Ness Auto IP NVR Setup Manual

Package Content
Inspect the packaging carton. Make sure the Ness Auto IP NVR is properly delivered. Remove all
items from the box and make sure the box contains the following items.
Ness Auto IP NVR
Front Panel
1 Channels
2 Direction Keys
3 Network LED
4 Record LED
5 Alarm LED
6 Power Switch
7 Shuttle/ Jog
8
USB 2.0 Ports
9 COPY
10 DOME
Ness Auto IP NVR Quick setup Guide
Ness Auto IP NVR
Setup Guide
SATA Cable
Mounting Kit
1. In Live and Playback modes, press any key to view the corresponding
video in full-screen.
2. In input interface, 1~10 can be used for direct input of numbers 0~9.
3. In Dome Camera Control mode, 1 is for entering the Set/ Go preset
menu; 11~16 is for quick access of preset points 1~6.
1. In Zoom mode, these keys function as normal direction keys.
2. In the OSD setup menu, the direction keys are used to move the
cursor to previous or next fields. To change the value in the selected
field, press UP / DOWN keys.
It lights up when network is connected. In addition, it blinks when data is
being transmitted via the network.
It blinks when videos are being recorded.
It lights up when an alarm is triggered.
1. Press this switch to power on the NVR. The LED will be lighten up.
2. Press and hold this key to quick shutdown the NVR. The LED will blink
when the power source is still available.
This is used to control playback operations.
The USB 2.0 ports allow users to connect an external USB device to the
unit, such as a USB ThumbDrive
This key is also used for marking time in quick video export function.
Press this key to enter Dome Camera Control mode.
Remote Controller
Software CD-CMS
®
or a USB mouse.
Power Cord
User's Manual
1
