Summary of Contents for GRAFTON BLARNEY

Page 1 GRAFTON STOVES U S E R M A N U A L B L A R N E Y...
Page 2: Table Of Contents
C O N T E N T S SECTION ONE: BLARNEY Technical Data ......................4 Technical Description ..................... 4 SECTION TWO: INSTALLATION INSTRUCTIONS Health and Safety ......................5 Stove Installation ......................5 III. Chimney ........................6 Flue Connection ......................6 Hearth and Fire Surround ....................
Page 3 GENERAL SAFETY INFORMATION This appliance must be installed and commissioned by a fully qualified, registered installer. HETAS registered installers are recommended by Grafton Stoves. Please visit www.hetas.co.uk for a list of approved installers in your area. • This appliance must be installed as per these instructions. No modifications o ralterations of any kind are permitted and will invalidate the warranty.
Page 4: Section One: Blarney
The appliance has been developed to burn wood as its primary fuel source. The Blarney is made primarily from cast iron with plates of sheet steel. The fire chamber is internally lined with cast iron firebricks. There is a riddling grate for clearing ash. The stove is equipped with ceramic glass (resistant up to 800 C) this provides an exceptional view of the combustion, whilst also preventing sparks and smoke deposits from escaping.
Page 5: Section Two: Installation Instructions
SECTION TWO: INSTALLATION INSTRUCTIONS Please read this guide carefully prior to installation and retain for reference purposes. I. HEALTH AND SAFETY All installation work must meet with the requirements of the Health and Safety at Work Act 1974. Appropriate protective equipment must be worn to ensure the safety of persons carrying out the installation.
Page 6: Chimney
III. CHIMNEY The chimney height must be no less than 4 metres (13ft), measured vertically from the top of the stove to the top of the chimney. It should terminate at least 1 metre above roof level. Optimum internal dimensions of the chimney should be 175mm (7”) or 200mm (8”) either square or round, and must not be less than 125mm (5”) in diameter.
Page 7 Check the flue is functioning correctly and ensure all products of combustion are vented to the atmosphere through the chimney terminal. Do not use single wall chimney connector pipe as a chimney on any stove. Connect your stove to an approved flue system serving only one appliance.
Page 8: Hearth And Fire Surround
V. HEARTH AND FIRE SURROUND In conformity with Building Regulations, the stove should be installed on a solid, non-combustible surface such as concrete or masonry. This must be at least 125mm (5”) thick. The specified depth may include the thickness of any solid non-combustible floor beneath the hearth. Combustible material should not be placed beneath constructional hearths unless there is an air-space of at least 50mm between the underside of the hearth and the combustible material, or the combustible material is at least 250mm (10”) below the top of the hearth.
Page 9: Ventilation
VI. VENTILATION If your stove has a lower nominal heat output than 5.0kw, a purpose provided air vent is not usually required. However, one may need to be fitted in small or tightly sealed rooms to ensure the efficient combustion of air. Air openings provided for this purpose must not be restricted.
Page 10: Section Three: Operating Instructions
The appliance must not be left unattended during the initial lighting sequence. • Do not overload the appliance with fuel. • Do not attempt to open the door immediately after igniting the fire. • Do not burn wood containing chemicals such as glue or paint. • Do not attempt to burn any liquid fuel in the stove. • Never use aerosol spray near the stove when it is alight. • If the appliance is left running with the air controls open for extended periods, serious damage can occur. I. BLARNEY Flue Outlet Air Wash / Top Vent Glass Door Handle Main Vent...
Page 11: Fume Emissions
II. FUME EMISSIONS Occasional fumes from ash clearance and refuelling may occur. However, persistent fume emission is potentially dangerous and must not be tolerated. If fume emission persists, the following immediate actions should be taken: a) Open doors and windows to ventilate room. b) Put the fire out or eject and safely dispose of fuel from the appliance.
Page 12: Fuel
VIII. INITIAL BURNING AND CURING Prior to use, this appliance must be installed and commissioned by a fully qualified, registered installer. HETAS registered installers are recommended by Grafton Stoves. Please visit www.hetas. co.uk for a list of approved installers in your area.
Page 13: Overnight Burning
X. OVERNIGHT BURNING When leaving the stove in use overnight, the fire door must be closed. Close all air flow dials and dampen the fire down by covering it with a coating of coal dust or dross. IMPORTANT • Do not fully load the appliance until you are familiar with the operation of all stove controls. •...
Page 14: Flue Draughts
XIII. FLUE DRAUGHTS Draught is created by warm air exiting the stove and rising in the collar air of the chimney. Prior to installation, the chimney can be checked with a smoke pellet. If the chimney does not pull the smoke, it may need attention.
Page 15 BAFFLE PLATE CLEANING: The baffle plate must be checked once a month and cleaned of any deposits. This must only be done when the stove is cold. The baffle plate should be removed and any build up of soot or fly ash brushed away. SHUTTING DOWN: If the stove is not to be used for a long period, all ashes should be removed.
Page 16 GRAFTON STOVES Exclusively distributed in the UK & Ireland by GM Distribution. 70 High Park Drive, Old Wolverton Mill, Milton Keynes MK12 5TT customerservice@graftondistribution.co.uk Specifications correct at time of going to press, we operate a policy of continuous improvement and reserve the right to amend product specifications without notice.
