- Page 1 TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay 1901 B 2101 B 2401 B WNER’S ANUAL Supplement...
-
Page 2: Table Of Contents
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Table of Contents Preface ............3 Fuel System ..........20 Hull Identifi cation Number ......3 Static Electricity and the Fuel System ..20 Explanation of Safety Labels ....... 4 Ethanol-Blended Fuel ........ -
Page 3: Preface
This document discloses subject matter in which Trophy has proprietary rights. The information and design disclosed herein were originated by and are the property of Trophy. Neither receipt nor possession thereof confers or transfers any right to produce, copy, alter or disclose the document or any part thereof, any information contained therein, or to construct boats or any item from it, except by written permission from or written agreement with Trophy. -
Page 4: Explanation Of Safety Labels
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Explanation of Safety Labels Safety Precautions The examples below are of precautions which appear The most important aspect of boating is safety. throughout this manual and must be observed when Although ever y effor t is made to add ress the operating or servicing your boat. -
Page 5: Legally Mandated Equipment (Minimum Required)
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Additional Recommended Equipment for Legally Mandated Equipment Safe Operation (Minimum Required) In addition to the legally mandated equipment, the following items are necessary for safe boating, especially Consult your National Boating Law Enforcement if your boat is out of sight of land. -
Page 6: General Considerations
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Fire Avoidance & Safety On the water there are no marked traffic lanes, no traffic Fire and explosion can be avoided by: signs or lights, and boats have no turn signals. The boat operator must keep her or his attention focused not only •... -
Page 7: Homeland Security Restrictions
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay WARNING WARNING • A n y o n e w h o c o n t r o l s t h e b o a t Wet decks are slippery. Wear proper footwear should have taken a boating safety course and use extreme caution on wet surfaces. -
Page 8: Servicing Your Boat
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Servicing Your Boat An Australian Builder’s plate means that your boat has been certifi ed to comply with safety standards set When your Boat needs to be serviced or regular by the National Marine Safety Committee. -
Page 9: Power Capacity
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Power Capacity Specifications & Dimensions The certification plate, as well as “Specifications & 1901 Bay Dimensions” has the maximum rated power listed for Overall Length 19’6” 5.94 m your boat. -
Page 10: Standard Features
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Standard Features Bow Casting Deck 208 qt. (196.8 L) Insulated Fishbox w/Overboard Drain (starboard thru-hull) Trolling Motor Panel (Option) Pull Up Bow Cleat Forward jump Seat w/Optional Cushions (P&S) - Page 11 TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Standard Features (Cont’d) Stainless Steel Thru Hull Fittings Raw Water Washdown Stainless Steel Fixed Cleats (4) Gunnel Mounted Rod Holders (2) Console Grab Rail Acrylic Windshield Electric Horn Console Vertical Rodholders (6, 3 ea.
- Page 12 TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Standard Features (Cont’d) 4 5 6 92 qt. (87 L) forward port fi shbox/storage* FWD Starboard Lockable Rod Storage* 115 EXLPT Optimax Mercury engine with Bay Star hydraulic Steering (1901 Bay)
-
Page 13: Seating
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Seating Forward Console Seat W/Backrest 94 qt. (88.9 L) Cooler Seat W/Reversible Backrest Leaning Post W/ Rocket Launchers (Option) Aft Bench Seat W/ Removable Backrest (Option) Forward Jump Seats W/cushions (P&S)*... -
Page 14: Optional Features
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Optional Features Mercury SmartCraft Gauges MP3 Receptacle Electric Trim Tab Control Pad* Stereo** Northstar 710 VHF Radio* Electronics*** Magnetic Compass* Aft Bench Seat w/Removable Backrest Stern casting chair base plate... - Page 15 TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Optional Features Available (not shown) Aluminum Single Axle Trailer Mechanical and Electrical • Dual Battery Switches • Torsion Suspension • Electric Jack Plate • LED Lighting • MotorGuide Great White hand-control •...
-
Page 16: Through Hull Locations
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Through Hull Locations NOTICE Transom • The deck drain provides self-bailing capabilities while the boat is static in the water and no passengers on board. This feature prevents the accumulation of water in the cockpit. -
Page 17: Label Location
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Label Location Proposition 65 WARNING CAUTION TRAILERING ENGINE WITH SEAT A wide variety of components used on this vessel contain or emit chemicals known to the State of... -
Page 18: Instrument Panel
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Instrument Panel Tachometer Speedometer HORN Fuel Gauge Voltmeter Horn Push Button Horn Breaker BILGE Navigation Lights Switch FUEL LIVEWELL Navigation Lights Breaker Bilge Pump Switch WASH DOWN Bilge Activation LED... -
Page 19: Gear Shift & Throttle Control
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Gear Shift & Throttle Control CAUTION To reverse power, bring the control lever back to engage the reverse gear and increase the reverse thrust. Shift only when engine is running. Pause in neutral The throttle control regulates the RPM of the engine. -
Page 20: Fuel System
Your boat must be in contact with the water or a land based 1901 Bay ....56 Gal. (211 L) grounding system. Here are some helpful suggestions to 2101 Bay . -
Page 21: Ethanol-Blended Fuel
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay • Allow areas where gasoline vapors could CAUTION collect to be ventilated before starting the engine(s). The use of fuels containing ethanol higher than 10 percent (E-10) can damage your engine and/ •... - Page 22 TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Fuel Filters Storage Mercury already provides the appropriate level of Long periods of storage and/or non-use, common to filtration to protect the engine from debris. The addition boats, create unique problems. When preparing to store...
