Summary of Contents for Green-Box Technology VS-201H
- Page 1 2/4/8-Port 350MHz Video Splitter VS-201H VS-401H VS-801H User Manual V1.0 www.green-box.com.tw www.data-av.com...
-
Page 2: Package Content
DC Power Adapter (DC 9V / 500mA) x 1 User Manual x 1 2. Product Introduction The main function of VS-201H/VS-401H/VS-801H is broadcasting one VGA source to multiple monitors each at 350MHz video outputs. It allows VGA Screen sharing multiple devices, including the projector, PDP, LCD TV. In addition, they also transfer the video signals within distances up to 65m. -
Page 3: Product Descriptions
2/4/8-Port 350MHz Video Splitter 5. Product Descriptions VS-201H VS-801H VS-401H Power To Monitor Status Display VGA Input (To PC) 3 / 8... -
Page 4: Installation
2/4/8-Port 350MHz Video Splitter 6. Installation and Operation 6.1 Installation (1) Plug the power adapter into the video splitter, the front panel's power LED should turn Green. (2) Use VGA Cable (Male-Female), plug female connector to video splitter's" INPUT", the other male connector to VGA resource (PC/Notebook's VGA port or standard VGA output port). -
Page 5: Operation
2/4/8-Port 350MHz Video Splitter 4/8-Port Video Splitter Connection 6.3 Operation (1) ACTIVE LED turns orange: VGA signal is connected. (2) POWER LED turns blue: Power adapter is on. 5 / 8... -
Page 6: Specifications
VGA source to VGA source to the VGA Signal 4 VGA outputs, 8 VGA outputs, outputs, 350MHz 350MHz 350MHz VS-201H VS-401H VS-801H Model No. Monitor Wires VGA Cable 1M Cable Distance 65m (200 feet) Max Signal Type VGA, SVGA, XGA, Multi-sync, TFT-LCD monitor... - Page 7 2/4/8-Port 350MHz Video Splitter 8. Remarks Before operating this system, please read operation manual carefully. II. Please use correct power adapter and use high quality cable for optimum broadcasting. III. To prevent potential power damage, pleaVH GRQ¶ W XVH Z L U H H[ W HQVL RQ FRU G and ensure AC outlets at relative devices on the same electronic phase and have correct grounding.
- Page 8 RoHS. E\ * U HHQ % R[ Green-Box Technology Co. Ltd. reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of Green-Box Technology Co.
