DO NOT touch the nozzle during, or after, use as it becomes extremely hot.
DO NOT leave the heat gun running unattended. Always turn off the power supply.
DO NOT use the gun on a task it is not designed for.
DO NOT use the gun in combination with chemical strippers.
DO NOT operate the gun when you are tired or under the influence of alcohol, drugs or intoxicating medication.
DANGER! DO NOT uSE THE HEAT GuN AS A HAIR DRYER.
WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and
situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this product,
but must be applied by the operator.
2. SPECIFICATION
Two step air flow control switch, with variable temperature range on both levels. Gun is designed to stand vertically, allowing use as a safe
Bunsen burner alternative. Suitable for paint stripping, soft soldering, removing sticky labels and defrosting frozen pipes. Fitted BS approved 3
pin safety plug. Supplied with four nozzles and scraper, all in a storage case.
Specification
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230V ~ 8.6A
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2000W
temperature range . . . . . . . . . . . . . . . . . 50-450°C / 90-600°C
Air flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250-500ltr/min
3. OPERATING INSTRUCTIONS
3.1.
Preparing the hot air gun for use
3.1.1. Before plugging into the mains ensure the gun switch is in the off '0' position.
3.1.2. When ready to start work, set switch to the required temperature setting (fig.1) and air flow speed (fig.2).
Allow one and a half minutes to heat.
NOTE: When new, the heat gun may generate smoke which will decrease with use.
WARNING! KEEP HANDS AWAY FROM THE IMMEDIATE NOZZLE AREA. IF LEAD PAINT IS bEING REMOVED FOLLOW THE
SAFETY WARNING AT THE bEGINNING OF THIS MANuAL. ALWAYS WEAR GLOVES AND EYE PROTECTION.
3.2.
Paint and varnish removal
the easy removal of paint and varnish requires practice. Follow these simple working techniques to achieve the required result.
NOTE: the heat gun is designed to remove both oil and latex based paints and varnishes from surfaces. It will not remove stains
or primer coats that have impregnated the surface.
3.2.1. Switch the gun on and allow it to reach its operating temperature.
3.2.2. Always test on a small non-critical area first.
3.2.3. Hold the gun nozzle 3" (75mm) to 4" (100mm) from the paint to be removed.
3.2.4. After a short time the paint will soften and begin to blister.
3.2.5. Do not overheat the paint as this will cause it to burn which makes it more difficult to remove. Wear eye protection, especially
when stripping paint from overhead. If lead paint is being removed, refer to the warning at the beginning of this manual.
3.2.6. Begin scraping the paint off. Work from top to bottom. Use a scraper with smooth even strokes, warming the surface in front
of the scraper by moving the gun slightly from side to side.
3.2.7. If the correct temperature has been applied to the paint, thick, even layers can be removed in a single pass (paint should be
removed in strips equal in width to the scraper blade). Scrape paint as soon as it becomes soft, as it will re-harden very quickly.
3.2.8. Keep the scraper blade edge clean and sharp to prevent paint peelings from building up.
3.2.9. After softening, shaped or profiled surfaces may be stripped by using a wire brush.
3.2.10. to protect surrounding surfaces from the heat, cover with a non-flammable material.
IMPORTANT: Do not concentrate the heat gun on glass as the glass may crack.
4. CARE AND MAINTENANCE
Unplug gun from power supply before performing any maintenance
4.1.
Keep the air intake and outlet openings clean and free from dirt and peelings.
4.2.
Use only a damp cloth and mild household cleaning agent to wipe the gun and nozzels clean. DO NOT use turpentine, paint thinner,
gasoline or similar substances to clean the gun.
4.3.
Check the gun, power lead and nozzles for damage before storage.
4.4.
Store the gun in a safe, dry, childproof area.
5. OTHER TASKS
The gun may also be used for the following:
• Removing self-adhesive stickers and trim • Loosening rusted or over-tightened nuts and metal screws • Thawing frozen pipes, doors,
padlocks, etc. • Highlighting natural woodgrain before staining or varnishing • Fast drying of paint or varnish • Softening old putty • Soldering •
Sterilisation 500°c • Removing candle wax • Restoring candles • Repair of tarpaulin or pvc • Drying wet timber prior to repairs or finishing •
Shrinking shrink-wrap sheeting • Shrinking polyvinyl wire joints • Joining garden hose • Melting pewter, tar, bitumen or wax • Model making •
Moulding pvc, wood, copper, Plexiglass into shape • Plumbing tasks • Roofing repairs • Applying veneer strips • Control of garden path weeds
• Waxing and de-waxing skis • Chemistry, use as a bunsen-burner/and more • Important: safety is a key principle when using the gun. When
approaching a new task consider the dangers that may arise, take any necessary precautions and practice first.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: no liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7Ar
Original Language Version
fig.1
01284 757500
01284 703534
fig.2
www.sealey.co.uk
Web
sales@sealey.co.uk
email
HS107K
Issue: 2 - 2/10/09
