Summary of Contents for BPC 8590
- Page 1 USER’S MANUAL BPC-8590 All-in-One Book-size PC Intel® Core 2 Duo For Socket 478 System BPC-8590 M1...
- Page 2 Copyright Notice BPC-8590 All-in-One Book-size PC OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist users in installing and setting up the system. The information contained in this document is subject to change without prior any notice. This manual is copyrighted January, 2008. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
-
Page 3: Fcc Notice
Copyright Notice FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 4: Table Of Contents
Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............ Case Illustration ............System Specification ........... Safety Precautions ............CHAPTER 2 SYSTEM CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ........... How to Set the Jumpers ..........FSB Frequency Selection ……………………………………. - Page 5 Contents CHAPTER 3 SOFTWARE UTILITIES Introduction ..............VGA Driver Utility ............. Flash BIOS Update ............. LAN Driver Utility ............. Sound Driver Utility ........... Intel Chipset Software Installation Utility …..……... Watchdog Timer Configuration ……………………. CHAPTER 4 AWARD BIOS SETUP Introduction ..............Entering Setup ............
-
Page 6: Chapter 1 Introduction
CHAPTER INTRODUCTION This chapter gives you the information for BPC-8590. It also outlines the System specification. Section includes: About This Manual System Specifications Safety precautions Experienced users can skip to chapter 2 on page 2-1 for Quick Start. Page:1-1... -
Page 7: About This Manual
1-1. ABOUT THIS MANUAL Thank you for purchasing our BPC-8590 Core 2 Duo Book-size PC enhanced with VGA / Sound / LAN, which is fully PC / AT compatible. BPC-8590 provides faster processing speed, greater expandability and can handle more task than before. -
Page 8: Case Illustration
Chapter 1 Introduction 1-2. CASE ILLUSTRATION ′ Page: 1-3 BPC-8590 USER S MANUAL... -
Page 9: System Specification
1 x Parallel Port (D-sub 25 pin) 1 x RJ45 Giga LAN 1 x PS/2 (Mini-Din 6 Pin) for K/B and Mouse with Y cable Expansion Slot : 1 x PCI or ,1x PCI-E (Optional) ′ Page: 1-4 BPC-8590 USER S MANUAL... -
Page 10: Safety Precautions
Avoid exposure to sunlight for a long period of time (for example in a closed car in summer time. Also avoid the system from any heating device.). Or do not use BPC-8590 when it‘s been left outdoors in a cold winter day. - Page 11 If heavy stains are present, moisten a cloth with diluted neutral washing agent or with alcohol and then wipe thoroughly with a dry cloth. d. If dust has been accumulated on the outside, remove it by using a special made vacuum cleaner for computers. ′ Page: 1-6 BPC-8590 USER S MANUAL...
-
Page 12: Quick Start
CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1... -
Page 13: Jumper & Connector Quick Reference Table
JUSB1, JUSB2, USB1, USB2, USB3 LAN1, JLAN2 (option) LAN Connector ………………………………………. JATX_PWR1 ATX Power Connector ………………………………… LINE_OUT Line-Out Connector ……………………………………. LINE_IN Line-In Connector ……………………………………... MIC Connector ……………………………………….. JDIMM1, JDIMM2 Memory Installation ........…..……… PCI1 PCI Connector ……………………….………… ′ Page: 2-2 BPC-8590 USER S MANUAL... -
Page 14: Component Locations
Chapter 2 Hardware Configuration 2-2. COMPONENT LOCATIONS BPC-8590 Connector, Jumper and Component locations ′ Page: 2-3 BPC-8590 USER S MANUAL... -
Page 15: How To Set The Jumpers
PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ′ Page: 2-4 BPC-8590 USER S MANUAL... - Page 16 Jumper Block looks like this JUMPER SETTINGS 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ′ Page: 2-5 BPC-8590 USER S MANUAL...
