Tomey UD-600 Operator's Manual

Ultrasound a/b scanner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Read this Operator Manual throughout prior to using this instrument for your correct
and safe operation.
If you come up any unclear things while in your operation, please ask Tomey or your
local representative.
• Do not use this instrument in an operation procedure other than specified
in this Manual.
• Keep this Manual in a place to where you can easily access.
• Should this Manual be lost, ask your representative for a new copy.
OPERATOR MANUAL
Ultrasound A/B Scanner
UD-6000
767A9090-20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UD-600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tomey UD-600

  • Page 1 Read this Operator Manual throughout prior to using this instrument for your correct and safe operation. If you come up any unclear things while in your operation, please ask Tomey or your local representative. • Do not use this instrument in an operation procedure other than specified in this Manual.

  • Page 3: Important Precautions

    Some of the output terminals are not insulated from inner circuits. Cer- tain connections to the output terminals may break the inner circuits. Be sure to contact TOMEY CORPORATION or our Local distributor when the output terminals are used. IMPORTANT PRECAUTIONS...
  • Page 4 Do not dirty or hurt the caution marks indicated on the instrument. There are one on the front and six on the back. In case the caution marks get broken and unclear, contact the place of purchase or TOMEY CORPORATION. IMPORTANT PRECAUTIONS...

  • Page 5: Guideline For This Operator Manual

    GUIDELINE FOR THIS OPERATOR MANUAL Components of this Manual This Manual is composed of the following. 1. PRIOR TO USE Precautions and confirmations for the installation and usage of this instrument 2. NAMES AND FUNCTIONS OF THE PARTS AND COMPO- NENTS Names and functions of parts and components 3.

  • Page 6: Symbols Used In This Manual

    SYMBOLS USED IN THIS MANUAL The symbols used in this Manual represent the following meanings. Extremely high risk of serous injury or death unless the instruction is observed. Possibility of serious injury or death unless the instruc- tion is observed. Possibility of minor injury, intermediate handicap or physi- cal loss or damage unless the instruction is observed.

  • Page 7: Table Of Contents

    CONTENTS IMPORTANT PRECAUTIONS ....................I GUIDELINE FOR THIS OPERATOR MANUAL ............... III Components of this Manual ........................iii SYMBOLS USED IN THIS MANUAL......................iv CONTENTS .............................. v PRIOR TO USE ......................1-1 Operating precautions ........................1-1 Confirmation of accessories ......................1-4 Explanation of the symbol marks ....................

  • Page 8: Contents

    Inputting of Index data ....................3-20 a) Inputting of patient ID number, patient's name, gender, and physician's name ..3-20 b) Inquiry for patient information (TOMEY Link) ............3-21 c) Setting of the eye to be observed ................3-23 d) Display of the probe applying angle ................3-23 3.3.5...
  • Page 9 c) Focus regions setting ....................3-55 d) Scope ........................3-56 e) Smoothing .........................3-56 f) Presetting of each gain and contrast ................3-57 Assistant function of Biometry ....................... 3-59 3.4.1 Changing to the biometry assistant (sub-) function ............3-60 3.4.2 Screen display information ..................3-61 a) Diagnosis display .....................3-61 b) Main menu at freeze ....................3-62 c) Main menu at real time .....................
  • Page 10 b) ON/OFF and movement of the line cursor ...............3-77 c) Probe applying position and ultrasound beam direction display ......3-78 d) Data saving .......................3-79 e) Stored Image Display ....................3-80 f) Transfer of patient data ..................... 3-84 3.5.8 Various functions at real time ..................3-85 a) Amp.
  • Page 11 a) Deletion of measurement data for both eyes (measurement preparation for a new pa- tient) ........................3-111 b) Deletion of measurement data for single eye (re-measurement preparation for the same patient) ........................3-112 IOL power calculation ......................... 3-113 3.7.1 Screen display information ..................3-113 a) Entering of calculation data and display of calculation results .......
  • Page 12 a) Registration of physician's names ................3-140 b) Setting of date and time (Time and Date) ............... 3-141 c) Setting of sound volume ..................3-142 d) Environment setting when turning the power on (Start settings) ......3-142 e) Selecting of language ..................... 3-143 f) Setting of data communication ................
  • Page 13 4.4.4 Pseudophakic (1 to 3) ....................4-15 Software version information ......................4-16 INSPECTION AND MAINTENANCE ................5-1 Warranty ............................5-1 How to replace the fuse ......................... 5-2 Routine maintenance ........................5-2 5.3.1 Maintenance of the probe ..................... 5-2 a) Checking of the outer appearance of the probe ............5-2 b) Cleaning ........................
  • Page 14 This page is intentionally blank.

  • Page 15: Prior To Use

    1. PRIOR TO USE Be sure to read this Operator Manual throughout before using this instrument for your correct and safe opera- tion. Do not use this instrument in any procedure other than specified in this Operator Manual. Make sure that there is no equipment in the surrounding of this instrument that generates an intensive magnetic field or such adverse influence that may cause noises, possibly making the instrument unable to correctly di-...
  • Page 16 - Be sure to connect the power plug to the outlet with a ground cable for three-prong plug. In case of leakage due to failure, an electric shock may result. - Do not put any heavy stuff on or pinch the power cable, or a fire may result.
  • Page 17 - When smoke, odor or abnormal noise comes out of the instrument, turn off the power immediately, pull out the power plug from the outle and contact the place of purchase or TOMEY CORPORATION. Do not let the patient touch the instrument.

  • Page 18: Confirmation Of Accessories

    1.2 Confirmation of accessories After unpacking the shipment, make sure that the following parts and components are delivered without being damaged. Should any of the following items be found missing or damaged, ask your local representative or distributer. The packaging containers and cushion materials should not be disposed but maintained, since they may be nec- essary when moving or transporting the instrument.

  • Page 19: Explanation Of The Symbol Marks

    1.3 Explanation of the symbol marks The symbol marks attached to the instrument imply the following mean- ings. : Brightness adjusting volume [MEMORY CARD] : Memory card slot [ | ] : ON side of the power source switch : OFF side of the power source switch [FOOT SWITCH] : Footswitch terminal [FIX LIGHT]...

  • Page 20: Outline Of The Operation

    1.4 Outline of the operation This model of UD-6000 is designed an ophthalmic diagnosis instrument, which provides the function acquires the ultrasound cross-sectional image of an eye with the ultrasound oscillators enclosed in the probe, that which acquires the A-scan wave shape, and that which measures the axial length. It is noted that the instrument is in suspension of ultrasound wave transmission.

  • Page 21: Biometry Function

    1.4.4 Biometry function The probe connected to this instrument transmits ultrasound waves into the internal part of the eyeball, while the ultrasound echo reflected from its anatomy will be received by the same probe. The instrument measures the time from the echo for corneal epithelium to that for the object to be measured, with which the length of the tissues is calculated by applying the sound velocity for conversion as set.
  • Page 22 This page is intentionally blank.

  • Page 23: Names And Functions Of Parts And Components

    2. NAMES AND FUNCTIONS OF PARTS AND COMPONENTS 2.1 Front and right side views and probes A Monitor/Touch Panel Display Ultrasound images, waveforms, and various data are displayed and used for operation. B Probe Holder The probe is kept in this holder. C B-scan probe terminal The B-scan probe is connected.
  • Page 24 F TOTAL · NEAR volume G CONTRAST · FAR volume H Volume function select button 1 I Volume function select button 2 J Total gain indicator K Contrast indicator L Near gain indicator M Far gain indicator <How to adjust gain contrast> The two adjusting volumes F, G have their respective type of function, which are selected with the volume function select buttons, 1 H and 2 I.

  • Page 25: Memory Card

    A/B indicator Lights while in process of the image diagnosis function as being set. Bio-indicator Lights while in process of the biometry function as being set. Built-in printer Biometry probe Used for biometry measurement. Memory card 2.1 Front and right side views and probes...

  • Page 26: Back And Left Side Views

    2.2 Back and left side views A Video output terminal (VIDEO OUT) The video signal cable is connected. B Video printer mode terminal (REMOTE) The remote cable of the Video Printer is connected. C Chin rest (AL-1100) fixation lamp power source plug terminal (FIX LIGHT) The power source cord for AL-1100 is connected.
  • Page 27 E Power terminal The 3P plug power source cord should be connected. F Fuse Holder Fuses are inserted. G Power switch The power can be turned ON/OFF. H 3P plug power source cord This cord should be connected to AC 3P power source receptacle. I Video output color/mono-chrome select switch (PRINTER M/C) The video output signal is selected for color or monochrome.
  • Page 28 This page is intentionally blank.

  • Page 29: Operation Procedure

    3. OPERATION PROCEDURE 3.1 Safety precautions The biometry probe and the A-scan probe must be sterilized before they are used. Do not use the biometry probe and the A-scan probe, if their eye contacting part is damaged, which may otherwise not only affect accurate diagnosis, but may also harm the cornea and the eyelids.

  • Page 30: Preparation Before Operation

    3.2 Preparation before operation 3.2.1 How to connect the accessories a) B-scan probe The inserting direction of the connector for the B-scan probe is specified. Insert the probe securely by aligning the inserting direction of its connector A A A A A to the direction of the terminal for B-scan probe connectorB B B B B .

  • Page 31: D) Footswitch

    c) Power cord The insertion direction of the connector for power source cord is specified. Securely insert the cord in specified di- rection. Insert the connector A for power source cord into the terminal B provided for power source cord in specified direction, by connecting all the 3 pins C.

  • Page 32: E) Probe Cable Guide

    e) Probe cable guide The cable guide, if used, helps prevent the probe from being damaged when accidentally falling down. (Fig. 1) 1) Two screw bolt A openings are provided at the bottom of the right side of the main body of the instrument to securely fix the block B with these two bolts.

  • Page 33: F) How To Insert And Remove The Memory Card

    (Fig. 3) 3) Connect the B-mode probe to the instrument and install the cable by turning along the spiral part F of the cable guide. (Fig. 3) f) How to insert and remove the Memory Card Since the memory card is ejected out when removed, press the removing button by holding the end of the card.
  • Page 34 How to insert the memory card Insert the memory card into the slot C located in the rear side of the instrument by turning the face side of the card to your side, until the card ejection button D rises to the same level as the card.

