Global V900-B1 User Manual

V900 series gsm remote camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

V900 Series
GSM REMOTE CAMERA

User Manual

Manual version 1.9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V900-B1 and is the answer not in the manual?

Questions and answers

Related Manuals for Global V900-B1

Summary of Contents for Global V900-B1

  • Page 1: User Manual

    V900 Series GSM REMOTE CAMERA User Manual Manual version 1.9...
  • Page 2 V900-B1 GSM REMOTE CAMERA USER MANUAL V900 Series GSM Remote Camera Thank you for purchasing the V900. This camera is a remote controlled image-capturing device consisting of a microphone, infrared lights and a high quality camera lens. The V900 can capture images according to a...

  • Page 3: Table Of Contents

    V900-B1 GSM REMOTE CAMERA USER MANUAL CONTENTS For your safety ............................6 EXCEPTION CLAUSE .......................... 6 Chapter 1 FEATURES AND ACCESSORIES ..................7 1.1 Main function ............................ 7 1.2 Sales package contents........................8 1.3 Products features ..........................8 1.4 Remote control Instruction ....................... 9 1.5 Light indicator ..........................
  • Page 4 V900-B1 GSM REMOTE CAMERA USER MANUAL 4.4.2 Set time period to send MMS images ................22 4.4.3 Disable timing send MMS image ................... 23 4.5 Remote control ..........................24 4.5.1 Add remote control(s) to the device ................24 4.5.2 Remote control instruction ....................24 4.5.3 The SMS notification message upon arming or disarming the camera via remote...
  • Page 5 V900-B1 GSM REMOTE CAMERA USER MANUAL 5.2 Automatic alarm settings ........................ 40 5.2.1 Warning tone upon alarm triggering ................41 5.2.2 No warning tone upon alarm (Default) ................41 5.2.3 No SMS notification upon alarm ..................41 5.2.4 SMS notification upon alarm (Default) ................41 5.2.5 No MMS notification upon alarm ..................

  • Page 6: For Your Safety

    V900-B1 GSM REMOTE CAMERA USER MANUAL 1. Purchase a GSM SIM card (mobile phone card) from GSM network service and install it in the device. This SIM card number is referred as V900 device number on this brochure. 2. The user needs to activate the MMS function and Caller ID Presentation function of SIM card, and deactivate PIN code of the SIM.

  • Page 7: Chapter 1 Features And Accessories

    V900-B1 GSM REMOTE CAMERA USER MANUAL incidental, consequential or indirect damages howsoever caused. 5. The contents of this document are provided “as is”. Except as required by applicable law, no warranties of any kind, either expressed or implied, including, but not limited to the accuracy, reliability or contents of this document. We reserve the right to revise this document or withdraw it at any time without prior notice.

  • Page 8: Sales Package Contents

    V900-B1 GSM REMOTE CAMERA USER MANUAL place required by the authorized user. Accessories: Includes 2 remote controls each consisting of a panic button as well as buttons to arm or disarm the device. Built-in lithium battery: Rechargeable battery ensures operation of V900 device amid external power failures.

  • Page 9: Remote Control Instruction

    V900-B1 GSM REMOTE CAMERA USER MANUAL 1.4 Remote control Instruction Figure 2: Remote control Instruction 1. Antenna 3. Arm the device button 2. Remote control indicator 4. Disarm the device button 5. Emergency button Battery: There is battery holder on the rear of the remote control. It needs one 27A/12V battery.

  • Page 10: Chapter 2 Installation

    V900-B1 GSM REMOTE CAMERA USER MANUAL Chapter 2 Installation 2.1 Install the SIM card  Remove the rubber cover from the left side of V900 device.  Open the SIM card slot by pressing the small dot beside the SIM card slot with the tip of a pencil, and pop open the slot.

  • Page 11: Power On/ Off

    V900-B1 GSM REMOTE CAMERA USER MANUAL be irradiated directly into the lens of the camera on the device. In order to avoid backlighting photography, it is suggested that the camera is located at the place where can look down the monitoring place with the minimum angel 30°.
  • Page 12 V900-B1 GSM REMOTE CAMERA USER MANUAL User Type Master Families Guests Functions Receive alarm calling Get images by E-mail Receive SMS Emergency Receive MMS alarm Receive emergency calling YES (Only emergency number) Call the camera to listen in live voice...

  • Page 13: Define Master User To Start The Device

    V900-B1 GSM REMOTE CAMERA USER MANUAL 3.2 Define Master user to start the device In order to enable all the functions on the device, the Master user must store his/ her mobile number in the device’s memory. Only one Master’s mobile number (Master number) is allowed for a camera.