-
Page 17: Fsb Frequency Selection
Chapter 2 Hardware Configuration 2-4. FSB FREQUENCY SELECTION JP11: CPU FSB Frequency Selection The selections are as follows: SELECTION JUMPER SETTING JUMPER (pin closed) ILLUSTRATION 533 MHz 667 MHz Open ′ Page: 2-6 BPC-8590 USER S MANUAL... -
Page 18: Com1 Port Ri & Voltage Selection
Chapter 2 Hardware Configuration 2-5. COM1 PORT RI & VOLTAGE SELECTION JP2 : COM1 Port RI & Voltage Selection The selections are as follows: JUMPER SETTING JUMPER SELECTION (Pin Closed) ILLUSTRATION +12V ***Manufacturing Default – RI1. ′ Page: 2-7 BPC-8590 USER S MANUAL... -
Page 19: Com2 Port Ri & Voltage Selection
Chapter 2 Hardware Configuration 2-6. COM2 PORT RI & VOLTAGE SELECTION JP1 : COM2 Port RI & Voltage Selection The selections are as follows: JUMPER SETTING JUMPER SELECTION (Pin Closed) ILLUSTRATION +12V ***Manufacturing Default – RI2. ′ Page: 2-8 BPC-8590 USER S MANUAL... -
Page 20: Com3 Port Ri/Voltage Selection
Chapter 2 Hardware Configuration 2-7. COM3 PORT RI & VOLTAGE SELECTION JP4 : COM3 Port RI & Voltage Selection The selections are as follows: JUMPER SETTING JUMPER SELECTION (Pin Closed) ILLUSTRATION +12V ***Manufacturing Default – RI3. ′ Page: 2-9 BPC-8590 USER S MANUAL... -
Page 21: Com4 Port Ri/Voltage Selection
Chapter 2 Hardware Configuration 2-8. COM4 PORT RI & VOLTAGE SELECTION JP5 : COM4 Port RI & Voltage Selection The selections are as follows: JUMPER SETTING JUMPER SELECTION (Pin Closed) ILLUSTRATION +12V ***Manufacturing Default – RI4. ′ Page: 2-10 BPC-8590 USER S MANUAL... -
Page 22: Keyboard/ Mouse Selection
Chapter 2 Hardware Configuration 2-9. KEYBOARD/ MOUSE SELECTION JP22 : Keyboard/ Mouse Selection. The selections are as follows: JUMPER SELECTION JUMPER SETTING ILLUSTRATION Mouse 1-3, 2-4 Keyboard 3-5, 4-6 ***Manufacturing Default –Keyboard ′ Page: 2-11 BPC-8590 USER S MANUAL... -
Page 23: Clear Cmos Data Selection
Note: To clear CMOS data, user must power-off the computer and set the jumper to “Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. ′ Page: 2-12 BPC-8590 USER S MANUAL... -
Page 24: Reset/ Nmi/ Clear Watchdog Selection
Chapter 2 Hardware Configuration 2-11. RESET/ NMI/ WATCHDOG SELECTION JP17: Reset/ NMI/ Watchdog Selection The selections are as follows: SELECTION JUMPER SETTING JUMPER (pin closed) ILLUSTRATION RESET *** Manufacturing Default: Reset. ′ Page: 2-13 BPC-8590 USER S MANUAL... -
Page 25: Com Port Connector
The COM2 is selectable as RS-232. The pin assignment is as follows : ASSIGNMENT Pin 9 is selectable for RI, +5V or +12V. For more information, please refer to our “2-6 COM2 RI and Voltage Selection”. ′ Page: 2-14 BPC-8590 USER S MANUAL... - Page 26 COM4 is fixed as RS-232. The pin assignment is as follows : ASSIGNMENT Pin 9 is selectable for RI, +5V or +12V. For more information, please refer to our “2-8 COM4 RI and Voltage Selection”. ′ Page: 2-15 BPC-8590 USER S MANUAL...
