Gro Clock User Manual

Your Gro–clock is fully compliant with the following EU legislation:
Technical Information
The EuP Regulation EC 278/2009 on external power supplies
● ●
Height: 14.5cm
● ●
The Low Voltage Directive: 2006/95/EC
● ●
Weight: 393g
● ●
The EMC Directive: 2004/108/EEC
● ●
Mains Supply Voltage: 230V, 50Hz.
● ●
The RoHS Directive: 2002/95/EC
● ●
Power Unit: 6V at 200mA.
● ●
Further information printed on rear and base of clock
● ●
When the time comes to dispose of this equipment, please help protect our environment by means of
proper disposal. Your local authorities will have special return and disposal facilities available for you.
Patent pending UK, USA and worldwide PCT patents and Design rights applied for.
Manufactured and distributed worldwide by:
The Gro Company, Linhay Business Park, Ashburton, Devon TQ13 7UP , UK
UK Tel: +44 (0)844 557 2960 www.gro.co.uk
gro–group international ltd trading as The Gro Company.
The Gro Company is a trademark of gro–group holdings ltd.
All text and images © 2010 gro–group holdings ltd.
The Gro Company reserve the right to amend the product specification at any time.
IMPORTANT! KEEP FOR FUTURE REFERENCE
GCM EN 004.indd 1
Frequently asked questions
Q. If the power is turned off, does the clock remember the correct time?
A. When the power goes off, the clock 'freezes' all the settings, including the main time, the wake up times
and brightness settings. Therefore if the power goes off for a few seconds and then back on, the time
will have been paused for a few seconds. However if the power was off say for 3 hours, then the time
will be out by 3 hours and will therefore need re–setting.
Q. If I need to keep the power on to maintain the correct time, should I worry about
electricity consumption?
A. No, your clock uses LEDs so it's naturally energy efficient. However it also has a built–in energy saving
mode. One hour after the wake up time has activated, the clock automatically turns off coloured LED
lights and runs on a tiny amount of electricity. To re–activate just press any key and the colour LEDs will
come back.
Q. What is the difference between the night–time and day–time nap mode?
A. In a way they are very similar because the clock works in exactly the same way in both modes. Once
activated, the clock will count down and the star will change into the sun at the time set in each
mode. The reason there are two modes is so that parents who are putting their children to sleep during
the day and at night can have the two different times stored, which saves them from having to re–set
the wake up times every session.
Q. Can I make the alarm sound at any time and in any mode?
A. Yes! The time you set for the alarm is independent of the night–time or day–time nap modes. Therefore
you could have the sun coming up silently at 7am and then the alarm sounding at 7.30am.
Q. How do I know if the alarm will sound?
A. The alarm bell icon appears in the cheek of the sun/star when the alarm is switched on.
Q. How can I stop my child from playing with buttons and changing the settings?
All rights reserved.
A. Very easily, by using the key–lock function, which is similar to the function on mobile phones. (See page 5).
GCM EN 004
6
Q. Is there a demo mode so I can show my child how it changes from the sun to Mr Star?
A. Yes! There is a built–in demo mode which runs through all the sun and Mr Star transitions. To set the
Demo mode on, just press and hold the UP button for three seconds and the clock will show all the
transitions on a continuous loop. To turn off the Demo mode, simply press and hold the UP button for
three seconds.
Q. My screen has frozen and is not responding to the controls.
A. Switch the clock off at the mains, wait a few seconds and switch back on.
If you have any other questions, please call our customer services helpline on 0844 557 2983.
Safety
Your clock is a safe low voltage device, powered from a small mains operated power unit. For your
continued safety and the reliability of your clock, please observe the normal electrical safety precautions:
● This product is not a toy. Please ensure that it is kept out of reach of children and never allow your child
to play with either the power unit or the connecting lead
● Keep the product away from water and moisture. It's intended for indoor use only
● Repairs should be carried–out only by a competent engineer. There are no customer adjustments or
fuses inside the clock case
● The clock has been designed to be robust, but it may be broken if dropped
● The connecting lead is low voltage only, but for reliability reasons it should be treated with care
● To completely disconnect the power unit, the AC/DC adapter must be unplugged from the mains
● Access to the AC/DC adapter should not be obstructed whilst in use
● Electro–static discharge may affect the working of your Gro–clock. If this occurs, simply switch the unit
off for several seconds and the unit will re–set
● The apparatus and AC/DC adaptor shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on apparatus and AC/DC adaptor
● For use only with the power supply KB1B–060–0200D, manufactured by KS
IMPORTANT! KEEP FOR FUTURE REFERENCE
●
7
How to use your