  • Page 35: How To Connect The Option Parts

    3.2.2 How to connect the option parts a) A-scan probe The connector must be securely inserted in specified po- sition. Insert the connector in specified direction into the position until a click sound is made. Make sure that the color of the label applied to the A-scan probe cable is blue.
  • Page 36 The direction of the connector for video printer is speci- fied. Sufficiently insert the connector in specified direc- tion, without causing any looseness. And be sure to use specified printer and the cable. This instrument must be connected to the equipment comply- ing with the IEC60601-1 or with the IEC60950-1 of which power source shall be isolated with the isolating trans- former, with the use of the video signal cable and the re-...
  • Page 37 c) How to connect to the external connection ID inputting device (barcode reader, etc.) The insertion direction of the connector is specified. Align the connector to the inserting direction and insert it securely. Insert the connector A of the external connection ID inputting device (barcode reader, etc.) to the P/S2 connection terminal B provided at the back side of the main unit.

  • Page 38: How To Connect The Instrument To The Chin Rest Al-1100

    3.2.3 How to connect the instrument to the Chin Rest AL-1100 For biometry measurement using the Chin Rest AL-1100, con- nect the supplied Chin Rest AL-1100 (option device) in the fol- lowing procedure. a) How to connect the biometry probe Make sure that the slider part moves smoothly.

  • Page 39: How To Install The Biometry Probe To The Applanation Tonometer

    3.2.4 How to install the biometry probe to the applanation tonometer In case of performing biometry measurement with the applanation tonom- eter, use the attachment for applanation tonometer. 1) Hold the prism mounted part A of the applanation tonom- eter with your fingers tightly so that it is not moved. 2) Insert the attachment for applanation tonometer B into the prism mounted part from the side of patient.

  • Page 40: Connection For Data Communication

    "TIMEY Link" (optional) or test data receiving software "DATA Transfer" (an accessory) is needed. See each of operator manuals of TOMEY Link and DATA Transfer for their setting and operation. In order to connect to TOMEY Link and DATA Transfer, connection setting should be done.

  • Page 41: B) Connection To Lan

    b) Connection to LAN LAN cable has a direction to be connected. Be sure to connect in the correct direction. The connector A of LAN cable is inserted to the LAN terminal B on the back of the instrument in the correct direction. LINK lamp C turns on when physical LAN connection is com- pleted at the power on.

  • Page 42: B-Scan Diagnosis

    3.3 B-scan diagnosis 3.3.1 Turing power on and adjustments a) Turning power on and adjustments When restarting the instrument, turn the power off and after a few minutes, turn the power ON again. 1) First, turn the power switch A provided on the left side of the instrument, by which its main unit and the B-probe are adjusted automatically.

  • Page 43: B) Changing The Mode To The B-Mode Function

    Sufficient care should be taken not to pinch your fingers when adjusting the angle of the monitor display. Adjust the monitor to such an angle that the display can be watched in the front forward from the examiner. Since the LCD has a narrow visible angle range, the core of the screen may be reversed when watching it from other di- rections.

  • Page 44: C) Information Displayed In The Starting Screen

    c) Information displayed in the starting screen (Fig. 1) 1) The start screen is displayed immediately after the power has been turned on, which will be followed by calibration of the B- probe. (Fig. 1) (Fig. 2) 2) If the B-probe is properly calibrated, the diagnosis screen (the initial screen) will be displayed.

  • Page 45: Display Information

    3.3.2 Display information a) Diagnosis images Conversion sound velocity The conversion sound Index velocity is displayed. ID number, name, gender of the Patient and name of the Physician, probe applying angle, and date are displayed. Memory number of image The memory number of the image(s) is displayed.

  • Page 46: B) Main Menu At Freeze

    Operates Motion Pictures Playback NEW Patient function. Deletes all patient information and measurement data and prepares for measurement for the new patient. EXPORT TOMEY Link Utility The EXPORT Check The Utility Screen is Screen is displayed. displayed. 3-18 3.3 B-scan diagnosis...
  • Page 47 c) Main menu at Scanning Focus Region Frame Rate Select Focus Regions. Changes the frame rate between 11 and 22 seconds. Default Settings Three settings of Total Gain, Contrast, Near Gain, and Far Gain values are preset. Scope Changes the range of image display.

  • Page 48: Deletion Of All Measurement Data (Measuring Preparation For A New Patient)

    3.3.3 Deletion of all measurement data (Measuring preparation for a new patient) Sufficient check must be given before deleting measure- ment data, since the data if once deleted, will not be re- stored. Be sure to press the NEW Patient key before a new patient is examined and delete all the measurement data.

  • Page 49: Inputting Of Index Data

    3.3.4 Inputting of Index data Various index data can be inputted only at freeze. In case of reading patient's ID by using an external connection ID inputting device (such as barcode reader, etc.), see "3.3.5 Inputting index data from external con- nection ID inputting devices (such as barcode reader, etc.)".

  • Page 50: B) Inquiry For Patient Information (Tomey Link)

    Link is required. See "3.8.2 f) Setting of data communica- tions". (Fig. 1) 1) Pressing of the Inquiry key after the ID number has been inputted starts inquiring to the TOMEY Link and next the screen displays the Patient Information Inquiry Screen (Fig. 2) . 3-22 3.3 B-scan diagnosis...
  • Page 51 4) Pressing the Inquiry key E restarts inquiry to the TOMEY Link and displays the Patient Information Interim Screen. (Fig. 5) Pressing the Cancel key F returns to the starting screen with- out proceeding in further operation.

  • Page 52: C) Setting Of The Eye To Be Observed

    Left for the eye to be observed are changed over every time when this key is pressed. When printing or saving measured data in the memory card or data communicating with the TOMEY Link or DATA Transfer, make sure that the display of the eye in subject is correct.
  • Page 53 (Fig. 2) 2) Press the probe applying angle mark display key B to display the probe applying angle mark C. If again pressing the probe applying mark display key, the screen will be the state of "un- display". 3) Press the probe applying angle mark rotation key D to set the display angle.

  • Page 54: Inputting Of Id Number From The External Connection Id Input Device (Barcode Reader, Etc.)

    (optional) which has networking availability. DATA Transfer accompanying this instrument cannot cover that function. As for setting of the server for TOMEY Link, see the In- structions for TOMEY Link. Setting of connection is necessary for connecting to the TOMEY Link.
  • Page 55 If changing patient information by using the following procedure with the patient information for measurement data (moving image data or similar) as having been input- ted, sufficiently make sure that the measurement data which has already been existing is that for the identical patient.
  • Page 56 (Fig. 3) 3) If the automatic inquiry for TOMEY Link has been set, in- quiry for patient information will automatically be started. As for the automatic inquiry for TOMEY Link, see "3.11.2 f) Setting of TOMEY Link". 4) When the inquiry of patient information has been completed, the message of "Complete"...

  • Page 57: Setting Of Various Gain Volumes

    3.3.6 Setting of various gain volumes Fine adjustment of various gain volumes shall be given as observing the ultrasound wave image. a) CONTRAST volume A A A A A The contrast of the whole image (white/black contrast) is set. (Adjustable range: 1 to 60dB) The higher contrast makes the images having the clearer white and black color definitions, but, at the same time, lowers the penumbra expression which makes it difficult to see delicate changes of the organization.

  • Page 58: Ultrasound Image Acquisition

    3.3.7 Ultrasound image acquisition Patient's cooperation is helpful for successful ophthalmic examination. Before going into examination, sufficiently explain the examination procedure to the patient and have him been sufficiently relaxed. When applying the ultrasound gel to the probe, care is to be taken not to cause air in the gel.

  • Page 59: Various Functions At The "Freeze

    3.3.8 Various functions at the "freeze" a) Motion pictures playback The UD-6000 is capable of recording a maximum number of images which can be accommodated in 202 pages and repeatedly played back. (Fig. 1) (Fig. 2) 1) By pressing the playback key A, saved images are replayed as a moving picture.

  • Page 60: B) Frame By Frame Forward/Rearward Replay

    b) Frame by frame forward/rearward replay The saved images are displayed page by page. 1) Each pressing of the forward (feeding) key A shows the images page by page in the forward direction. 2) Each pressing of the backward (returning) key B shows the images by page by page in the backward direction.

  • Page 61: D) Vector-A

    2) Pressing the Skip Back key B will display the image in every fifth page receding page then displaying. Consecutively pressing either of these keys shows the image in every fifth page in respective direction of forward or backward. d) Vector-A This function displays A-scan waveforms of images.
  • Page 62 <Movement of the Vector-A waveform> (Fig. 3) 1) Press the Vector-A MOVE key D (Fig. 1) to change the display to the Vector-A positioning mode. (Fig. 3) 2) Next press the UP/DOWN key E to move the cursor line (yellow) up and down, so that the A-scan waveform (pale blue) in the cursor line is displayed at real time.

  • Page 63: E) Distance Measuring

    e) Distance measuring The distance measuring function displays the straight distance between two optional points in the image. This function displays the caliper marks of "+" and "x" in the image, showing the distance between these two points. One caliper mark is red (active caliper) and the other mark is yellow.
  • Page 64 (Fig. 3) 3) Press the "Number" key D to input a sound velocity which is proper for measuring distance. 4) After inputting as above, press the V-set key C to return to the previous screen. (Fig. 4) 5) Press the Move key F to move the active caliper. 6) Touch the image, so the active caliper will move to the touching position.

  • Page 65: F) Area Calculation

    f) Area calculation This function is used to calculate the area in the region of interest. If an area in the image is touched and enclosed, such enclosed area will be marked with a range of 3 to 64 points. The newest point is colored with red (active point) while the other points are colored white.
  • Page 66 (Fig. 3) 3) Press the "Number" key C and input a sound velocity D to appropriate the distance measurement. 4) After inputting above, press the V-set key B to return the mode to the previous screen. (Fig. 2) 5) Touching the image in the screen displays the active point E in the touching position.
  • Page 67 (Fig. 4) 10) Press the Calculation key L, so the beginning point and the ending point are connected to start area calculation. The letters of "Now Processing" are shown in the results dis- play panel M in process of calculation. When the calcula- tion is finished, the calculation results will be displayed.

