4 / 8 / 16 channel Series DVR...
  • Page 11 C Type – 4 / 8 / 16 channel Series DVR...
  • Page 12 D Type – 4 / 8 / 16 channel Series DVR...
  • Page 13 E Type – 4 / 8 / 16 channel Series DVR...
  • Page 14 F Type – 4 / 8 / 16 channel Series DVR...
  • Page 15 G Type – 4 channel Series DVR...

  • Page 16: Installation

    2. Installation 2.1 Hard disk and DVD-RW Installation 2.1.1 SATA Port A Type  - Main substrate of this DVR has one SATA port: it is indicated as SATA 1. - Only one SATA device (hard disk) is possible to connect in Serial to the SATA port. B and D Type ...

  • Page 17: Hdd Installation

    2.1.2 Internal SATA Storage (E, F and G Type)  These series DVRs have 5 Internal SATA Ports: The picture below shows internal ports 1-4 SATA Port and 5 SATA Port.  1-3 SATA Port: It is designed to mount HDD. ...

  • Page 18: Maximum Hdd Capacity

    2.1.5 Maximum HDD Capacity  Each model has a different HDD capacity recognition.  Below table shows the recommended maximum HDD capacity for each model. Model A type B type C type D type E type F type G type Capacity 16TB 16TB...

  • Page 19: Audio Connections

     If user wishes to hear audio via HDMI cable, check the box HD Audio Output  Click the box below to select resolution. - User can select the resolution among ‘1920x1080 RB’, ‘1920x1080’, ‘1680x1050 RB’, ‘1680x1050’, ‘1280x1024’, and ‘1024x768’ - The default setting of DVR is ‘1280 x 1024’.

  • Page 20: Power Supply Connections

    2.2.11 Power Supply connections A Type  : Plug the power supply adapter (DC 12V, 3.33A) which include in this product to ’DC12V’ connector and plug another side to power source. Adapter input voltage is a free volt (100 VAC ~ 240 VAC). Please do not use any different power supply adapter because it may cause the DVR to malfunction.

  • Page 21: Input Device And Screen Icons

    3. Input Device and Screen Icons 3.1 Key and LEDs  B and D Type KEYS PTZ KEY Operating mode Setup mode •Up/Down/Left/Righ ▲, ▼, ◄, ► • Control Pan/Tilt rotation of up/down/left/right in PTZ mode t on screen cursor control 1 ~ 10 •...
  • Page 22  C, E, F and G Type KEYS PTZ KEY Operating mode Setup mode •Up/Down/Left/Righ ▲, ▼, ◄, ► • Control Pan/Tilt rotation of up/down/left/right in PTZ mode t on screen cursor control 1 ~ 16 • Camera select keys : (4/8/16 channel DVR) DISPLAY •...

  • Page 23: Camera Select Keys For 16 Channel Dvr

    3.2 Camera Select Keys for 16 Channel DVR B and D Type  Below shows how to select camera channel for 4 channel DVR - Select Camera No. 1~4: press key and use 1~4 key  Below shows how to select camera channel for 8channel DVR - Select Camera No.

  • Page 24: Using A Remote Controller

    B and D Type 4 Channel DVR 8 Channel DVR 16 Channel DVR C, E, F and G Type 4 Channel DVR 8 Channel DVR 16 Channel DVR 3.4 Using a Remote Controller  Usage of a remote controller is same as the front panel keys. ...

  • Page 25: Using A Mouse

    3.5 Using a Mouse  Mouse provides an easier access to adjustment. Refer to below for proper use.  Left mouse button functions the same as Enter ( ) key on the front panel of DVR.  Right mouse button displays the following “Function keys” on screen. ...

  • Page 26: Screen Icon

    3.6 Screen Icon Icon Description Icon Description Continuous recording mode In Audio recording Event recording mode CMS access indication/ No. of accesses (Alarm In/Motion) (up to 4) In recording In channel sequencing PTZ registration / PTZ mode Lock Remote Controller Setup in HDD Overwrite mode Setup in HDD No Overwrite mode Setup in HDD No Overwrite mode...

  • Page 27: Setup

    4. Setup 4.1 Login / Logout  At the default setting of DVR, user has to input the password to enter the set up menu.  Please press SETUP key to enter the setup menu and the following screen will appear. ...

