Page 1: User Manual
TB400 User Manual Version 6.11.43.14... -
Page 2: Table Of Contents
NeoGate TB400 User Manual Table of Contents 1. INTRODUCTION ..................4 1.1 Hardware Specification ................ 4 1.1.1 Exterior Appearance ..............4 2. SYSTEM SET UP ..................5 2.1 Installation of BRI Module..............5 2.2 Ethernet Line Connection ..............5 2.3 Power Supply Connection .............. - Page 3 NeoGate TB400 User Manual 3.6 System Settings ................32 3.6.1 Options ..................32 3.6.2 Password Settings ............... 33 3.6.3 Date and Time ................33 3.6.4 Backup and Restore..............34 3.6.5 Reset and Reboot ................ 34 3.6.6 Firmware Update................. 35 3.7 Reports ................... 36 3.7.1 Call Logs ..................
-
Page 4: Introduction
1. Introduction NeoGate Gateway for Maximum Efficiency & Cost Savings NeoGate TB400 is a device for connecting BRI Network to VoIP Network directly, which can support two-way communication: BRI to VoIP or VoIP to BRI. It is the best solution ever to connect IP-based telephone systems, soft switches, and IP-PBXs to BRI network. -
Page 5: System Set Up
Orange Shining: BRI 3 connected ⑦BRI 4 Orange Shining: BRI 4 connected 2) Back Side Figure 1-2 NeoGate TB400 Back Side Picture 2. System set up 2.1 Installation of BRI Module. Open the case of NeoGate, adjust the pins to the slots and insert then insert the spins into the slots. -
Page 6: Power Supply Connection
NeoGate TB400 User Manual the other end of the Ethernet line with a hub, switch, router, LAN or WAN. Once connected, check the status of the LED indicator. The orange LED indicates connected successfully, while green indicates the port is working property 2.3 Power Supply Connection... -
Page 7: Bri Settings
NeoGate TB400 User Manual Figure 3-1 3.2 BRI Settings 3.2.1 Module List You can check the information of the status of BRI modules and trunks. Click edit to configure the trunk. Figure 3.2.1 NeoGate Status Description: Status... -
Page 8: Bri Settings
NeoGate TB400 User Manual OK: The port is idle. Disconnected: No line connects to this port. 3.2.2 BRI Settings 3.2.2.1 Basic Settings Figure 3.2.2.1 Trunk Name: A name of this Trunk. Ex: 'BRI1' etc. Signaling: You can choose the signaling of BRI. It supports BIR-NET, BRI-NET-PTMP, BRI CPE, BRI-CPE-PTMP. -
Page 9: Advanced Settings
NeoGate TB400 User Manual 3.2.2.3 Advanced Settings Figure 3.2.2.3 ·Switch Type: National: National ISDN type2 (common in US) ni1: National ISDN type1 dms100: Nortel DMS100 4ess: AT&T 4ESS 5ess: Lucent 53SS Euroisdn: Euro ISDN Qsig: Minimalistic protocol to build a ‘network’ with two or more pbx of different vendors. - Page 10 NeoGate TB400 User Manual ·Overlap Dial Whether MyPBX can dial this switch using overlap digits. If you need Direct Dial-in (DDI; in German \"Durchwahl\") you should change this to yes, then MyPBX will wait after the last digit it receives.
-
Page 11: Dod Settings
NeoGate TB400 User Manual 3.2.2.4 DOD settings Spare DOD for each numbers, which is higher than the default DOD in priority Figure 3.2.2.4 3.3 VOIP Settings 3.3.1 Trunks We can create multiply trunks here to the provider in this page 3.3.1.1 VOIP Account... - Page 12 NeoGate TB400 User Manual Figure 3.3.1.1 · Name Define the name of this trunk · Type Choose the type of this trunk, SIP or IAX, the default is SIP · Transport Define the transport here, UDP, TCP or TLS, the default is UDP (recommend) ·...
