ADAMOTE-UM-ENG-0212
Adamote User Manual
Thank you for purchasing Adamote. Please read this manual carefully to
install and use Adamote properly. Let's Play!
Content
Parts
Adamote
Fixation
Magnetic Brick
User Manual
1
X 1
X 4
X 1
USB Connector
Sync Button
Red-Blue Indicators
Status Indicators
IR Sensors

Advertisement

loading
Need help?

Need help?

Do you have a question about the Adamote and is the answer not in the manual?

Questions and answers

Summary of Contents for Akar Adamote

  • Page 1 ADAMOTE-UM-ENG-0212 Adamote User Manual Thank you for purchasing Adamote. Please read this manual carefully to install and use Adamote properly. Let’s Play! Content Adamote Fixation Magnetic Brick User Manual Parts USB Connector Sync Button Red-Blue Indicators Status Indicators IR Sensors...

  • Page 2: Supported Accessories

    ➀ Windows XP or later versions. ➁ Mac OS 10.5 or later versions. Due to Adamote being a standard HID device, if a host supports USB HID, then Adamote can be used in the host. In the emulator (B) mode, it requires at least:...
  • Page 3 ADAMOTE-UM-ENG-0212 Installation Put the fixation bricks into the holes of the Adamote’s back. ➀ ➁ ➂ ➃ Tear off the white tapes of the magnetic bricks. ➄ ➅ Fix the Adamote on the top side of the screen. ➆ Plug in the USB connector to the PC.

  • Page 4: Installation Locations

    Adamote are starting to flash repeatedly in an alternating way. ➂ After successful pairing (synchronization), the 1P indicator on the Wii Remote lights up, and the red-blue indicators on the Adamote flash three times. * You only need to pair them once. During the next use, just press any button to reconnect.
  • Page 5 ADAMOTE-UM-ENG-0212 Pair/Sync PS3 DualShock3 Controller Confirm that AMSS is running and Adamote is plugged in. ➀ One USB-A-to-Mini-USB-B cable is required. Plug the Mini-USB-B side to the PS3 DualShock3 Controller. ➁ Plug the USB-A side to the PC. ③ After the confirm window is shown, press the OK button.
  • Page 6 ③ After successful pairing (synchronization), the indicator on the PS4 DualShock 4 will light up , and the red-blue indicators on the Adamote will flash three times. You only need to pair them once. During the next use, just press the PS button to reconnect.
  • Page 7 Ⓑ In mode B, you can connect up to 4 Wii Remotes to the Adamote, and you can run the AKAR Wii Emulator for Adamote to play backup games. The indicators on Wii Remotes of mode B are 1P(■□□□), 2P(□■□□), 3P(□□■□) and 4P(□□□■).
  • Page 8 MotionPlus positioning to calculate the cursor position. ➀ In the range of IR sensors, Adamote will use IR positioning to calculate the position of the cursor. In this status, the red color of the red-blue indicators will light up.
  • Page 9 ADAMOTE-UM-ENG-0212 Quick Overview of Feature Keys Features in Mode A Button Sequence Reference MotionPlus Calibration Page 10 IR Mouse Sensitivity Page 11 Adjusment IR/HCP Mouse Page 11 Cursor Mode Page 12 Anti-Shake Mode Page 12 Default Key Mapping Page 13...
  • Page 10 ADAMOTE-UM-ENG-0212 MotionPlus Calibration in Mode A Calibrate the MotionPlus on Wii Remotes if the cursor of MotionPlus positioning is unstable: ➀ Click the HOME button. The Wii Remote’s 1P and 2P indicators light up. ➁ Press the Dpad’s Down button on the Wii remote.
  • Page 11 ADAMOTE-UM-ENG-0212 IR Mouse Sensitivity Adjustment in Mode A ➀ Click the HOME button. The Wii Remote’s 1P and 2P indicators will light ➁ Press the Dpad’s left or right buttons on the Wii Remote to adjust the cursor ranges. Indicators in Mode A...
  • Page 12 Please refer to the Appendix for the default key mapping. Macro in Mode A You can customize your own key mapping in mode A. Detailed macro settings are available on our web site (Adamote Macro Setting Software, or AMSS manual) https://akar.cc.
  • Page 13 ADAMOTE-UM-ENG-0212 Toggle Key Mapping between Default and Macro ➀ Click the HOME button. The Wii Remote’s 1P and 2P indicators will light ➁ Press the ○ – button to switch to the default mapping, and the ○ + button to switch to the customized macro setting.
  • Page 14 It will flash the blue indicator of the red-blue indicators when a third-party remote is connected. Due to the compatibility of third-party Remotes, Adamote might not work properly if any third-party remote is connected. XBOX 360 Controller Emulator (Xinput Support) in Mode B Please visit our official web site https://akar.cc for the latest AMSS to...
  • Page 15 Appendix: Default Key Mapping of 1P Wii Remote Normal (Function Key Released) Function (Function Key Pressed) * The complete default key mapping is available in the AMSS manual of http://akar.cc. * Wii, Wii U, Nunchuck, and MotionPlus are trademarks of Nintendo.

  • Page 16: Fcc Warning

    ADAMOTE-UM-ENG-0212 FCC Warning Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The device has been evaluated to meet general RF exposure requirements. The device can be used in portable exposure conditions without restriction.