  • Page 28: System

    4.2 SYSTEM 4.2.1 Information  Please click ( ) SYSTEM>Information and the following screen will appear. Status Site Description  Decide on a name of DVR.  Please click ( ) keyboard icon on Site Description frame and the following virtual keyboard will appear. ...
  • Page 29  Import: Copy the Menu setup stored in USB memory stick into DVR. Please plug in the memory stick and then click ( ) Import.  Export: Store the Menu setup of DVR in USB memory stick. Please plug in the memory stick and then click ( ) Export. ...

  • Page 30: Admin

     User shall designate the total recording days from 1 day to 30 days and unlimited.  User may set for beeping or notifying messages that notify the used percentage of disk.  Check Disk Overwrite and user may activate the overwrite function. - This function makes restart the recording from the beginning when the HDD is full.
  • Page 31  Please click ( ) SYSTEM>Admin and the following screen will appear. Date / Time Date  This menu will allow user to adjust the settings.  Please follow the procedure below for time adjustment. ① Click ( ) items (Y, M, D) to change. A designated item will be highlighted in a box (Y: Year, M: Month and D: Date). ②...
  • Page 32  Set time indication format. Please click ( ) Time Format frame to select a format from the list.  When user complete Date/Time input, please click ( ) NTP and the following screen will appear.  This menu is for accurate setting of time of day clock in DVR. ...
  • Page 33  Using E-SATA port will allow users to connect up to maximum 12 HDD +1 DVD-RW.  When user installs full storage device and DVD-RW including two e-SATA storage, then following procedures will be listed as below: - 1. Internal SATA 1~4 Ports - 2.

  • Page 34: Account

     Click ( ) ▲, ▼ direction buttons on the right-hand side of HDD Damage frame to set the permissible level of HDD damage (%). HDD is a very crucial element for DVR recording, so set the permissible level within 1% to 2% to assure maximum safety.

  • Page 35: New User

    New User  Please click ( ) New User and the following screen will appear.  Click ( ) the keyboard icon on the right-hand side of User Name frame and the virtual keyboard will appear. Click desired characteristics (up to 8 characteristics) on the virtual keyboard. ...

  • Page 36: System Log

     This is a screen for password resetting.  Input password by clicking the keyboard icon on the right-hand side of the frame.  Use key if wish to erase password on keyboard. 4.2.4 System Log  Please click ( ) SYSTEM>System Log and the following screen will appear. ...

  • Page 37: Exit

    - Execute Clear All Data in SYSTEM>Information>Record and choose ‘OK’ on the popup dialogue box. Please note that all normal recorded video data are deleted from database. - Press Factory Reset Switch on the back panel. Please note that the entire menu setup is also defaulted. 4.2.5 Exit ...

  • Page 38: Main Monitor

    OSD Margin  The OSD Margin menu will allow user to adjust the position of OSD (letters) on the monitor. Use it when some of letters are dropped out and invisible on the monitor.  Adjust Horizontal to change margin between both ends of the monitor on horizontal side and OSD. Margin range is between 0 and 50, with a larger number representing greater margin.

  • Page 39: Spot Monitor

     Adjust interval for ‘X9 Split Screen sequencing’.  Check  check box next to the camera that wish to include in sequencing. Any camera with unchecked check box will be excluded from channel sequencing.  Adjust the rotation interval of camera by clicking Dwell column. The rotation interval changes to 3>5>10>15>30>60 seconds by each press.

  • Page 40: Vga (D, E And F Type)

     The Multi Spot menu will allow user to adjust channel sequencing interval of Spot monitor. Full Seq  Adjust interval for ‘Full screen sequencing’.  Check  check box next to the camera that wish to include in sequencing. Any camera with unchecked check box will be excluded from channel sequencing.

  • Page 41: Devices

    G Type  Users are able to set its video output resolution from 1024x768 to 1920x1080  If user wishes to hear audio via HDMI cable, check the box HD Audio Output  HD-SDI DVR displays and records differently with previous NTSC or PAL methods. ...
  • Page 42 Network Type  Please click ( ) Network Type. When you click ( ) the button, it changes alternately to Static (fixed IP) and DHCP (floating IP).  In Static, user must manually set the static IP address for use. - Set IP Address, Subnet Mask and Gateway.
  • Page 43 varies every time when user access. The best alternative is DDNS (Dynamic Domain Naming System) which uses name (domain name) instead of IP address (numbers). DDNS automatically recognizes ever changing, floating IP addresses, so it will allow easy Internet access. ...