-
Page 13: Voip Trunk
NeoGate TB400 User Manual ·Permitted ‘IP address/Subnet mask’ The input format should be ‘IP address’+’/’+’Subnet mask’. e.g."192.168.5.100/255.255.255.255" means only the device whose IP address is 192.168.5.100 is allowed to register this extension number. e.g."192.168.5.0/255.255.255.0" means only the device whose IP address is 192.168.5.XXX is allowed to register this extension number... -
Page 14: Service Provider
NeoGate TB400 User Manual · Outbound Proxy Server A proxy that receives requests from a client, even though which may not be the server resolved by the Request-URI. ·Enable SRTP Define whether SRTP is enabled ·Caller ID Define the default caller id of this trunk (default DOD) Figure 3.3.1.2... -
Page 15: Advanced Setting
NeoGate TB400 User Manual Note: 5060 is the standard port number used by SIP protocol. Don’t change this part if it is not required. Figure 3.3.1.3 3.3.1.4 Advanced Setting ·Max. Call Duration (min) Set the maximum call duration here. 0 means no limit. -
Page 16: Dod Settings
NeoGate TB400 User Manual 3.3.1.5 DOD settings Figure 3.3.1.5 Spare DOD for each numbers, which is higher than the default DOD in priority 3.3.2 SIP settings 3.3.2.1 General Figure 3.3.2.1... -
Page 17: Nat
NeoGate TB400 User Manual ·UDP Port Port use for sip registrations, Default is 5060. ·RTP Port Start Beginning of RTP port range ·RTP Port End End of RTP port range ·Max Registration/Subscription Time Put down the maximum duration (in seconds) of a SIP registration. Default is 3600 seconds. - Page 18 NeoGate TB400 User Manual Figure 3.3.2.2 ·Enable STUN STUN (Simple Traversal of UDP through NATs) is a protocol for assisting devices behind a NAT firewall or router with their packet routing. ·STUN Address The STUN server allows clients to find out their public address, the type of NAT they are behind and the internet side port associated by the NAT with a particular local port.
-
Page 19: Codes
NeoGate TB400 User Manual '192.168.0.0/255.255.0.0' : All RFC 1918 addresses are local networks; '10.0.0.0/255.0.0.0' : Also RFC1918; '172.16.0.0/12':Another RFC1918 with CIDR notation; '169.254.0.0/255.255.0.0' : Zero conf local network. Please refer to RFC1918 for more information. ·NAT Mode Global NAT configuration for the system. The options for this setting are as follows: Yes = Use NAT. -
Page 20: Advance Settings
NeoGate TB400 User Manual Figure 3.3.2.4 3.3.2.5 Advance settings Define where to get the DID and the caller ID Figure 3.3.2.5 ·From field Define where to get the caller ID ·To field Define where to get the DID 3.3.3 IAX settings If the trunk you have created is IAX, you need configure some details here 3.3.3.1 General... -
Page 21: Route Settings
NeoGate TB400 User Manual ·Bandwidth Low/medium/high with this option you can control which codec to be used. ·Min Registration Time Minimum duration (in seconds) of a IAX2 registration. Default is 60 seconds. ·Max Registration Time Maximum duration (in seconds) of a IAX2 registration. Default is 1200 seconds. - Page 22 NeoGate TB400 User Manual The scope of time which is allowed to make calls via this route. ·Dial pattern Outbound calls that match this dial pattern will use this outbound route. There are a number of dial pattern characters that have special meanings:...
- Page 23 NeoGate TB400 User Manual ·DID Number Define the expected DID Number if this trunk passes DID on incoming calls. Leave this field blank to match calls with any or no DID info. Only service provider, E1 trunks, BRI trunks or SIP trunks need to be configured with this setting.
