Summary of Contents for dtec Denta/Dentaplus
- Page 1 Denta/Dentaplus Owner´s Manual...
- Page 2 Note: Do not use sharp objects when unpacking the luminaire! 1. Unpacking your Denta/Dentaplus Open the packaging carefully without using any sharp objects! The packaging includes: • Wire arrangements for attaching the luminaire to the ceiling (4 pieces) • The Denta/Dentaplus luminaire...
- Page 3 Parallel Crosswise 4 attachment points 2. Positioning your Denta/Dentaplus The luminaire should be positioned in one of the following two posi- tions: • Parallel position - the eyes of the patient should be in line with 1/3rd of the luminaire.
- Page 4 A TT ACHMENT POINT A TT ACHMENT POINT 3. Preparing the mounting of your Denta/Dentaplus After unpacking the luminaire use the packaging as a guide for mark- ing the attachment points in the ceiling. • On the outside of the cardboard, there are four attachment points marked out.
- Page 5 Ceiling attachment Aluminum nipple Wire Wire Gripper Gripper 4. Mounting your Denta/Dentaplus in the ceiling There are two options of mounting kits enclosed with your luminaire. Use the kit suitable to your needs and preferences.
- Page 6 5. Operating your Denta luminaire The luminaire is operated by a pulling string/cord or, on special re- quests, by a wall switch. The luminaire could be faded in such a way that the two middle sections of lights are switched off by a pull of the string.
- Page 7 6. Operating Your Dentaplus luminaire The luminaire is operated by a pulling string/cord or, on special re- quests, by a wall switch. Instructions to operate the dimmer function: • Switching the lamp on/off: short pull (<0,5 second) • Dimming: Long pull (>0,5 second), the dimming direction is changed with each pull.
- Page 8 7. Exchange of fluorescent light tubes • Denta: 6 x 28 W • Dentaplus: 6 x 54 W...
-
Page 9: General Information
Zone 3 Zone 2 Zone 1 8. General information Image of recommended light conditions for dentists. • Zone 1 = 20 - 40 000 lux • Zone 2 = 3 - 5000 lux • Zone 3 = 500 - 1000 lux... - Page 10 On-line support http://www.d-tec.se/support • Owner’s manual • Användarmanual • Bedienungsanleitung • Mode d’emploi...
- Page 11 Facts: Denta/Dentaplus • Environmentally friendly and energy-saving • CDP (conical de-glaring prism) • Option of indirect light and dimmer • High intensity of illumination Denta: 4 000 lux/1,2 m Dentaplus: 280-5 800 lux/1,2 m • Size 1 355 x 700 x 55 mm •...