  • Page 44: Camera / Ptz

    CAUTION CHANGES BEING MADE ARE APPLIED AFTER COMPLETE SETUP TO EXIT. CAUTION ONCE PORT NUMBERS ARE CHANGED, IT MUST BE CHANGED THE PORT NUMBERS OF CMS (Central Monitoring Station) PROGRAM AS WELL.  Choose ‘OK’ to confirm the setting. Notification ...

  • Page 45: Audio

     If a check box is checked  on Covert column, a video is recorded but is not displayed on the monitor.  Click ( ) each frame on PTZ column to select PTZ protocols connected to a corresponding camera. ...

  • Page 46: Alarm Out

     The Alarm In menu will allow user to give title and to select the type of Alarm input.  Click ( ) the keyboard icon on the right-hand side of each frame on Title column and the virtual keyboard will appear. Then, please register the title of Alarm input.

  • Page 47: Record

    4.5 RECORD  Please click ( ) RECORD and the following screen will appear. 4.5.1 Setting A, B, C, D, E and F Type  Please click ( ) RECORD>Settings and the following screen will appear.  There are three kinds of recording mode. - Continuous: record continuously.
  • Page 48 NTSC(PAL) 360x240 (360x288) 720x240 (720x288) 720x480 (720x576) 4 Channel DVR 120 (100) 120 (100) 120 (100) 8 Channel DVR 240 (200) 240 (200) 120 (100) 16 Channel DVR 480 (400) 240 (200) 120 (100) F Type NTSC(PAL) 360x240 (360x288) 720x240 (720x288) 720x480 (720x576) 8 Channel DVR 240 (200)
  • Page 49 8 Channel DVR 240 (200) 240 (200) 240 (200) 16 Channel DVR 480 (400) 480 (400) 480 (400)  Click ( ) each frame on Quality column to select recording quality of a corresponding camera. User may select one of Super, High and Std.
  • Page 50  There are three kinds of recording mode. - Continuous: record continuously. - Event: record only when Sensor or Motion calls. - Emergency: record when press EMERGENCY key. Continuous  The Continuous menu will allow user to set recording mode. ...
  • Page 51 4 Channel DVR 120(100) 120(100) 120(100) 120(100) 120(100)  Click ( ) each frame on Quality column to select recording quality of a corresponding camera. User may select its recording quality from Super, High and Std.  Click ( ) each frame on Duration column to select recording duration (i.e., 1 second ~3 hours) of a corresponding camera. ...

  • Page 52: Schedule

    When the HD-SDI input changed manually, DVR will start restart to apply changed resolution. CAUTION ALTHOUGH USERS TURN ITS SYSTEM SETTING TO DEFAULT, THE ANALOG OUTPUT WILL STAY PREVIOUS OUTPUT METHOD AND NOT EFFECT BY THE DEFAULT SETTING. 4.5.2 Schedule ...

  • Page 53: Pre Alarm

    Motion / Continuous Motion / PreAlarm Motion / Alarm In Motion / Alarm In / Continuous Motion / Alarm In / PreAlarm  Choose ‘OK’ to confirm the setting. (NOTE) Holiday (H) registration is done with a separate menu. 4.5.3 Pre Alarm A, B, C, D, E and F Type ...

  • Page 54: Motion Detection

    16 Channel DVR 480 (400) 240 (200) 120 (100) F Type NTSC(PAL) 360x240 (360x288) 720x240 (720x288) 720x480 (720x576) 8 Channel DVR 240 (200) 240 (200) 240 (200) 16 Channel DVR 480 (400) 480 (400) 480 (400)  Click ( ) each frame on Quality column to select recording quality of a corresponding camera. User may select one of Super, High and Std.

  • Page 55: Holiday

     The Motion Detection menu will allow user to set Motion detection alarm.  Press SETUP key (or right mouse button) and the SETUP menu will appear.  SETUP menu descriptions. - Camera: select camera for setup. - Sensitivity: select sensitivity (Low, Normal and High) - Reverse Vert: activate the entire column at the cursor’s position.

