TIARA PETITE B
DIRECT VENT ROOM HEATER
Model:
TIARAP-BK
TIARAP-BR
TIARAP-CES
• Important operating and
maintenance instructions
included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- Do not try to light any appliance.
Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory-trained
professionals, or technicians supervised by an NFI
certifi ed professional.
CAUTION
DO NOT DISCARD THIS MANUAL
• Read, understand and
follow these instructions
for safe installation and
operation.
Heat & Glo • Tiara Petite B • 7026-101 Rev. N • 10/11
Owner's Manual
• Leave this manual with
party responsible for use
and operation.
WARNING
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in the same room as
appliance
• Alert children and adults to hazards of high temperatures
High temperatures may ignite clothing or other
fl ammable materials.
• Keep clothing, furniture, draperies and other combustibles
away.
In the Commonwealth of Massachusetts:
• installation must be performed by a licensed plumber or
gas fi tter.
See Table of Contents for additional Commonwealth of
Massachusetts requirements.
This appliance may be installed as an OEM installation in
manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer's instructions and
the manufactured home construction and safety standard, Title
24 CFR, Part 3280 or Standard for Installation in Mobile Homes,
CAN/CSA Z240MH.
This appliance is only for use with the type(s) of gas indicated on
the rating plate.
Installation and Operation
O-T L
O-T
Tested and
Listed by
C
US
OMNI-Test Laboratories, Inc.
HOT SURFACES!
Glass and other surfaces are
hot during operation AND cool
down.
Portland
Oregon USA

Advertisement

Table of Contents
loading

Related Manuals for Heat & Glo TIARAP-BK

Summary of Contents for Heat & Glo TIARAP-BK

  • Page 1 TIARA PETITE B DIRECT VENT ROOM HEATER Model: O-T L Portland Tested and Listed by Oregon USA TIARAP-BK OMNI-Test Laboratories, Inc. TIARAP-BR TIARAP-CES CAUTION DO NOT DISCARD THIS MANUAL • Read, understand and • Important operating and • Leave this manual with...
  • Page 2 Read this manual before installing or operating this appliance. Please retain this owner's manual for future reference. Congratulations Congratulations on selecting a Heat & Glo gas appliance - an This Owner's Manual should be retained for future reference. elegant and clean alternative to wood burning appliances. We suggest that you keep it with your other important The Heat &...

  • Page 3: Table Of Contents

    - TABLE OF CONTENTS - Section 7: Electrical Information Section 1: Listing and Code Approvals A. Recommendation for Wire ....29 A. Appliance Certifi cations ......4 B. Connecting to the Appliance ....29 B. Glass Specifi cations ......4 C. Standing Pilot Ignition System C.

  • Page 4: Section 1: Listing And Code Approvals

    Listing and Code Approvals A. Appliance Certifi cation C. Specifi cations *Steady MODEL Tiara Petite B Maxi- Mini- Orifi ce State Model **P.4 LABORATORY OMNI-Test Laboratories, Inc. Size Effi - (US or Canada) Input Input (DMS) ciency 061-S-47b-5 TYPE Vented Gas Fireplace Heater Tiara Petite B 17,000 12,000...

  • Page 5: Requirements For The Commonwealth Of Massachusetts

    Inspection NOTE: The following requirements reference various The state or local gas inspector of the side wall horizontally Massachusetts and national codes not contained in this vented gas fueled equipment shall not approve the installa- document. tion unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with G.

  • Page 6: Section 2: Getting Started

    Getting Started C. Inspect Appliance & Components A. Design & Installation Considerations Heat & Glo direct vent gas appliances are designed to oper- ate with all combustion air drawn from outside of the building WARNING and all exhaust gases expelled to the outside. No additional air source is required.

  • Page 7: B. Clearances To Combustibles

    Appliance Location and Clearances NOTE: WARNING · Illustrations refl ect typical installations and are FOR Fire Risk DESIGN PURPOSES ONLY. Provide adequate clearance: · Illustrations/diagrams are not drawn to scale. • Around air openings · Actual installation may vary due to individual design •...