  • Page 14: Change Password

    V900-B1 GSM REMOTE CAMERA USER MANUAL Change the master user’s number: #14#NewMasterNumber#  Successful SMS reply New master number is *********. Then the old master user’s number will not be able to control V900 device anymore. 3.2.3 Change password Authority: Master user.

  • Page 15: Check Family User's Number

    V900-B1 GSM REMOTE CAMERA USER MANUAL Add a family number: #06#FamilyNumber# Add several family numbers: #06#FamilyNumber#...#FamilyNumber#  Up to 10 family users’ number can be stored on one device.  Successful SMS reply The family number has been added successfully.

  • Page 16: Add Emergency Number

    V900-B1 GSM REMOTE CAMERA USER MANUAL 3.5.1 Add emergency number Authority: Master user.  Description  The master user’s number default to be emergency number.  When the Emergency button is pressed, V900 device will automatically dial the Master user’s number, followed by the other pre-set emergency numbers (the default mode is dial phone mode).

  • Page 17: Check Emergency Number

    V900-B1 GSM REMOTE CAMERA USER MANUAL Delete several emergency numbers: (12) #107#EmergencyNumber#…#EmergencyNumber# Delete all emergency numbers: #107# (13)  Successful SMS reply Emergency number successfully deleted. 3.5.3 Check emergency number Refer to Chapter 4.15 Check status. Chapter 4 Basic use and settings 4.1 Network parameter settings...

  • Page 18: Sending Mms Message Via Http

    V900-B1 GSM REMOTE CAMERA USER MANUAL The user sends following SMS message in order to: Choose a network operator’s MMS parameter from V900 device MMS list: (14) #145#name#  The name should be the name of GSM provider, such as Vodafone. For...

  • Page 19: To Capture Images

    V900-B1 GSM REMOTE CAMERA USER MANUAL 4.2 To capture images Authority: Master/ family / guest send SMS to the camera to get the MMS image or send the image(s) to an appointed mobile or E-mail address. Master/ family member call the camera to get the images.

  • Page 20: To Capture Images And Send To User's E-Mail Address

    V900-B1 GSM REMOTE CAMERA USER MANUAL  Image quantity should be in the range of 1-8 when the image size is set at 160×128 or 320×240 (See 5.5.1 image size.) The default image size is 320×240(QVGA).  Image quantity should be in the range of 1-2 when the image size is set at 640×480.

  • Page 21: To Capture Images And Send To An Appointed Mobile Or E-Mail Address

    V900-B1 GSM REMOTE CAMERA USER MANUAL 4.2.4 To capture images and send to an appointed mobile or E-mail address Authority: Master, family and guest users.  Method The user sends the following SMS message in order to: Capture image(s) and send to appointed mobile or E-mail address:...

  • Page 22: Delete All E-Mail Address(Es)

    V900-B1 GSM REMOTE CAMERA USER MANUAL address is set onto one user number, V900 device will only recognize the E-mail address put in the last.  If the user wishes capturing an image and sending to his/her E-mail address, see 4.2.3 to capture images and send to user’s E-mail address.

  • Page 23: Disable Timing Send Mms Image

    V900-B1 GSM REMOTE CAMERA USER MANUAL The user sends following SMS message in order to: Set time period to auto-send MMS image: (31) #116#WorkDay#StartTime1#EndTime1#IntervelTime1#...#StartTime3#EndTi me3#IntervelTime3#  Max allow 3 periods per workday. Each period time should set by start time, end time and interval.

  • Page 24: Remote Control

    V900-B1 GSM REMOTE CAMERA USER MANUAL 4.5 Remote control 4.5.1 Add remote control(s) to the device  Description When a remote control is added to a device, it can control the device. A device can be added up to 5 remote controls.

  • Page 25: The Sms Notification Message Upon Arming Or Disarming The Camera Via Remote Control

    V900-B1 GSM REMOTE CAMERA USER MANUAL green. This indicates that V900 device is in disarmed mode.  V900 device will not detect any motion or receive sensor alarm signal. Emergency button  When is pressed, the indicator light on V900 device will rapidly flash green.

  • Page 26: Emergency Alarms

    V900-B1 GSM REMOTE CAMERA USER MANUAL 4.6 Emergency Alarms Authority: Master and family users.  Description When the emergency button (panic button) on the remote camera is pressed, V900 device will go into emergency mode to alarm. There are two modes of the emergency alarm could be set on the device: Emergency Mode1 (Default): To dial the master user’s number as well as the pre-set...

