Summary of Contents for LIFE Ionizer M7 UC

  • Page 2: Table Of Contents

    M7 UC NG Installation (under counter) Quick Connect Fittings and Tubing Display Overview Function Options M7 NG Operation Method (counter top) M7 UC NG Operation Method (under counter) Internal Filter Replacement Filter Reset Instructions Scaling Filter Installation Filtration Media Pre-Filter Replacement...

  • Page 3: Safety Guide

    Safety Guide - Read Completely Before installation or operation of the LIFE Ionizer®, read this instruction manual completely. Note- Some parts may have been altered to improve product quality, function or ease of use. Symbols Refer to the following key symbols and indicators throughout the manual.
  • Page 4 Do not place the machine in humid areas such as bathrooms. Do not clean this machine by spraying the ionizer with water as it may cause electrical shock. M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 5 1. Unplug power cord from electrical outlet 2. Wipe the machine down and place in shaded area 3. Contact your LIFE Ionizer® dealer Use only (110v) in the U.S.A. and Mexico. Use (100v) in Japan. Most other countries require (220v). The power cord cannot be altered from manufacturer’s specs.
  • Page 6 DO NOT DRINK ACIDIC WATER. Do not store Alkaline or Acidic water in metal containers, although you can put alkaline water in the Water for LIFE stainless steel bottles as they are designed to maintain pH and ORP. M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 7 If the machine will not be used for 3 days or more... 1. Unplug the power cord from the electrical outlet 2. Turn off the water valve to avoid leaking 3. Remove filters, drain and place in refrigerator in plastic bags. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 8: Installation Of Parts Guide

    Installation of Parts Guide Flexible Hose User Manual 1/4” Tubing Hose For M7 UC NG Diverter Valve Cold Water Connect Alkaline/Acid Hoses Reagent Drops pH Color (pH Test Drops) Chart BTB Chemical Faucet Patch Cable Tubing/Cable Protector Extra Faucet Fuse...

  • Page 9: Parts Of The Ionizer

    Parts for the Ionizer (Bottom) 1. Source water inlet 2. Acidic outlet 3. On/Off Power Switch 4. Fuse Box 5. Power Plug ** Plugs must be removed before installation. See page 16 for Quick Connect Fittings and Tubing instructions. M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 10 Read these inst r uctions tho r oughly be f or e at t empting install ation Faucet (for M7 UC) 1- Water Spout 1- Acid W at er Spout 2- Digital Indicator 2- Digital Indi cat or 3- Water Spout...

  • Page 11: M7 Ng Installation (Countertop)

    Some units may contain water Don’t be alarmed; we test units for quality before shipment. Your installation is now hooked up and ready to operate! M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 12 Diverter valve STEP 3: round nut STEP 5: Diverter valve 1/4” tubing elbows STEP 4: plugs (in green) Pre Filter Bottom of ionizer Bottom of ionizer STEP 6: inlet valve Diverter valve outlet valve suction M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 13: M7 Uc Ng Installation (Under Counter)

    Union connectors Source water inlet MCU cable connector Acidic outlet valve Front Alkaline outlet Faucet turret Faucet patch cable Back x x x - x x x x x - x x - x x Plug connector M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 14 Turn the main water line to the valve back on. Cold Water Connect valve. Source Water IMPORTANT ** Highlighted plugs must be removed before installation. See page 16 for Quick Connect Fittings and Tubing instructions. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 15: Quick Connect Fittings And Tubing

    Ensure system is depressurized before removing fittings. Push in the collar against the face of the fitting. With the collar held in this position, the tube can be removed. The fitting can then be re-used. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 16: Display Overview

    4. Acidic Selector 5. Menu/Function 6. Filter 1 Indicator/Reset 7. Filter 2 Indication/Reset 8. Filter 1/Life Indicator 9. Filter 2/Life Indicator 10. Operation Display Lamp 11. Level Indicator 12. Indicator Water Type (Alkaline/Acidic/Purify) 13. pH Indicator M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 17: Function Options