  • Page 8: Section 4: Termination Locations

    Termination Locations A. Vent Termination Minimum Clearances HORIZONTAL WARNING OVERHANG Fire Risk. 2 FT. 20 INCHES MIN. VERTICAL MIN. Explosion Risk. WALL LOWEST Maintain vent clearance to combustibles DISCHARGE as specifi ed. OPENING GAS DIRECT VENT • Do not pack air space with insulation or TERMINATION CAP other materials.
  • Page 9 (See Note 2) U.S. (3 FT) Electrical Service J or K = VENT TERMINAL = AIR SUPPLY INLET = AREA WHERE TERMINAL IS NOT PERMITTED = 3 ft. (U.S.A.) = 12 inches ..... clearances above grade, veran- 6 ft. (Canada) ..clearance to a mechanical (See Note 1) da, porch, deck or balcony (powered) air supply inlet...

  • Page 10: Section 5: Vent Information

    Vent Information A. Venting Components B. Use of Elbows In order to comply with applicable codes and product warranties, use only following venting components: CAUTION • Hearth & Home Technologies (HHT) ALL vent confi guration specifi cations MUST be followed. •...

  • Page 11: How To Use The Vent Graph

    How to Use the Vent Graph Venting Guidelines Notes: Measure the distance from the top of appliance to the • The maximum horizontal vent run is 15 ft. (5m) when the center of the 90° elbow. On the graph below, draw a vertical vent rise is 10 ft.

  • Page 12: Horizontal Termination

    F. Horizontal Termination WARNING Fire Hazard. Type A - Up & Out Installation Exhaust Fume Risk. Impaired Performance of Appliance. TERMINATION CAP 90° ELBOW • Ensure vent components are locked together correctly. CENTER LINE • Pipe may separate if not properly joined. PIPE LENGTH WALL THIMBLE Step 2.
  • Page 13 Step 3. Step 4. For installations using a round support box/wall thimble Position the horizontal termination cap in the center of the 10 (check pipe manufacturer's instructions), mark the wall for a in. x 10 in. (254mm x 254mm) square hole and run a bead 10 in.
  • Page 14 Note: The attachment from the vent pipe to the vent (NOTE: Some termination caps may cause the vent pipe to be off center on flashing). Ensure that proper termination cap must be sealed with silicone. Termination clearances to combustible materials are maintained. caps shall not be recessed into a wall or siding.

  • Page 15: Vertical Termination

    G. Vertical Termination 1. Direct Vent Pipe VERTICAL TERMINATION STORM COLLAR 25 ft. (8m) FLASHING MAXIMUM FIRESTOP SUPPORT BOX PIPE LENGTH Figure 5.11 Step 2. et the gas appliance in its desired location. Drop a plumb bob down from the ceiling to the position of the appliance flue exit, and mark the location where the vent will penetrate the ceiling.
  • Page 16 Step 3. To install the round support box/wall thimble cover in a flat CAP AND STORM ceiling, cut a 10 in. (254mm) square hole in the ceiling, Shingles overlap on COLLAR NOT SHOWN top edge of flashing centered on the hole drilled in Step 2. Frame the hole as FOR CLARITY shown in Figure 5.13.
  • Page 17 Step 9. Twist-lock the vent cap and seal. Note: For multi-story vertical installations, a ceiling firestop is required at the second floor, and any subsequent floors (Figure 5.16). The opening should be framed to 10 in. x 10 in. (254mm x 254mm) inside dimensions, in the same manner as shown in Figure 5.13 on page 16.
  • Page 18 2. Cathedral Ceiling Step 1. Follow installation Steps 1 and 2 under vertical installation section, page 15. Step 2. Remove shingles or other roof covering as necessary to cut the rectangular hole for the support box. Cut the hole 1/8 in. (3mm) larger than the support box outline.
  • Page 19 3. Class A Metal Chimney Step 4. Pass the flex pipe down through the center of the chimney system, and center the top adapter on the top of the chimney pipe. Drill four 1/8 in. (3mm) diameter holes through the TERMINATION top adapter, and into the chimney top.
  • Page 20 4. Existing Masonry Chimney Type A & B Co-Axial to Co-Linear CHIMNEY LINER CHIMNEY LINER TERMINATION TERMINATION CAP 25 ft. (8m) OF 3 in. (76mm) FLEX LINER EXHAUST SECTION 3 in. (76mm) THIS SECTION OF CO-AXIAL TO FLEX LINER THE CHIMNEY MUST CO-LINEAR BE SEALED CO-AXIAL TO...
  • Page 21 CAUTION Cut and bend flashing as needed to fit Ensure that existing chimney is functionally sound and clean. • Have inspection done by qualified chimney sweep or professional installer BEFORE converting to direct vent appliance. Step 1. Before cutting any holes, assemble the desired sections of direct vent pipe to determine the center of the masonry penetration.
  • Page 22 Flex Liner 6 in. (152mm) diameter opening in masonry wall Flex Coupler Sheet Metal Screws Retro Connector (3) Masonry Bolts Figure 5.27 (Not included) Figure 5.29 Step 8. Secure the top adapter to the flashing. Use three sheet Step 10. metal screws through the side of the top adapter into the Slide wall thimble cover over retro connector and secure flange on the flashing (Figure 5.28).

