- Page 1 Seat Comfort Systems Revitalizer Massage Installation Manual SCS6MC Seat Comfort Systems www.seatcomfort.com...
-
Page 2: Important Safety Instructions
Important Safety Instructions The Reviltalzer Massage System is a vibration system that has been designed to be installed into the seat back foam in a minimal amount of time with readily available tools. The unique design allows the driver and passenger to experience revitalizing massage in the Lumbar area in almost all of today's vehicles. - Page 3 Motor Placement 30 31 40 41...
- Page 4 Motor Installation (A.) Foam Cutout: Cut out the foam to receive the shape of the motor housing by pulling back the long cut of the foam and placing the blade on an angle and cut towards the center. Repeat this on the other side and remove the foam cutout . 2 "...
- Page 5 Wire Placement Route the motor wires through the foam and connect to the distribution box (below). Make sure that there are no loose wires that may interfere with the lumbar or recliner mechanisms. Attach the power connector wire to P/W (below) and route the wire with fuse to 12 volt power.
- Page 6 System Power Connection Power Connection To Vehicle 1.Run the power harness under the carpet and along the scuff plate toward the fuse box. 2.Install the negative wire to ground and secure in place. 3.Connect the red wire (positive) to 12 volt power. Fuse Box Harness Extension Fuse...
-
Page 7: Operating Instructions
Operating Instructions Massage Operation On/Off - This button turns on the massage system Function - Cycles through 8 programs Time - Selects duration of massage Speed - Increases or decreases massage intensity Massage Description 1: Z1 - Z2 - Z3 : "Chaos" 2: Z1 - Z2 - Z3 : "Wave"... - Page 8 Seat Comfort Systems - Warranty Information 36 MONTH/36,000 MILE LIMITED WARRANTY Seat Comfort Systems warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven to have defective material or workmanship within 36 months or 36,000 miles of the original purchase, such defect(s) will be repaired or replaced without charge for the parts.
