Quick Start Guide

GV-Recording Server V1.1
Thank you for purchasing GV-Recording Server. This guide is designed to assist
the new user in getting immediate results from the GV-Recording Server. For
advanced information on how to use the GV-Recording Server, please refer to
GV-Recording Server User's Manual on Software DVD.
© 2011 GeoVision Inc. All rights reserved.
1
Introduction
Welcome to the GV-Recording Server Quick Start Guide. This quick guide
will guide you through the basic installation of GV-Recording Server,
connecting to IP video devices and distributing to clients. For the detailed
user manual, see the GV-Recording Server User Manual on the
GV-Recording Server Software DVD.
Packing List
● GV-Recording Server Software DVD
● GV-Recording Server Quick Guide
● GV-USB Dongle
The GV-USB Dongle supports connection with up to 128 IP channels.
GV-Video Gateway dongle comes in two types, internal and external
dongles. GV-Recording Server dongle comes in internal type. The following
dongle options are available:
GV-Video Gateway Only (without recording functions):
● Third-party IP devices (includes GV-IP devices): 128 IP channels.
GV-Recording Server (full functions available):
● GV-IP video devices only: 32, 36, 40, 44, 48, 52, 56, 60, 64, 68, 72,
76, 80, 84, 88, 92, 96, 100, 104, 108, 112, 116, 120, 124, 128 IP
channels.
● Third-party IP devices (includes GV-IP devices): 32, 36, 40, 44, 48,
52, 56, 60, 64, 68, 72, 76, 80, 84, 88, 92, 96, 100, 104, 108, 112, 116,
120, 124, 128 IP channels.
Note: To see how to install the internal GV-USB Dongle, refer to
Appendix D. Install the Internal USB Dongle in the GV-Recording
Server User Manual.
2011/12
English
RSV11-QG-A

Advertisement

loading
Need help?

Need help?

Do you have a question about the GV-Recording Server V1.1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GeoVision GV-Recording Server V1.1

  • Page 1: Quick Start Guide

    Appendix D. Install the Internal USB Dongle in the GV-Recording advanced information on how to use the GV-Recording Server, please refer to Server User Manual. 2011/12 GV-Recording Server User's Manual on Software DVD. English © 2011 GeoVision Inc. All rights reserved. RSV11-QG-A...
  • Page 2: Minimum System Requirements

    System Requirements Minimum System Requirements Optimal System Requirements Servers meeting the following minimum system requirements have the Servers meeting the optimal system requirements have the capacity to perform one of the following: capacity to receive up to 128 channels and transmit up to 300 channels with the image settings of 1280 x 1024 resolution, 30 fps and H.264 / MPEG4 ●...
  • Page 3: Network Requirements

    20 fps H.264 3 TB 7200RPM hdd x 4 (SATA3) 32 ch / 3 TB 12 TB Compatible Versions of GeoVision Applications JPEG 4 ch / 2 TB 64 TB 3 TB 7200RPM hdd x 32 (SATA3) ● GV-System, GV-Control Center, Multi View, Multicast: version 8.4 or later.
  • Page 4 2. Insert Software DVD to the computer. This window pops up automatically. 3. To install USB driver, select Install or Remove GeoVision GV-Series Driver and click Install GeoVision USB Devices Driver 4. Type the ID and Password. The default login name and password for to start.
  • Page 5 Connecting to IP Devices When logging in the GV-Recording Server for the first time, the Install 5. The GV-Recording Server will try to connect to the devices using admin as the default ID and password. To connect with other ID and password, Wizard will be prompted to help you add IP video devices, assign storage select the camera, click the Edit button and select Host Setting.
  • Page 6 Panasonic, Sony, VIVOTEK and protocols: ONVIF, PSIA, RTSP. To see the supported models for each brand, refer to the Supported IP Camera List at http://www.geovision.com.tw/english/4_21.asp. To see how to add IP devices using protocols, refer to 5.2.1 Install Camera in the GV-Recording Server User Manual.
  • Page 7 Passive Connection To access GV-Recording Server on GV-IP devices: The GV-IP device must also be configured to access the GV-Recording To create passive connection, the GV-Recording Server must be configured Server. to allow connections from GV-IP video devices. 1. Access the Video Gateway / Recording Server setting page on the To allow passive connection on GV-Recording Server: Web interface of the GV-IP device.
  • Page 8 Distributing to Clients The GV-Recording Server can simultaneously transmit up to 300 channels To start passive connection on GV-Recording Server: to clients. User accounts can be created for clients to access GV-Recording 1. On the GV-Recording Server, select Install Camera in the left menu. Server through Web interface.
  • Page 9 Connecting with the GV-System 6. Click OK to return to the User Account List. You need to configure the GV-System to access video streaming from the 7. To set access rights, select a user account and click the Privilege GV-Recording Server. button .
  • Page 10 4. Keep the default communication port of GV-Recording Server as 1. In the login dialog box, click the Edit button.This dialog box appears. 11000, or modify to match the TCP/IP port on the GV-Recording Server. Click the Query button to attempt connection to the GV-Recording Server.
  • Page 11 Connecting with the GV-Control Center Connecting with Multicast You need to configure the GV-Control Center to access video streaming The Multicast view allows you to receive video and audio streams from a from the GV-Recording Server. multicast group. You need to first enable the multicast function. See 5.3.5 Video Gateway in the GV-Recording Server User Manual for details.
  • Page 12 4. Type the ID and Password of a GV-Recording Server user account. 9F, No. 246, Sec. 1, Neihu Rd., Neihu District, Taipei, Taiwan 5. To add the GV-Recording Server to address book under a group, Tel: +886-2-8797-8376 Fax: +886-2-8797-8335 select a Group Name or type a new name. support@geovision.com.tw http://www.geovision.com.tw...