  • Page 23: Slim Line Wall Thimble

    Slim Line Wall Thimble BEFORE YOU BEGIN: Review the venting confi gurations in Figures A, B and C on the next page. 1. Assembling Slim Line Trim Ring and Heat Shield Figure 5.33 Attach the heat shield to the trim ring with the four screws provided.
  • Page 24 FIG. A 90 DEGREE ELBOW PLACE MARK WHERE PROTRUDES THROUGH EXTERIOR WALL TO CUT OFF EXCESS 90° ELBOW CENTER LINE TERMINATION CAP HEAT SHIELD PIPE LENGTH OVER PIPE TRIM RING PIPE LENGTH FIG. B 45 DEGREE ELBOW TRIM RING HEAT SHIELD OR WALL THIMBLE OVER PIPE 45°...

  • Page 25: Section 6: Gas Information

    Gas Information A. Fuel Conversions PILOT HOOD MILLIVOT GENERATOR THERMOCOUPLE Before making gas connections ensure that the appliance being installed is compatible with the available gas type. Any natural or propane gas conversions necessary to meet ALIGNMENT NOTCH the appliance and locality needs must be made by a qualifi ed technician using Hearth &...
  • Page 26 2. Valve Regulator Replacement Screws WARNING Fire Risk. Explosion Risk. • Disconnect any electrical cords and turn off gas supply to unit before Rubber Gasket proceeding if converting fuel on an appliance already fully installed. Identification Label Remove upper and lower back shield. Loosen the set col- lars on the extension rods with the 3/32 in.

  • Page 27: Gas Pressures

    B. Gas Pressures C. Gas Connection Proper input pressures required for optimum appliance per- formance, gas line sizing requirements need to be followed NOTE: Have the gas supply line installed in accordance with from NFPA51. local building codes, if any. If not, follow ANSI Z223.1. Instal- lation should be done by a qualifi...
  • Page 28 HIGH ALTITUDE INSTALLATIONS WARNING Omni-Test Laboratories, Inc. listed gas appliances are tested and Fire Risk or Explosion Hazard. approved without requiring changes for elevations from 0 to 2000 • Gas build-up during line purge may ignite. feet in the U.S.A. and 0 to 4500 feet in Canada. •...

  • Page 29: Section 7: Electrical Information

    Electrical Information A. Recommendation for Wire Ensure the thermostat is mounted level for accurate See B5 below for recommended maximum lead length (two readings. wire) when using wall thermostat/switch. The thermostat should be mounted on an inside wall and not in direct line with the appliance convection air. NOTE: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence 10.

  • Page 30: Ignition Module Access And Battery Replacement

    PILOT ASSEMBLY Ignition Module TPTH Black ON/OFF Switch Black VALVE Figure 7.1 CAUTION CAUTION Shock hazard. Label all wires prior to disconnection when servicing controls. • Replace damaged wire with type 105 Wiring errors can cause improper and dangerous operation. rated wire.

  • Page 31: Section 8: Appliance Setup

    Appliance Setup A. Remove Shipping Materials C. Flue Restrictor Installation Remove shipping materials from inside or underneath the When your installation falls within a shaded area on the vent fi rebox. graph (page 11), a fl ue restrictor must be installed for proper operation.