    Once you do this F10 will appear on the display and below that it will show a number. • To increase volume, press and release the “FILTER 2” button, to decrease the volume setting press and release the “FILTER 1” button. M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 18 For optimum performance of the unit, you will need to clean your ion- izer with the CITRIC ACID CLEANING FILTER also known as the SCALING FILTER. We recommend using this cleaning cartridge 2-3 times a year depending on the hardness of your water. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...
  • Page 19 WATER FLOW CHECK (F-80) (0 is default setting) RUN TIMER (F-81) 10 minutes (10 is default setting) To show the power consumption and water flow information, press the “Menu” button and “Filter 1” button simlutaneously and hold down for about 8 seconds. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 20: M7 Ng Operation Method (Counter Top)

    STOP collecting water, press the “ON/OFF” button. Purified water discharge method Press the “ON/OFF” button and then select the “PURIFIED” button to start dispensing filtered, purified water. To STOP collecting water, press the “ON/OFF” button. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...

  • Page 21: M7 Uc Ng Operation Method (Under Counter)

    M7 UC NG Operation Method (Under the Counter) DISPLAY WINDOW OPERATION MENU DESCRIPTION When you select alkaline water. 1~4 phases appear in number and light is marked by blue color. When you select acid water, 1~3 phases appear in number and light is marked by orange color.

  • Page 22: Indicator Functions

    *Acidic Water 2 - 2nd grade of acid water is being extracted now. *Acidic Water 1 - 1st grade of acid water is being extracted now. Purified Water Button *Purified Water is being extracted now. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...

  • Page 23: Internal Filter Replacement

    → Reset the filter counter (see page 25). * When you place your order for pre-filters, you can also purchase a filter wrench which will ease the installation process. An oil filter wrench will also work. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 24: Filter Reset Instructions

    2) If the machine has not been used for a few days, let the water run for 3-5 minutes at the “Purified Water” setting before making Ionized Alkaline water for consumption. 3) Consult with the installer or retailer on the purchase of filters if in question about usage or installation. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...

  • Page 25: Scaling Filter Installation

    Citric Acid (Scaling) cleaning filter can be used up to 3 (three) times per year. ON/OFF PURIFIED NOTE: If the water dispersed from the spout is still slower than the waste water, the machine may need to be sent in for deep cleaning. M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 26 This step will purge all of the citric solution, along with any scale, out of the machine. The cleaning process is now complete. Remove the scaling filter and throw it way or recycle it and reinstall a #2 filter. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...

  • Page 27: Filtration Media

    Generates negative ions, increases water’s ionization 3. BioMass ball-Ceramic Filter - High quality ceramic filter designed for bacteria control. 4. Vitamin C Ceramic Technology™ Laboratory filtration technology for Chlorine and Chloramines. 5. Special Quality Sediment Filter Prevents sediment discharge. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 28: Pre-Filter Replacement

    Tighten with pre-filter wrench clockwise. 7. Repeat process if needed to your other filters. 8. Connect inlet and outlet tubing. 9. Apply water pressure. 10. Run ionizer on “PURIFY” mode for around 3-5 minutes to flush out pre-filter. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...

  • Page 29: Explanation Of Ionized Water

    - such as calcium, potassium, magnesium, and sodium. The anode has a positive charge and produces acidic ionized water (pH range 3.5~6.5) with positively charged hydroxide ions and attracts acidic minerals – such as chlorine, sulphur, phosphorus. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 30: Alkaline And Acidic Water Usage Guide

    B) When the Acid button is pressed, Acid water will be dispensed from the top spout and Alkaline water will be dispensed from the bottom spout. C) When the purify button is pressed, purified water will be dispensed from the bottom and top spouts. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...

  • Page 31: Uses Of Ionized Alkaline/Acidic Water

    Tea: Taste and aroma are everything to many people. You will be surprised at the improved color, taste, and aroma. You can use less tea and still achieve a full rich taste. M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 32 Alkaline one. Water pH: 7.0 Free of chlorine, rust and cloudiness. Clean water is delicious drinking water. Children: Use purified water with a pH of 7.0 when preparing baby food. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...
  • Page 33 24 hours. Dishes: Dishes and glasses come out sparkling clean. Polishing: Polish mirrors, eyeglasses, glass objects and windows to a high sheen. House Cleaning: Remove dirt from hardwood floors, ceramic tiles, etc. without leaving a sticky residue. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 34: Performance Features

    SMPS Power System- Combine MESH Technology with our new advanced SMPS Power System (the same system used in High Definition Televisions) and your LIFE Ionizer® M series will outper- form any other model in its class. The system generates up to 450 watts of power and it can be adjusted to compensate for hard water problems.

