Firewarm 4KW Insert
HD Insert Stove 04D
MULTI FUEL
INSERT S T O V E
FOR STANDARD 16" FIREPLACE
OPENING
Installation and Operating
Instructions
Please hand these instructions to the stove user when the
installation is complete. Leave the system ready for operation
and instruct the user in the correct use of the appliance and
operation of controls.
Installation – We strongly recommend installation by a
qualified plumber or suitably qualified fitter
Advertisement
Table of Contents
Summary of Contents for Firewarm 4KW Insert
- Page 1 Firewarm 4KW Insert HD Insert Stove 04D MULTI FUEL INSERT S T O V E FOR STANDARD 16” FIREPLACE OPENING Installation and Operating Instructions Please hand these instructions to the stove user when the installation is complete. Leave the system ready for operation and instruct the user in the correct use of the appliance and operation of controls.
-
Page 2: Assembly Instructions
Assembly Instructions PLEASE READ THESE INSTRUCTIONS CAREFULLY It is important that your stove is correctly installed, as HD Insert Stoves cannot accept responsibility for any fault arising through incorrect installation. The HD Insert Stove is only suitable for installation in a solid fuel fireplace; the fireplace must be capable of withstanding the high temperatures generated by this stove. - Page 3 1. Secure the Fixing Bar and the tightening screw to the rear of the appliance 2. Open sealing kit supplied and glue sealing rope into channel on rear edge of appliance. Some types of fire cement/glue are caustic and should not be allowed to come into contact with the skin.
- Page 4 4. Create a seal with the fascia of the fireplace. Remove the baffle plate. Place hand through the stove flue collar and tighten the wing nut on the tightening bar. The fixing bar creates pressure when it contacts the chimney/lintel. The stove should be tightly sealed to the fireplace fascia.
-
Page 5: List Of Components
List of Components Description of Parts Door Handle Airwash Control Handle Primary Air Caps Ash Pan Ash Pan Tool Coal Guard Baffle Plate Fixing Bar M8 Bolt M8 Nut Tightening Screw Wing Nut M6 Bolt M6 Nut Floor fixing bolt Rawl Plug Stove Glove... -
Page 6: Installation Instructions
Installation Instructions READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION These instructions cover the basic principles to ensure satisfactory installation of the stove, although detail may need slight modification to suit particular local site conditions. In all cases the installation must comply with National and European Building Regulations, Local Authority Byelaws and other specifications or regulations as they affect the installation of the stove. - Page 7 require 3 x 550 sq mm = 1650 sq mm of fixed ventilation. If more than one appliance is installed in the same room, the ventilation requirements for each appliance must be added together. If ventilation grilles are installed ensure they are free from any potential blockage.
- Page 8 Safety Distances from Combustible Surfaces: Side/Front HD Insert 4KW Stove 275mm* 275mm *The HD Insert 4KW stove can be situated 200mm from the side of a wooden fireplace mantel if the mantel is flush (or less deep) with the front of the appliance Commissioning and Handover Upon completion of the installation, allow a suitable period of time for any fire cement and mortar to dry out.
-
Page 9: Operating Instructions
Operating Instructions This appliance is not suitable for use in a shared flue. This appliance should not be operated with the doors open. This appliance is capable of intermittent operation. Aerosol Sprays Do not use an aerosol spray on or near the stove when it is alight. Air Controls This stove has been designed to burn clean and efficient. - Page 10 Your HD Insert Stove is fitted with a removable cast iron grate. It is important to de-ash regularly, to ensure that the primary airflow is not impeded, as a build-up of ash can damage the cast iron grate. Ashpan It is essential that you empty the ashpan regularly. Use the “T” end of tool to lift the ashpan out of the stove.
-
Page 11: Safety Notes For Your Guidance
Light the fire at the base leaving all air controls open. Allow the fuel to reach a steady glow and build the fire up gradually. Once you have a good fire established across the grate bed, further fuel can be added as required. Shutting Down In order to shut down the stove, close the primary air controls, then close the secondary air slider by moving the handle all the way to the left. -
Page 12: Frequently Asked Questions
Place a fireguard or spark guard in front of the stove. • Feel the chimneybreast for sign of excessive heat. • If the wall is becoming hot, move the furniture away. Ensure that the Fire Brigade can gain access to your roof space in order to check this area for signs of fire spread. Frequently Asked Questions 1 Do I need a fireplace suitable for solid fuel? The HD Insert Stove can only be installed in a fireplace that is suitable for burning solid... - Page 13 6 What warranty policy do I get? HD Insert Stoves will replace, free of charge, any working part that fails (under normal operating conditions) within 12 months of purchase. Consumables such as glass or stove rope are not guaranteed. A call out charge will apply if our engineer attends any stove problem that is not related to product failure.