  • Page 56: Alarm In

     The LINK menu will allow user to set recording modes of all kinds of alarms (Sensor, Motion Event, Video loss, System Event, etc.), alarm output, e-mail notification and the like. 4.6.1 Alarm In  Please click ( ) LINK>Alarm In and the following screen will appear. ...

  • Page 57: Video Loss

     Select cameras for recording while the motion sensor is in operation and alarm outputs and set up E-mail addresses for notification.  Link Notification displays E-mail addresses registered in DEVICES>Network>Notification.  Please follow the setup procedures below. ① Click ( ) Motion Event frame and select Motion Event 1. ②...

  • Page 58: System Event

    4.6.4 System Event  Please click ( ) LINK>System Event and the following screen will appear.  Select recording cameras and alarm outputs while Emergency recording using EMERGENCY key and set E-mail addresses for notification.  Link Notification displays E-mail addresses registered in DEVICES>Network>Notification. ...

  • Page 59: Operation Instruction

    5. OPERATION INSTRUCTION 5.1 Viewing 5.1.1 First Image  Power on DVR and the following live video will appear, while viewing and recording at the same time.  The screen will display date/time and icons below. Icon Description Continuous recording mode Event recording mode (Alarm In/Motion) In recording PTZ registration/PTZ mode...

  • Page 60: View Format

    5.1.2 View Format  The available view formats when the Main Monitor is in viewing mode include Full Screen, Split Screen, Channel Sequencing Screen and PIP screen. - Full Screen: Please press camera select key (1~16) to view the corresponding camera image in full view format. (NOTE) Using a mouse: Double click to view the corresponding camera image in full view format and click one more time to back to Split Screen.
  • Page 61  In Pan/Tilt mode, the icon is displayed on the bottom of the screen.  Following is the key usage found in Pan/Tilt mode. Function ▲, ▼, Up/Down/Left/Right rotation Zoom out Zoom in Focus near Focus far Iris Close Iris Open Save Preset Go to the Preset Go to OSD main menu...

  • Page 62: System Log

    items. - Since these functions make use of a memory function of the camera itself, user should set them in Camera OSD. - Once user completes the setup, close the Camera OSD menu. - User can conveniently use Tour and Pattern functions simply by clicking Tour and Pattern buttons. - Particulars on how to setup each function on OSD Menu are found in the manual of a corresponding camera.

  • Page 63: Date / Time Search

     There are three ways to search video, i.e., by date/time and by calendar. - Date/Time Search: search by inputting date/time. - Calendar Search: search by using calendar. - Event Search: search by event. 5.2.1 Date / Time Search  Please click ( ) Date/Time Search in SEARCH menu and the following input box will appear. ...

  • Page 64: Event Search

    ③ Click ( ) the box on the time indication bar to select the search time. The selected time zone will be focused in different color. ④ Click ( ) the selected time box to show pop-up window on the screen, If there is a recorded data. ⑤...
  • Page 65  There are three ways to search video, i.e., by date/time and by calendar. - Date/Time Search: search by inputting date/time. - Calendar Search: search by using calendar. - Event Search: search by event.  There are three other functions in playback mode; - Archive: The Archive function will allow user to copy the recorded video (moving images and still images) from a storage device (USB memory stick, DVD-RW).

  • Page 66: One-Touch Playback

    Go to End • Go to end of recorded data  Press SEARCH key to stop playing back video. 5.4 One-touch Playback  Press the PLAY/PAUSE key or double click the mouse wheel (central button) in the viewing mode. Then, user will be able to view the wanted recorded video right away without going through the search procedure.

  • Page 67: Menu Bar

    Archive Fail message will pop up. In this case, user must try again. (NOTE) PLEASE DO NOT USE JPEG FORMAT SELECTING WHILE ARCHIVING IN LIVE MODE. (NOTE) PLEASE DO NOT CHANGE THE SETTINGS BY DVR OR CMS, WHILE BACKUP. (NOTE) WHEN THE TARGET FILE SIZE IS OVER 2GB, PRESS “...

