[Please keep this Owner's Manual for future reference. If you sell or give this product to someone, please include
this Owner's Manual, and ask the new owners to read the instructions completely before operating.]
Please read this Owner's Manual completely before assembling or operating this product.
Assembly of this product should be carried out by an adult.
Parts are wrapped in paper or protective covering to prevent damage during shipment. Remove all parts and
packing materials from the box prior to assembly. Save all packing materials until assembly is complete to
make sure no parts are accidentally thrown away. After assembly is complete, properly discard all waste.
Refer to the Parts List and Diagram on page two of this manual to make sure all parts are accounted for.
Do not return this product to the store! If any parts are missing or damaged, please contact one of our
Customer Service Representatives by phone at 1-800-242-6110, or by e-mail at Info@instep.net.
WARNING Always wear an approved safety helmet when riding!
WARNING Never leave your child unattended on this product!
WARNING This trailer bike is designed to attach to an adult bicycle with 26", 27", or 700C wheels!
WARNING This trailer bike does not have a brake. Make sure the adult bike brakes function properly!
WARNING Recommended for ages 4 through 9! Maximum weight capacity of rider is 75 pounds!
WARNING Make sure the child riding the trailer bike understands how to operate it correctly!
WARNING Always use the safety flag when riding with this product!
WARNING A bicycle with the trailer bike attached requires a wide turning radius! Use caution when turning!
WARNING Do not ride over curbs! Avoid bumps and potholes! Do not turn sharply!
WARNING Before riding, check that all parts are assembled correctly per the manufacturer's instructions!
WARNING Tire should be inflated to the pressure reading shown on the tire sidewall! Check before each use!
WARNING Use a foot pump or hand pump to inflate tires! Pressurized air hoses can cause overinflation!
WARNING Do not ride at night!
WARNING Do not ride barefoot!
WARNING Do not ride in wet weather or when road surface is slippery!
WARNING Periodically re-check all fasteners to make sure they are tight!
Adjustable wrench (or a 15mm wrench, a 13mm wrench, and an 8mm wrench)
6mm Allen wrench
Pathfinder
Trailer Bike
Owner's Manual
PRIOR TO ASSEMBLY:
IMPORTANT SAFETY INFORMATION:
TOOLS REQUIRED FOR ASSEMBLY:
1
Advertisement
Table of Contents
Related Manuals for InStep Pathfinder
Summary of Contents for InStep Pathfinder
- Page 1 Refer to the Parts List and Diagram on page two of this manual to make sure all parts are accounted for. Do not return this product to the store! If any parts are missing or damaged, please contact one of our Customer Service Representatives by phone at 1-800-242-6110, or by e-mail at Info@instep.net. IMPORTANT SAFETY INFORMATION:...
- Page 2 (found on carton or manual) and assembly instructions ready when calling. If neither is available, please tell us the name of the product in question. For questions concerning the safe use of this product, please contact us at Schwinn/InSTEP at 1-800-242-6110 info@instep.net E-mail: Web site: www.instep.net...
- Page 3 ASSEMBLY AND OPERATING INSTRUCTIONS STEP 1 Open carton, remove contents, and compare contents with parts list Note: To prevent scratching of the frame, it is recommended that you lay the parts out on top of a flattened cardboard box, or other soft surface. Remove all contents from the carton.
- Page 4 STEP 3 Attach the handlebar Unscrew all four Allen-head screws using a 6mm Allen wrench and remove the handlebar clamp. Place the handlebar into the groove of the clamp base with the handlebar grips toward the rear of the trailer bike. Replace the clamp over the handlebar, insert all four Allen head screws back into the clamp, and tighten with your fingers.
- Page 5 STEP 5 Attach the pedals to the cranks Locate the right pedal (marked with an “R” at the end of the threaded shaft), and the left pedal (marked with an “L” at the end of the threaded shaft). Thread the right pedal clockwise into the right crank arm (the side with the chain) by hand.
- Page 6 STEP 7 Install the red rear reflector Remove the screw from the reflector bracket with a Phillips screwdriver and snap the bracket on to the seat post as shown. Once the reflector bracket is in position, replace the screw in the hole. Tighten it down with the Phillips screwdriver.
- Page 7 Attach trailer bike to adult bike and secure seat post clamp Place the Pathfinder behind the adult bike with the seat post clamp against the adult bike seat post. The seat post should rest in the valley of the seat post clamp.
- Page 8 STEP 12 Remove the Pathfinder from the adult bike 12A. Flip the quick-release lever up, and unscrew the nut from the other side. 12B. Remove the nut and slide the quick-release bolt completely out. 12C. Slide the coupler assembly out from the seat post clamp. Replace quick-release pin.
- Page 9 ACCESSORIES FOR YOUR PATHFINDER TRAILER BIKE Additional Coupler Kits allow you to switch your PATHFINDER from one bike to another. The PATHFINDER Coupler Kit includes the seat post clamp, four bolts, and the Q/R pin bolt. PF001...
