Summary of Contents for OverTek OT-3407SVW
- Page 1 OT-3407SVW/UX 4 Ports + 3 SFP Gigabit Smart Switch User Manual Ver.A0...
-
Page 2: Table Of Contents
DIRECTORY ..........15 Chapter 1 Product Specification ........1 5.3 Software Upload ........1 5.4 Configuration File Transfer ........15 1.1 Product Characteristics ............16 ........1 5.5 Logout 1.2 Product Specifications .........3 Chapter 6 Command Line Interface ......16 1.3 Package Contents ..........16 6.1 Com Port Set-up Chapter 2 Hardware Installation ........3 .........3... -
Page 3: Chapter 1 Product Specification
Chapter 1 Product Specification 1.1 Product Characteristics IEEE802.3, 802.3u, 802.3ab, 802.3x Standards Wire-speed Performance Complies with IEEE802.3，IEEE802.3u，IEEE802.3ab standards; MAC Address Auto-Learning and Auto-aging 4 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Basic Function IEEE802.3x flow control for Full-Duplex Mode Auto-MDI/MDIX and 3 SFP independent expansion slots supporting and backpressure for Half-Duplex Mode Mini GBIC module;... -
Page 4: Package Contents
1.3 Package Contents Chapter 3 Configuration Guide 1 piece of 7-port Ethernet Switch 3.1 Fast Log on 1 piece of external power adapter Notice: You may have to configure a new IP for a managing computer, 1 piece of console cable because default switch IP is 192.168.2.1. -
Page 5: System Configuration
3.2 System Configuration Here provides current switch status and you can set them according to your demands. MAC address： Software Version ： Hardware Version ： Active IP Address：192.168.2.1（in default ） 255.255.255.0（in default） DHCP Server：0（in default） Lease Time Left：0（default） 3.4 VLANs Configuration Can set 16 VLAN groups for 802.1q VLAN 3.3 Port Configuration Here provides port status and available to set speed and flow... -
Page 6: Lacp Configuration
3.6 LACP Configuration 3.8 802.1X Configuration LACP(IEEE 802.3ad Link Aggregation Protocol) provides a way to set Here provides 802.1X process and available to set for each port of the up aggregation between switches automatically. switch. 3.7 RSTP Configuration 3.9 IGMP Configuration RSTP is a protocol that prevents loops in a network and dynamically it reconfigures to forward frames. -
Page 7: Mirroring Configuration
3.12 Filter Configuration Set source IP filter through ports to block unwanted access. 3.10 Mirroring Configuration Bandwidth of mirror port should be larger or equal to that of mirror source. 3.13 Rate Limit Configuration Policer/ShaperSpeed(options):128kbps, 256kbps, 384kbps, 512kbps, 640kbps, 768kbps, 836kbps, 896kbps, 1024Mbps, 1152kbps, 1280kbps, 1408kbps, 1536kbps, 1664kbps, 1792kbps, 1920kbps, 2048kbps, 2176kbps, 2304kbps, 2432kbps, 2560kbps, 2688kbps, 2816kbps, 2944kbps, 3072kbps, 3200kbps, 3328 kbps,... -
Page 8: Storm Control Configuration
3.14 Storm Control Configuration Broadcast Control speed(options): 1kfps, 2fps, 4fps, 8fps, 16fps, 32fps, 64fps, 128fps,256fps, 512fps, 1024fps, 2048fps, 4096fps, 8192fps, 16384fps, 32768fps. 4.3 LACP Status Here provides LACP port Status. Chapter 4 Monitoring Guide 4.1 Statistics Overview Here provides statistics of current forwarding and receiving data. 4.4 RSTP Port Status Here provides RSTP port Status. -
Page 9: Igmp Status
4.7 Ping Ping function is used to test connection between the switch and destination. 4.5 IGMP Status Here provides IGMP Status. Chapter 5 Maintenance Guide 5.1 Warm Restart 4.6 VeriPHY Warm Restart : click “Yes” to start restart the switch. 5.2 Factory Default Restore Factory Configuration: click “Yes”... -
Page 10: Software Upload
Chapter 6 Command Line Interface 6.1 Com Port Set-up To use the command line interface you may connect a PC COM port 5.3 Software Upload to the RS-232 connector and activate a terminal program, e.g. Update process takes about 1 minute, the switch reboots HyperTerminal under Windows. -
Page 11: Help Utility
6.4 Help Utility Syntax: You may get help by pressing the ? key or entering “help”. The help info Console Password [<password>] depends on the context: At top level, a list of command groups is displayed. At group level, a list of the command syntaxes for the current group is Description: displayed. -
Page 12: Sfp Fiber Optic Module Components Description
7.2 SFP fiber optic module components description Step 3 Insert it with right fiber optic cable. Matching fiber optic cables according to spec label are required to avoid of possible damage, and to get maximum effective transmission distance of optical signal. -
Page 13: Specification On Fiber Optic Connection
7.5 Specification on fiber optic connection Be sure of that Tx of interface is connected to Rx of its opposite end, and Rx to Tx of its opposite end. Be sure of cleanliness of optical interfaces Limit shrapnel LC connector 7.6 Notes on optical used Please do not directly look at optical interface when no optical connectors or dust covers fixed on, because invisible rays from it...