  • Page 68: Color Control And Position

    mode. : Displayed channel on Spot monitor 2 can be changed by clicking the wanted channel. Sequence stops at “SP2” mode. : Displayed channel on Spot monitor 3 can be changed by clicking the wanted channel. Sequence stops at “SP3” mode.
  • Page 69 (NOTE) THIS FUNCTION IS ENABLED ONLY WHEN LIVE MODE AND 4 SPLIT SCREEN MODE OR HIGHER. (NOTE) ONLY 4 ALARM CONTROLS ARE AVAILABLE FOR TYPE B,D AND G.  Please click ( ) Color / Alarm in SEARCH popup menu or in front panel and the following input box will appear. ...
  • Page 70 Intuitive CMS (Central Monitoring Station) User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 71: Program Installations

    6. PROGRAM INSTALLATIONS 6.1 System Recommendations  Power on DVR and the following live video will appear, while viewing and recording at the same time. - Processor: Intel Pentium(R) (at 2.8GHz or higher) - Memory: 1.00GB or more - Video: 128 MB AGP VGA card, 1024 x 768 Resolution, 32-bit Color, DirectX® 8.1 version or later - HDD Space: 500 MB of space - Monitor: SVGA or XGA, 1024 x 768 Resolution, 32-bit Color - OS: Windows®...

  • Page 72: Login

    ⑥ When the following screen appears, select folder and click Next. ⑦ When the following screen appears, click Install. ⑧ When the following screen appears, click Finish to complete the installation. 6.3 Login  After install CMS software, CMS icon below appears on desktop. ...

  • Page 73: Function And Instructions

    7. FUNCTION AND INSTRUCTIONS  Below lists are functions of the program. ICON ICON NAME WATCH MODE SEARCH MODE REMARKS System Log DVR System Log PTZ Control DVR PTZ Control System Health Check DVR System Health Check DVR Data Playback DVR Data Playback CMS(PC) Data Playback CMS(PC) Data Playback...

  • Page 74: Watch Mode

    8. WATCH MODE 8.1 LOGIN Screen  When user login CMS, the following screen will appear. This screen is of Watch mode.  Because it is not connected to DVR, images do not show.  Please do Local Setting first before connecting to DVR. 8.2 Local Setting ...

  • Page 75: Remote Site

     Save Option: allow user to select Drive(C, D) and folder to save data.  Choose ‘OK’ to confirm the setting. 8.2.2 Remote Site  This menu is for Network setup.  Make CMS IP address and Port coincide with DVR. ...
  • Page 76 - Click “Scan DVR” button then IP address of DVR will be listed which is currently connected with PC in the network. - Select the IP address and click “Add site” then the connected DVR is automatically registered in the CMS. ...

  • Page 77: Live Video

    8.3 Live Video 8.3.1 Network Connection  As the setup is completed, user should connect CMS to DVR over Network. Please click in REMOTE DVR on the screen.   It will turn to blue, while being activated.  Please click REMOTE CONNECT button. ...

  • Page 78: Watch Mode

    Tool Bar Watch Mode Date/Time LED Site Tree (DVR and Channels) Color Control Bar Instant Record Button System Log Alarm Out Channels Audio Channels Two way Audio Video Display Screen Network Connect/Disconnect Button/Exit CMS 8.3.2 Watch Mode  The first image (or the initial image) shows the available maximum split screen format, but user is able to select a watch mode among below modes.

  • Page 79: Multi Screen

    (scaled to fit the screen). To cancel, please press the right mouse button.  E Map: load and close E Map image program.  Mouse Double Click: If user does double click of the mouse on a split screen, it will turn to full screen mode. Double click the mouse to back to the previous watch mode.

  • Page 80: Alarm Out

    8.3.7 Alarm Out  This is for operating Alarm Out of a selected DVR from a remote distance.  Click a channel number and Alarm Out of the corresponding channel will operate.  If user sees an intruder, use this function to turn on a siren in an area where the DVR is installed. 8.3.8 One touch Recording ...

  • Page 81: Health Check

    Zoom In / Zoom Out Focus Far / Focus Near Iris Open / Iris Close Preset Control / Go to Preset ③ Preset Control button The completed Preset  Click on Preset Control button and the following screen will appear. Please input Title and Preset Number. ...

  • Page 82: Camera Connections And Operating Status

    CMS connections (up to 4) Camera connections and operating status HDD connection and its operating status Recording status Motion recording status Alarm In connection and operating status Alarm Out connection and operating status Version Recording start/end date and time 8.5.1 Camera connections and Operating Status Camera is in normal operation.