  • Page 68: G) Zoom

    g) Zoom The image is magnified by 1.5 times with this function. This function, while it is being set, does not allow the use of the vector-A function (d) of this section). No magnification can also be given by the Quad image display function (k) of this section).

  • Page 69: H) Smoothing

    <Movement of the magnification display range> 1) First press the Zoom MOVE key B to change the mode for zoom positioning set screen. (Fig. 2) 2) Press the display range moving key C, to move the display range. The display range movement key, if continuously pressed, keeps moving the display range and if pressed for short time, moves the display range to the neighboring area.

  • Page 70: I) Echo Data Storage

    Echo Data Storage You can store the image on screen as Echo Data Format onto memory card. Echo Data Format: This Format is originally designed for TOMEY Ultra- sound B-Scan. The image, saved as this format, can be loaded and dis- played by using Stored Data Display Function.

  • Page 71: J) Stored Image Display

    Stored Image Display The image, stored on Memory Card as Echo Data Format, can be loaded by using this function. This function is not activated until any image is stored on Memory Card. The image, loaded from Memory Card, will be transformed to JPEG format.
  • Page 72 (Fig. 2) 3) When "10M/20M" is selected, the images, captured by standard B-Scan probe (10MHz) or optional 20MHz ante- rior probe, are listed. When "UBM" is selected, the im- ages by optional High Frequency Probe are listed. 4) Press "Up/Down" B, "FWD" C, "BCK" D to select the pa- tient.
  • Page 73 6) Press "Up/Down" I, "FWD" J, "BCK" K to select the data. 7) Press "View" L to review the stored data (Fig.4). (Fig. 4) 8) Press "Up/Down" M to page up/down the images on the list for selected patient. The image number and total amount of images are shown on screen N.
  • Page 74 10) Press "OK" P on the screen to change from OD to OS or OS to OD and go back to former screen (Fig.4). The change on Memory Card will NOT be saved until "SAVE Echo" R is pressed. 11) Press "Cancel" Q on the screen to cancel OD/OS change and go back to former screen (Fig.4).
  • Page 75 20) Press "Exit" to go back to Store Image Screen (Fig.4). 21) Press "Recall Image" to go back to Data list of a patient (Fig.3). 22) Press "Patient List" to go back to Patient List (Fig.2). 23) Press "Exit" to go back to Freeze Screen (Fig.1). <Delete Data on Memory Card>...
  • Page 76 2) Press "Up/Down" B, "FWD" C, "BCK" D to select patient. Press and hold "Delete" E for one second to delete all the data for the patient. 3) When deleting a part of data for a patient, press "Data List" F to go to Data List screen and press "Delete"...

  • Page 77: K) Quad Windows (Four Images Display)

    K) Quad Windows (Four Images Display) Four images are simultaneously displayed on screen. The images must be saved on Memory Card as Echo Data Format, before using this function. JPEG images cannot be used on this function. (Fig. 1) 1) Press "Quad Windows" A to go to Quad Windows Mode (Fig.2).
  • Page 78 (Fig. 3) 3) When "10M/20M" P is selected, the images, captured by standard B-Scan probe (10MHz) or optional 20MHz ante- rior probe, are listed. When "UBM" Q is selected, the im- ages by optional High Frequency Probe are listed. 4) Press "Up/Down" C, "FWD" D, "BCK" E to select the patient.
  • Page 79 6) Press "Up/Down" J, "FWD" K, "BCK" L to select the data. 7) Press "View" M to review the stored data (Fig.5). 8) Press "Patient List" R to show Patient List Screen (Fig.3). 9) Press "Exit" S to go back to Quad Windows Screen (Fig.2). (Fig.

  • Page 80: L) Transfer Of Patient Data

    Link", the networking available system (optional), or "DATA Transfer" (accompanying this instrument) is needed. See each manual of TOMEY Link or DATA Transfer for their setting. Connecting to TOMEY Link or DATA Transfer needs com- munication setting. See "3.8.2 f) Setting of data commu- nication".

  • Page 81: Troubleshooting

    (Fig. 2) 2) Patient ID, eye to be measured, patient's name, patient's gen- der, and patient's birthday are displayed in the EXPORT Con- firmation screen (Fig. 2). Press the EXPORT key C to start communications. 3) If no communications is used, press the Cancel key D, so no communications will be given and the screen will be returned to the initial screen.

  • Page 82: M) Total Gain Vs. Contrast Change After Freeze

    6) When "Send Only", "Send and Print", "Send and Store" or (Fig. 5) "Send/Store/Print" is selected in the footswitch function setting, data can be sent to TOMEY Link or to DATA Transfer by stepping the footswitch pedal "SAVE/PRINT" F just after freeze.

  • Page 83: Various Functions At Real Time

    3.3.9 Various functions at real time a) Vector-A See "3.3.8 d Vector-A function". b) Frame rate setting This function sets the frame rate in two steps. "High (22 frames/sec.)" allows smooth and natural moving images even in case of fast moving testing eye and still short playback time for one travel of moving image playback function, while "Low (11 frames/second) does the inferior smoothness than "High"...

  • Page 84: C) Focus Regions Setting

    c) Focus regions setting This function sets three focus regions depending on the observation position. Press the Focus Region key A for this setting. Each pres of this key changes over three stages of "Near", "Middle" and "Far". <Focus regions> The following shows three focus regions from the head of the probe for setting of the scope function (explained in subpara- graph below).

  • Page 85: D) Scope

    d) Scope This function sets the scope of display depth of the image in two steps. Therefore, select the scope to suit the region desired for observation. Press the Scope key A for this setting. Each press of this key sets the scope for "Normal"...

  • Page 86: F) Presetting Of Each Gain And Contrast

    f) Presetting of each gain and contrast Three groups of presetting values for total gain, contrast, near gain and far gain are prepared for this instrument <Average Settings A A A A A > Total gain, contrast, near gain and far gain are set with the standard val- ues.
  • Page 87 1) Press any key of the Average Settings key A, the High Con- trast key B, and the Wide Dynamic Range key C to set total gain, contrast, near gain, and far gain at the values to suit the selected keys. Each set value is displayed at the left upper part D of the image.

  • Page 88: Assistant Function Of Biometry

    3.4 Assistant function of Biometry This function is an additional function used for biometry purpose, but it is not a biometry instrument. This function is intended to provide information to determine the data to be employed for measurement, by using the B-scan image, in case no stable biometry results are obtainable with the ordinary biometry instru- ment due to intraocular disease.

  • Page 89: Changing To The Biometry Assistant (Sub-) Function

    3.4.1 Changing to the biometry assistant (sub-) function (Fig. 1) When the power source of the instrument is turned on, the operation starts with the B-scan image diagnosis function. Next press the B-Diag key A in the Freeze screen (Fig. 1) for approximately one second, so the instru- ment will automatically adjust the B-scan probe as well as itself.

  • Page 90: Screen Display Information

    3.4.2 Screen display information a) Diagnosis display The type of the eye INDEX to be measured ID number, patient's The eye type, sound name, gender, Memory number of value used for physician's name, probe image measurement, and IOL applying angle, and date The memory number of thickness are displayed.

  • Page 91: B) Main Menu At Freeze

    Captured image is cursor. played back. NEW Patient EXPORT TOMEY Link All the patient data and Utility The screen is changed to measured data are deleted and The screen is measurement is prepared for the EXPORT Confirmation the new patient.
  • Page 92 c) Main menu at scanning The type of eye to be measured The type of eye to be measured, the ultrasound velocity, and the IOL thickness are set. The amp. type is changed. Scope The image display region is changed. 3-64 3.4 Assistant function of Biometry...

  • Page 93: Deletion Of All Measured Data (Measuring Preparation For New Patient)

    3.4.3 Deletion of all measured data (Measuring preparation for new patient) Since data, if once deleted, cannot be restored, sufficient check shall be given before deleting data. Be sure to press the NEW Patient key to delete all saved patient data, before the new patient is placed for mea- surement.

  • Page 94: A) Contrast Volume A

    a) CONTRAST volume A A A A A The contrast (or the difference between white and black) of the image is set. (Adjustable range: 1 to 60dB) b) TOTAL volume B B B B B The echo sensitivity of the whole images is set. (Adjustable range: 1 to 60dB) c) NEAR volume C C C C C The reflective echo in the area near the anterior is set.

  • Page 95: Various Functions At Freeze

    1) Have the patient lay down himself. 2) In case of freeze condition, press the FREEZE button A or the footswitch pedal B to release the condition of "freeze". 3) Put the attachment to the head of the B-san probe and next fill the attachment with ultrasound gel without letting air bubbles insides.

  • Page 96: E) Echo Data Saving

    1) Press the cursor line moving key (UP/DOWN) A, so the cur- sor line will move up and down. Move the cursor line, so each of the cornea front cursor B, the crystalline lens front cursor C, the crystalline lens rear cursor D, and the retina cursor will automatically move to its automatically detected position.

  • Page 97: Various Functions At Real Time

    3.4.8 Various functions at real time a) Setting of eye type to be measured (Fig. 1) 1) Press the eye type setting key A, the screen mode will be changed to the Eye Type Setting screen (Fig. 2). (Fig. 2) 2) Select the eye type in the Eye Type Select screen B.

  • Page 98: B) Scope

    <Setting of sound velocity> 1) After selecting desired the eye type in the Eye Type Setting screen (Fig. 2), press the Sound Velocity Setting key C to change the screen mode to the Sound Velocity Setting screen (Fig. 3). (Fig. 3) 2) Next press the Number key D to change the sound veloc- ity and the lens thickness used for measurement.