  • Page 27: Listening In Upon Emergency Alarm

    V900-B1 GSM REMOTE CAMERA USER MANUAL then listen in the live audio in the monitoring area. Only one line can be connected to V900 device at a time. 4.7.2 Listening in upon emergency alarm  Description  When V900 device is in arm or disarm status, it will automatically dial the Master user’s phone number if the emergency button is pressed.

  • Page 28: Motion Detection

    V900-B1 GSM REMOTE CAMERA USER MANUAL Deactivate infrared body detector: #118#0# (39)  Successful SMS reply Infrared body detector activated. Infrared body detector deactivated.  When the infrared body detection alarms, the notification pictures will be sent on one message via MMS. The default quality of individual picture is 5 and the size is 320×240 pixels.

  • Page 29: Activate/Deactivate Motion Detection

    V900-B1 GSM REMOTE CAMERA USER MANUAL 4.9.1 Activate/Deactivate motion detection Authority: Master and family users.  Method The user sends following SMS message in order to: Deactivate motion detection (default setting): #22#0# (40) Activate motion detection: #22#1# (41)  Successful SMS reply Motion detection de-activated.

  • Page 30: Wireless Sensor(S)

    V900-B1 GSM REMOTE CAMERA USER MANUAL #141#DetectedTimes#TimePeriod#  Motion Times should be in the range of 1-255 times.  Time Period should be in the range of 1-255 minutes.  Successful SMS reply Set parameter successfully, quantity: ** , time: ** minutes.

  • Page 31: Remove Wireless Sensor

    V900-B1 GSM REMOTE CAMERA USER MANUAL  If you add * at front of sensor description, V900 device will send out MMS and SMS alarm message. when “door2” sensor triggers V900 device alarm, E.g. #05#*door2# V900 device will send out SMS and MMS alarm messages.

  • Page 32: Arming Or Disarming V900 Device Manually

    V900-B1 GSM REMOTE CAMERA USER MANUAL remove. Remove all wireless sensors: #112# (46)  Successful SMS reply Sensor deleted successfully. 4.11 Arming or disarming V900 device manually 4.11.1 Arming V900 device manually Authority: Master and family users.  Description  When V900 device is arming, all loaded sensors, infrared body detector and motion detector are in work status.

  • Page 33: Disarming V900 Device Manually

    V900-B1 GSM REMOTE CAMERA USER MANUAL V900 device, a notification will be sent via SMS to preset user numbers. Five notification pictures will be sent on one message via MMS. MMS image size is 320×240(QVGA). 4.11.3 Disarming V900 device manually Authority: Master and family users.

  • Page 34: Set Time Period To Arm The Device

    V900-B1 GSM REMOTE CAMERA USER MANUAL 4.12.2 Set time period to arm the device  Method The user sends following SMS message in order to: Set time period to arm the device: (50) #129#WorkDay#ArmTime1#DisarmTime1#...#ArmTime3#DisarmTime3#  Up to 3 periods be allowed per workday. Each period time should set by ArmTime, DisarmTime.

  • Page 35: Auto-Disarming The Device

    V900-B1 GSM REMOTE CAMERA USER MANUAL 4.13 Auto-disarming the device  Description In order to avoid V900 device sending out alarm message all the time and out of Master’s attention, V900 device can be set auto-disarm when it has been sent out alarms certain times (At least one alarm message should be sent via MMS).

  • Page 36: Device Language Setting

    V900-B1 GSM REMOTE CAMERA USER MANUAL 4.14 Device language setting Authority: Master user.  Description V900 device supports both English and Spanish (or the user’s first language) display.  Method The user sends following SMS message in order to set: The user’s first language (or Spanish) version:...

  • Page 37: Resetting The Device

    V900-B1 GSM REMOTE CAMERA USER MANUAL The user can send SMS to V900 device in order to get the SMS command list which the command description as well as the codes will be supplied or get the MMS named “V900 user manual” on which all the command descriptions as well as the codes will be supplied.

  • Page 38: Chapter 5 Advanced Settings

    V900-B1 GSM REMOTE CAMERA USER MANUAL The user sends following SMS message to V900 device in order to: Reset the device: #08#password# (63)  Successful SMS reply The GSM camera has successfully reset to its default settings. Chapter 5 Advanced settings 5.1 Image settings...

