Elicom EVLplus xx LТ3 User Manual

Electronic scales
Hide thumbs
Table of Contents

Advertisement

Quick Links

Elicom Electronic Ltd.
Electronic Scales
E V L
plus
Models T and M
User's Manual

Table of Contents

1.
Warranty card ............................ 3
2.
Brief description ....................... 4
3.
Main functions........................... 4
4.
Technical data ........................... 4
5.
Scale Overview.......................... 5
6.
Preparing for use ...................... 6
7.
8.
Operation modes ...................... 7
8.1. Weighting Mode................ 8
8.2. Counting Mode ............... 18
Mode ................................ 19
8.4. Service Mode .................. 21
devices ............................ 29
8.6. Error Mode ...................... 30
9.
ЕO Declaration of conformity 31
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVLplus xx LТ3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Elicom EVLplus xx LТ3

  • Page 1: Table Of Contents

    Table of Contents Page Warranty card ......3 Elicom Electronic Ltd. Brief description ....... 4 Main functions......4 Electronic Scales Technical data ......4 Scale Overview......5 Preparing for use ...... 6 E V L plus Installation instructions.... 7 Operation modes ...... 7 Models T and M 8.1.
  • Page 2 Scale Models Series EVLplus EVLplus xx LТ3 EVLplus xx LМ6 EVLplus xx BТ3 EVLplus xx BМ6...

  • Page 3: Warranty Card

    Elicom Electronic Ltd. 1. Warranty Card...

  • Page 4: Brief Description

    Owner’s Manual 2. Brief Description The electronic scales from series EVLplus xx LM, LM, LT, BT, are precise measuring devices for determining the weight of goods in retail stores and warehouses. All scales from series ELVplus are designed to work in temperature range from -10° C to +40° C and to work without external power supply for up to 100 hours.

  • Page 5: Scale Overview

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 4.2. Technical data for all models Model Maximal Minimal Maximal Tare Value of the real Load Load check division e=d= EVL+ 3 3 kg 20 g minus 3 kg EVL+ 3/6 3/6 kg 20 g minus 6 kg...

  • Page 6: Preparing For Use

    Owner’s Manual Metal Platter - the measured loads are placed on top Plastic lid cover - covers the electronic unit and the load cell unit. It protects the keyboard, operator’s (8) and customer’s (7) display. The following information is also placed on the cover License registration Indications for state control Leveler - for the scales to be horizontally placed adjust the legs (5) till the bubble in the leveler...

  • Page 7: Operation Modes

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 Scale Metal platter AC adaptor Operation Manual Passport Warranty card Installation of the metal platter – place the tray legs in the corresponding holes on the upper side of the scale. Sway it gently until it finds a stable position. Place the scale on a flat surface (table).

  • Page 8: Weighting Mode

    Owner’s Manual Model: LM, BM 8.1. WEIGHING Mode Place the load and wait till the scale stands still or until the indication for total price or the load indication blinks repeatedly. 8.1.1 Keyboard keys ON/OFF – Turn on/off the scale. Turn off with this button lessens but doesn’t stop the energy supply from the adaptor.
  • Page 9 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 Keyboard keys 00 , 0 , 1 , 2 , 3 , 4 , 5 , 6 , 7 , 8 , 9 , C .are used in the Weighing mode for entering article prices. Wrong figures are deleted by pressing the button and the price setting starts from the beginning.
  • Page 10 Owner’s Manual 1.700 0.000 2.80 2.50 ___4.76 ____.__ If the price is wrong it can be deleted it by Remove the load from the platter – in the Price per kg field remains the last price entered. pressing the key. The field for TOTAL remains blank until the load Correct the figures by entering 2 , 5 , 0 is under the minimum load for the scale...
  • Page 11 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 N E T 0.200 Т 0.150 1.20 1.20 __0.24 __0.00 If there is a previously set Tare for PLU 3. The After the load is removed the Tare is shown with Tare will be deducted from the load and only a negative sign and the “T”...
  • Page 12 Owner’s Manual N E T 0.000 Т 0.426 3.00 3.00 __0.00 __0.00 Enter price per kg of 3.00 (Example) and After the pot is removed the scale shows the remove the pot. weight of the Tare with a negative sign and the „Т”...
  • Page 13 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 0.000 Т 0.426 3.00 3.00 __0.00 __0.00 key is also used to clear the Tare Т value. To clear the Tare, the scale must be unloaded. Note 1: The following steps are performed for accumulating of the Tare value: Set the Tare and place the first product as described above.
  • Page 14 Owner’s Manual 0.000 -Р- __._6 0.25 ___.__ ___1.5 To add a number of fixed price articles to the Enter the price by pressing the 2 , 5 keys. customer’s bill (For example: 6 onions by 0.25 Press the + to add the sale to the customer’s each).
  • Page 15 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 1.900 -Р- .__6 2.10 2-- 2 ___3.9 ___1.5 With the are reviewed all of the sales recorded in the client’s bill. -Р- .__6 totAL ---- 0.25 ___1.5 ___5.49 To go back to “Weighing Mode” press the “C” or “CP” keys. 8.1.5.3 To delete a particular sale, choose the desired sale by pressing MR .To delete press the MC key two times.
  • Page 16 Owner’s Manual To delete sale #1: 1.900 -Р- .__6 2.10 1-- 1 ___3.9 ___1.5 After the delete is shown the next sale in the Use the MС and MС keys to delete a sale. client’s bill. The total number of sales is now 1. 8.1.5.4.