-
Page 27: Keyboard/ Mouse Connector
The pin assignments are as follows : ASSIGNMENT KBDATA MSDATA 5VSB KBCLK MSCLK 2-14. POWER BUTTON JPWBT1: Power Button 2-15. CPU FAN CONNECTOR JCFAN1 : CPU Fan connector The pin assignment is as follows: ASSIGNMENT FAN POWER LPC_FAN1IN ′ Page: 2-16 BPC-8590 USER S MANUAL... -
Page 28: System Fan Connector
JSFAN2 : System Fan connector The pin assignment is as follows: ASSIGNMENT VCC12 LPC_FAN2IN 2-17. VGA CONNECTOR VGA1: VGA Connector The pin assignments are as follows: ASSIGNMENT GREEN BLUE VGA_VCC5 DDC_DATA HSYNC VSYNC DDC_CLK ′ Page: 2-17 BPC-8590 USER S MANUAL... -
Page 29: Dvi Connector
Chapter 2 Hardware Configuration 2-18. DVI CONNECTOR DVI1 : DVI Connector. The pin assignments are as follows: ASSIGNMENT TDC2J TDC2 SC_DDC SD_DDC A_VSYNC TDC1J TDC1 VCC5 Hot Plug Detect TDC0J TDC0 TLCJ A_RED A_GREEN A_BLUE A_HSYNC ′ Page: 2-18 BPC-8590 USER S MANUAL... -
Page 30: Hard Disk Drive Connector
ASSIGNMENT IDERST# P DIOW# PDD7 P DIOR# PDD8 PDD6 PIORDY PDD9 PDD5 PDDACK# PDD10 PDD4 IRQ14 PDD11 PDD3 PDA1 PDD12 P66DETECT PDD2 PDA0 PDD13 PDA2 PDD1 PDCS#1 PDD14 PDCS#3 PDD0 IDEACTP# PDD15 PDREQ ′ Page: 2-19 BPC-8590 USER S MANUAL... -
Page 31: Serial Ata Connector
Chapter 2 Hardware Configuration 2-20. SERIAL ATA CONNECTOR SATA1, SATA2: The BPC-8590 possesses two Serial ATA Connector. The pin assignments are as follows: SATA1: ASSIGNMENT SATAHDR_TXP0 SATAHDR_TXN0 SATAHDR_RXN0 SATAHDR_RXP0 SATA2: ASSIGNMENT SATAHDR_TXP1 SATAHDR_TXN1 SATAHDR_RXN1 SATAHDR_RXP1 ′ Page: 2-20 BPC-8590 USER... -
Page 32: Printer Connector
As to link the Printer to the card, you need a cable to connect both DB25 connector and parallel port. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT AUTFE ERROR INIT SLCTIN BUSY SLCT ′ Page: 2-21 BPC-8590 USER S MANUAL... -
Page 33: Universal Serial Bus Connector
JUSB1: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USB2_VCC5 USB3_VCC5 USBN2_L USBN3_L USBP2_L USBP3_L JUSB2: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USB2_VCC5 USB3_VCC5 USBN2_L USBN3_L USBP2_L USBP3_L ′ Page: 2-22 BPC-8590 USER S MANUAL... - Page 34 The pin assignments are as follows: ASSIGNMENT USBP0- USBP0+ USB2: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USBP0- USBP0+ USB3: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USBP0- USBP0+ ′ Page: 2-23 BPC-8590 USER S MANUAL...
-
Page 35: Lan Connector
MDI_0P MDI_0N MDI_1P MDI_1N MDI_2P MDI_2N MDI_3P MDI_3N JLAN2: LAN Connector. The pin assignment is as follows : ASSIGNMENT 1MDI_3+ 1MDI_3- 1MDI_2+ 1MDI_2- 1MDI_1+ 1MDI_1- 1MDI_0+ 1MDI_0- VCC25-CG 1VCC3.3R 1LINK-R 1ACT 1SPEED100 1SPEED1000-R ′ Page: 2-24 BPC-8590 USER S MANUAL... -
Page 36: Atx Power Connector
The pin assignments are as follows: ASSIGNMENT GROUND GROUND +12V VCC SBY GROUND PS_ON -12V 2-25. AUDIO CONNECTOR JAUDIO1 : Audio Connector The pin assignments are as follows: ASSIGNMENT MIC_IN LINE-L LINE-R SPK-L SPK-R ′ Page: 2-25 BPC-8590 USER S MANUAL... -
Page 37: Line-Out Connector
LINE-OUT1 : Line-Out Connector 2-27. LINE-IN CONNECTOR LINE-IN1 : Line-In Connector 2-28. MIC CONNECTOR MIC1 : MIC Connector 2-29. MEMORY INSTALLATION BPC-8590 CPU Card can support up to 1GB in one DIMM socket. DIMM 1 DIMM 2 TOTAL MEMORY 128MB 128MB... -
Page 38: Pci Connector
AD30 AD08 C/BE0# AD29 +3.3V AD07 +3.3V AD28 +3.3V AD06 AD27 AD26 AD05 AD04 AD25 AD03 +3.3V AD24 AD02 C/BE3# GNT2# AD01 AD00 AD23 +3.3V +5V(I/O) +5V(I/O) AD22 ACK64# REQ64# AD21 AD20 AD19 ′ Page: 2-27 BPC-8590 USER S MANUAL... - Page 39 CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, Sound driver, and flash BIOS update. It also describes on how to install the watchdog timer. Section includes: VGA Driver Utility Flash BIOS Update LAN Driver Utility SOUND Driver Utility Intel®...