  • Page 39: Image Brightness

    V900-B1 GSM REMOTE CAMERA USER MANUAL V900-171154(Sensor 1).  For motion detection alarm: Model-Time (Motion detection), such as V900-171154 (motion detection). 5.1.3 Image brightness  For master and family users: #34#value# (66)  The value should be in the range from 1-5. Value 1 is the darkest and value 5 is the brightest.

  • Page 40: Image Compressibility

    V900-B1 GSM REMOTE CAMERA USER MANUAL  The value should be in the range of 1-5.  The default value is 4.  Successful SMS reply Image contrast has been set successfully: *  Note This function needs to be used carefully as it may lower the image quality.

  • Page 41: Warning Tone Upon Alarm Triggering

    V900-B1 GSM REMOTE CAMERA USER MANUAL  When motion is detected or  when the wireless sensors are triggered. The user sends the following edit message via SMS to V900 device in order to activate the following functions: 5.2.1 Warning tone upon alarm triggering ...

  • Page 42: Mms Notification Upon Alarm (Default)

    V900-B1 GSM REMOTE CAMERA USER MANUAL 5.2.6 MMS notification upon alarm (Default)  For master and family users: #12#1# (76)  Successful SMS reply Alarm set with MMS notification successfully. 5.2.7 No call notification upon alarm (Default)  For master and family users:...

  • Page 43: Mms Notification To Pre-Set E-Mail Address

    V900-B1 GSM REMOTE CAMERA USER MANUAL 5.2.10 MMS notification to pre-set E-mail address  For master and family users: #110#1# (80)  Successful SMS reply Alarm set with MMS notification to an E-mail address successfully.  If the MMS notifications is set to be send to both a mobile phone number as well as to an e-mail address, the MMS image will firstly be sent to the mobile phone number and then to the E-mail address.

  • Page 44: Sms Notification Upon The Power Supply Changing

    V900-B1 GSM REMOTE CAMERA USER MANUAL captures image.  If the infrared (IR) lights are turned on, V900 device can auto-control the IR lights according to the environment lightness when it works on arming mode. If the environment brightness is not strong enough, V900 device will turn on the IR light.

  • Page 45: Chapter 7 General Troubleshooting

    V900-B1 GSM REMOTE CAMERA USER MANUAL problem can not be solved, contact with the dealer immediately.  To prolong the life-span of the battery, connect the camera V900 device to the power supply to charge the built-in Lithium battery for 4 hours every 3 months if the camera does not use for long time.

  • Page 46: Chapter 8 Main Technical Parameters

    V900-B1 GSM REMOTE CAMERA USER MANUAL General Trouble Possible Reason Solution Didn’t set master user number Set master number before add sensor. Can’t start the camera Battery runs out of power. Connect camera after long time supply external AC power and charge with the battery.
  • Page 47 V900-B1 GSM REMOTE CAMERA USER MANUAL Category Function Command User Add a family number (4) #06#FamilyNumber# Master Add several family numbers (5) #06#FamilyNumber#...#FamilyNumber# Master Delete a family number (6) #113#FamilyNumber# Master Delete several family (7) #113#FamilyNumber#…#FamilyNumber# Master numbers simultaneously Delete all family numbers...
  • Page 48 V900-B1 GSM REMOTE CAMERA USER MANUAL Category Function Command User antity# Add/modify an E-mail Master (28) #108#EmailAddress# E-mail address Family settings Delete all E-mail address (29) #109# Master Enable timing sends MMS (30) #115#1# Master images (31)#116#WorkDay#StartTime1#EndTime1#Int Timed Set time period to auto-send ervelTime1#...#StartTime3#EndTime3#Intervel...
  • Page 49 V900-B1 GSM REMOTE CAMERA USER MANUAL Category Function Command User Master Remove all wireless sensors (46) #112# Family Arming V900 device Master (47) #01# manually Family Disarming V900 device Master (48) #02# manually Family Enable timing arms the Master (49) #128#1#...
  • Page 50 V900-B1 GSM REMOTE CAMERA USER MANUAL Category Function Command User Master Image compressibility (69) #119#value# Family Master Image Interval (70) #103#time# Family Warning tone upon alarm Master (71) #130#1# triggering Family No warning tone upon alarm Master (72) #130#0# (Default)
  • Page 51 V900-B1 GSM REMOTE CAMERA USER MANUAL Category Function Command User data from the sensor before, then it will reply 0,0. #163#Data1#Data2# Data1: the temperature low limit. It can not be ℃ under -40 Data2: the temperature upper limit. It can not ℃...