-
Page 23: Electrical System
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Electrical System The battery is located inside DANGER t he af t st a rboa rd st or age compa r t me nt a nd ca n be... -
Page 24: Starting The Engine
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Starting The Engine Warming Up The Engine CAUTION The “THROTTLE ONLY” button on the gear shift/ throttle control allows the operator to increase engine NEVER start nor operate your engine (even... -
Page 25: Ignition Shutdown Switch
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Ignition Shutdown Switch 12 Volt Accessory Receptacle CAUTION NOTICE Wear your lanyard at all times while operating DO NOT insert a cigarette lighter into this the boat. It is for emergency stopping only. Do receptacle. -
Page 26: Bilge Pump
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay the navigation lights are in good working order. The Maintenance navigation lights will let other boaters see the direction Frequently inspect the area under the float switch to your craft is traveling and its approximate length. -
Page 27: Hydraulic Steering
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Hydraulic Steering Propeller Your boat is equipped with a hydraulic steering system DANGER (See chart on page 13). Disconnect power by removing the battery While underway the engine exerts a tremendous amount cables before performing any work on the of torque on the steering wheel. - Page 28 TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay The livewells keep bait fish alive by circulating fresh Flow Control Valve seawater through the tanks. The seawater intake seacock located in the aft bilge must be in the open position in order for the livewell system to work.
-
Page 29: Raw Water System
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Raw Water System Trolling Motor Receptacle There is a raw water fitting Your boat is equipped with a trolling located on the port side of motor receptacle located forward of the motorwell. -
Page 30: Trolling Motor Charging System
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay NOTICE WARNING IT IS IMPORTANT to crimp and heat seal the The charger should be used ONLY on lead acid unused butt connector on your extension or gel cell type batteries. Use on other battery cord to avoid damage to your trolling motor types may explode and cause personal injury. - Page 31 TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay To Operate the charger: Maintenance Periodically clean both battery terminals with baking Your batteries may be connected in parallel for a 12 volt soda and tighten all connections, No other maintenance system or in series for a 24 volt system (See illustration on the charger is required.
-
Page 32: Mooring & Lifting Points
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Mooring & Lifting Points Bow and Stern Eyes DANGER The bow eye is used to haul and hold your boat onto a trailer. The stern eyes should be used as tie down points Use only the lifting points specifi... -
Page 33: Anchoring Information
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Anchoring Information Since you want to know how much rode to use when Your boat is equipped anchoring, use this common formula. with an anchor storage compartment located in Rode length=(bow height + water depth) x Scope the bow of the boat. -
Page 34: Trailer
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Trailer (Option) Tie-down straps can be used to secure the boat from the DANGER stern. The tie-down straps hook into the tie-down loops on the trailer frame to the lifting eyes on the transom. -
Page 35: Hull Maintenance
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Hull Maintenance the formation of hull blistering: Epoxy coatings can be applied to the hull, followed by hull painting. An alkyd- Clean the bottom of your boat of marine growth... -
Page 36: Vinyl Cushion Care
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay Long Term Storage Painted Hull Care (Bottom) The painted hull bottom will need to be inspected annually. Storage or winter lay-up will require you to make sure Any growth will affect the boats performance and overall that your boat and its systems are properly conditioned look. -
Page 37: Canvas Care & Maintenance
TROPHY Owner’s Manual Supplement 1901 Bay - 2101 Bay - 2401 Bay NOTICE The effects of ultraviolet light can sometimes be reduced by chemical treatment of canvas items. Store the batteries in a cool, dry location. Keep Consult your dealer or check with your owner’s manual the batteries in their plastic boxes. -
Page 38: Maintenance Record Log
1901 Bay - 2101 Bay - 2401 Bay After the scheduled services are performed, fi ll out the areas below. Maintenance Record Engine Serviced Maintenance Performed Date Hours Notes Trophy • P.O. Box 9029 • Everett, WA 98206 • 360-435-5571 MRP #1916753...