  • Page 99: A-Scan Diagnosis

    3.5 A-scan Diagnosis 3.5.1 Changing to the A-scan diagnosis function (Fig. 1) 1) When turning the power on, the instrument starts its opera- tion from the B-scan image diagnosis function. Next press the Utility key A in the Freeze screen (Fig. 1) of the B- scan image diagnosis function to change the screen mode to the Utility screen (Fig.
  • Page 100 (Fig. 3) 3) To return the A-scan diagnosis function to the B-scan diag- nosis function or the biometry measuring sub-function, press the Utility key C to select the Utility screen (Fig. 4) and next press the B-Diag select key D for approximately one second to that the function will return to the B-scan diag- nosis function.

  • Page 101: Screen Display In Formation

    3.5.2 Screen display in formation a) Diagnosis screen INDEX Memory number of A- Conversion sound ID number, patient's name, gender, scan waveform velocity physician's name, and data/time are displayed. Memory number of A-scan Conversion sound waveform is displayed. velocity is displayed. Scope Display range of A- scan waveform as set...

  • Page 102: B) Main Menu At Freeze

    b) Main menu at freeze If the B-scan image diagnosis function is selected, all the data acquired by A-scan diagnosis function will be de- leted. Line cursor ON/OFF key Line cursor ON/OFF is selected. Index The Index Enter screen The Amp type is is displayed.

  • Page 103: C) Main Menu At Real Time

    c) Main menu at real time The type of amplifier is selected. Scope The display range of A-scan waveform is changed. 3-75 3.5 A-scan Diagnosis...

  • Page 104: Deletion Of All Measurement Data (Measuring Preparation For New Patient)

    3.5.3 Deletion of all measurement data (Measuring preparation for new patient) No data, if once deleted, can be restored. Therefore, suffi- cient care must be taken for deleting data. Before examining a new patient, always press the NEW Patient key to delete all the data for the previous patient. If taking data the new patient without pressing the NEW Patient key, acquired data do not correspond to the pa- tient information.

  • Page 105: Entering Of Index Data

    3.5.5 Entering of index data See "3.3.4 Entering of index data". 3.5.6 Acquiring of A-scan shape Patient's cooperation is necessary for successful exami- nation. Sufficient explanation should be given to the pa- tient before carrying out examination. And have the pa- tient relaxed during examination.

  • Page 106: Various Functions At Freeze

    3.5.7 Various functions at freeze a) Data display change This instrument memorizes as much capacity as for that of maximum 202 data. Acquired wave data are displayed in or- der, every time when pressing the Data Display Select key A. b) ON/OFF and movement of the line cursor This line cursor can be used as the reference line of total gain.

  • Page 107: C) Probe Applying Position And Ultrasound Beam Direction Display

    c) Probe applying position and ultrasound beam direction display This function is used to display the probe applying position, ultrasound beam direction, position of interest (lesion). (Fig. 1) (Fig. 2) 1) Nine positions are each displayed every time when press- ing the probe applying position key A.

  • Page 108: D) Data Saving

    d) Data saving This function is used to save acquired A-scan waveforms in the memory card. (Fig. 1) Make sure that Memory Card is inserted into main unit properly. Patient ID and OD/OS must be properly selected, before storing the data into Memory Card. DO NOT remove Memory Card, while the data is stored or loaded.

  • Page 109: E) Stored Image Display

    e) Stored Image Display DO NOT remove Memory Card, while the displayed im- age is loaded from the same Card. Otherwise, the dis- played image will be closed and the screen changes into Freeze Initial. This function is to display A Diagnostic waveform, saved on Memory Card.
  • Page 110 2) Press "Up/Down" B, "FWD" C, "BCK" D to select the pa- tient. You can search patient by Patient ID. Click on the blank E for ID type in and type ID for the patient you want to search. Click on the blank again or press "Enter" F to complete input. Then, press "Search"...
  • Page 111 6) Press "Up/Down" M to page up/down the images on the list for selected patient. The image number and total amount of images are shown on screen. 7) Press "OD/OS" N to switch the eyes to be measured. Each time the button is pressed, warning screen (Fig.5) comes up on screen.
  • Page 112 <Delete Data on Memory Card> The data, which was once deleted, cannot be restored. Please pay special attention not to delete necessary infor- mation. (Fig. 1) 1) Press "Recall Image" A to go to Patient List (Fig.2). (Fig. 2) 2) Press "Up/Down" B, "FWD" C, "BCK" D to select pa- tient.

  • Page 113: F) Transfer Of Patient Data

    4) When deleting all data on the list, press "Delete All" G and keep holding for one second to delete all. Once the Memory Card is formatted, all the data on the card will be lost. Lost data cannot be restored. 5) Press "Memory Card Format"...

  • Page 114: Various Functions At Real Time

    3.5.8 Various functions at real time a) Amp. selection Log amp (Log), linear amp. (Linear), and S-curve amp (S) are alternately selected every time when pressing the Amp. Select key A. b) ON/OFF and movement of the line cursor See "3.5.7 b) ON/OFF and movements of line cursor". c) Probe applying position and ultrasound beam direction display See "3.5.7 c) Probe applying position and ultrasound beam direction display".

  • Page 115: Biometry

    3.6 Biometry 3.6.1 Turning the power on and adjustments a) Turning the power on and adjustments See "3.3.1 a) Turning the power on and adjustments". b) Switching to the biometry function. When the biometry function is switched, all the data ac- quired by B-scan image diagnosis, the assistant function of biometry, and A-scan diagnosis function are deleted.

  • Page 116: C) Starting Screen Display Information

    c) Starting screen display information (Fig. 1) 1) Immediately after the power is turned on, the Start screen is displayed to calibrate the biometry probe. (Fig. 1) (Fig. 2) 2) After the calibration of the probe is given properly, the Mea- surement screen (the initial screen) is displayed.
  • Page 117 3) If the OK key B is next pressed, the Measurement screen (the initial screen) will be displayed. (Fig. 2) If the error message is displayed, see "6. TROUBLESHOOTING". If this error message is repeatedly displayed, consult with your Tomey representative from which you purchased your in- strument. 3-89 3.6 Biometry...

  • Page 118: Screen Display Information

    3.6.2 Screen display information a) Measuring display Measurement mode setup The measuring method is set up. The eye to be measured Measurement mode select (OD/OS) The contact mode or the immersion Shows which eye (Right or Left) mode is diaplayed. will be measured.

  • Page 119: B) Measuring Finish Screen

    b) Measuring finish screen Standard deviations (S.D) for axial length data The standard deviations for axial length data are displayed. The range of measured axial lengths Average of axial length data The difference between the shortest and The average of measured axial longest axial lengths is displayed.

  • Page 120: C) Confirmation Display Of Measured Data

    c) Confirmation display of measured data Memory number and waveform of selected measurement data Display of the memory number and waveform of selected measurement data, Display of selected measurement data Selected data is displayed as reversed black/white. Level cursor/level line In the auto mode, data is taken when the wave rises higher...

  • Page 121: Setting Of Measuring Conditions

    3.6.3 Setting of measuring conditions The following conditions are set immediately after turning the power on and after switching the function to the biometry mode. · Eye to be measured: Right eye (R) · Type of eye to be measured: Normal (Sound velocity to be same as set in the previous use.) ·...

  • Page 122: B) Setting Of The Eye Type To Be Measured And The Sound Velocity For Conversion

    b) Setting of the eye type to be measured and the sound velocity for conversion This function will be applied only on selected eye to be measured (OD or OS). The setting for both eyes cannot be changed automatically. The setting for each eye should be properly selected, according to the conditions.
  • Page 123 (Fig. 1) 1) Press the setting key A of the eye type to be measured, to switch to the setting screen. (Fig. 2) (Fig. 2) 2) Press the setting key B of the eye type to be measured for setting. 3) When selecting "Normal", choose the axial length calcula- tion method of "Mean Velocity (M/V)"...
  • Page 124 (Fig. 3) 5) Inputting of the converted sound velocity is made with the number keys G. 6) When setting the input information by Enter key H, the following items are ready for measurement. [Inputting Range] Normal (Average ultrasound velocity) Axial length average ultrasound velocity (Avg): 1500 to 1600 m/s Lens ultrasound velocity (LENS): 1540 to 1740 m/s...

  • Page 125: C) Setting Of Gains

    7) After setting he converted sound velocity, press the sound velocity setting key F to return the screen to the mode to the Eye Type Setting screen (Fig. 2). 8) Press the Eye Type Setting key E to return the mode to the Measurement screen (Fig.

  • Page 126: D) Id Number/Patient's Name/Patient's Gender/Physician's Name

    d) ID number/patient's name/patient's gender/physician's name See "3.3.4 a) Entering of ID number, patient's name, patient's gender, and physician's name", or "3.3.5 ID inputting from external connection in- putting devices (barcode reader, etc.)" e) Setting of the measuring method This function will be applied only on selected eye to be measured (OD or OS).

  • Page 127: F) Selection Of The Contact Mode/The Immersion Mode

    f) Selection of the contact mode/the immersion mode See "3.11.3 1) Selection of the contact mode/immersion mode". 3.6.4 Confirmation of operation Neither of measuring nor calibrating of this instrument can be given with this test piece. The operational confirmation of this instrument is given with the test piece supplied for axial length measurement.

  • Page 128: Measurement

    3.6.6 Measurement a) How to handle the biometry probe in the contact mode and the immersion mode <Contact mode> Apply the eye contacting part of the biometry probe directly to the center of the cornea at a right angle. <Immersion mode> The biometry probe can also be applied with the cornea protective media, such as water, methylcellulose gel, etc.

  • Page 129: B) How To Use The Slider When Taking Measurement By Using The Chin Rest

    b) How to use the slider when taking measurement by using the chin rest 1) Install the biometry probe to the instrument. Use a sufficient length of the probe cord, or the cor- nea may otherwise be subjected to undue pressure by measurement.

  • Page 130: C) Selection Of Retinal Waveform

    c) Selection of retinal waveform This function will be applied only on selected eye to be measured (OD or OS). The setting for both eyes cannot be changed automatically. The setting for each eye should be properly selected, according to the conditions. In case the instrument cannot recognize the ordinary waveform due to a waveform existing between the lens rear waveform and the retinal waveform, set the retinal waveform selecting cursor at...

