- Page 1 Kundendienst: HEAT PUMP WP2 - AE Type: Model: WP2 - AE INSTRUCTIONS FOR INSTALLATION AND USE Includes Declaration of Warranty...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ................... 2 INTRODUCTION ...................... 3 CUSTOMER SERVICE .................... 3 PURPOSE OF USE ....................4 SPECIFICATIONS ....................4 DESCRIPTION OF THE HEAT PUMP AND OPERATION ....... 5 ) ...... 5 EFRIGERANT CIRCUIT UNCTIONAL PRINCIPLE OF THE HEAT PUMP ) .................. -
Page 3: Introduction
2. Introduction We appreciate the trust you have given us by purchasing our heat pump. We believe that the product will serve its purpose, thus providing satisfaction both to you and to us. Please read the instructions thoroughly before first operation of the device. -
Page 4: Purpose Of Use
5. Specifications Produkt: HEAT PUMP FOR TAP WATER HEATING Type: Model: WP2 - AE Max. power consumtion: 560 W / 1910W* Max. heat output: 1850 W / 3200W* Max. power output: 680 W (60°C) -
Page 5: Description Of The Heat Pump And Operation
The slot in heat pump WP2 – AE in specifically designed for tap water heating by using the heat stored in the ambient air. The heat pump uses the heat stored in the ambient air by cooling it and is therefore preferably instaled in the cellar or storage room. -
Page 6: Water Heater (Boiler)
6.2 Water heater (Boiler) The slot in heat pump WP2-AE is designed for water heaters with a standard flange (Φ180 mm/8 hole). It is to be instaled on the side of the water heater. 6.3 Aditional electrical heater Additional electric heater EG with power 1.3 kW is used for: quick heating of the tap water - simultaneous operation of the heat pump and the electric heater. -
Page 7: Operating Conditions
The display shows the notification E7. 6.5 Operating conditions The ambient temperature during normal use is +8 to +35°C. The air should be clean, relative humidity should not exceed 50% at +40°C. Higher relative moisture values are allowed only with lower ambient temperature. If a device is used at an altitude of more than 1000 m, its heating and air conditioning capacity is reduced due to air pressure. -
Page 8: Elektrischer Schaltplan
7.3 Elektrischer Schaltplan Heater 230 V AC 50Hz High pressure switch Compressor Water temperature probe (T1) Ambent air temperature probe (T2) Figure 1: Wiring diagram. 7.4 Grounding cabel instalation Heat pump flange Seal Grounding washer Bolt M12x40 Rack washer Heat pump flange Hot water tank housing... -
Page 9: Heat Pump Start-Up
The necesary parts are preinstalled and loosely attached. The grounding cable is to be connested with a AMP-plug. The AMP-plug has to be connected according to drawing in figure 2. The grounding of the water heaters must be done according to the drawing in figure 2. -
Page 10: Operating Procedure
AMBIENT TEMPERATURE PROBE TAP WATER TEMPERATURE PROBE HEATER COMPRESSOR Figure 3: Function diagram. 7.5.1 Operating procedure Within 2 seconds after the heat pump is connected to water supply and electricity source according to these instructions, the display shows the type of the regulator and default settings for operation, for example 'P1', as well as all parameters and their values. -
Page 11: Short Instructions For Operation
7.5.2 Short instructions for operation Water temperature display Display of the selected operating mode/ programme Switch between different Setting the water temperature operating programms parameter values Quick key for single superheating to 60°C (legionella control) The display on the control panel in the main menu displays the current water temperature. - Page 12 If the air temperature is too low or if it drops below ☼ blinks the switching level, selecting the P4 programme means heating the water with the oil fired boiler and selecting the P5 means heating with the blinks or on electric heater.
-
Page 13: Operating Programmes
7.5.3 Operating programmes 1. Water heating only with the compressor (the 'P1' programme must be selected): The device heats the water with the compressor until the set temperature is reached and as long as the air temperature remains above the minimum operating temperature (5°... -
Page 14: Heat Pump Instalation Site
60°C) 1. Setting the time interval of the automatic thermal disinfection / Safety heating (60° C): To enter the parameter display menu, press the keys + and – simultaneously. Use these keys to scroll between the functions in the menu (see the chapter 'Parameter display'). -
Page 15: Safety Warnings
The air must be sucked and discharged without hinderance. In no case should you cover any of the perforations on the heat pump housing. One must also garantie that the heat pump has enough space for normal operation (see figure below). The energy needed for tap water heating comes for the most part from the ambient air that is being sucked by the device. -
Page 16: Instructions For Safe Maintenance
BEFORE ANY SERVICING INTERVENTION, PULL THE PLUG FROM THE WALL SOCKET. Place the heat pump on such location, where the supply cord plug is accessible any time. Place the pump on solid, horizontal, non-slip floor. Make sure there is enough space (at least 2 m ) around the pump to allow handling and manipulation. -
Page 17: Transport And Storage
11. Transport and storage Before transport, protect the heat pump with protective foil and cardboard packaging to avoid eventual damages (scratches, bumps). Move or transport the heat pump only when disconnected from power supply. The total dimensions of the pump vary for different types. The ambient temperature for transport and storage shall be between 10 and 45°C, but in exceptional cases and for a shorter period (up to 24 hours), it may reach up to max. -
Page 18: Safety Warnings
13. Safety warnings This product is manufactured in compliance with the standards which allow the manufacturer to mark it with CE sign. In order to assure functionality of the product, the following warning signs had been used to mark potential hazards. The warning signs have the following meaning: Do not place in Be sure to read the... -
Page 19: Resolving Technical Deficiencies
14. Resolving technical deficiencies Warning Ventilate the room and let it warm up to adequate temperature (open the door, window) Adjust the switch-over temperature to lower setting The pump switches off due to the (from 5 to 25°C) too low ambient temperature. In case of connecting to the oil fired boiler, switch to the 'P2' or 'P3' operation mode (the 'P'... - Page 20 temperature. Circulation consuming too much Switch off the pump and close heat. the circulation valve. Gas leakage in the system. Call the authorised servicing centre. Damaged evaporator due to Call the authorised servicing careless cleaning. centre. The pump operates Not enough gas in the system. Call the authorised servicing continuously –...
-
Page 21: Guarantee, Warranty And Product Liability
15. Guarantee, warranty and product liability Warranty is made according to the legal provisions of the Republic of Austria and the EU. 1. The prerequisite for honouring of warranty terms on the part of the manufacturer (hereinafter referred to as Manufacturer) is presentation of a paid invoice for the purchase of the appliance in question, whereby the identity of the appliance including model and fabrication number must be indicated on the invoice and presented by the claim applicant. - Page 22 10. Claims exceeding the terms of the warranty, in particular those for damage and consequential damages, are precluded insofar as these are legally permissible. Pro rata work times for repairs as well as the costs for restoring the equipment to its original condition must be paid in full by the purchaser. The guarantee provided extends according to this guarantee declaration only to the repair or replacement of the appliance.
