Version 1.0 Table of contents Structure __________________________________________________________ 4 Power supply ______________________________________________________ 7 Way of connecting __________________________________________________ 8 GAIN switch ______________________________________________________ 10 Footswitches _____________________________________________________ 10 Chorus tone setting ________________________________________________ 10 MIDI controlling ___________________________________________________ 12 Technical parameters ______________________________________________ 13 FCC Compliance___________________________________________________ 14 Declaration of Conformity ___________________________________________ 15... - Page 5 Dear Customer! Thank you for choosing our product. G LAB Tidy Chorus (TCH-1) is a classic chorus effect with wide range of chorus tone settings. In the device is applied the G LAB MAX ANALOG technology what means that in the signal path are used discrete components and classic LFO and VCO analog circuit innovatively controlling the 24 bits DSP processor.
-
Page 6: Structure
Structure... - Page 7 1 - ON/OFF footswitch 9 - MIX A proportion switch 2 - CHORUS A DEPTH regulator 10 - MIX B proportion switch 3 - CHORUS A RATE regulator 11 - FAT +XX – CHORUS B switch 4 - FAT +XX – CHORUS A switch 12 - CHORUS B indicator 5 - FAT +X –...
- Page 8 19 - IN signal connector 21 - 9V power supply connector 20 - OUT signal connector 22 - MIDI IN input 23 - MIDI THRU output...
-
Page 9: Power Supply
Power supply The TCH-1 should be supplied from external regulated 9V DC power supply, with capacity of 90 mA or more. It is recommended to use separated source e.g. G LAB PB-1 in order to avoid ground loop. Before connecting please check if the connector’s polarization is CTR –... -
Page 10: Way Of Connecting
Way of connecting It is recommended to connect the TCH-1 to the amp effect loop before delay and reverb type effects. This connection mode is required if you play on amp overdriven channels. - Page 11 If you use for overdriven tones only the stompboxes the TCH-1 should be connected after overdrive and distortion effects and before delay and reverb effects.
-
Page 12: Gain Switch
GAIN switch GAIN switch with help of PEAK indicator enables to match the chorus sensitivity to the signal. It is recommended to set GAIN switch to HIGH position, switch on the chorus effect and check if PEAK indicator lights while playing (especially on clean tone). - Page 13 decreasing the DEPTH. The FAT +X and FAT +XX switches enable to match the „weight” of the chorus tone by changing the delay time of the modulated signal. The RATE regulator sets the speed of the modulation and the DEPTH regulator enables to set the depth of the modulation.
-
Page 14: Midi Controlling
MIDI controlling To set the MIDI channel on which the TCH-1 receives the commands serves the MIDI CHANNEL rotary switch. To set the channel it is needed to use a small, flat screwdriver and to turn right or left the middle part of the switch. The arrow-head indicates selected channel. -
Page 15: Technical Parameters
Technical parameters Dimensions: depth 120 mm width 120 mm height 60 mm Weight 0,56 kg Input impedance 1 MΩ Maximal input signal GAIN HIGH +5 dBu (+2,8 dBV) GAIN LOW +10 dBu (+8 dBV) 600 Ω Output impedance Power supply 9V DC (8,7 to 9,4V regulated) Current consumption 90 mA... -
Page 16: Fcc Compliance
FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 17: Declaration Of Conformity
Declaration of Conformity ELZAB S.A., ul. Kruczkowskiego 39, 41-813 Zabrze, Poland, declare under sole responsibility, that the following product: G LAB/TIDY CHORUS TCH-1 (G LAB TCH-1) conforms with requirements of the EC Council Directives: ● 2006/95/EEC Low Voltage Directive, ● 2004/108/EEC Electromagnetic Compatibility, and holds CE mark. - Page 18 DO NOT PLACE THIS PRODUCT INTO THE WASTE CONTAINER ! This device is marked with a cross-lined waste container symbol according 2002/96/EU Directive Waste Electric and Electronic Equipment. Such marking informs that after usage equipment can not be trashed together with other household waste. An user obligation is to return wasted equipment to a party collecting wasted electric and electronic equipment.
