Grancom OP-4E1+ETH+32Vo User Manual

Voice broadband optical multiplexer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Voice Broadband Optical Multiplexer
CHPATER 1 GENERAL INFORMATION ....................................... 3
................................................................................. 3
CHPATER 2 FUNCTION DESCRIPTION ....................................... 5
2.1.1 Front Panel LED Indicators .............................................. 5
2.1.2 CONSOLE Interface ........................................................ 6
2.1.3 Fiber Interface .................................................................. 6
CHAPTER 3 TECHNICAL SPECIFICATIONS ............................... 8
CHAPTER 4: INSTALLATION ...................................................... 10
....................................................................................... 11
CHAPTER 5 APPENDIX ............................................................... 12
5.1.1 How to make E1 connecting cable ................................. 12
connecting cable ...................................................................... 13

Table of contents

......................................................................... 3
........................................................................... 5
...................................................... 8
......................................................................... 8
................................................................. 8
.......................................................... 8
.............................................................. 9
......................................................... 10
....................................................................... 11
...................................................... 12
.................................................................. 16
Manual
User
................................................. 6
................................................... 8
......................................... 9
............................................... 11
....................................... 11
....................... 14
.. 9
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OP-4E1+ETH+32Vo and is the answer not in the manual?

Questions and answers

Summary of Contents for Grancom OP-4E1+ETH+32Vo

  • Page 1: Table Of Contents

    Voice Broadband Optical Multiplexer Manual User Table of contents CHPATER 1 GENERAL INFORMATION ........3 1.1 I ................. 3 NTRODUCTION 1.2 F ................. 3 EATURES CHPATER 2 FUNCTION DESCRIPTION ........5 2.1 F ................5 RONT ANEL 2.1.1 Front Panel LED Indicators ..........5 2.1.2 CONSOLE Interface ............
  • Page 2 Brief Introduction This User Manual describes the installation and operation of OP-4E1+ETH+32Vo . Before you use our device for the first time, please read all the included materials carefully, and install and operate this series of products in keeping with items listed in the manual, so as to avoid damaging the device resulting from malpractice.

  • Page 3: Chpater 1 General Information

    User Chpater 1 General Information 1.1 Introduction OP-4E1+ETH+32Vo is a new generation highly-integrated single-board PCM base group multi-connection equipment based on independent software and thick & thin film technology. It can provide a 4~32-line voice interface directly upon the optical transmission channel with a 4-line E1 interface, a 4-line(100M shared) Ethernet data interface.
  • Page 4 Voice Broadband Optical Multiplexer Manual User  1.9 inches structure with 1U height supported, high single-machine density, and lower machine room occupancy.

  • Page 5: Chpater 2 Function Description

    Voice Broadband Optical Multiplexer Manual User Chpater 2 Function Description 2.1 Front Panel Fiber Port CONSOLE (Figure of Front Panel) 2.1.1 Front Panel LED Indicators There are 52 LED indicators with different functions at the front panel. Their functions are described as follows: Name Color Function...

  • Page 6: Console Interface

    Voice Broadband Optical Multiplexer Manual User Ethernet connected properly Indication connection ACT1-4 Green activities of Ethernet 1-4 Connection off flash Data packet transferring Full duplex Indication of full/half duplex of DUP1-4 Green Ethernet 1-4 Half duplex 100M Indication of operation speed of SPD1-4 Green Ethernet 1-4...
  • Page 7 Voice Broadband Optical Multiplexer Manual User Ethernet VOICE E1 120Ω 9-12 13-16 9-12 13-16 DC48V AC220V (Figure of Rear Panel-120Ω) 2.2.1 E1 Interface 4-line E1 interface on rear panel, next to voice interface is E1 of line. 75Ω/RX: 75Ω unbalanced E1 signal input. 75Ω/TX: 75Ω...

  • Page 8: Chapter 3 Technical Specifications

    Voice Broadband Optical Multiplexer Manual User Chapter 3 Technical Specifications 3.1 Operating Environment The device has a wide range of operating temperature and is able to work normally and stably in highly adverse environment. Operating Temperature: 0℃ ～ +50℃ －40℃ ～ +70℃ Storage Temperature: Relative Humidity: 10 %～95 %...

  • Page 9: Ethernet Interface

    Voice Broadband Optical Multiplexer Manual User Interface Connector: Q9 (75Ω) 3.6 Ethernet Interface Ethernet Interface Rate: 10M/100M adaptive, 10M half-duplex, 10M full-duplex, 100 M half-duplex or 100M full-duplex optional Compatible Portocol: IEEE802.3 Transmission Rate: 100M 3.7 Serial Interface (RS232/RS485/RS422) Data Interface Transmission Rate: ≤115.2kbps Adaptive Transmission Type: Asynchronous Interface Connector: RJ45...

  • Page 10: Chapter 4: Installation

    Voice Broadband Optical Multiplexer Manual User Chapter 4: Installation 4.1 Safety Requirements Please read the following safety items before installation to avoid physical injury and damage to this product or any other products connected. To avoid potential hazard, the product can be used only within specified scope.

  • Page 11: Inspection Upon Unpacking

    Voice Broadband Optical Multiplexer Manual User 11. Do not point the optical header toward eyes, lest that laser injures the retina. 4.2 Inspection upon Unpacking After unpacking the product, inspect the type, quantity and condition of device and accessories inside according to the list of contents specified in this manual.

  • Page 12: Chapter 5 Appendix

    Voice Broadband Optical Multiplexer Manual User Chapter 5 Appendix 5.1 How to make the cable 5.1.1 How to make E1 connecting cable 75Ω mode: 120Ω mode: Core connects with core, The Pinout of 120Ω mode are Sheath connects with connects, and illustrated below Core is isolated from sheath.

  • Page 13: How To Make Serial (Rs232/485/422) Interface

    Voice Broadband Optical Multiplexer Manual User 1) 1 and 2 are used for sending, 3 and 6 for the receiving, and 4, 5, 7 and 8 are two-way lines. 2) 1 and 2 must be twisted pair, 3 and 6 twisted pair, 4 and 5 twisted pair, and 7 and 8 twisted pair.

  • Page 14: How To Make Voice Interface Connecting Cable

    Voice Broadband Optical Multiplexer Manual User 5.1.4 How to make voice interface connecting cable 8 RJ45 interfaces provide 32 lines of telephone; each one provides four lines, Definition [1..2] Voice Line1 [3..4] Voice Line2 [5..6] Voice Line3 1,2,3,4,5,6,7,8 [7..8] Voice Line4 5.1.5 How to make CONSOLE interface connecting cable Definition RS232Input...
  • Page 15 Voice Broadband Optical Multiplexer Manual User connected. transmission distance on specifications of the ordered exceeds specifications of the product. ordered product. Contact the distributor. Failure optical interface module. The network cable is not Make the connecting cable properly twisted-pair Change the network structure to The cascade of HUBER is too reduce the multiple cascades of Ethernet...

  • Page 16: Warranty Card

    Voice Broadband Optical Multiplexer Manual User 5.3 Warranty Card The Company guarantees: Maintenance Service Within the free-of-charge warranty period (12 months from the date of purchase), the Company will replace or repair any damaged components free of charge, should the device fail under normal operation circumstances recognized by the Company.
  • Page 17 Voice Broadband Optical Multiplexer Manual User not limited to loss of information, resulting from defects of the product. Product repair, maintenance records Name： OP-4E1+ETH+32Vo Device Num： Repair Date Service Num...