  • Page 17: Counting Mode

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 To go back to WEIGHING MODE use the C or CP keys 6.590 0.840 PLU 001 PLU . ° __2.56 __20.00 On the first line is shown total weight, on the Use the key to switch the articles on bottom line is shown the total turnover at the...
  • Page 18 Owner’s Manual 8.2.1 Activating from Service mode 2. Press PRG, DW after that press the PRG key rapidly till the “cnt 0” is shown on the display. By pressing the C key from the numeric keyboard change the blinking „0” to „1” .Press СР to exit. 8.2.2 Before you start work, place an exact number of details, you want to count and define their exact number.

  • Page 19: Labeling And Pre-Labeling Mode

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 As a result on the middle line of the display is shown „0”, on the weight line is shown „0.000” and „base” Place the “Basic number of details” and enter their number by the numeric keyboard. The entered number will be displayed on the “Price per unit”...
  • Page 20 Owner’s Manual After the readout is stabilized press PRN to print the label and to record the measurement Remove the load and place the next one….. 8.3.2. Label print by using the keyboard to enter a number of particular article. Method of work: •...
  • Page 21 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 Double click PRG . By continuous pressing of the PRG key is switching to the different functions of the mode.
  • Page 22 Owner’s Manual 0.000 0.000 0.00 0.00 PL1775 ____.__ The first mode is „Programming of price and tare” PRG , PRG - switching to programming of – described in detail in p.8.4.3. articles (in detail p. 8.4.3). This function is available only for price computing scales CALIb 6.41 _.__...
  • Page 23 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 A0f00 o4P50 PRG - AUTO OFF – by using the numerical - software version keyboard is set time after which the scale automatically turns off. When turning the scale on after AUTO OFF, no initial test is preformed Au0-2 CALIb ___.__...
  • Page 24 Owner’s Manual SP.104 SP.200 - Parameter for work with Scanner – Parameter for work with scanner By pressing PRG the scale is going back to “WEIGHING Mode” From each function of the Service Mode you can switch to “WEIGHING Mode” by pressing CP .
  • Page 25 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 Е3nr 151008 1410 – Setting-up the clock for real time. Use PRG - Counter number PRG set of the date and the time ≡ ≡ ≡ ≡ nbr °nbr PRG - Operator’s number - Logical number of the scale in LAN network Print...
  • Page 26 Owner’s Manual 000000 cLiEnt ____.__ ____.__ PRG – Enable/Disable function CLIENT’S BILL PRG - party number 1 – To change use C . 000000 000000 ____.__ ____.__ PRG - party number 2 PRG - party number 3 * The access to the parties numbers can be obtained in WEIGHING Mode with unloaded scale by pressing PRG followed by the PRN.
  • Page 27 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 0.000 0.00 PLU 1 ____.__ ____.__ PRG – switching between article by number PRG - going back to WIGHING Mode PLU (PLU1) or article by article’s number (Art1) – to change use C . For in detail description how to use PRE-LEBALING function, see p.8.3.4;...

  • Page 28: Service Mode

    Owner’s Manual 0.000 0.000 6.00 PLU121 PLU121 1 , 2 , 1 - switch to article № 121 by – To confirm the entered number. As a entering the 3 digits! result is shown the set price and tare of the article PLU121 and the price is blinking 0.000 1.050...

  • Page 29: Connecting With External Devices

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 b-6.11 batLO If battery is Low, the following message is PRG , PRG , PRG – battery status. If the displayed: “batLO” adapter is connected to the scale the sign „ – „ is changing consecutively: - = ≡...

  • Page 30: Error Mode

    Owner’s Manual Speed, Second First digit Protocol [baud] digit 4800 Electronica 1200 КА ORGTECHNICA КА Еlka 752, Datecs 2400 4800 КА Karat, Deisy, Bimco scales 9600 КА Eltrade Protocol with continuous 19200 dispatching of the weight 38400 Connection with PC, PRN 4800 Scales Angel, CAS, DIBAL For example: CASH 02 means speed 4800 for cash register Е752 or Datecs.
  • Page 31 7500 Silistra, Bulgaria 5, Saidinenie sq. PO Box 188 Tel.: +359/ 86 /820 200, 882 255 Fax: +359/ 86 /820 555 e-mail: info@elicom-bg.com OFFICE AND SERVICE 1784 Sofia, Bulgaria 131, Tsarigradsko shosse, "ATM Center", fl. 4, office 403 Tel.: +359/ 2 / 974 4391 Fax: +359/ 2 / 974 4391 e-mail: elicomsf@elicom-bg.com...