  • Page 83: Alarm Out Connection And Operating Status

     Above the maximum number of cameras allowed. 8.5.6 Alarm Out Connection and Operating Status  Camera is in normal operation.  Recording is stopped.  Above the maximum number of cameras allowed. 8.6 Remote Setting  User may change DVR’s Menu setup through CMS. ...

  • Page 84: Search Mode

    9. SEARCH MODE 9.1 Search Screen  This menu is for playing back recorded data.  Click on REMOTE SEARCH button in Watch mode and the following Screen mode screen will appear.  Search mode provides three search functions. One is for searching DVR video by clicking REMOTE SEARCH button and another is for searching video stored in CMS (HDD of PC) by clicking LOCAL SEARCH button and the other is for searching event recorded data stored in DVR by clicking REMOTE EVENT button.

  • Page 85: Remote Search

    9.2 Remote Search  The REMOTE SEARCH button allows user to playback recorded video of DVR.  Select Date - In Calendar, dates with recorded data are marked in red. - Click the wanted date among the dates marked in red. In background of Time Select Bar, data recorded time is displayed in bar shape.

  • Page 86: Event Search

    9.4 Event Search  The REMOTE SEARCH button allows user to search event recorded data of DVR. ① Designate Event Search start time. ② Designate Event Search end time. ③ Select camera (video) to search data. ④ Check a check box (Motion/Alarm In/Emergency/Serial in) Check box. ⑤...

  • Page 87: Print

    9.5.2 Print  This is for printing a selected image (within the red outline). Click IMAGE PRINT button and the following screen will appear.   Choose ‘OK’ to confirm the setting. Then, the printing proceeds. 9.5.3 Save  This is for saving still image(s) in Bitmap or JPEG file. ...

  • Page 88: Archive

    9.5.4 Archive  This is to back up the DVR’s moving image data to EXE file in PC(CMS).  Work only in playback mode.  Press STOP button first to make sure the playback is stopped and then press ARCHIEVE button. ...

  • Page 89: Others

    10. Others 10.1 Viewer  The Format of archive file is .exe(executable file).  Please double click on the icon to execute the program. PLAY • Playback mode: 1X PLAY • Playback mode: PAUSE PAUSE • Frame-by-frame backward still image BACKWARD playback •...
  • Page 90  Please click on the icon to load the image file.  To create an icon, please select the icon you want and click it at a desired position on the map. Please click on the icon to move created on the map.

  • Page 91: Watermark Check System

    10.3 Watermark Check System  Mouse double click WCS.exe program in the CMS program folder (Default: C:\Program Files\CMS\WCS.exe).  To open the check .exe or .jpg or .bmp file just click Load File button.  To click the check button, user will get following message; - Result: - Verification OK ! - Corrupted or Modified...

  • Page 92: Exe To Avi Converter

    10.5 EXE to AVI Converter  Users are able to convert Archived file(EXE format) to AVI format.  Users will be required a converting codec between “ Microsoft MPEG-4 codec” and “XVID MPEG-4 codec” or able to use both.  Both are able to download freely in many web-sites. ...

  • Page 93: Cms Web Client

    CMS Web Client CMS Web Client User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 94: Setup And Login

    11. CMS WEB CLIENT 11.1 Setup and Login  MS Explorer web browser is required for installation and using this program.  Open a browser and type the IP address of DVR.  It is required to install ActiveX in the first connection. ...

  • Page 95: Live Display

    11.2 Live Display  After Login, following screen will appear. ① ④ ③ ② ⑤  The screen contains following features: ① Display current live video ② Setting display mode - Playback : Transferring search mode. - Freeze : Pause current display. - Resume : Resume paused display.

  • Page 96: Playback Screen

    11.3 Playback Screen  Click [Playback] then following screen will appear. ① ⑤ ③ ④ ⑥ ②  The screen contains following features: ① Searched playback video displays. ② Transferring Live mode. ③ Setting Date/Time to search. - Click a date in calendar, then recorded data will be showed up in Time bar. - Start Time : Setting start time.
  • Page 97 CMS Mobile Viewer CMS Mobile Viewer User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 98: Cms Mobile Viewer

    12. CMS MOBILE VIEWER 12.1 iPhone Mobile 12.1.1 System Requirements  There are no other requirements to run this program because it is specialized to perform on iPhone interface. 12.1.2 Installation  Turn on the iPhone then connect to App Store. ...
  • Page 99  Select “ ” program which is offered from dvrdomain by free.  When user clicks a “ ” button, it will be turned to “ ”  Click “ ” to start installation.  If user already has a iTunes account, then input user’s account to download the program. ...

