- Page 1 English VIDEO DOOR PHONE SYSTEM USER MANUAL VT-ENG-6910-V1.0 090S223...
-
Page 2: Table Of Contents
CONTENT: 1. Parts and Functions ------------------------------1 2. Mounting and Installation----------------------1 3. Standard System Wiring-------------------------2 4. Extending Monitors or Auido Phones---------3 5. Extending 2 Outdoor Stations------------------4 6. Operation Instructions---------------------------5 7. Precautions-----------------------------------------9 8. Specifications--------------------------------------9... -
Page 3: Parts And Functions
1. Parts and Functions LCD Touch Screen ( ) UNLOCK Button ( ) MONITOR Button ( ) INTERCOM Button ( ) TALK/PLAY Button ( ) MENU Button Microphone Loud Speaker Power Port 10. Extention Port 11. Extention Port(Audio) 12. 1st Outdoor station 13. -
Page 4: Standard System Wiring
3. Standard System Wiring Terminal Discriptions: ● 1R Power positive. +12V present when Door Station calling or being monitored ● 2W Power negative (GND) ● 3Y Image signal (Video signal) ● 4B Talk and control signal (Audio signal) It’s recommended to use RVVP 4x0.3mm2 Shielded Cable. And when distance is over 30m, we suggest to use additional co-axle cable SYV- 75-3 (RG-59) connect 3Y and 2W pin. -
Page 5: Extending Monitors Or Auido Phones
4. Extending Monitors or Auido Phones CN101 JS/VP JS/AP JS-OS2 JS-OS1 GX-3P JS/AP CN101 JS/VP JS-OS2 JS-OS1 CN101 JS/AP JS/VP JS-OS2 JS-OS1 JS/VP JS/AP CN101 JS-OS2 JS-OS1... -
Page 6: Extending 2 Outdoor Stations
5. Extending 2 Outdoor Stations CN101 JS/VP JS/AP JS-OS2 JS-OS1 CN101 JS/VP JS/AP JS-OS2 JS-OS1 JS/AP JS/VP CN101 JS-OS2 JS-OS1... -
Page 7: Operation Instructions
6. Operation Instructions 6.1 Basic Functions 1. When visitor presses the Call Button on the IMG 16 Outdoor Station, the monitor rings, at the UNLOCK same time, the screen displays the visitor EXIT image, and the TALK LED will flush. 2. - Page 8 6.3 Intercom function(available when Multi Monitors installed) 1. Intercom can be initiated by any Monitor. Press INTERCOM ( ) Button on one Monitor, the other Monitors will ring, and press INTERCOM ( ) Button again to Redial redial. If TALK/PLAY ( ) Button is pressed EXIT on any other Monitor, intercom talking is...
-
Page 9: Basic Setup Instructions
6.5 Basic Setup Instructions 1. During standby state, press the MENU ( Button to display MAIN MENU. (see the first exit picture) intercom 2. Then press the MENU ( ) Button again to monitor select and enter the SETUP page. play 3. - Page 10 6.6 Operation for Picture Memory 1. A picture will be recorded automatically by the monitor every time after 2 seconds exit the visitor pressed the call button on the Outdoor station. The image capacity is intercom above 120 pcs, and the oldest one will be monitor replaced if the memory is full.
-
Page 11: Precautions
7. Precautions ● All parts should be protected from violence vibration. And not allow be impacting, knocking and dropping. ● For clean the Lens& Screen, using hands or wet cloth is forbidden. ● Please do the cleanness with soft cotton cloth, please do not use the organic or chemical clean impregnate. - Page 12 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved. VT-ENG-6910-V1.0 090S223...
