Summary of Contents for FIREFOLD HDMI-2SPLITTER
- Page 1 HDMI-2SPLITTER HDMI-2SPLITTER USER MANUAL Technical Support: Tel: 704-979-1700 Fax: 704-979-7150 E-mail: CustomerService@FireFold.com Address: FIREFOLD 2701 Derita Rd Concord, NC 28027 １ WWW.FIREFOLD.COM...
-
Page 2: Table Of Contents
HDMI-2SPLITTER Table Of Contents 1.0 Introduction………………………………...…………...……..3 2.0 Specifications…………………………………….………..……4 3.0 Package Contents………………………………………….…..5 4.0 Panel Descriptions…………………………………….…….…5 5.0 Connect and Operate............5 6.0 Troubleshooting……………………………………….…….…6 7.0 Limited Warranty……………………………………………..7 ２ WWW.FIREFOLD.COM... -
Page 3: Introduction
Every effort has been made to ensure that this product is free of defects. FireFold cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use. It is the responsibility of the user of the hardware to check that it is suitable for his/her requirements and that it is installed correctly. -
Page 4: Specifications
HDMI-2SPLITTER 2.0 SPECIFICATIONS Signal Inputs/Output Input Video Signal 0.5 -1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) Maximum Single Link Range 1920X1200, 1080P Output Video HDMI 1.2a+ HDCP1.0/1.1 Video format supported 640x480,800x600,1024x768,1920x1200 DTV/HDTV 480i/576i/480p/576p/720p/1080i/1080P Digital Signal I/O HDMI Compliance HDMI 1.3... -
Page 5: Package Contents
Note: Please retain the original packing material in the case of needing to return the unit. If you find any items are missing, contact FireFold immediately. Please have the model number, serial number and invoice available for reference when you call. -
Page 6: Troubleshooting
A non-HDCP compliant DVI device will not work with a signal that has HDCP encoding present 6.2 Cable Length If you need to span a longer distance to reach the amplifier splitter, purchase FIREFOLD’s HDMI Splitter/Extender which will allow you to extend a cable run up 100FT. ６ WWW.FIREFOLD.COM... -
Page 7: Limited Warranty
HDMI-2SPLITTER 7.0 LIMITED WARRANTY Should any consumer product from FireFold fail due to defects in materials or workmanship within one year from the date of the original sale to the end-user, FireFold guarantees that we will replace the defective product at no cost. Freight charges for the replacement unit will be paid by the customers.