  • Page 32: Intake Damper Operation

    D. Intake Damper Operation F. Positioning the Logs The intake damper can be used with or without the fl ue While still breakable, the logs do not become fragile until restrictor to adjust the air fl ow. Opening the damper makes after the appliance is burned and they have cured.

  • Page 33: Mineral Wool

    H. Accessories Install approved accessories per instructions included with accessories. Refer to Section 12 for appropriate accesso- ries. WARNING Shock or fi re risk. Use ONLY optional accessories approved for Figure 8.10 Place the twig with the center resting on the fl at this appliance.

  • Page 34: Blower Installation

    I. Blower Installation KIT CONTENTS: 1 - Blower Mounted in Housing 2 - Speed Control Knob 3 - Pal Nut 4 - Ceramic Snap Disk 5 - Speed Control (Rheostat) 6 - Wire Harness (attached to Blower) 7 - 12 Screws 8 - 12 inch Glass Tape 9 - 1 Zip Tie Figure 8.13...
  • Page 35 Plug in the blower. The blower will not run until the appliance has heated up enough to activate the snap disc. This can take up to 15 minutes depending on the temperature of the room. Likewise, the blower will not automatically turn off until the appliance has cooled off enough to turn off the snap disc.

  • Page 36: Glass Replacement

    VARIABLE SPEED CONTROL JUNCTION BOX BLOWER RECEPTACLE BLACK BLACK WHITE GROUND TEMPERATURE SENSOR SWITCH BLOWER GREEN BLACK 110 - 120 VAC POWER SUPPLY Figure 8.19 Complete Assembly J. Glass Replacement Turn the appliance OFF and let it cool down before replacing the glass.

  • Page 37: Section 9: Operating Instructions

    Operating Instructions A. Before Lighting Appliance WARNING Read this entire manual prior to using the appliance. Failure to follow the instructions may result in property damage, Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to bodily injury, or even death.

  • Page 38: Lighting Appliance

    C. Lighting Appliance FOR YOUR SAFETY READ BEFORE LIGHTING FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life A. This appliance has a pilot that must be lit manually. When lighting the pilot, follow these instructions exactly. B.

  • Page 39: After Appliance Is Lit

    D. After Appliance is Lit CAUTION Initial Break-in Procedure • Prevent accidental appliance operation when not When you light your appliance, you may notice that it pro- attended. • Unplug or remove batteries from remote control if absent duces heat which does have an associated odor or smell. If or if appliance will not be used for an extended period of you feel this odor is excessive it may require the initial three time.

  • Page 40: Section 10: Troubleshooting

    Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualifi ed service person in the diagnosis of a problem and the corrective action to be taken.
  • Page 41 Symptom Possible Cause Corrective Action 3. (Continued) c. Defective valve. Turn the valve knob to the ON position. Place the ON/OFF switch in the ON position. Check the millivolt meter at the thermopile terminals. The millivolt meter should read greater than 125mV. If the reading is acceptable, and if the burner does not come on, replace the gas valve.

  • Page 42: Maintaining And Servicing Appliance

    Maintaining and Servicing Appliance Although the frequency of your appliance servicing and CAUTION maintenance will depend on use and the type of installation, a qualifi ed service technician should perform an appliance Handle glass assembly with care. check-up at the beginning of each heating season. NOTE: Clean glass after initial 3-4 hours operation.

  • Page 43: Maintenance Tasks

    A. Maintenance Tasks Inspect Maintenance Tasks Doors 1. Inspect for scratches, dents or other damage and repair as necessary. 2. Verify no obstructions to air fl ow. 3. Verify maintenance of proper clearance to combustible household objects. Gasket Seal, Glass 1.

  • Page 44: Section 12: Reference Materials

    Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For clearances to combustibles refer to Section 3. Location Inches Millimeters Location Inches Millimeters 18-1/8 22-3/4 15-3/8 16-1/4  Figure 12.1 Appliance Dimensions Heat & Glo • Tiara Petite B • 7026-101 Rev. N • 10/11...

