User Manual: LS4195
DMX-controlled RGB LED 4-Spot T-Bar
■ Maintenance
This unit does not need regular maintenance. The internal circuit is protected by a
USER MANUAL
250V/2A slow-blow fuse 5x20mm fuse. If this fuse fails, this usually indicates an
internal fault requiring servicing by a qualified engineer. The fuse shall only be replaced
by a fuse of same specification, and the replacement has to be made by qualified
LS4195 MultiBar
personnel obeying applicable safety rules.
DMX-controlled RGB LED 4-Spot T-Bar
■ Technical data LS4195 MultiBar DMX-controlled RGB LED 4-Spot T-Bar
LED.................788pcs.x5mm 0.06W LEDs
[4 panels with each
49red/96green/52blue]
ENGLISH Page 2-16
Mains Input....................................................................... AC90-250V~ 50/60Hz
Power supply type...........................................................................switch mode
Power Consumption.........................................................................max. 55.2W
Fuse..........................................................250V 2A T (slow blow, 5x20mm glass)
Sound control........................internal microphone with Automatic Gain Control (AGC)
DMX connections.........................................................3 pin XLR (Male / Female)
Modulation Type.........................................Advanced Bit Angle Modulation (ABAM)
Control protocol.......................................................................................DMX 512 (1990)
Dimensions ...........................................................L
916.0 x H 297.4 x D 62.5mm
Weight ..................................................................................................7,2 kg
■ Standards
This product complies with the following standards:
EU safety................................................................EN60598-1:2008, EN60598-2-1:1989
EU EMC.......................................EN55015: 2006 + A1:2007, EN61547:1995 + A1:2000
EU Harmonics ...................................................................................EN61000-3-2:2006
EU Flicker ............................................................................EN61000-3-3:2008
US safety ..........................................................................................UL60065
US EMC........................................................................................FCC Part 15
This product meets both the EMC Directive 2004/108/EC and the Low Voltage Directive
2006/95/EC.
16
V1.00 (01-2010) © Multiform Lighting
RevA 01/2010 Order code: 12-010-0353-80100-1-01
Advertisement
Summary of Contents for Multiform LS4195 MultiBar
-
Page 1: User Manual
LS4195 MultiBar personnel obeying applicable safety rules. DMX-controlled RGB LED 4-Spot T-Bar ■ Technical data LS4195 MultiBar DMX-controlled RGB LED 4-Spot T-Bar LED.…………..788pcs.x5mm 0.06W LEDs [4 panels with each 49red/96green/52blue] ENGLISH Page 2-16 Mains Input….…………………………………………………………. - Page 2 25 seconds the display is switched off. As soon as one of the put in us with this decision. Multiform is one of the leading global manufacturers of buttons is pressed again, the display switches on immediately. In this case the first professional equipment and has decades of experience in design, production and touch of the button is ignored in respect to the normal function of that button.
-
Page 3: General Advice
RGB LED 4-Spot T-Bar – do not use other footswitches, this may damage protection. the unit. The 4 foot pads on the LC400F control the LS4195 MultiBar DMX-controlled Where the mains plug or an appliance coupler is used as a dis-... - Page 4 All on Run right security check. in /out Run left left / right Random To meet all aspects of functionality and security during mainte- V1.00 (01-2010) © Multiform Lighting V1.00 (01-2010) © Multiform Lighting...
- Page 5 000-127 = Master dimmer (overall weighting to the values received on CH13/14/15), Strobe off Main parts: 1 pcs. LS4195 main unit 128-227 = Strobe (128= slow / 227= max. speed 23 Hz) 1 pcs. Flightcase 228-255 = Master dimmer full on, Strobe off 1 pcs.
- Page 6 001, and mirrors the received data on the DMX output. Main audience. Make sure pull force on a cable can not make the tripod fall over. purpose is to receive a signal from a master-unit of the Multiform LS4195 being in •...
- Page 7 (8); note that pattern 33 is excepted As an alternative to tripod mounting, the LS4195 MultiBar DMX-controlled RGB LED 4- from this. In this case, the middle decimal point LED (4) flashes with the beat of the Spot T-Bar can be truss-mounted by means of two M10 mounting points which are music.
- Page 8 Risk of fire / Safety risk: The AC socket providing power to the 5 Soft Fade for program change in C/CP-Mode LS4195 MultiBar DMX-controlled RGB LED 4-Spot T-Bar must be 6 Brightness reduction by 25% in A-/F-Modes properly and separately earthed. Do not use any other AC cords than...