-
Page 40: Introduction
Enclosed with our BPC-8590 package, you will find a CD ROM disk containing all types of drivers we have. As a BPC-8590 user, you will only need the some of files contained in the CD ROM disk, please take note of the... -
Page 41: Vga Driver Utility
Chapter 3 Software Configuration 3-2. VGA DRIVER UTILITY The VGA interface is embedded with our BPC-8590 system to support CRT display. The following illustration briefly shows you the content of VGA driver in D:\VGA\: 3-2-1. Installation of VGA Driver (1) Start the computer (Win 2000/XP/Vista). -
Page 42: Flash Bios Update
Chapter 3 Software Configuration 3-3. FLASH BIOS UPDATE 3-3-1. System BIOS Update: Users of BPC-8590 can use the program “Awdflash.exe” contained in the Utility Disk for system BIOS update. 1. Install “Awdflash.exe” from Utility Disk to Drive D. 2. Insert the BIOS file you have obtained from the vendor. - Page 43 File Name to Program: 8590xxxx.bin Checksum: XXXXX Reset System or Power off to accomplish update process! F1: Reset F10: Exit Please reset or power off the system, and then the Flash BIOS is fully implemented. ′ Page:3-5 BPC-8590 USER S MANUAL...
-
Page 44: Lan Driver Utility
Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction The BPC-8590 is enhanced with LAN function that can support various network adapters. The content of the LAN driver is found as follows: For more details on Installation procedure, please refer to Readme.txt file found on LAN DRIVER UTILITY. -
Page 45: Sound Driver Utility
“D:\Driver\Sound\path” refers to the full path to the source files. (3) Click on the OK button or press the ENTER key. (4) Click on the “Next” and OK prompts as they appear. (5) Reboot the system to complete the driver installation. ′ Page:3-7 BPC-8590 USER S MANUAL... -
Page 46: Intel Chipset Software Installation Utility
3. Click Setup.exe file for utility installation. 4. Follow the instructions on the screen to complete the installation. 5. Once installation is completed, shut down the system and restart in order for the changes to take effect. ′ Page:3-8 BPC-8590 USER S MANUAL... -
Page 47: Watchdog Timer Configuration
;-------------------------------------------------------------------------------------------------- ; Disable Watch-Dog Timer ;-------------------------------------------------------------------------------------------------- dx, (800h+66h) ; Disabled Watch Dog al, 00h dx, al dx, (800h+67h) al, 00h dx, al dx, (800h+68h) ; Clear Status Bit al, 00h dx, al ′ Page:3-9 BPC-8590 USER S MANUAL... - Page 48 CHAPTER AWARD BIOS SETUP This chapter shows how to set up the Phoenix Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Features The Advanced BIOS Features The Advanced Chipset Features Integrated Peripherals Power Management Setup PNP/PCI Configuration PC Health Status Load Fail-Safe Defaults Load Optimized Defaults Password Setting...