  • Page 45: Vent Components Diagram

    B. Vent Components Diagram 6-3/8 in. (162mm) 6-1/2 in. (165mm) 9-1/4 in. (235mm) 6-1/2 in. (165mm) 9-5/8 in. 6-3/8 in. (244mm) (162mm) 6-5/8 in. (168mm) SLP45-BK 6-5/8 in. (168mm) 9-5/8 in. SLP90M (244mm) 17-24 in. 6-1/2 in. (432-610mm) (165mm) 11-3/4 in. (298mm) 5-3/4 in.
  • Page 46 C. Vent Components List Description HHT SLP Simpson ® M= Multi Pack (6) Dura-Vent DirectVent Pro 4” Pipe Length, Galvanized SLP4M 4” Pipe Length, Black SLP4-BK 6” Pipe Length, Galvanized SLP6M 46-DVA-06 6” Pipe Length, Black SLP6-BK 46-DVA-06B 9” Pipe Length, Galvanized 46-DVA-09 9”...

  • Page 47: Vent Components List

    C. Vent Components List (continued) Simpson HHT SLP ® Description Dura-Vent M= Multi Pack (6) DirectVent Pro ° 0 ° 0 ° 0 ° 0 Adjustable Flashing, 0/12-6/12 SLP-RF6M 46DVA-F6 Adjustable Flashing, 7/12-12/12 SLP-RF12M 46DVA-F12 c i t ” 2 Attic Insulation Shield, Adjustable 11”-20”...

  • Page 48: Service Parts List

    TIARA PETITE B D. Service Parts Direct Vent Stove Color SKU No. Mfg. Dates Color SKU No. Mfg. Dates Almond TiaraP-AL 6/04-8/05 Matte Black TiaraP-BK 6/04-Active Almond TiaraP-AL-B 8/05-3/07 TiaraP-BR 6/04-Active Brown Green TiaraP-GR 6/04-8/05 Espresso Tiarap-CES 9/07-Active Tuscan Olive...
  • Page 49 DESCRIPTION COMMENTS: PART NUMBER Log Set Assembly LOGS-TPB Log 1 7026-106 7026-105 Log 2 Log 3 7026-107 TIARAP-AL 476-0010PAL TIARAP-AL-B 476-0010CAL TIARAP-BK 476-0010BK TIARAP-BR 476-0010PBR TIARAP-CES 476-0010CES TIARAP-CTO 476-0010CTO TIARAP-GR 476-0010PGR Baffl e 7016-125 Baffl e, Back 7016-126 TIARAP-AL 476-0020PAL...
  • Page 50 TIARA PETITE B D. Service Parts Beginning Manufacturing Date: 4-04 Direct Vent Stove Ending Manufacturing Date: ______ # 20 Firebox Assembly 20.3 20.1 20.2 20.4 20.5 20.10 20.6 20.9 20.7 20.8 IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number.
  • Page 51 Blower Assembly (Optional) BK-GAS Burner Stop 7010-152 Burner Support 7016-120 Component Pack TIARAP-AL 7026-007 TIARAP-AL-B 7026-010 TIARAP-BK 7026-003 Contains Warranty card, On/Off valve, mineral wool, TIARAP-BR 7026-008 leveling assembly, snap disc bracket, restrictor, owners TIARAP-CES 7026-011 manual, fasteners, touch-up paint TIARAP-CTO 7026-012...

  • Page 52: Limited Lifetime Warranty

    E. Limited Lifetime Warranty Hearth & Home Technologies Inc. LIMITED LIFETIME WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance...
  • Page 53 E. Limited Lifetime Warranty (continued) WARRANTY CONDITIONS: WARRANTY EXCLUSIONS: This warranty is void if: LIMITATIONS OF LIABILITY: 4021-645C 12-29-10 Page 2 of 2 Heat & Glo • Tiara Petite B • 7026-101 Rev. N • 10/11...

  • Page 54: Contact Information

    F. Contact Information Heat & Glo, a brand of Hearth & Home Technologies Inc. 7571 215 Street West, Lakeville, MN 55044 www.heatnglo.com Please contact your Heat & Glo dealer with any questions or concerns. For the location of your nearest Heat & Glo dealer, please visit www.heatnglo.com.
