Viking Use/Installation Guide
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
call 1-888-VIKING1 (845-4641)
or visit the Viking Web site at
vikingrange.com
Food Waste Disposer
F20351A EN
(032508J)
Advertisement
Summary of Contents for Viking Food Waste Disposer
- Page 1 Viking Use/Installation Guide Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-VIKING1 (845-4641) or visit the Viking Web site at vikingrange.com Food Waste Disposer F20351A EN (032508J)
-
Page 2: Installation Instructions
TOOLS AND MATERIALS YOU WILL NEED: INSTALLATION INSTRUCTIONS Slotted Screwdriver, Adjustable Pliers, Plumber’s compound, Electrical Tape TOOLS AND MATERIALS YOU MAY NEED: CHECK INSTALLATION DIMENSIONS Phillips Screwdriver, Drain Auger, Hammer, Hacksaw, Pipe Wrench, 3/8 inch Electrical Clamp Connector, Wire Nuts (2), A: Disposer height Second 1 1/2 inch Drain Trap, , Water Hose Clamp, Copper Ground Wire, Dishwasher Drain Connection Kit, Air Gap, B: Distance from bottom of sink bowl to centerline of discharge out-... - Page 3 ATTACH UPPER MOUNTING ASSEMBLY TO SINK FLANGE CLEAN SINK DRAIN LINE You may wish to place a weighted object in the sink to hold the sink flange in place. (Place a Failure to clean sink drain line may result in drain line blockage. towel under object in sink to prevent scratching.) Reference Figure 5-1 for part identification.
- Page 4 Connect Disposer to Electrical Supply/Ground Disposer ATTACH DISCHARGE TUBE TO WASTE DRAIN WARNING Follow these instructions to direct wire the disposer. 1. Remove electrical cover plate from bottom of disposer and pull out Electric Shock black and white wires (see Figure 9-1). DO NOT REMOVE CARD- •Disconnect electrical power at fuse box CAUTION BOARD INSULATION SHIELD.
- Page 5 Continuous feed disposers have a one-piece cover/stopper that acts only as a The best disposer for a septic tank is one which grinds the food into fine particles and adds as little water as possible. The VIKING seal. A wall switch is used to turn the disposer on or off. To SEAL the cover for holding grind system is super fast and extremely efficient and is especially well suited to installation with a septic tank.
-
Page 6: User Maintenance Instructions
-Press the Jam-inator button on the front side of the disposer and release - If you are unable to obtain the name of an authorized service agency, or continue to have service problems, call Viking, DO NOT HOLD. (888) - Page 7 (10) years for Model 1000 or seven (7) years for Model 750 from the date of original retail purchase. Viking Range Corporation, warrantor,agrees to repair or replace, at its option, any part which fails or is found to be defective during the warranty period.
