- Page 1 Owner’s Manual Axial Blow-Dryer Series Read the owner’s manual throughly before use Save the Owner’s Manual...
-
Page 2: Table Of Contents
Index 1.0 Specifications --------------------------------------------------------------------------Page 2 2.0 Important safety instructions -----------------------------------------Page 3 3.0 Operating instructions --------------------------------------------------------Page 4 4.0 Functions of Operating panel 4.1 Hour Meter ----------------------------------------------------------------------------Page 4 4.2 Socket and Earth leakage protector -------------------------Page 4 4.3 Three-way Switch --------------------------------------------------------------Page 4 4.4 12A Overload Protector --------------------------------------------------Page 5 5.0 Parallel Operations ----------------------------------------------------------------Page 5... -
Page 3: Specifications
1.0 Specifications Models CGZL-1/230 CGZL-1/120 CGZL-2/230 CGZL-2/120 Parameter Rated Voltage 230 V 120 V 230 V 120 V Current,Frequency 1.25 A，50/60 Hz 2.5 A，50/60 Hz 1.25 A， 50/60 Hz 2.5 A，50/60 Hz Rated Power 1/4 HP 1/4 HP Weight 16.4 kg... -
Page 4: Important Safety Instructions
Important Safety Instructions WARNING This equipment is not designed to use combustible/volatile substance such as gasoline or kerosene, in, on, or near the machine. The use of such materials will cause an extreme hazardous condition. Do not operate the machine with a cut or frayed power cord. Replace cord if it becomes damaged. -
Page 5: Operating Instructions
3.0 Operating Instructions CGZL series are running 2 models, CGZL-1 and CGZL-2. CGZL-1 is equipped with draw bar and wheels for easy transportation and an hour meter for calculating operating time. CGZL-2 is not equipped with the draw bar, wheels and hour meter. In transportation for CGZL-2 please use the handle on top of the blow-dryer. -
Page 6: Parallel Operations
4.4 12A Overload Protector（Fig 3,1.4） CGZL series blow-dryers are equipped with 12A overload protectors. It will automatically cut off the circuit once current is over 12A due to circuit fault. Press “Reset” button when the circuit fault is eliminated. Please contact authorized service center or your local dealer if the “Reset”... -
Page 7: Maintenance
area in method of 5.0 Parallel Operation. Meantime it offers convenience to dry off the area far from the fixed power supply. 7.0 Maintenance Regularly check whether the insulation of power cord is broken or discolored. If yes, replace it please.。 Check whether the fasteners get loose. -
Page 8: Wiring Diagram
Part Number Description 3CGA-0008 Motor / 1/4HP YDK139/200-4 3CGG-0006 Motor fixing bracket 3CGE-0012 Front Grille / Ф470 3CGE-0013 Rear Grille / Ф470 2SJ25B01-0003 Motor Grille 2SJ25E01-0001 Foot 3XCH-0015 Three-way Switch / B00188 3CGK-0001 Overload Protector 12A/ ZE800-12 3CGZ-0007 Socket 3CGZ-0006 Hour Meter JY732-03 2SJ25Q01-0001 2SJ25A01-0005... - Page 9 Suzhou Premier Electrical Appliance Co.,Ltd 9# Yangqing Road, Suzhou,215001, P.R.China Service Line：86-512-67255986 Fax: 86-512-67259661 Website：www.premie.com.cn...