  • Page 131: D) Posterior Lens Spike Select

    d) Posterior Lens Spike Select This function will be applied only on selected eye to be measured (OD or OS). The setting for both eyes cannot be changed automatically. The setting for each eye should be properly selected, according to the conditions. When there are several spikes inside lens and the unit cannot pick up one as posterior lens spike, Posterior Lens Cursor should be moved on left of posterior lens spike.

  • Page 132: E) What Is A Good Waveform

    e) What is a good waveform <Contact mode> In the auto measurement, the waveforms which satisfy the following conditions A to C are considered to be Fall between retina and sclera (choroids) preferable waveforms as measurement data. RETINA SCLERA A The following waveforms stand high from the level cursor line position.
  • Page 133 <Immersion mode> For auto measurement in the immersion mode, the following conditions are added to those for A to C provided for the con- tact mode. Immersion echo Lens front echo D The corneal waveform shall be within the range of 2.2 to 5.0mm (which is shown with the broken lines in the fig- ure).

  • Page 134: Measurement

    3.6.7 Measurement Make sure before taking measurement that the converted sound velocity has been set as desired, since the con- verted sound velocity has direct influence on measure- ment data. Make sure also before measurement that the settings of contact mode and immersion mode have been set prop- erly.

  • Page 135: B) Manual Measurement (Manual)

    <Chin measurement> Continue measurement until all ten pieces of measured data come within the range of ±0.1mm to the average. It is also noted that this measurement can be discontinued on the way of measurement. 1) The instrument reports it with a monitor sound of "beep" when the measuring conditions are satisfied.

  • Page 136: Confirmation Of Waveforms After Measurement

    3.6.8 Confirmation of waveforms after measurement a) Display of optional waveform data (Fig. 1) Confirmation can be made by calling optional data from the measurement data. 1) Press the Edit key A to change the screen mode to the Mea- surement Data Confirmation screen (Fig.

  • Page 137: B) Selection Of Particular Axial Length Data To Be Used For Iol Power Calculation

    b) Selection of particular axial length data to be used for IOL power calculation Generally, the average of measurement data saved for IOL power cal- culation or in the memory card is used for IOL power calculation, while optional measurement data can also be used for this purpose as well. 1) Optional data is displayed as black and white reversely high- lighted in the Measurement Data Confirmation screen.

  • Page 138: D) Caliper Function

    2) Press the Delete key A for data deletion. If the Delete key is erroneously pressed, move the cursor to the number of the data pressed and next press the Recall key B to redisplay the data. If the screen returns to the Measurement screen, the deleted data will not be redisplayed with the Recall key.
  • Page 139 1) After measurement is finished, press the Calip key A to switch to the Caliper screen (Fig. 3), so the caliper lines B will be displayed. A particular data can also be displayed in the Mea- surement Data screen (Fig. 2) for distance measurement. (Fig.

  • Page 140: Deletion Of Measurement Data

    3.6.9 Deletion of measurement data Since the data, if once deleted, will not be restored, suffi- cient care must be given for data deletion. Be sure to press the NEW Patient key A A A A A to delete the data for previous patients.

  • Page 141: B) Deletion Of Measurement Data For Single Eye (Re-Measurement Preparation For The Same Patient)

    b) Deletion of measurement data for single eye (re-measurement preparation for the same patient) The measurement data for single eye only is deleted. This deletion is performed by pressing the Retake key A for approximately one second until a sound of "beep" is made. The ID number and patient's name and gender will remain.

  • Page 142: Iol Power Calculation

    3.7 IOL power calculation In case of using data measured for IOL power calculation, the physician must always examine such data. 3.7.1 Screen display information a) Entering of calculation data and display of calculation results The eye to be IOL power formula select measured key for Lens C/D Sets left or right eye...

  • Page 143: B) Iol Data List Display Screen 1

    b) IOL Data List display screen 1 Entered data display Shows calculation data entered and also which lens of A/B/C/D is used. IOL data Shows registered IOL maker name, lens type, and various lens constants to suit calculation formula. IOL data select key IOL data is selected.

  • Page 144: C) Iol Data List Display Screen 2

    c) IOL Data List Display screen 2 IOL data list page select key IOL data list page select key The screen mode is changed to the IOL The screen mode is changed to the IOL Data List Display screen 1. Data List Display screen 3.

  • Page 145: Calculation

    3.7.2 Calculation When using the measurement results of axial length mea- surement for IOL power calculation, the physician shall always check the measurement results before calcula- tion. The UD-6000 may have some extent of calculation error due to the effective digits of internal calculation. There may appear an imaginary number in the formula SRK/T.

  • Page 146: Inputting Of Calculation Data

    The formula setting key A is used for setting the calculation for- mula. The formula is set at SRK II, SRK/T, HOLLADAY, Hoffer Q, HAIGIS optimized, or SRK SHOWA in this order every time when pressing the key. ( ) The HAIGIS standard and the SRK SHOWA formula have not been selected in the stage of shipping;...

  • Page 147: B) Inputting Of Corneal Refractive Power Or Corneal Curvature (K1/K2)

    b) Inputting of corneal refractive power or corneal curvature (K1/K2) 1) Press the K1 A or the K2 key B, to change the display to the white/black reverse-highlighted mode. 2) Input the data for calculation with the number key C. [Input range] Corneal refractive power: 30.00 to 60.00 D...

  • Page 148: D) Inputting Of The Lens Constant (A-Const/Sf/Acd-Const/A0 · A1 · A2)

    1) Press the Desired Ref. key A to change the display to the black/ white reverse-highlighted mode. 2) Enter the data for calculation with the number key B. [Input range] - 30.00 to +10.00 D 3) Again press the Desired Ref. key A. d) Inputting of the lens constant (A-Const/SF/ACD-Const/a0 ·...
  • Page 149 1) Press the lens constant key A to switch the display to the white/black reverse-highlighted mode. 2) Input the data with the number key B. [Input range] A-Const: 100.00 to 130.00 - 5.00 to +10.00 3) Again press the lens constant key A. <In case of imputting from the IOL data list>...

  • Page 150: Saving Of Patient Data

    (Fig. 2) 2) When confirming the values of a0, a1, and a2, press the IOL data list select key C to display the IOL Data List Display screen 2 (Fig. 2). 3) Press the IOL data list page select key D, to return the dis- play mode to the IOL Data List Display screen 1 (Fig.

  • Page 151: B) Inputting Of Implanted Iol Power (Iol Power)

    1) Press the Implanted IOL Model key A, so the IOL model name and the maker name B will be displayed as black/ white reverse-highlighted. (Fig. 1) (Fig. 2) 2) Next press the black/white reverse-highlighted IOL model name and maker name B, so the IOL model name C will be inputted.

  • Page 152: C) Saving Of Patient Data

    c) Saving of patient data Make sure that the memory card is inserted in the main body of the instrument. The saving data is controlled with the ID number. When saving measured data in the memory card, always input the ID number of the patient. 3-124 3.7 IOL power calculation...

  • Page 153: Operating Of The Input Keys

    Used only for the index enter display of the B-scan diagnosis func- tion and the biometry sub-function. The probe mark display is turned every time when turning the key. L Inquiry key: Used to inquire patient information to the TOMEY Link. 3-125 3.8 Operating of the input keys...

  • Page 154: Printout

    3.9 Printout 3.9.1 How to print out Printout will start when "PRINT" button is pressed or "SAVE/ PRINT" pedal of the footswitch is stepped. In order to print with the footswitch, however, the footswitch should be set at "Print Only", "Store and Print", "Send and Print"...

  • Page 155: Contents Of Printout By Built-In Printer

    3.9.2 Contents of printout by built-in printer a) Printout of biometry (Example of "Normal") Standard mode A Measuring date and time B Patient name C ID number D Physician name E Right/left eye F Measurement mode G Type of eye to be measured H Contact/immersion I Axial length calculation method J Axial length average sound velocity...

  • Page 156: B) Printouts Of Iol Power Calculations (Examples Of Srk/T)

    b) Printouts of IOL power calculations (Examples of SRK/T) Standard mode A Measuring date and time B Patient name C ID number D Physician name E Left/right eye for calculation F Axial length G ACD H Corneal refractive power or corneal cur- vature I Expected post-surgery refractive power J Calculation formula name...
  • Page 157 Simple mode 3-129 3.9 Printout...

  • Page 158: C) Printouts For Iol Power Calculation After Axial Length Measurement (Example Of

    c) Printouts for IOL power calculation after axial length measurement (Example of Normal SRK/T) Standard mode A Measuring date and time B Patient name C ID number D Physician name E Right/left eye for calculation (eye for cal- culation) F Measuring method G Type of the eye to be measured H Contact/immersion I Axial length calculation method...
  • Page 159 Simple mode 3-131 3.9 Printout...

  • Page 160: D) Printouts Of Calculation With Personal/Corresponding Value

    d) Printouts of calculation with Personal/Corresponding Value Standard mode A Measuring date and time B Patient name C ID number D Physician name E Right/left eye to be measured (for calcula- tion) F Post-surgery refractive power G Implanted IOL power H Axial length I ACD (Anterior Chamber Depth) J Corneal refractive power and corneal cur-...

  • Page 161: Data Saving Into The Memory Card By Biometry Function And Iol Power Calculation Function

    3.10 Data saving into the memory card by biometry function and IOL power calculation function When data is saved by this function, input the ID number for saving. The ID number is used as the file name. 3.10.1 How to save data Press Save A to save data into Memory Card.

