Summary of Contents for Nothern Industrial tools Impact Driver
- Page 1 19.2V CORDLESS 2-IN-I COMBO KIT OWNER'S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 331804...
-
Page 2: Technical Specifications
0 - 2000 RPM Gearbox: 2 Speed Impacts: 0 - 2900 BPM Max. torque: 210 ft/lbs Torque rating: 8.8 ft/lbs Hammer function: Chuck size: " ACCESSORIES 1 x Impact Driver 1 x Cordless Drill 2 x 1.5Ah Ni-Cd Batteries 1 x Fast Charger... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS WARNING! A battery operated tool with integral batteries or pack must be recharged only with the specific charger for the that may be suitable for one type of battery may create a risk with another battery. • Avoid accidental starting. Make sure the switch is in position before inserting the battery pack. - Page 4 • Remove adjusting keys and wrenches. Always check that adjusting keys and wrenches are removed from the tool before operating the tool. • Extension cords. Before use inspect the extension cords and replace if damaged. When using the tool outdoors, only use extension cords intended for outdoor use and marked accordingly.
- Page 5 SAFETY INSTRUCTIONS FOR BATTERY PACK & CHARGER THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR BATTERY CHARGER. • Before using the charger, read all instructions and cautionary markings on charger, battery pack and product using the battery pack. Danger! If the battery packs casing is cracked or damaged, do not insert into charger.
- Page 6 ADDITIONAL SAFETY RULES FOR CHARGERS & BATTERY The battery pack is not fully charged out of the carton. First read the safety instructions and then follow the charging notes and procedures. • The longest life and best performance can be obtained if the battery pack is charged when the air temperature is between 64°–75°F (18°–24°C).
- Page 7 OPERATION FOR IMPACT DRIVER On/off switch To turn the impact driver on, depress the trigger switch, to turn off, release the trigger switch. Speed control The speed can be varied from 0 to maximum, depending on the pressure applied to the trigger.
- Page 8 • Place the head of the power bit into the head of the screw. Ensure the power bits head matches the head of the screw. • Apply a forward pressure on the impact driver so the head of the power bit sits firmly in the screw head. Ensure the impact driver is kept pointing straight to the screw.
- Page 9 General Hints for Drilling in all Materials • Always use sharp drill bits. • Mark the place where you would like the hole to be drilled. • Commence with a slow rotation speed to start the hole. • Reduce your pressure on the tool when the drill bit is about to break through the material. Metal Drilling •...
-
Page 10: Maintenance
• If the enclosure of the impact driver requires cleaning do not use solvents but a moist soft cloth only. Never let any liquid get inside the tool; never immerse any part of the tool into a liquid. - Page 11 DIAGRAM & PARTS LIST (IMPACT DRIVER)
- Page 12 Part Description Part Description Circlip Gear Shaft Washer Roller Pin Spring Gear Locking Ring Washer Screw Internal Gear Ring Gear Case Bearing Front Bearing Screw Felt Motor Gear Rubber Gasket Gearbox Washer Motor Steel Ball Radiator Spindle Lever Steel Ball Switch Assy.
- Page 13 DIAGRAM & PARTS LIST (CORDLESS DRILL)
- Page 14 Part Description Part Description Screw Washer Chuck Keyless Gearbox Screw Clip Pressure Plate Screw Sleeve Steering Gear Bracket Gear Support Bush Planetary Gear Set Spindle Gear support Washer Planetary Gear Set Spring Internal Gear Ring Limited Block Shim Impact Gear Screw Screw Flange...