  • Page 35: Common Problems And Solutions

    • Unit is • The problem is • Unplug the unit from making an internal and requires the power source and unusual noise. a qualified technician. call Technical Support. • Unplug the unit from the • Ionizer is • The problem is internal power supply and call leaking. and requires a qualified Technical Support. technician. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 36: Operation Warnings/Error Messages

    E1 : Water flow from ionizer is too low If the following error messages appear on the LCD screen, be sure to contact our technical support at 866.321.3116. E2 : Water flow from faucet is too high M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...

  • Page 37: Acidic Cleaning Instructions

    • Run the ionizer on acid level 2 for one minute. • Turn off the source water to the ionizer. • Let the water “soak” in the chamber overnight (several hours). • Run the unit again on acid level 2 to rinse the minerals from the machine. • Return the unit to normal operation. Note: If this does not work, you will need to purchase a scaling filter (Citric Acid Cleaning Filter) to clean the internal workings of the machine. M7/M7 UC NG www.LifeIonizers.com/Support...

  • Page 38: Frequently Asked Questions

    Ionized Alkaline Water at strength level 1 (one) and strength level 2 (two). Children between the ages of 4 and 12 years of age should never drink Ionized Alkaline Water at strength level 3 (three) or strength level 4 (four). M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...
  • Page 39 1-3 glasses per day for the first week. You may increase the number of glasses per day during the first week if you’re feeling good. On average, two to three weeks per level; work your way up to a 10.5 pH (strength Level 4 (four). M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 40 The Higher pH (Alkaline properties) will last approximately 1-2 weeks. Q: Does Ionized Alkaline Water have any negative effects? Absolutely none, as long as it is used properly. Only the Ionized Alkaline Water should be consumed. NEVER DRINK THE ACIDIC WATER. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...
  • Page 41 Q: How does a water ionizer work? A: Your counter top Alkaline LIFE Ionizer® M7 NG can be directly connected to a diverter valve at the end of your faucet. Connecting directly to your faucet takes about 10-15 minutes. Once connected your water ionizer uses a two step process to transform your tap water into refreshing, healthy alkaline water.
  • Page 42 NOTE: All water filters have both a liters/gallons life and a time period before they stop working optimally. If you only use your ionizer on a limited basis, you will still need to change them annually so they are working correctly. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...
  • Page 43 Although it is safe to drink, wash the container - add one spoon of edible vinegar and water to the container, leave the container for approximately 1 hour, and wash the container. M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 44 Your water source plays an important role on how your water Ionizer creates Ionized Alkaline Water. Being able to adjust the amperage will allow you to find the optimum pH for the best production of Alkaline Ionized water based on your water source. M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...
  • Page 45 A: A water report is necessary to determine what type of filter is needed. Well water may need to be tested by an independent water testing company. Please contact your sales representative and they will pull your Federal Water Report, analyze it, and recommend filters. M7/M7 UC NG www.LifeIonizers.com/Support...
  • Page 46 • Citric acid cleaning filter should be used 3 to 4 times per year. Following these easy steps ensures optimal performance and guarantees your Lifetime Warranty on part & labor. If you buy a LIFE Ionizer® from an unauthorized seller/dealer, M7/M7 UC NG www.LifeIonizers.com/Support www.LifeIonizers.com/Support...
  • Page 47 Q: What is your return policy? A: We invite you to try out our new range of LIFE Ionizer® and enjoy the benefits for 60 days. We are so sure that you will be satisfied with your ionizer that we offer you a 60-day money back guarantee.
  • Page 48 LIFE Ionizer® authorized repair facility. LIFE Ionizer® will repair or replace any malfunctioning ionizer for the specified time frames disclosed above.
  • Page 49 Contact U 6352 Corte Del Abeto, Suite H Carlsbad, CA 92011 866.321.3116 760.431.8047 *When calling technical support please be prepared to give your ionizer serial number located on the back of the unit. www.LifeIonizers.com/Support...
  • Page 50 revised 3-4-15...