  • Page 162: Data To Be Saved In Each Display

    3.10.2 Data to be saved in each display Data measured for both eyes are saved in a file. <Display after measurement> A ID number B Patient name C Physician name D Measuring date E Immersion/contact mode F Measuring method G The type of eye to be measured H Axial length calculation method (only in case of "Normal") I Average sound velocity J Lens sound velocity...
  • Page 163 <Confirmation screen of measurement data> A ID number B Patient name C Physician name D Measuring date E Immersion/contact mode F Measuring method G The type of eye to be measured H Axial length calculation method (only in case of type of eye to be measured) I Average sound velocity J Lens sound velocity K ACD sound velocity...
  • Page 164 <IOL power calculation screen> A ID number B Patient name C Physician name D Measuring date (*1) E Immersion/contact mode (*1) F Measuring method (*1) G The type of eye to be measured (*1) H Axial length calculation method (only in case the type of eye to be measure is for "Normal) I Average sound velocity (*1) J Lens sound velocity (*1)
  • Page 165 <Patient data editing screen (Patient data for utility)> A K1, K2 values B Expected refractive power C Implanted IOL power D Manufacturer of implanted IOL E Model of implanted IOL F A-constant of implanted IOL G SF value of implanted IOL H a0 value of implanted IOL I a1 value of implanted IOL J a2 value of implanted IOL...

  • Page 166: Utilities

    Select the language to be displayed. Time and Date Set date and time. Link Setting Set the communication mode for the TOMEY Link or DATA Transfer. Image color selection Select the display color of image. Footswitch Sound SAVE/PRINT pedal is Set sound volume.
  • Page 167 Select the language to be displayed. Time and Date Enter the date and Link Setting time. Set the communication mode for the TOMEY Link or DATA Transfer. Image color select Select the display color of the image. Footswitch Sound SAVE/PRINT pedal is Set sound volume.

  • Page 168: C) Utility Screen For A-Scan Diagnosis

    Select the language to be displayed. Time and Date Enter date and time. Link Setting Set the communication mode for the TOMEY Link or DATA Transfer. Footswitch Sound Select the function of SAVE/ Sound volume is PRINT pedal of the footswitch. set.
  • Page 169 Enter date and time. Set the The screen returns to the communication previous screen. mode for the Sound TOMEY Link or DATA Transfer. Set sound volume. Patient Data IOL Data Entry Display and edit Enter IOL data. patient data saved in the memory card.

  • Page 170: Setting Items For B-Scan Diagnosis Assistant Function/A-Scan Diagnosis Function

    3.11.2 Setting items for B-scan diagnosis assistant function/A-scan diagnosis function a) Registration of physician's names If physician's names are registered in the list of physicians, the physician who performs measurement can be selected from the list of physicians by inputting the index. The name of each physician is inputted with a nmber of less than 14 letters and up to ten names at maximum can be registered.
  • Page 171 b) Time and Date Set the date and time. (Fig. 1) 1) Press the Time and Date key A to change the display screen to the Date and Time Setting screen (Fig. 2). (Fig. 2) 2) Press the item B desired to change to the white/black re- verse-highlighted mode.
  • Page 172 c) Sound volume Set the sound volume for the input sound of the touch panel and for the warning sound. The sound volume is changed in the order of off, small, middle and large volumes, each time when pressing the Sound key A. d) Start settings The setting of the initial environment when turning the power on is made by the following two ways.
  • Page 173 2) The then set information is displayed in B. In case of the Fa- vorite setting, the details of each set value ares displayed in C. 3) Select the Last Setting key D or the Favorite Setting key E. 4) Press the Cancel key F, so the selected setting will be can- celled and the mode will be returned to the setting which has been made effective previously.

  • Page 174: F) Setting Of Data Communication

    1) Press the TOMEY Link key A. 2) TOMEY Link/DATA Transfer button B selects the connection (Fig. 2) to TOMEY Link or to DATA Transfer. Select "Connect" and these connections become available, and select "Disconnect" and these connections are cut off.
  • Page 175 C to F cannot be made. DNS is also used with DHCP. See the next item for the detail. 2) The Login TOMEY Link is used to set the user ID I and the user's password J in order to login the TOMEY Link. Input- ting of these information is performed with up to 16 alpha-nu- meric characters.
  • Page 176 If physical connection is normal, the message of "Test Complete" should be displayed. [Example] If only this instrument and TOMEY Link server or a computer for receiving DATA Transfer, the setting can be made by fol- lowing the below.
  • Page 177 <Connection Setting : DNS> 1) In DHCP "DNS" key A appears. If "DNS" key is pressed, the host IP address (Fig. 3, F) will change to the name of the host computer B to set the host computer with its computer name ( a full name).

  • Page 178: G) Selection Of Image Colors

    g) Selection of image colors This instrument provides four gradation sequences for the B-scan image display. The gradation sequences are changed each time when pressing the Image Color Select key A. h) Setting of the footswitch function Set up the function of the function of the "SAVE/PRINT" pedal. Every time "Footswitch Function"...

  • Page 179: Setting Items Of Biometry Function/Iol Power Calculation Function

    3.11.3 Setting items of biometry function/IOL power calculation function. a) Registration of physician's names See "3.11.2 a) Registration of physician's names". b) Setting of date and time See "3.11.2 b) Setting of date and time". c) Setting of sound volume See "3.11.2 c) Setting of sound volume".
  • Page 180 4) When setting the A (SRK II), A (SRK/T), A (HAIGIS), and A (SHOWA), press Page Change key E to display the Registration screen-2 (Fig. 3). 5) When inputting a0, a1, and a2, press the Page Change key F to display the Registration screen-3 (Fig. 4). To return to the Registration screen-1 (Fig.

  • Page 181: E) Calculation Of Personal Constants

    e) Calculation of personal constants Personal A-Constant, Personal SF, Corresponding SF and Per- sonal ACD-Const are sued for calculation. (Fig. 1) (Fig. 2) 1) Press the Personal/Corresponding Value key A to select the right eye or the left eye to change the screen to the Cal- culation screen (Fig.

  • Page 182: F) Selection Of Iol Power Calculation Formulas

    f) Selection of IOL power calculation formulas Select the calculation formulas to be used for the IOL Power Calculation screen, of which formulas can be chosen up to five formulas at the same time. <Selection of IOL power calculation formuls> 1) Press the IOL Formula key A to switch the display to the IOL power calcualtion formula selecting mode (Fig.

  • Page 183: G) Selecting Of Languages

    g) Selecting of languages See "3.11.2 e) Selecting of languages". h) Setting of data communications See "3.11.2 f) Setting of data communications. Displaying and editing of patient data saved in the memory card Patient data saved in the memory card is displayed and edi- fied.
  • Page 184 <Displaying of patient data> 1) Press the Echo key F to display the waveform of se- lected patient data (Fig. 3). 2) The distance between the cursors is displayed with the use of the Fix key G and the Caliper Move key H. (See "3.6.8 d) Caliper function".) 3) Press the List key I to return the screen to the List screen (Fig.
  • Page 185 <Calculation of personal lens constant> 1) Press the PCV key S to change the display to the screen for personal lens constant calculation. (Fig. 6) 2) If all the items are inputted, relevant calculation results will automatically be displayed. 3) Press the Personal/Corresponding Value key T to re- turn the display to the List screen (Fig.

  • Page 186: J) Statistical Processing Of Patient Data

    Statistical processing of patient data This function statistically processes patient data saved in the memory card and displays them in four types of graph. The statistical processing of patient data is given by IOL Model saved in the memory card. In case different lens constants for IOLs in the model are saved in the memory card, their statistical processing is given as an identical IOL.

  • Page 187: K) Setting Of Printout Modes

    (Fig. 5) Table 1. X-axis and Y-axis of the graph of each calculation formula Graph1 (Fig. 2) Graph2 (Fig. 3) Graph3 (Fig. 4) Graph4 (Fig. 5) x-axis y-axis x-axis y-axis x-axis y-axis x-axis y-axis Axial Personal Personal Personal Personal Frequency SRK II length power...
  • Page 188 (Fig. 2) 2) Next select the output mode whether it is from the built-in printer or the video printer. Press the Internal Printer key B for selecting the built-in printer and press the Video Printer key C for the video printer. 3) If the built-in printer is selected, the following screen modes will furthermore be set for the Measure frame D and the IOL Calculation frame E.

  • Page 189: L) Switching Of Contact Mode/Immersion Mode

    Switching of contact mode/immersion mode The contact mode and the immersion mode are alternately changed. 1) Press the Contact/Immersion key A in the Axial Length Utility screen (Fig. 1) to change the screen mode to the Selection Confirmation screen (Fig. 2). (Fig.

  • Page 190: Memory Card

    3.12 Memory card Use the memory card for saving the data measured by this instrument supplied. The operation of this instru- ment will not be guaranteed, if a memory card other than supplied with this instrument is used. Neither of change nor deletion of the data saved in the memory card by personal computer is allowed, since such data will not otherwise be displayed by this instru- ment.

  • Page 191: Handling Of The Files In The Memory Card

    4) Files other than in the text mode can be opened by NOTEPAD (application), to confirm the details of the information contained. 5) JPEG image files are opened with Image Viewer software com- plied with JPEG. 6) After reading the data saved in the memory card, remove the memory card out of the personal computer.
  • Page 192 This page is intentionally blank. 3-164...

  • Page 193: References For Technical Information

    4. REFERENCES FOR TECHNICAL INFOR- MATION 4.1 Calculation method of axial length by biometry sub-function Normal / Dense Cataract / Aphakic The measured values are calculated with the average sound velocity for axial length, by using the following calculation for- mula.

  • Page 194: Amplifier Characteristics Of A-Scan Diagnosis Function

    4.2 Amplifier characteristics of A-scan diagnosis function The input and output characteristics of log amplifier, linear am- plifier and S-curve amplifier, which are selected in A-scan di- agnosis function, are as shown in the following figure. Log amplifier Linear amplifier S-curve amplifier Input 4.2 Amplifier characteristics of A-scan diagnosis function...

  • Page 195: Iol Power Calculation

    4.3 IOL power calculation 4.3.1 SRK-II formula 1. Implanted IOL power for Emmetropization (D) = A1 - 0.9K - 2.5L emme 2. Implanted IOL power for Ametropization (D) - REF · CR ament emme 3. Post surgery expected refractive power (D) = (P - P) / CR emme...
  • Page 196 4. Personal A-Constant A = P + AREF·RF + 2.5L + 0.9K - COR where, Implanted IOL power (D) AREF: Power of spherical lens equal to the post surgery refractive power (D) = S+C/2 Cylinder lens power (D) Spherical lens power (D) Refractive factor P >...