  • Page 100: Site Registration

     When user registered the account, the program will be automatically installed. 12.1.3 Site Registration  Click “ ” icon on iPhone menu then below will show.  Move to “ ” and enter site information which are same as CMS site registration. ...

  • Page 101: Connection

     Enter ID/Password.  Click “ ” to save the setting. 12.1.4 Connection  On “ ” window, click one of the registered site and click “ ”.  To Select other channels, click the channel bar below the Site Name. ...

  • Page 102: Disconnection

     Touch and drag upside on the center of the screen to zoom out.  Touch and drag downside on the center of the screen to zoom in.  Touch sides and corners of the screen to change the direction as user want. ...

  • Page 103: Uninstall

    12.1.7 Uninstall  Click the “ ” icon and hold for a while until the program icon shows x mark on the top-left side.  Click the “ ” icon then it will ask to delete the program.  Click “ ”...

  • Page 104: Android Phone

    12.2 Android Phone 12.2.1 System Requirements  This Program is designed and applied only for Android OS based Smart phones. 12.2.2 Installation  Turn on the phone then connect to Android Market.  Move to search menu and type “mviewer” then select “ ”...

  • Page 105: Site Registration

     Click “ ” then “ ” to start installation.  The program will be automatically installed in user’s application menu. 12.2.3 Site Registration  Click “ ” icon on application menu then below will show.  Move to “ ”...

  • Page 106: Connection

     Enter Admin/Stream port value.  Enter ID/Password.  Click “ ” to save the setting. 12.2.4 Connection  Click “ ” icon and select one of the registered site and click “ ”.  Move to “ ” tab and click “ ”...

  • Page 107: Disconnection

     Touch sides and corners of the screen to change the direction as user want.  Touch right side of the screen to move right and left side to move left.  Touch up side of the screen to move up and down side to move down. ...

  • Page 108: Blackberry Mobile

     Click “ ” icon then it will ask to delete the program.  Click “ ” button to successfully uninstall the program. 12.3 Blackberry Mobile 12.3.1 System Requirements  This Program is designed and applied only for RIM Blackberry OS based Smart Phones. 12.3.2 Installation ...

  • Page 109: Site Registration

     Select the “DVR viewer” which is offered from dvrdomain by free and start to install the program by clicking the icon. 12.3.3 Site Registration  After downloading the program, click “ ” icon in the download folder or applications folder and the following screen will be shown.

  • Page 110: Ptz Control

     Click “Menu>Connect” to connect the site.  If users want to change the channels, click “Menu” to select another camera. 12.3.5 PTZ Control  Users are able to control PTZ by blackberry phone.  Press volume up button on the right side of the phone to zoom in. ...

  • Page 111: Disconnection

    (NOTE) Touch type Blackberry phone (Ex. Storm) user may control PTZ as the same way as Android Phone. 12.3.6 Disconnection  When disconnecting, please click "Disconnect” and exit the mobile viewer program. 12.3.7 Uninstall  Click “Menu>Delete” on the “DVR Viewer” icon in the download folder to uninstall the program. 12.4 Windows Mobile 12.4.1 System Requirements ...
  • Page 112  Click “Next” button.  Click accepting the license agreement, then click “Finish” button.  Installation box will appear.  Click [OK] to start installation.  When installation completed, following pop-up will appear.  Click [OK].  If following message appeared, it has successfully installed.

  • Page 113: Site Configuration

    (NOTE) Depending on mobile device, successful installation message may not appear. Click [OK] when license agreement message appear.  Move to [Programs] page to check whether CMS has installed. 12.4.3 Site Configuration  Click [Add] to appear following screen.

  • Page 114: Connection

     Fill in correct information. - Site Name : Insert the name of site. - IP/Domain : Insert the IP address or Domain name of the site. - ID : Input the registered ID of the site. - Password : Input the password of the registered ID. - Command Port : Insert Command Port of the site.

