TC Series Cutting Plotter
User's Manual
TC Series Cutting Plotter.
Thank you very much for purchasing LIYU
TM
To ensure correct and safe usage with a full understanding of this product's
performance, please be sure to read through this manual completely and
store it in a safe location.
The contents of this operation manual and the specifications of this product
are subject to change without notice.
The operation manual and the product have been prepared and tested as
much as possible. If you find any misprint or error, please inform us.
ANHUI LIYU COMPUTER EQUIPMENT MANUFACTURING CO., LTD.
Hefei, Anhui, China
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Anhui Liyu Computer Equipment Manufacturing TC Series
- Page 1 The operation manual and the product have been prepared and tested as much as possible. If you find any misprint or error, please inform us. ANHUI LIYU COMPUTER EQUIPMENT MANUFACTURING CO., LTD. Hefei, Anhui, China...
-
Page 2: Table Of Contents
User’s Manual of TC Series Cutting Plotter Table of Contents Chap 1 Attention.................…..………..3 Chap 2 Part Names and Functions.............……….……..4 2-1 Accessories..................…..……..4 2-2 Introduction of main machine..............……...…...4 2-3 Parts of stand and assembly...............…...….…..5 2-4 Cutter/Plotter..................….….……..6 2-5 Parameters table................…….…..7 Chap 3 Operation Directions............…………...…..8 3-1 Installation of the USB driver............………….……..8... -
Page 3: Chap 1 Attention
User’s Manual of TC Series Cutting Plotter Chap 1 Attention Ensure the supply voltage to the TMC Series Cutting Plotter is AC220V and varying within the range of ±10%, otherwise a voltage stabilizer must be used. Please don’t place any small iron-magnetic subject near the carriage. -
Page 4: Chap 2 Part Names And Functions
User’s Manual of TC Series Cutting Plotter Chap 2 Part Names and Functions 2-1 Accessories Item Quantity Main machine Cutter holder Plotter holder Refill Cutter USB cable Note ： There is a free Power cord special machine stand for Machine cover... -
Page 5: Parts Of Stand And Assembly
User’s Manual of TC Series Cutting Plotter 2-3 Parts of stand and assembly 1 Parts of stand Item Quantity Pillars Pillar-bars Left column Right column Crossbeam Paper-hold roller of variable distance Connection board Paper roller Screw M4×20 Screw M4×8 2 Assembly of machine stand... -
Page 6: Cutter/Plotter
User’s Manual of TC Series Cutting Plotter 2-4 Cutter/Plotter 1 Structure of cutter holder and items of components Rotate the cutter holder to adjust the out-stretching length of the cutter as to ensure that it doesn’t cut off the bottom layer of stickness (consists of upper and bottom layer). -
Page 7: Parameters Table
User’s Manual of TC Series Cutting Plotter 2-5 Parameters table ITEMS / MODEL TC631 /801 TC1061/1261 1060mm/1260 Maximum cutting size 630mm/800mm Maximum media size 710mm/880mm 1130 mm/1350 800 mm/s Cutting speed (8—800)g Cutting force 0.025mm/step Mechanical resolution Buffer capacity 0.1mm... -
Page 8: Chap 3 Operation Directions
User’s Manual of TC Series Cutting Plotter Chap 3 Operation Directions 3-1 Installation of the USB driver During the installing of the USB driver, any operate to the controlling-panel is invalidation. 1 Turn on the power and connect the USB cable with the computer. - Page 9 User’s Manual of TC Series Cutting Plotter 3 Select , then click 4 Select , then click ９...
- Page 10 User’s Manual of TC Series Cutting Plotter 5 Select as following drawing, then click 6 Click １０...
- Page 11 User’s Manual of TC Series Cutting Plotter 7 Click ,choose the LiYuDrv and install(in the CD-ROM/USB Drv); １１...
- Page 12 User’s Manual of TC Series Cutting Plotter １２...
- Page 13 User’s Manual of TC Series Cutting Plotter 8 Click for finish the installation of the USB driver; １３...
- Page 14 User’s Manual of TC Series Cutting Plotter 9 After installation，the device will appeared in the Device Manager as follows，please change the port number according to the require of the computer. １４...
-
Page 15: Controlling-Panel Operations
User’s Manual of TC Series Cutting Plotter 3-2 Controlling-panel operations Controlling-panel Static screen: In the connecting state, when waiting for the data inputting, LCD displays: SPD：6 PRS：8 LOCAL TEST COPY Therein, SPD:6 means the current speed is the sixth level, PRS:8 means the current press is the eighth level. - Page 16 User’s Manual of TC Series Cutting Plotter Original point: The place of cutter/plotter just at the time of confirming “LOCAL” state. Select key: In the static screen state, press this key can select “LOCAL”, “TEST” and “COPY” function in sequence.
-
Page 17: Operation Skills
User’s Manual of TC Series Cutting Plotter Test function: Under the static screen, press SELECT key to select “TEST” function, then press ENTER key, the machine will plot self-check graph. Light:ON OFF: When the cursor in the “ON”, press ENTER key can choose the Light ON or OFF, the LCD does not quit this interface and displays: SPD：6... - Page 18 User’s Manual of TC Series Cutting Plotter 3 Lift up / adhere When cutting over… 1. Cut off the paper with scissors or a knife. 2. Get rid of the useless part with tweezers (you can easily do this if you add a side frame around the pattern when cutting).
-
Page 19: Chap 4 Faq
User’s Manual of TC Series Cutting Plotter Chap 4 FAQ Question 1: What shall I do if I can not enter into the cutting system? Answer: 1. The files of the cutting system are damaged. Reinstall the cutting system with the CD-ROM enclosed. - Page 20 User’s Manual of TC Series Cutting Plotter knifepoint will pick the film and cause the waster. 2. Suggest using the compensation function for best effect when cutting the small pattern. The angle compensation should be set between 0.3mm to 0.5mm according to the fact.
- Page 21 User’s Manual of TC Series Cutting Plotter Question 8: Why the paper cannot return to the original point? Answer: 1. Wrong operation on the pinch-rollers. 2. The pinch-rollers is frayed badly. 3. The paper is not loaded rightly. 4. No test running of the paper before cutting the long pattern.
