User Manual for GSM / LED Touch Keypad Wireless Intelligent Home Alarm System
I. Foreword
Thank you for purchasing and using GSM / LED touch keypad wireless intelligent home alarm system. This is a
Hi-performance and
Please read the below information carefully before using for a proper usage.
II. Brief introduction of the Product
A. Product components: This product is composed of alarm host, basic accessories and optional accessories.
Alarm Host
wireless remote, wireless
GSM/ LED
door sensor,
Touch Screen
wireless wide-angle PIR
Alarm Host
sensor, wired indoor siren.
III. Function Features
Touch keypad, concise LED display. Nice looking and easy operation.
Compatible with GSM network, reports alarm events by calling and SMS.
Use
SIM
card,upto 6 phone numbers(2 for management center, 4 for personal) can be pre-stored and then dial in
sequence when alarming.
15 wireless zones (Each zone supports up to 4 sensors) and 1 dedicated zones for remotes (Supports up to 10
remotes). 8 wired zones can be extended and each wired zone can be separately armed and disarmed.
Record up to a 10 second voice message in the host, then can be heard via phone when answering alarm call.
Intelligent logic analysis technology, corresponding zone number can be displayed by LED lights. Corresponding
zone number and sensor name can be displayed via SMS.
Disconnection alarm, auto priority to occupy the telephone and monitoring function to hear what is happening.
5-ways of arm/disarm:SMS, remote controller, built-in keypad, wireless keypad(optional device), phone call.
Non-volatile chip, information stored automatically when off power.
One-key arm,learning sensors to alarm host, very easy operation.
Built-in Li-Ion backup battery, available in AC\DC.
Supports CID uploading to CMS(Center monitoring Station) , can user our GSM CID connector to have this
function.
Extended Functions: Wireless "Ding Dong" doorbell.
IV. Understanding of the Products
A. Understanding of the Alarm Host
Pro g ra m
Le a rning
LED display for wireless zones
Hi-tech household security product. It will make your life safer and
Basic Accessories
Table 1: Product components
Each number can be set as phone call alarm or SMS alarm according to actual needs.
Open and closed status (of door and window) mornitoring and alert
Wireless siren with sound and light
Wireless DVR functions.
And more.
Wireless Optional Accessories
intelligent door sensor,
capacity li-ion battery wide-angle PIR sensor, gas alarm, smoke
alarm, indoor siren with sound and light, outdoor siren with
sound and light, doorbell button, LED keypad, LCD keypad and
more.
System self-check, alert of low backup battery power.
Awa y
Ho m e
Em e rg e nc y
more
colorful.
intelligent control door sensor,
high
Advertisement
Summary of Contents for Kingeye ki-g18
- Page 1 User Manual for GSM / LED Touch Keypad Wireless Intelligent Home Alarm System I. Foreword Thank you for purchasing and using GSM / LED touch keypad wireless intelligent home alarm system. This is a Hi-performance and Hi-tech household security product. It will make your life safer and more colorful.
- Page 2 Ala rm lig hts fo r wire d zo ne s Arm & d isa rm lig hts fo r wire d zo ne s LED display for wired and wireless zones Insta ll GSM a ntenna here Sig na l/Po wer Lig ht Sta tus Lig ht Low-Power Lig ht Awa y...
- Page 3 Char ging time: 12 hours frequency: Dual-Band(900 / 1800 MHZ),Quad-Band(850 / 900 / 1800 / 1900 MHZ) emitting power:2W Product dimension(host) 150×107×26(mm) 2. Zo ne types and definitio one types: Perimeter zone, Motion zone, Emergency zone Definitions: Perimeter zone: Detecting the spa ce like doors, windows, etc., generally use wireless door magnet sensors and wireless cu rtain PIR sensors...
- Page 4 alarm) “X”: 0 or 1. (“0”: 0 second; “1”: 15 Exit delay 1 + X + ENT seconds) “X”: 0 or 1. (“0”: 0 second; “1”: Entry delay 2 + X + ENT seconds) Emergency 3 + X + ENT “X”: 0 or 1.
- Page 5 Telephone alar m: After receiving the call, you will hear the recorded voice message immediately, it can be played for 30 seconds repeatedly, then follow the below instruction: 1. Inp ut “8” to enter into the listening status for 20 seconds automatically, you can hear the alarming event sounds from phone.
- Page 6 —— ireless remo te & Wireles s Keypa Wirele ss S moke Alarm, pport s upto 01 ~ 05 Emergency zone Wireless Gas Alarm& Panic button etc. 4 wireless Wireless sensors Wireless Door/Window Sensor & sensors for 06 ~ 10 Perimeter zone Wireless Curtain PIR etc.
- Page 7 “Home” is setting “Armed home”, please take notes that “Arm Home” is only effective for sensors in Perimete r Zone (door sensor\curtain PIR sensor) and sensors in Emergency Zone (Like Gas sensor\Smoke sensor\Glass sensor \Emergency button), it is not effective all sensors in Motion zone(Like wide-angle PIR).
- Page 8 2. When exceeds 4,the latter added wireless door sensors will cover the former added one. 3. Al l the wire less door sensor in this group are cancelled after your cancelling operation for one group . You have to do the adding operation if you need one or more. Wireless Wide-Angle PIR Sensor Features:...
- Page 9 Repeatedly receiving the alarm Fail to operate according to the llow the below instructions after answering telephone operation instruction the alarm phone calls and hearing the telephone alarm corded messag (See Point 6 of “How to operate the Alarm t?”) Can’t receive alarm sms or 1.