  • Page 115: Uninstall

     Live display screen of the site will appear if it is successfully connected.  Users are able to select a camera by clicking camera button.  Click [Disconnect] then, live display screen will be closed and Site list box will appear. 12.4.5 Uninstall ...

  • Page 116: Keyboard Controller

    Keyboard Controller Keyboard Controller CP1200A User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 117: Keyboard Controller

    13. KEYBOARD CONTROLLER 13.1 Connection  User may connect cameras and Keyboard through DVR in various ways.  Below shows the major probable connection methods through RS-485; 13.1.1 Configuration Diagram I  Single system configuration (1 Camera, 1 DVR) DVR PTZ Port RS485 RS485 Tx1+...

  • Page 118: Configuration Diagram Iii

    13.1.3 Configuration Diagram III  Multiple system configuration (Multi Cameras, Multi DVRs) Max 16 camera RS485 RS485 RS485 RS485 … … … … Multi port Max 16 DVR DVR 1 DVR 2 … … Multi port  Please make sure to connect “Tx to Rx “or “Rx to Tx” with positive polarity. (+ to +) and (- to -). 13.2 Keyboard Setup in DVR ...

  • Page 119: Keyboard Configuration

    13.3 Keyboard Configuration 13.4 Operation 13.4.1 DVR/PTZ Mode conversion  Press System ID number (For example, ID: 001 press Num Pad ) with button.  OSD will show “KBD:1” in right-bottom side that the keyboard is on DVR mode as below picture; ...

  • Page 120: Ptz Control Mode

    the PIP channel. In case of 4 or 9 channel screen, it changes the screen to a next one in the sequence. - FREEZ: freeze a current image. - SETUP: pop up Setup window. - PLAY/PAUSE: play/pause recorded data in play mode. - SEARCH: pop up Search window, or switches play mode to search mode.
  • Page 121 Serial In (POS / ATM) Serial In (POS / ATM) User`s Manual This document contains preliminary information and is subject to change without notice.

  • Page 122: Serial In (Pos/Atm)

    14. SERIAL IN (POS/ATM) 14.1 Usage of Serial-In Function  Enables to record/search/display all transactions on monitoring screen by connecting POS/ATM/Cash Register.  User can choose the data whether to record/display on their taste without limitedly designated protocols. 14.2 Connection Method ...

  • Page 123: Link

     F Type Using RS-232: Connect RS-232 port to USB port at front/rear of DVR by using a converter. 14.4 Link 14.4.1 Link Setup  Click “Setup>Link>” then shows as below. (NOTE) The above menu is only available on the DVR model with Serial-In function. ...

  • Page 124: Schedule Setup

     Select POS/ATM port by clicking ‘Serial In’ button.  Assign the port to display/record channel by clicking a “Link Camera”.  Select “Link Alarm Out” item to run alarm output when the serial in events occur.  Designate the E-Mail address or IP/Domain name at “Link Notification” box when the serial in events occur. (NOTE) E-Mail address or IP/Domain configuration is possible to set in ‘Setup>Network>Notification’...

  • Page 125: Title

    (NOTE) This [Serial In] section does not show without additional Serial-in option. 14.5.1 Title  Click “Title” item then virtual keyboard will appear.  Input the title then click ( ) to save. 14.5.2 Port Setting  Press ( ) the “Port Setting” button in order to set up the port. Default values are Baud rate 2400 bps, Data Bit 5 bit, Stop Bit 1 bit, Parity None.

  • Page 126: Pattern Setting

    - Both: displays all the information on both Live and Playback mode. 14.5.4 Pattern Setting  User can select the name of serial device if click ( ) the keyboard button of Title.  When “Use” items of Numbers 1-4 are checked on Serial-In page, it receives the data from the applicable serial device. ...
  • Page 127  Input a certain repeated string to “Line Delimiter”.  Decide the number of minimum characters in “MCPL” item to hide data under the designated number of characters.  Input the pattern of dummy data to Discard Pattern.  Choose the data which willing to display and enter the Start Pattern and End Pattern.

  • Page 128: Search

     Then tick the Auto box off in order to make the DVR recognizes the data between the Start and End patterns.  Finally, test again and adjust data to remove missed dummy data. 14.6 Search  Using event search function. ...

Table of Contents