-
Page 49: Introduction
4-1. INTRODUCTION This chapter will show you the function of the BIOS in managing the features of your system. The BPC-8590 Core 2 Duo Book Size PC is equipped with the BIOS for system chipset from Award Software Inc. This page briefly explains the function of the BIOS in managing the special features of your system. -
Page 50: Entering Setup
You may use the cursor the up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-3 BPC-8590 USER S MANUAL... -
Page 51: The Standard Cmos Features
< Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the time as 16:30:00. ′ Page: 4-4 BPC-8590 USER S MANUAL... - Page 52 Auto: The BIOS automatically determines the optimal mode. Normal: Maximum number of cylinders, heads, sectors supported are 1024, 16 and 63. Large: For drives that do not support LBA and have more than 1024 cylinders. ′ Page: 4-5 BPC-8590 USER S MANUAL...
- Page 53 BASE MEMORY: Displays the amount of conventional memory detected during boot up. EXTENDED MEMORY: Displays the amount of extended memory detected during boot up. TOTAL MEMORY: Displays the total memory available in the system. ′ Page: 4-6 BPC-8590 USER S MANUAL...
-
Page 54: The Advanced Bios Features
The “BIOS FEATURES SETUP” allow you to configure your system for basic operation. The user can select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. A brief introduction of each setting is given below. ′ Page: 4-7 BPC-8590 USER S MANUAL... - Page 55 Do not type anything and just press <Enter>, it will disable security. Once the security is disabled, the system will boot and you can enter Setup freely. ′ Page: 4-8 BPC-8590 USER S MANUAL...
- Page 56 This option is only valid for multiprocessor motherboards as it specifies the version of the Multiprocessor Specification (MPS) that the motherboard will use. The MPS is a specification by which PC manufacturers design and build Intel architecture systems with two or more processors. ′ Page: 4-9 BPC-8590 USER S MANUAL...
-
Page 57: Advanced Chipset Features
The value in this field depends on performance parameters of the installed memory chips (DRAM). Do not change the value from the factory setting unless you install new memory that has a different performance rating than the original DRAMs. ′ Page: 4-10 BPC-8590 USER S MANUAL... - Page 58 Front Side Bus Frequency. DVMT MODE: Intel Dynamic Video Memory Technology Mode. DVMT/FIXED MEMORY SIZE: DVMT Memory Size Select. BOOT DISPLAY To select the boot-up display type. PCI SERR# NMI To Enable/Disable the PCI SERR# interrupt ′ Page: 4-11 BPC-8590 USER S MANUAL...
-
Page 59: Integrated Peripherals
If bios setup menu item supports USB device boot, it will cause Win9x detects the same storages twice when the system is rebooted, and USB HDD will fail. Note: this cause just happen under Win9x, the phenomenon is a limitation. ′ Page: 4-12 BPC-8590 USER S MANUAL... - Page 60 To Enable/Disable the IDE DMA transfer access. 3. On-Chip Primary PCI IDE The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately. ′ Page: 4-13 BPC-8590 USER S MANUAL...
- Page 61 USB 2.0 Controller [Enabled] USB Keyboard Support [Disabled] Menu Level ► ↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Descriptions on each item above are as follows: ′ Page: 4-14 BPC-8590 USER S MANUAL...
- Page 62 2. Onboard Serial Port 1/2 Select an address and corresponding interrupt for the first and second serial ports. 3. UART Mode Select This item allows you to select UART mode. 4. TxD, RxD Polarity Active ′ Page: 4-15 BPC-8590 USER S MANUAL...
- Page 63 Select a logical COM port name and matching address for the third and forth serial ports. Select an address and corresponding interrupt for third and forth serial port. WATDOG SUPPORT: To select watch-dog times ′ Page: 4-16 BPC-8590 USER S MANUAL...
