0801_GB_99 Instructions for installation, use e maintenance ELECTRIC KITCHENS M62P M64P M62V M64V · · · M74P M74PQ M76P M72V M74V · · · · M74PFXE M74PQFXE M76PFXE · · M74VFXE 03/2007... - Page 2 CHARACTERISTICS Supplied by: Date: Customer Service: e-mail 0801_GB_99 - ELECTRIC KITCHENS 03/2007 2 · 20...
-
Page 3: Table Of Contents
INDEX Diagram Characteristics of the appliances Technical data 4 Installation instructions 4.1 Safety rules 4.2 Structure, framework and safety devices of the appliances 4.2.1 Oven Electric version GN 1/1 ventilated 4.3 Assembly 4.3.1 Installation premises 4.3.2 Statutory regulations and technical requirements 4.3.3 Installation 4.3.4 Electrical connection 4.3.5 Equipotential... -
Page 4: Diagram
1 - DIAGRAM M64P M62P Electric power Electric power Electric Data plate Electric power power Data plate Data plate M76P M74P - M74PQ 1000 Electric Electric power power Data plate Electric power Electric power Electric power 1000 0801_GB_99 - ELECTRIC KITCHENS 03/2007 4 ·... - Page 5 1 - DIAGRAM M76PFXE M74PFXE - M74PQFXE 1000 Electric Electric power power Data plate Electric power Electric power Electric power 1000 M74VFXE Electric power Data plate Electric power Data plate 0801_GB_99 - ELECTRIC KITCHENS 03/2007 5 · 20...
- Page 6 1 - DIAGRAM M64V M62V Electric Electric power power Data plate Electric power Electric power Data plate Data plate M74V M72V Electric Electric power power Data plate Electric power Electric power Data plate Data plate 0801_GB_99 - ELECTRIC KITCHENS 03/2007 6 ·...
-
Page 7: Characteristics Of The Appliances
BEFORE INSTALLING AND USING THE APPLIANCE. THE APPLIANCE MUST BE INSTALLED BY QUALIFIED PERSONNEL. 3 - TECHNICAL DATA Model Description Dimensions in mm. (LxDxH) M62P Electric range 2 plates 400 x 600 x 270 M64P Electric range 4 plates 600 x 600 x 270... -
Page 8: Installation Instructions
4 - INSTALLATION INSTRUCTIONS 4.1 Safety rules 4.3 Assembly 4.3.1 Installation premises • Only a local gas utility technician is authorized to carry out gas installations and connections. The statutory regulations (applied The appliance must be installed in a well-ventilated room, and if in Germany VDE, Austria ÖVE, Switzerland SEV, etc.) and connec- possible under a range hood (check current regulations). -
Page 9: Equipotential
4 - INSTALLATION INSTRUCTIONS 4.3.5 Equipotential The appliance must be hooked up to a unipotential system.The required terminal is located near the power cable and it is marked by a tag with a symbol The manufacturers cannot be held responsible for any dam- age due to inadequate or incorrect installation. -
Page 10: Instructions For Use
6 - INSTRUCTIONS FOR USE 6.1 Safety, cleaning and repair rules Fig. 1 • This appliance is used for the preparation of meals at industri- al level. Usage and cleaning can be carried only by expert per- sonnel. Maintenance and repair can be carried out only by skilled technical personnel. -
Page 11: Lighting And Shutdown Of Electric Oven Gn 1/1
6 - INSTRUCTIONS FOR USE 6.3 Lighting and shutdown of electric oven acid). These acids are used if the steel has undergone strong chemi- cal stresses, hence generally losing its inactive coat. GN 1/1 The inactive layer can be chemically damaged or jeopardized by reducing agents (oxygen consumption) if they come in contact with With knob (pos. -
Page 12: Weee Directive
6 - INSTRUCTIONS FOR USE 6.6.3 The 2002/96/EC (WEEE) Directive: information to users This informational note is meant only Fig. A for owners of equipment marked with the symbol shown in fig. A on the adhe- sive label featuring the technical specifi- cations applied on the actual product (the label also giving the serial number). -
Page 13: Appendix: Electrical Diagram
7 - APPENDIX: ELECTRICAL DIAGRAMS M62P - 1xR1 + 1xR2 M62V - 1xR3 + 1xR4 M72V - 1xR1 + 1xR2 400V 3N Position plates B1 plate rear B2 plate front 230V 3 2000 w 1200 w 2300 w 1500 w... - Page 14 7 - APPENDIX: ELECTRICAL DIAGRAMS M64P - 2xR1 + 2xR2 M64V - 2xR3 + 1xR4 + 1xR5 M74P - 4xR2 M74V - 2xR3 + 1xR4 + 1xR5 R... R... R... R... Position plates B1 plate rear left 400V 3N B2 plate front left B3 plate rear right L1 L2 L3 N B4 plate front right...
- Page 15 7 - APPENDIX: ELECTRICAL DIAGRAMS M74PFXE - 4xR1 + 1xR6 M74VFXE - 2xR3 + 1xR4 + 1xR5 + 1xR6 R... R... R... R... Position plates B1 plate rear left B2 plate front left B3 plate rear right L1 L2 L3 N B4 plate front right 400V 3N L1 L2 L3...
- Page 16 7 - APPENDIX: ELECTRICAL DIAGRAMS M76P - 6xR1 Position plates B1 plate rear left B2 plate front left B3 plate rear central B4 plate front central B5 plate rear right B6 plate front right L1 L2 L3 230V 3 400V 3N L1 L2 L3 N 2000 w 1150 w...
- Page 17 7 - APPENDIX: ELECTRICAL DIAGRAMS M76PFXE - 6xR1 + 1xR6 Position plates B1 plate rear left B2 plate front left 400V 3N L1 L2 L3 N B3 plate rear central B4 plate front central B5 plate rear right B6 plate front right L1 L2 L3 230V 3 2000 w...
- Page 18 7 - APPENDIX: ELECTRICAL DIAGRAMS M74PQ - 4xR1 Position plates B1 plate rear left 400V 3N B2 plate front left B3 plate rear right L1 L2 L3 N B4 plate front right L1 L2 L3 230V 3 2600 w 1800 w 1200 w 600 w 400 w...
-
Page 19: Appendix: Electrical Diagram
7 - APPENDIX: ELECTRICAL DIAGRAMS M74PQFXE - 4xR1 + 1xR6 Position plates B1 plate rear left B2 plate front left B3 plate rear right L1 L2 L3 N B4 plate front right 400V 3N L1 L2 L3 230V 3 2600 w 1800 w 1200 w 600 w... - Page 20 WARNING THE MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR ANY INACCURACIES IN THIS BOOKLET DUE TO COPYING OR PRINTING ERRORS. DUE TO ITS POLICY OF CONTINUAL PRODUCT IMPROVEMENT, THE MANUFACTURER RESERVES THE RIGHT TO MAKE ANY CHANGES DEEMED NECESSARY. THE MANUFACTURER CANNOT BE HELD RESPONSIBLE IF THE INSTRUCTIONS CONTAINED IN THIS MANUAL ARE NOT OBSERVED.
