Summary of Contents for Evolio Smart TV Box
- Page 1 Evolio Smart TV Box User Manual...
-
Page 2: Fcc Information And Copyright
EVOLIO SMART TV BOX User Manual FCC Information and Copyright This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in residential installations. -
Page 3: Safety Precautions
EVOLIO SMART TV BOX User Manual Safety Precautions Don’t use the TV box near water. Clean only with a dry cloth. Don’t block any of the ventilation openings, install according to the manufacturer’s instructions. Don’t install near any heat sources such as radiators, heat registers, stoves, or other apparatus(including amplifiers) that produce heat. -
Page 4: Table Of Contents
EVOLIO SMART TV BOX User Manual Contents FCC INFORMATION AND COPYRIGHT ......I SAFETY PRECAUTIONS ..........II CONTENTS ..............III CHAPTER 1 BASICS ............1 ............... 1 ARTS AND ONTROL ..............1 EMOTE ONTROL ................. 5 OWER SUPPLY ................5 ONNECTIONS ............ -
Page 5: Chapter 4 Troubleshooting
EVOLIO SMART TV BOX User Manual & ............21 IRELESS NETWORKS ................... 22 OUND ................. 22 ISPLAY .................. 22 CREEN ................22 TORAGE ..................22 ................22 ECURITY & I ............... 23 ANGUAGE NPUT & ..............23 ACKUP RESET ............... 23 DD ACCOUNT &... -
Page 6: Chapter 1 Basics
Chapter 1 Basics EVOLIO SMART TV BOX is a smart TV box based on Android v4.2.2 operating system. It supports HDTV, network function, and third party software. User can get access to over 450,000 apps, share and enjoy TV shows, movies, music and much more. -
Page 7: Remote Control
Chapter 1 Basics 6. Standby button – Press to go to standby or wake-up mode. 7. IR window –To receive IR signal from IR remote control. 8．Memory card slot – supports SD card 9．Status indicator – blue light for working mode, red light for standby mode. - Page 8 Chapter 1 Basics STANDBY button – press to go to standby/wake-up mode SUB MENU button – press to display the option menu SETUP button – press to enter into settings PG.UP/DN button – press to go to previous/next song/video HOME button –...
- Page 9 Chapter 1 Basics BACKSPACE button – press to delete a character OK button – press to confirm the selection Directional buttons – press to move the cursor left/right/up/down. INFO button – press to display the media file information. PLAY/PAUSE button –...
-
Page 10: Power Supply
Chapter 1 Basics Battery Replacement When the battery become weak, the operating distance is greatly reduced and you will need to replace them. Take out the Lithium battery at the bottom of the unit cover. Insert a new identical Lithium battery. Note: you can also use the wireless remote control with mouse and keyboard (not included) for quick operation and more control on TV screen. -
Page 11: Transferring Contents
Chapter 1 Basics 1. Use the AV cable to connect the unit to TV/Monitor. 2. Use the AC adapter to connect a suitable wall outlet. 3. Turn on your TV. Connecting to the internet Wi-Fi connection: if the unit detects Wi-Fi signal, in Settings <... - Page 12 Chapter 1 Basics To remove SD card, push the card once again until it clicks. When a SD card is inserted in or ejected from the TV box, it may take few seconds for the TV box to update the content.
-
Page 13: Home Screen
Chapter 1 Basics Home screen When the TV box is turned on, it will enter into the Home screen. Use the Directional buttons and press OK button or use Wireless Mouse key to press any icon on the home screen to get started. -
Page 14: Onscreen Keyboard
Chapter 1 Basics Wireless Mouse key to press an desired application icon to launch the application. Press on remote control or on TV screen to return to home screen. Adding icons on category You can add shortcuts or widgets to the media category. ... - Page 15 Chapter 1 Basics Numeric/punctuation/symbol key...