-
Page 24: Black List
NeoGate TB400 User Manual Figure 3.4.1.1 3.4.2 Black list Blacklist is used to block an incoming/outgoing call for the numbers you have set here... -
Page 25: Network Settings
NeoGate TB400 User Manual Figure 3.4.2 3.5 Network Settings 3.5.1 LAN settings Figure 3.5.1 ·DHCP If this option is set, NeoGate will use DHCP to get an available IP address from your local network. Not recommended. ·Enable SSH This is the advance way to access the device, you can use the putty software to access the device. -
Page 26: 2Firewall
NeoGate TB400 User Manual Set the host name for NeoGate. ·IP Address Set the IP Address for NeoGate. ·Subnet Mask Set the subnet mask for NeoGate. ·Gateway Set the gateway for NeoGate. ·Primary DNS Set the primary DNS for NeoGate. - Page 27 NeoGate TB400 User Manual Figure 3.5.2.1 1) Enable Firewall Enable the firewall to protect the device. 2) Common Rules ·Name A name for this rule , e.g. ‘HTTP’. ·Description Simple description for this rule . E.g.: Accept the specific host to access the web interface for configuration.
- Page 28 NeoGate TB400 User Manual ·Action Accept: Accept the access from remote hosts. Drop: Drop the access from remote hosts. Ignore: Ignore the access. Figure 3.5.2.2 3) Auto Defense ·Port Auto defense port, e.g.: 8022. ·Protocol Auto defense protocol , TCP or UDP.
-
Page 29: Vlan Settings
NeoGate TB400 User Manual ·Port The port used for SIP protocol. ·Protocol Choose the protocol need to be protect, etc: UDP. ·SIP Packets The SIP packets allowed in specific time interval . ·Time Interval The time interval to receive SIP packets . - Page 30 NeoGate TB400 User Manual Figure 3.5.3 ·NO.1 Click the NO.1 you can edit the first VLAN over Lan. ·VLAN Number .The VLAN Number is a unique value you assign to each VLAN on a single device. ·VLAN IP Address Set the IP Address for NeoGate VLAN.
-
Page 31: Vpn Settings
NeoGate TB400 User Manual 3.5.4 VPN Settings A virtual private network (VPN) is a method of computer networking--typically using the public internet--that allows users to privately share information between remote locations, or between a remote location and a business' home network. -
Page 32: System Settings
NeoGate TB400 User Manual ·Password User account’s password . ·Host Name Note: DDNS allows you to access your network using domain names instead of IP address. The service manages changing IP address and updates your domain information dynamically. You must sign up for service through dyndns.org, freedns.afraid.org, www.no-ip.com, www.zoneedit.com... -
Page 33: Password Settings
NeoGate TB400 User Manual .MAX Call Duration The absolute maximum amount of time permitted for a call. A setting of 0 disables the timeout. Default value is 6000s. ·HTTP Bind Port/Web Access Port Port use for HTTP sessions. Default: 80 3.6.2 Password Settings... -
Page 34: Backup And Restore
NeoGate TB400 User Manual Figure 3.6.3 3.6.4 Backup and Restore You can backup your configure in this page. After back up, you can see the back up in the list. You can restore the configure in this page also. Note: the restore will only work after reboot. -
Page 35: Firmware Update
NeoGate TB400 User Manual Figure 3.6.5 3.6.6 Firmware Update Upgrading of the firmware is possible through the Administrator web interface using a TFTP Server or an HTTP URL. Enter your TFTP Server IP address and firmware file location, then click start to update the firmware. -
Page 36: Reports
NeoGate TB400 User Manual 3.7 Reports 3.7.1 Call Logs The call Log captures all call details, including Source, Destination, Start Time, End Time, Duration, Billable Duration, Disposition, Communication Type, etc. Administrator can export CDR data to a CSV file. Figure 3.7.1 3.7.2 System Info... -
Page 37: Application
NeoGate TB400 User Manual Figure 3.7.2 4. Application Application 1 Figure 4-1 Application 2... - Page 38 NeoGate TB400 User Manual Figure 4-2 <Finish>...
