Summary of Contents for Elexim GSM Gateway Proline Digital
-
Page 1: User Manual
Ver. 1.01 This document contains technical information and user manual for GSM Gateway Proline Digital. In this document you can find information how to connect and configure GSM Gateway Proline Digital. Last update: 29.10.1012 Copyright © 2010 “ Elexim LTD “... -
Page 2: Table Of Contents
3.4 Start the device 4. Configuration and software update 4.1 Configuration of the software 4.2 Firmware update 5. Functions of GSM Gateway Proline Digital 5.1 CLIP and CLIR 5.2 Polarity reverse 5.3 Volume of the signal in handset 5.4 Time interval between dial and connection 5.5 Default settings... -
Page 3: Introduction
GSM Gateway Proline Digital User Manual Introduction GSM Gateway Proline Digital is design to meet the latest requirements and trends in the telecommunications and electronic equipment. GSM Gateway Proline Digital emulate phone line with standard parameters and it is design to plug in directly to ordinary phone or telephone exchange. -
Page 4: Contents Of The Package
GSM Gateway Proline Digital User Manual 1. Contents of the package GSM Gateway Proline Digital is delivered to the client in cardboard box with all required supplements necessary for work. Package consists of: ➢ GSM Gateway Proline Digital; ➢ AC/DC power supply 220V/12V, 500mA;... -
Page 5: Technical Parameters
Maximum power consumption: 3.6 W 2.4 Antenna GSM Gateway Proline Digital comes with external antenna. Description of how to mount the antenna and how to connect it to the device you can find in chapter 3 - “Getting started” in the document. -
Page 6: Gsm Network
GSM Gateway Proline Digital User Manual • Length of the cable: 3 m; • Magnetic backing for mounting to magnetic surface Note: The manufacturer is not responsible for the occurrence of noise and interference during a call if using other antennas 2.5 GSM Network... -
Page 7: Getting Started
User Manual 3. Getting started 3.1 SIM card and antenna connection Before you start GSM Gateway Proline Digital insert SIM card and switch the antenna as it shown on picture 2. picture 2 Note: SIM card inserted in the device must be with disabled PIN code. In other case the device will not start properly. -
Page 8: Connection Of Power Supply
GSM Gateway Proline Digital User Manual Picture 3 Picture 4 3.3 Connection of power supply If you are sure that SIM card is inserted, the antenna is switch and the phone line is connected to the device you can connect power supply. -
Page 9: Configuration And Software Update
Description and more information of all functions and how do they set you can find in chapter 5 - “Functions of GSM Gateway Proline Digital” or in file „Configurations of GSM Gateway Proline.pdf“, which you can find in Install CD included in the package set. -
Page 10: Volume Of The Signal In Handset
GSM Gateway Proline Digital User Manual GWC+POL=n , where: if n=0 – function is disable if n=1 – function is enable and the polarity will reverse at the beginning of every call. 5.3 Volume of the signal in handset You can set the volume of the signal in the handset. - Page 11 • If you have troubles with drivers download them from www.elexim.com/downloadbg.php If you have troubles that you can't solve alone please contact us at tel. +35929718880 or write an e-mail to us at support@elexim.com. We always will assist you to resolve problems associated with our devices.
