Summary of Contents for giff audio alana
- Page 1 INSTALLATION AND OPERATING MANUAL...
- Page 2 OPERATION INSTRUCTIONS: UNPACKING: When removing the Alana from the shipping carton, care must be taken. Use a sharp knife to carefully open the box, being careful not to extend the knife into the box. Once the box is opened, the packing material may be box.
- Page 3 “POWER” switch. To avoid source turn on noise, it is best to turn the Alana on after the source is powered and before the ampli er is turned on. The LED above the switch will light when the power is on. The volume should not be turned up until it has had a couple minutes to warm up and stabilize.
- Page 4 The Alana is heavy and should be placed on a sturdy support. A lot of heat is generated and there should be several inches of ventilation room around the unit. Excessive heat build up will decrease the life of the components inside.
- Page 5 To remove the top/side panel, loosen and remove the allen bolts from the top and bottom of the Alana. The t is very tight to minimize vibrations during use, so handle it carefully. The tubes are inserted as shown in the diagram below.
- Page 6 TWO YEAR WARRANTY: Gill Audio Design warrants that all products have been carefully tested, inspected, and warranted for two (2) years from the date of original purchase. This includes parts and labor for all internal components. Vacuum tubes are covered for 90 days.
- Page 7 SPECIFICATIONS: Type: Solid state Integrated Ampli er Gain: 12dB with 15 Volt maximum output Distortion: 0.5% Output Impedance: 500 ohms Frequency Response: 20Hz - 20kHz full output Input Impedance 50 kohms S/N Ratio: 90dB. Dimensions: 16.5" x 15" x 4.5" [ W x D x H ] Weight:: 35 lbs.
- Page 8 4 GRE AT VIE W AVENUE NORTH. PROVIDENCE , RI 029 0 4 401.226.5299...