  • Page 197: Srk/T

    4.3.2 SRK/T 1. Implanted IOL power for emmetropization (D) 1000na·X = ————— emme (L1-C1)Y 2. Implanted IOL power for ametropization (D) 1000na{X-0.001REF(V·X+L1·r)} = ——————————————— amet (L1-C1){Y-0.001REF(V·X+C1·r)} 3. Desired postoperative refraction (D) 1000na·X-P·Y(L1-C1) = ————————————————— na(V·X+L1·r)-0.001P(L1-C1)(V·Y+C1·r) 4. Personal A-Constant A = (-b+ b -4ac) /2a where, a: 0.62467...
  • Page 198 Ofst: Calculated distance between iris and optical surface of the implanted IOL (including corneal thickness) (mm) = ACDconst-3.336 = (0.62467A-68.747)-3.336 Height of the corneal dome (mm) = r - r A-Constant Average corneal refractive power (D) = (K1+K2)/2 Implanted IOL power (D) Vertex distance (mm) = 12 Refractive index of aqueous humor and vitreous body = 1.336...

  • Page 199: Holladay

    4.3.3 HOLLADAY 1. Implanted IOL power (D) 1000na{X-0.001REF(V·X+L2·r)} P = —————————————————— (L2-C2-SF)[Y-0.001REF{V·Y+r(C2+SF)}] 2. Post surgery expected refractive power (D) 1000na·X-P·Q·Y = ————————————————— amme na(V·X+L2·r)-0.001P·Q{V·Y+r(C2+SF)} Where, na·r-L2(nc-1) na·r-(nc-1)(C2+SF) L2-C2-SF Aqueous humor and vitreous refractive index =1.336 Corneal refractive index =4/3 Axial length (mm) Average corneal curvature (mm) =337.5/K Average corneal refractive power (D)
  • Page 200 3. Personal SF SF={-BQ- BQ -4AQ·CQ}/(2AQ)-C2 Where, AQ=(nc-1)-0.001AREF{V{nc-1)-r} BQ=0.001AREF{L2·V{nc-1)-r(L2-V·na)} -{L2(nc-1)+na·r} CQ1=0.001AREF[V{na·r-L2(nc-1)}+L2·r] CQ2=1000na{na·r-L2(nc-1)-CQ1}/P CQ3=L2·na·r-0.001AREF·L2·V·r·na CQ=CQ3-CQ2 Corneal refractive index = 4/3 Aqueous humor and vitreous refractive index = 1.336 Average corneal curvature (mm) = 337.5/K Average corneal refractive power (D) = (K1+K2)/2 Vertex distance (mm) = 12 Axial length (mm) Corrected axial length = L+0.2...

  • Page 201: Hoffer Q

    4.3.4 Hoffer Q 1. Implanted IOL power (D) 1336 1.336 P = ————— - ——————— L - C-0.05 1.336 C+0.05 ——— - ——— 1000 Where, R = ————— 1-0.012Rx 2. Post surgery expected refractive power with spectacles (D) Rx = ————— 1+0.012R Where, 1.336...
  • Page 202 3. Personal ACD 4·1336(N-L) L+N- (L-N) + —————— ACD = ——————————————— - 0.05 Where, 1336 N = ———— K + R R = ————— 1-0.012ARx 4. Post surgery expected ACD (ACD) ACD = X+Y where, X=C1+0.3(L-23.5) + (tan K) Y=0.1M(23.5-L) tan{0.1(G-L) }-0.99166 →...

  • Page 203: Haigis Optimized / Haigis Standard

    4.3.5 HAIGIS optimized / HAIGIS Standard Implanted IOL power (D) 1000na P = ———— - ——————— L - D —— - ——— 1000 Where, Z = DC + ——————— REF·V 1 - ——— 1000 d=a0+a1 ·ACD+a2 ·L (ACD g 0) d=(a0-0.241·a1)+(a2+0.139·a1)L (ACD = 0) a0=0.62467A-72.434 -------*...
  • Page 204 Personal A-Constant d-a1·ACD-a2·L+72.434 A = ——————————— (ACD g 0) 0.62467 d-L(a2+0.139·a1)+0.241·al+72.434 A = ——————————————— 0.62467 (ACD = 0) Where, P(L·z+1000na) - P (L·z + 1000na) - 4P·z(1000L·na·z + 1000L·na·P - 1000 ·na d = ————————————————————————————————— 2P·z AREF Z = DC + ——————— AREF·V 1 - ————...

  • Page 205: Srk (Showa)

    4.3.6 SRK (SHOWA) 1. Implanted IOL power (D) L < 22.0 : P=A-2.5L-0.9K+1.4-1.45REF 22.0 L < 24.5 : P=A-2.5L-0.9K-1.67REF 24.5 L < 27.0 : P=A-2.5L-0.9K+0.71-1.25REF 27.0 : P=A-2.5L-0.9K-1.69REF-1.69 2. Post surgery expected refractive power (D) L < 22.0 : R=(A-2.5L-0.9K+1.4-P)/1.45 22.0 L <...

  • Page 206: Axial Length Calculation Of Biometry

    4.4 Axial length calculation of Biometry 4.4.1 Normal Axial length is calculated by the following formula. <Calculation with mean velocity> V · t L = ——— Axial length Average sound velocity Time <Calculation with sectional velocity> · · · L = ————— + ————— + ———— Axial length : ACD ultrasound velocity : Lens ultrasound velocity...

  • Page 207: Dense Cataract

    4.4.2 Dense cataract Measured axial length is calculated in the similar manner to that using the normal average sound velocity. 4.4.3 Aphakic Measured axial length is calculated in the same manner to that using the normal average sound velocity. 4.4.4 Pseudophakic (1 to 3) The factory setting of the IOL ultrasound velocity is the refer- ence assumed from the below table.

  • Page 208: Software Version Information

    4.5 Software version information (Fig. 1) The Start-up screen (Fig. 1) is displayed when turning on the main switch. Software version A is displayed in the upper right area of the screen. 4-16 4.5 Software version information...

  • Page 209: Inspection And Maintenance

    Tomey, nor to a product whose serial number or batch number is removed, altered or ef- fected.

  • Page 210: How To Replace The Fuse

    5.2 How to replace the fuse Be sure to disconnect the power plug from the receptacle before replacing the fuse, or you may be subjected to electric shocks otherwise. 1) Turn the power switch off and next disconnect the power plug from the receptacle.

  • Page 211: B) Cleaning

    b) Cleaning For cleaning the eye contacting part of the probe, use absorbent cotton to avoid damaging the part. Do not pull the cord with an undue force, which may otherwise cause power disconnection. The connector jointed part shall not be wetted by clean- ing.

  • Page 212: Maintenance Of The Main Unit

    5.3.2 Maintenance of the main unit No organic solvent, such as thinner, is allowed for cleaning the main unit of the instrument, which may otherwise harm the surface of the instrument. For disconnecting the card from the power source, do not pull them with undue force.

  • Page 213: Replacing Of The Printer Paper Roll

    5.4 Replacing of the printer paper roll When the printer paper show the red marks on both sides, replace the paper roll in the following procedure. Pay attention not to have your hand cut, when opening or closing the printer cover. 1) Open the printer cover B upward.

  • Page 214: Storing Of The Instrument

    5.5 Storing of the instrument Store the instrument in a place where it is not subjected to water and chemicals. Store the instrument in a place where it is not influenced with direct sunbeams, high temperature, high moisture, dust, salts, or sulfur- contained air.

