Pyroclassic Fires Pyroclassic Flue System Installation Instructions Manual

100mm sloping ceiling eco flue kit

INSTALLATION INSTRUCTIONS

for PYROCLASSIC FIRES LTD

100mm SLOPING CEILING ECO FLUE KIT

THIS FLUE KIT HAS BEEN MANUFACTURED IN ACCORDANCE WITH AS/NZS 2918:2001.

WARNING: TO ENSURE SAFETY THIS FLUE KIT MUST BE INSTALLED AS OUTLINED IN THESE INSTRUCTIONS.

WOOD FIRE AND FLUE PIPE CLEARANCES FROM COMBUSTIBLE WALLS MUST BE IN ACCORDANCE WITH

WOOD FIRE MANUFACTURERS SPECIFICATIONS AND AS/NZS 2918:2001.

CAUTION: MIXING FLUE SYSTEM COMPONENTS FROM DIFFERENT SOURCES OR MODIFYING THE

DIMENSIONAL SPECIFICATION OF COMPONENTS MAY RESULT IN HAZARDOUS CONDITIONS. WHERE SUCH

ACTION IS CONSIDERED, THE MANUFACTURER SHOULD BE CONSULTED IN THE FIRST INSTANCE.

CAUTION: IT IS THE RESPONSIBILITY OF THE INSTALLER TO ENSURE THAT THE INSTALLATION OF THIS FLUE

KIT COMPLIES WITH AS/NZS 2918:2001. THE APPLIANCE MANUFACTURERS SPECIFICATIONS FOR FLUE PIPE

SHIELD AND CEILING PLATE AND THAT THE RELEVANT BUILDING CODES ARE ADHERED TO.

To install this flue design the installer should be familiar with the installation of flue kits for standard ceilings

and have competent carpentry and roofing skills. They should also be aware of the 4.6 metre height

requirements of AS/NZS 2918:2001 and minimum height requirements as per figure 4.9 (Diagram C).

This Sloping Ceiling kit is designed for installations into ceilings with slopes of up to 45 degrees.

All instructions refer to Diagrams C and D.

The flue pipes are tapered to fit the upper section inside the lower one.

Our Full Flow Cowl (ie. no cap), prevents dripping of condensed acids down the chimney.

The flue discharges some 18 litres of water as vapour for each 30kg of dry wood burned.

Do not put a cap on the Pyroclassic Flue System.

Table of Contents

Do you have a question about the Pyroclassic Flue System and is the answer not in the manual?

Page 1: Installation Instructions
Our Full Flow Cowl (ie. no cap), prevents dripping of condensed acids down the chimney. The flue discharges some 18 litres of water as vapour for each 30kg of dry wood burned. Do not put a cap on the Pyroclassic Flue System.
Page 2 To install the Pyroclassic Sloping Ceiling Flue Kit begin by locating the Pyroclassic IV fire (or the Pyroclassic Raised Hearth if it is being used) in its proposed position, and mark a point on the ceiling that is directly above the centre of the fire’s flue outlet, (or the hole in the raised hearth). Check the location allows the Outer Casing of the Thermosyphon Assembly to clear all structural roof timbers.
Page 3 Push fit the Full Flow Pyroclassic Cowl Assembly into the upper end of top flue section sufficiently for a secure fit. (It is a tight interference fit and may require encouragement with a block of wood and hammer.). Slide slip liner upwards until it contacts the Free Flow Cowl skirt. Now fix the slip liner to the 200x600mm Liner with four rivets spaced equally around circumference.