-
Page 64: Power Management Setup
Soft-Off state when the system has “hung”. The choices are Delay 4 Sec and Instant-Off. PWRON After PWR-Fail: This item allows you to select if you want to power on the system after power failure. The choice: Off, On, Former-Sts. ′ Page: 4-17 BPC-8590 USER S MANUAL... -
Page 65: Pnp/Pci Configuration
Plug and Play-compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as Windows 95. By choosing “manual”, you are allowed to configure the IRQ Resources and DMA Resources. ′ Page: 4-18 BPC-8590 USER S MANUAL... -
Page 66: Chapter 4 Award Bios Setup
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Descriptions on each item above are as follows: IRQ-n Assigned to: You may assign each system interrupt a type, depending on the type of device using the interrupt. ′ Page: 4-19 BPC-8590 USER S MANUAL... -
Page 67: Pc Health Status
Windows 98 ACPI mode. CURRENT CPU TEMPERATURE: This item shows you the current CPU temperature. Vcore/5V/12V Show you the voltage of 3.3V/5V/12V FAN1/2 SPEED This item shows you the current CPU/ SYSTEM FAN speed. ′ Page: 4-20 BPC-8590 USER S MANUAL... -
Page 68: Load Fail-Safe Defaults
When you press <Enter> on this category, you get a confirmation dialog box with a message similar to the following: Load Optimized Defaults ( Y/N ) ? N Pressing "Y" loads the default values that are factory setting for optimal performance system operations. ′ Page: 4-21 BPC-8590 USER S MANUAL... -
Page 69: Password Setting
PASSWORD DISABLED!!! Press any key to continue... Press the < Enter > key again and the password will be disabled. Once the password is disabled, you can enter Setup freely. ′ Page: 4-22 BPC-8590 USER S MANUAL... -
Page 70: Save & Exit Setup
You may always call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. ′ Page: 4-23 BPC-8590 USER S MANUAL... -
Page 71: Exit Without Saving
►Integrated Peripherals word Quit Without Saving (Y/N)? N ►Power Management etup ►PnP/PCI Configura Saving ►PC Health Status Esc : Quit ↑↓→← : Select Item F10 : Save & Exit Setup Abandon all Data ′ Page: 4-24 BPC-8590 USER S MANUAL... -
Page 72: System Assembly
APPENDIX SYSTEM ASSEMBLY This appendix contain exploded diagram of the system. Section includes: Exploded Diagram for Whole System Unit Page: A-1... -
Page 73: Exploded Diagram For Whole System Unit
Appendix A System Assembly EXPLODED DIAGRAM FOR WHOLE SYSTEM UNIT ′ Page: A-2 BPC-8590 USER S MANUAL... - Page 74 Appendix A System Assembly ′ Page: A-3 BPC-8590 USER S MANUAL...
- Page 75 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: Block Diagram Interrupt Map RTC (Standard) RAM Bank Timer & DMA Channels Map I / O & Memory Map Page: B-1...
-
Page 76: Block Diagram
Appendix B Technical Summary BLOCK DIAGRAM ′ Page: B-2 BPC-8590USER S MANUAL... -
Page 77: Interrupt Map
Cascade for IRQ 8-15 Serial port 2 Serial port 1 Parallel Port 2 Floppy Disk adapter Parallel port 1 RTC clock Available Serial 3 Serial 4 PS/2 Mouse Math coprocessor IDE Controller IDE Controller ′ Page: B-3 BPC-8590 USER S MANUAL... - Page 78 Second alarm Minutes Minutes alarm Hours Hours alarm Day of week Day of month Month Year Status register A Status register B Status register C Status register D 0Eh-7Fh 114 Bytes of User RAM ′ Page: B-4 BPC-8590USER S MANUAL...
-
Page 79: Timer & Dma Channels Map
System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available Available / Parallel Floppy Disk adapter Available / Parallel Cascade for DMA controller 1 Available Available Available ′ Page: B-5 BPC-8590 USER S MANUAL... - Page 80 RTC Controller RTC Controller NMI & RTC controller RTC RTC Controller RTC Controller RTC Controller NMI & RTC controller RTC RTC Controller RTC Controller RTC Controller NMI & RTC controller RTC RTC Controller RTC Controller ′ Page: B-6 BPC-8590USER S MANUAL...
- Page 81 2. Only if IDE Standard I/O space is enabled for Secondary Drive. Otherwise, the target is PCI. 3. If POS_DEC_EN bit is enabled, reads from F0h will not be decoded by the ICH2. If POS_DEC_EN is not enabled, reads from F0h will forward to LPC. ′ Page: B-7 BPC-8590 USER S MANUAL...
