Drill/Driver - Operating Instructions

Use the MPB switch on the POWERhandle to
select the direction of rotation, then pull the
trigger. This trigger switch is an electronic
variable speed control which enables the user to
vary the speed continuously. The speed varies
according to how far the trigger switch is
depressed. The further it is depressed the faster
the chuck will rotate and the lighter it is
depressed, the slower it will rotate.
To stop the drill, release the trigger switch.
NOTE. You can only change the direction of the
rotation of the drill using the forward / reverse
switch when the trigger is NOT depressed.
Drilling uses the forward mode. The reverse
mode is intended for the removal of screws.
Drilling Positions
This symbol indicates the DRILLING MODE.
Used for all normal drilling (wood, aluminium,
and steel) in this mode the clutch is deactivated.
This symbol indicates the HAMMER MODE.
(some models of this product have hammer
function) This mode will activate the hammer
action while drilling. For best results in hammer
mode, set the gear selector to high gear.
NOTE. Hammer Mode is not available on the
drill model WS1-LD01
Torque Adjustment/Hammer Selection Collar
By rotating the torque adjustment / hammer
selection collar behind the chuck, it is possible to
adjust the torque to each of the 20 settings, or
select hammer action setting.
NOTE. Hammer Mode is not available on the
drill model WS1-LD01
The range of 20 torque settings allows better
control when using the drill as a screwdriver as it
prevents over-tightening of the screws.
The symbols circling the collar are used to
indicate the level of torque. The larger the
symbol or number on the collar, the higher
torque and the larger the fastener which can be
driven. To select any of the symbols, rotate the
collar until the desired symbol aligns with the
arrow head indicator on the housing.
Speed Gearbox
The 2 Speed Gearbox allows you to select a
gear with the optimum speed and torque to suit
the application.
NOTE. When changing the gear selector ensure
the drill is not operating.
To select the LOW gear (low speed, high torque
setting), pull the gear selector back, always from
the chuck. The word LOW will be displayed.
To select the HIGH gear (high speed, low torque
setting), push the gear selector forward, towards
the chuck. The word HIGH will be displayed.