  • Page 215: Troubleshooting

    6. TROUBLESHOOTING Before judging that the instrument has trouble, check the fol- lowing items. If it has any trouble that cannot be corrected for yourself, ask your local representative for countermea- sures. Do not remove the body cover from the instrument or leave it as being opened, which will otherwise cause the operator directly ex- pose him/herself to high voltage.
  • Page 216 Broken fuse Cause 3 Take the fuses and holder apart to check if Remedy the fuses are proper or broken. If broken, change the fuses as per "5.2 How to replace the fuses". If the replacement fuse is again broken second time, the instrument may have the possibility of functional disorder.
  • Page 217 The brightness and color tone of the printout from the video printer are noticeably different from those on screen. Setup value of the video printer is not as prescribed. Cause 1 Adjust the contrast, brightness and color Remedy tone, in accordance with the Operating In- structions for the Video Printer.
  • Page 218 If the same error messages are followed every time when turn- ing the power on, ask your Tomey represen- tative for inspection and repair. The button which is different from that pressed in the touch panel was reacted.
  • Page 219 "BAD CONNECTION. TP" was displayed when the power is turned Nonconforming touch panel. Cause 1 Turn the power source off and ask your Remedy Tomey representative for inspection and re- pair. "Freeze" cannot be released by pressing the footswitch. Footswitch connection is not correct. Cause 1...
  • Page 220 No printout can be made even by pressing the SAVE/PRINT pedal for footswitch. The connection of the footswitch is not correct. Cause 1 Make sure that the footswitch is connected Remedy for secured lock. The footswitch is set for "SAVE", "SEND" or Cause 2 "SEND/SAVE".
  • Page 221 <ID number input from external device> Even when a Patient ID is input by external device, the beep sounds without showing anything on screen. The PS/2 port connection is not correct. Cause 1 Correctly connect the PS/2 port of the exter- Remedy nal connection ID input device to its corre- sponding connector located at the rear side...
  • Page 222 <Patient data inquiry to the TOMEY Link> "Comm. Busy!! Retry!!" is displayed. Because of the internal communications, communi- Cause 1 cations are not received temporarily. Give operation again after a short time of Remedy elapse. "NO ID!!" is displayed. Patient ID number has not been inputted.
  • Page 223 A-scan diaguosis function f) Setting of com- munication". As for confirming on the details of this setting, see the Operation Manual for TOMEY Link and also ask for your System Administrator. "Invalid Patient ID!! (044)" is displayed. Patient information corresponding to inputted ID Cause 1 number is not registered to the TOMEY Link.
  • Page 224 The following error messages are displayed. “Comm. ERROR!!” “Illegal Format!!” “System ERROR!! (***)” “Server Comm. ERROR!! (041)” “Server Comm. ERROR!! (043)” These errors are caused by internal Cause 1 nonconformities. Try again minutes later. If the same error is Remedy repeated many times, ask your representa- tive for inspection and repair.
  • Page 225 <Patient data transfer> The SEND button is not available. "CONNECT" is not selected in communication Cause 1 setting. Make correct setting in "3.8.2 Setting items Remedy for B-scan diagnosis assistant function/A- scan diagnosis function f) Setting of data communication" "Comm. Busy!!" is displayed. The communication cannot be established tempo- Cause 1 rarily because of internal processes.
  • Page 226 "LAN Connection ERROR!!" is displayed. LAN cable connection is not correct. Cause 1 Make sure that the connection of the LAN Remedy cable to the connector located at the rear side of the main body and to the network side (switching hub, etc.) is proper.
  • Page 227 "Registration Error!! (***) " appears. TOMEY Link server/ Conputer of DATA Transfer Cause 1 has temporary memory shortage . Send it again. If this error appears often, in- Remedy crease RAM of the computer. Software version is not correct. Cause 2...
  • Page 228 <Connection setting screen / connection test> The following error messages come up on screen. "ERROR!!(***)" "F-ROM ** NG!!" "Illegal Format!!" "SYSTEM ERROR!!(***)" These errors are caused by wrong internal process. Cause 1 If the same error message is repeatedly ap- Remedy peared, contact your representative for in- spection and repair.
  • Page 229 <B-scan image diagnosis function> The B-scan image is not displayed. The B-scan probe is not connected properly. Cause 1 Make sure the probe is connected throughly Remedy deep enough to the main unit. The B-scan image is too dark to see. The total gain setting is lower than it should be.
  • Page 230 The vector-A waveform is not displayed and/or the vector-A wave- form automatically disappears. Other function, which cannot be used with the vec- Cause 1 tor-A function, is working. The vector-A function cannot be on, while the fol- lowing functions are on duty. ·...
  • Page 231 TOTAL, CONTRAST volumes cannot be used. The volume controller is not switched as TOTAL / Cause 1 CONTRAST. Press the Volume Function Select button-1 Remedy to select it to TOTAL / CONTRAST. NEAR / FAR volumes cannot be used. The volume controller is not swithced as NEAR / Cause 1 FAR.
  • Page 232 <Assistant function of biometry> The B-scan image and the A-scan waveform are not displayed. The connection of the B-scan probe is not correct. Cause 1 Make sure that the B-scan probe is inserted Remedy sufficiently for secured connection. The B-scan images are too dark to see. The setting value of total gain is too low.
  • Page 233 The saved image loading function cannot be used. The data was not saved in the Echo Data mode. Cause 1 The memory card is not saved with data. The data, loaded on main unit, is only avail- Remedy able in the memory card with the Echo Data format.
  • Page 234 <A-scan diagnosis function> A-scan waveforms will not be on screen. The connection of the A-scan probe is not correct. Cause 1 Check if the A-scan probe is connected prop- Remedy erly as being locked. The eye protective gel was not applied or less. Cause 2 Apply an appropriate amount of corneal pro- Remedy...
  • Page 235 <Biometry function> Axial length measurement cannot be taken. The biometry probe is not properly connected. Cause 1 Connect the biometry probe until you hear Remedy click sound to be locked. See "3.2.1 b) Con- necting of the biometry probe" for details. The condition is not suitable for immersion mode.
  • Page 236 Ambient noises Cause 2 If there is any noise generation source (such Remedy as motor or laser surgery equipment) located close to this instrument, move such noise source away from the instrument. The fixation light for patient is not proper. Cause 3 Guide the patient's eye direction by using the Remedy...
  • Page 237 The measurement mode is set as auto measurement Cause 2 “Chin” or “Hand”. Set the mode as "Manual". (See "3.6.3 e) Remedy Setting of the measuring method".) Measured data is not stable or correct, which largely differs from those measured previously. The connection of the biometry probe is not cor- Cause 1 rect.
  • Page 238 The immersion attachment is used while the con- Cause 6 tact mode is selected. Ultrasound gel is too much. Use proper amount of gel and see “3.6.6 a)” Remedy for details. Biometry probe is directly attached to the cornea Cause 7 with Immersion mode.
  • Page 239 Monitoring sound (beep) for axial length keeps working. Measure- ment is taken, even when the probe is not in use. A drop of water or gel sticks on the probe tip. Cause 1 Remove the water or gel from the probe by Remedy wiping it away with soft texture.

  • Page 240: Memory Card

    <Memory card related troubles> Data cannot be saved in the memory card. The memory card is not properly inserted. Cause 1 Properly insert the memory card. See "3.2.1f) Remedy How to insert and remove the memory card". The ID number of the patient is not input. Cause 2 The ID is necessary for Echo data and Biom- Remedy...

  • Page 241: Spare Parts And Option Parts

    7. SPARE PARTS AND OPTION PARTS When the following spare parts and option parts are necessary, ask your local Tomey Representatives. 7.1 Option parts A-scan diagnostic probe Please specify "A-scan disgnostic probe for UD". Monochrome video printer Contact your local dealer for the printer...

  • Page 242: Spare Parts

    7.2 Spare parts Built-in printer paper Please specify “Built-in Printer Paper” for UD Gel for ultrasound diagnosis Please specify "Gel for ultrasound diagosis". Immersion Attachment Please specify "Immersion Attachment" for UD-6000. 7. Spare parts and option parts...

  • Page 243: Specifications

    8. SPECIFICATIONS 8.1 Specifications 8.1.1 B-scan Diagnosis Focus Dynamic focus Frame rate High: 22 frames/sec. Low: 11 frames/sec. Maximum moving images (Assistant Function of Biometry) 202 images Maximum waveform data taking number (A-scan diagnosis function) 202 images Image display range Normal: 34.5mm×46.4°...

  • Page 244: Assistant Function Of Biometry

    Image Adjustment TOTAL: 1 to 60dB (Moving image display) ±5 steps (at freeze) CONTRAST: 1 to 60dB (Moving image display) ±6 steps (at freeze) NEAR: 1 to 40dB FAR: 1 to 40dB B-scan probe Scan type: Sector scan Oscillator type: Annular array Oscillator frequency: 10MHz Dimensions and weight:...

  • Page 245: A-Scan Diagnosis

    8.1.3 A-scan Diagnosis A-scan diagnositc probe (Optional) Type: Solid type Oscillator frequency: 10MHz Tip diameter: 5.3mm∅ (flat) Dimensions and weight: 8mm∅×97mm/30g 8.1.4 Biometry/IOL power calculation Measurement range Axial length: 15.00 - 40.00mm ACD: 1.80 - 7.00mm Lens thickness: 2.00 - 6.00mm Accuracy of the instrument Measurement accuracy: ±0.1mm...
  • Page 246 IOL thickness Pseudophakic1: 0.8mm Pseudophakic2: 1.0mm Pseudophakic3: 0.8mm IOL Power Calculation Formulas SRK II SRK/T SRK (SHOWA) HOLLADAY Hoffer Q HAIGIS optimized HAIGIS standard Biometry probe Type: Solid type Fixation light: Enclosed in the probe (Red LED) Oscillator frequency: 10MHz Tip diameter: 5.3mm∅...

  • Page 247: Main Unit

    8.1.5 Main unit TFT LCD: 10.4 inch, color touch screen Dimensions and weight: W360×D427×H346mm/14kg 8.1.6 Power Source Voltage: AC 100-120V / 220-240 V Frequency: 50/60Hz Consumption power: Less than 80AV+15% * Specifications and outlook of the unit will be modified for the improve- ment of the design.

  • Page 248: Energy And Other Consumptions

    8.2 Energy and Other Consumptions 8.2.1 Influences of ultrasound energy on the human body This instrument shall not be used for any purposes other than ophthalmic application. This instrument is primarily designed as an ultrasound diag- nosis equipment for ophthalmic use. Since, therefore, the instrument is set for the application of a very weak ultrasound energy to suit the application of this instrument, use it with a minimum extent of diagnosis and...

  • Page 249: Index

    MI : the Mechanical index Ispta3 : the derated spatial-peak temporal-average intensity. Isppa3 : the derated spatial-peak pulse-average intensity. pr.3 : the deratad peak rarefactional pressure. Wo : the ultrasonic power fc : the center frequency Zsp : the axial distance at which the reported parameter is measured. x-6, y-6 : are respectively the in-plane(azimuthal) and out ofplane (elevational) -6dB dimensions in the x-y plane where Zsp is found...
  • Page 250 α : ACOUSTIC ATTENUATION COEFFICIENT Aaprt : -12dB OUTPUT BEAM AREA Deq : EQUIVALENT APERTURE DIAMETER deq : EQUIVALENT BEAM DIAMETER fawf : ACOUSTIC WORKING FREQUENCY Ipa : PULSE-AVERAGE INTENSITY Ipa, α : ATTENUATED PULSE-AVERAGE INTENSITY Ipi : PULSE-INTENSITY INTEGRAL Ipi, α...

  • Page 251: Noises

    8.3 Noises This instrument makes noises in the following processes of opera- tion. When turning the power on. When self-diagnosing. When starting to print. When pressing various keys. When measuring (such as taking measurement data). When inserting and recognizing the completion of inser- tion of the memory card When data transfer is completed When errors occur.

  • Page 252: Appendix

    Appendix Electromagnetic guidance Caution: Medical electrical equipment. EMC (Electro Magnetic Compatibility) must be considered before any medical electrical equipment is installed or put into service. Follow the information in the accompanying documentation when installing and operating the UD-6000. Caution: Portable or mobile RF communication equipment can effect Medical Electrical equipment. Guidance and manufacturer's declaration electromagnetic emissions Table 201...