-
Page 16: Web Browser
Chapter 2 Getting Started Web browser View a webpage From Home screen or APPS, press the Browser icon to open web browser. On address bar, type the web address and press or OK button on the remote control to open the webpage. ... -
Page 17: Watching Videos
Chapter 2 Getting Started Press to use more available function, including Privacy & security, Accessibility and so on. Refresh/Stop Press to refresh on the current page, press X to stop loading the current page. Forward Press ←/→ go to previous/next webpage screen. Using the option menu Press Menu to display the browser option menu. -
Page 18: Chapter 2 Getting Started
Chapter 2 Getting Started Controlling Video Playback When playing video, press Menu button on the remote control to pop up control toolbar. Play or Pause Press video Play previous/next video Press Fast rewind or fast forward Press and hold Skip to any point in Press anywhere or drag a video the playhead on the... - Page 19 Chapter 2 Getting Started Adjust the screen Press size: full screen,16:9,4:3 Display video Press playback menu Return to the video Press browser screen ： Notices By default, the bookmark will be added automatically, it allows you to continue playing from the bookmark when you open the video file next time.
-
Page 20: Playing Music
Chapter 2 Getting Started Playing Music About music library On the Home screen or APPS, press Music icon to enter into music library. Sorting by artist Sorting by album All songs Sorting by Playlist Return to Now playing screen Playing songs 1. -
Page 21: Chapter 2 Getting Started
Chapter 2 Getting Started list. 2. Press the Directional-up/down button to scroll the song list. 3. Press the desired songs to start playing. Note: If you want to exit music mode, press pause, then press Return button or Controlling Song Playback Pause play Press... -
Page 22: Viewing Photos
Chapter 2 Getting Started current Press Menu Add to playing song playlist. playlist To return to the Press the Return button Media Library Using the playlist Use the playlist to manage the songs in the library Creating a new playlist New, In the music playback screen, press and enter the name for the new playlist, then press... - Page 23 Chapter 2 Getting Started Thumbnail view displays the catalog as a table of thumbnail images in adjustable sizes. Press to start photo slide show, press anywhere on the screen to stop the slide show. Press on the desired photo to full screen view. ...
-
Page 24: Managing Third Party Applications
Chapter 2 Getting Started Start to view photo Press on the screen to show / hide the control bar. View the previous / Press next photo. Directional-right/left button Zoom in or zoom out Press Zoom button on the remote control. ... - Page 25 Chapter 2 Getting Started 2. Copy the downloaded applications to the unit via USB device (you can also download the desired applications from the browser in your device.). Note: The system only supports XXX.apk format applications to be installed. 3. From Main menu, press SettingsSecurityunknown source.
-
Page 26: Chapter 3 Settings
If more than one previously used network is in range,EVOLIO SMART TV BOX joins the one last used. When EVOLIO SMART TV BOX is connected to a Wi-Fi network, the Wi-Fi icon at the bottom of the screen shows connection strength. -
Page 27: Sound
Chapter 3 Settings networks. Sharing a Data Connection as a Portable Wi-Fi Hotspot 1. From home screen or Main menu, press Settings More portable hotspot. 2. If you select Portable Wi-Fi hotspot to share a data connection, you can press Set up Wi-Fi hotspot to configure portable Wi-Fi hotspots. -
Page 28: Language & Input
TV BOX system to factory settings. Add account Add an account of Email or google to let you access all your stuff( photo etc.) from EVOLIO SMART TV BOX . Date& Time Set date, time, time zone and display format. -
Page 29: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting Power on the TV box, but TV detects no signal Make sure the HDMI /AV cable is securely connected firmly. Make sure the TV is selected for the correct HDMI/AV port. Can’t power on the TV box Make sure the power adapter is correctly plugged, if the unit is powered on, the status indicator at the front panel will lights in red. -
Page 30: Chapter 5 Appendix
Chapter 5 Appendix Maintenance If TV box does get wet, turn off TV box immediately. Wait for TV box to dry completely before turning on again. Clean the unit with a soft and dry cloth; be careful not to wipe it with anything abrasive. ... -
Page 31: Disposal And Recycling Information
Chapter 5 Appendix Connectivity Data transfer: USB 2.0 High Speed Audio: phone jack (L/R Stereo audio ),SPDIF,HDMI1.4 LAN : RJ45 (10/100MB) Wireless connectivity Wi-Fi : Built-in, 802.11b/g/n Power supply DC 5.0V, 2.0A Physical properties Dimension:160*145*33mm Weight:171G ※ Design and specifications are subject to change without prior notice. - Page 32 Chapter 5 Appendix please contact the local authority or your retailer where you purchased the product.
