Gas Hobs

User and

Installation Manual

Model: UGH602SS

Table of Contents

Need help?

Do you have a question about the UGH602SS and is the answer not in the manual?

Questions and answers

Summary of Contents for Appliance 365 Limited UGH602SS

Page 1 Gas Hobs User and Installation Manual Model: UGH602SS...
Page 2: Customer Service
When calling customer service, please ensure you have the model and serial number to hand. • • Please keep your receipt or invoice in a safe place as they will be required as proof of date of purchase. Appliance 365 Limited, 730 Mandarin Court, Centre Park, Warrington, WA1 1GG...
Page 3: Installation
These instructions have been drawn up for your safety and that of others. We therefore request you read them carefully before installing and using this appliance. Keep this instruction manual in a convenient place near the appliance for future reference. If the appliance is sold or moved, make sure that the manual is handed over to the new user.
Page 4: General Safety
edge of the hob. Do not cover the hob or place combustible materials on or near the surface when the hob is in use Do not fill deep fat frying pans more than one third full of oil and NEVER leave them unattended.
Page 5 This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
Page 6: Igniting The Burners
Instructions for use The symbols on the hob control knobs are as follows: No gas flow or OFF Maximum gas flow Minimum gas flow ● All operating positions must be set between the maximum and minimum flow settings, and never between the maximum setting and the closed position. Igniting the burners To obtain a flame more easily, light the burner before placing a cooking utensil on the pan stand...
Page 7: Cleaning And Maintenance
Cleaning and maintenance Before undertaking any cleaning operation, disconnect the appliance from the electrical supply and allow it to cool down. Keep the appliance thoroughly cleaned. Accumulations of food residues may cause fire risks. Clean the hob regularly with a soft damp cloth and lukewarm water with a little liquid detergent.
Page 8: Instructions For Installation
Model Number: Serial Number: Any service work on this appliance should only be carried out by an Authorised Technical Service Centre, who will always use original spare parts. Instructions for installation CAUTION: This appliance must only be installed and used in rooms with a means of permanent ventilation, compliant to current Gas Regulations.
Page 9: Connection To The Gas Supply
Connection to the gas supply The gas connection must be made in accordance with Gas Regulations. When installing, fit an isolation tap upstream of the hob. The appliance leaves the factory tested and set for the type of gas indicated on the data plate on the underside of the appliance. Make sure that the type of gas to be supplied to the appliance is the same as that shown on the plate.
Page 10: Replacing The Power Supply Lead
The wires in the mains cable are coloured in accordance with the following code: Green & Yellow = Earth, Blue = Neutral, Brown = Live If you wish to make a direct connection to the mains, an omni polar switch with a separation gap between the contacts of at least 3 mm, with suitable R.C.D.
Page 11 Changing the gas injectors 1) Remove the pan stands. 2) Remove the burner and flame caps from the burners. 3) Use a socket wrench (B) to unscrew and remove the injectors (A), replacing them with those corresponding to the type of gas to be used (see table above). 4) Reassemble the parts, reversing the operations described above.
Page 12: Building Into Fitted Kitchen Units
Building into fitted kitchen units This hob is designed for installation into fitted kitchen units up to 600mm deep on the assumption that the clearances indicated below are observed. The worktop height should be between 40 and 50mm. A. The height clearance to the underside of a chimney hood not less than 750mm (a). B.
Page 13: Installation Dimensions
Option 2: If installing this appliance above an oven it is necessary to remove the front cross rail of the oven housing unit to provide adequate ventilation within the cabinetry. Installation dimensions A = W557mm B = D477mm Inserting and fixing the hob Before inserting the hob into the work surface, place the adhesive seal (a) around the underside edge of the hob.
Page 14 Worktop Fixing bracket Screw Secure the hob to the underside of the worktop using the fixings provided. Screw one end of the bracket into the pre-drilled holes in the underside of the hob. The other end of the bracket should be located underneath the worktop to secure the hob in position.
Page 15: Troubleshooting
Trouble Shooting Symptom Solution • There burner fails to ignite Check that the unit is wired in and the power supply is switched on • Check the main fuse has not blown • Check there is not a problem with your gas supply •...
Page 16 Note: Consistent with our continuing product development policy, improvements may have been made which render the contents of this package slightly different to that shown. Model No. UGH602SS October 2009 Appliance 365 Ltd. Cranage House 730 Mandarin Court Centre Park...
