- Page 1 ® ConnectX -2 VPI Dual Port QSFP and SFP+ Card User’s Manual P/N: MHZH29-XTR, MHZH29-XSR Rev 1.0 www.mellanox.com...
- Page 2 THIS HARDWARE, SOFTWARE OR TEST SUITE PRODUCT (“PRODUCT(S)”) AND ITS RELATED DOCUMENTA- TION ARE PROVIDED BY MELLANOX TECHNOLOGIES “AS-IS” WITH ALL FAULTS OF ANY KIND AND SOLELY FOR THE PURPOSE OF AIDING THE CUSTOMER IN TESTING APPLICATIONS THAT USE THE PROD- UCTS IN DESIGNATED SOLUTIONS.
-
Page 3: Table Of Contents
Appendix B Interface Connectors Pinout B.1 I2C-Compatible Connector Pinout B.2 PCI Express x8 Connector Pinout B.3 QSFP Connector Pinout B.4 SFP+ Connector Pinout Appendix C Avertissements de sécurité d’installation (Warnings in French) Appendix D Sicherheitshinweise (Warnings in German) Mellanox Technologies... -
Page 4: List Of Figures
Figure 12: Placing the Bracket on the Card Figure 13: Schematic of the ConnectX-2 MHZH Adapter Card Figure 14: Compatible Connector Plug and Pinout Figure 15: Connector and Cage Views Figure 16: Rear View of Module With Pin Placement Mellanox Technologies... -
Page 5: List Of Tables
Revision History Table Table 2: Documents List Table 3: Mellanox Cards Part Numbering Key Table 4: Hardware and Software Requirements Table 5: Jumper Configuration Table 6: Specifications for MHZH29-XTR Table 7: I2C-compatible Connector Pinout Table 8: SFP+ Connector Pinout Mellanox Technologies... -
Page 6: Revision History
Rev 1.0 Revision History This document was printed on 11/3/09. Table 1 - Revision History Table Date Comments/Changes October Initial Release 2009 Mellanox Technologies... -
Page 7: About This Manual
Rev 1.0 About this Manual ® This User’s Manual describes Mellanox Technologies ConnectX -2 VPI IB and Ethernet PCI Express x8 adapter cards. It provides details as to the interfaces of the board, specifications, required software and firmware for operating the board, and relevant documentation. -
Page 8: Chapter 1 Overview
Rev 1.0 Overview Overview This document is a User’s Manual for Mellanox Technologies network VPI adapter cards based on ® the MT25408 ConnectX -2 VPI integrated circuit device. The cards described in this manual have the following main features: • IBTA v1.2.1 compliant •... -
Page 9: Mellanox Part Numbering Legend
ConnectX-2 VPI InfiniBand and Ethernet Adapter Card User’s Manual Rev 1.0 Figure 1: Component Side Mellanox Part Numbering Legend Table 4 describes the Mellanox Technologies adapter cards part numbering legend. Table 4 - Mellanox Cards Part Numbering Key Adapter Card Field... -
Page 10: Finding The Guid/Mac And Serial Number On The Adapter Cards
<blank> = non RoHS, C = RoHS R-5 w/ Exemption, R = RoHS R-6 Lead-Free For example, the part number MHZH29-XTR describes Mellanox Technologies’ ConnectX-2 card with dual ports one SFP+ and one QSFP, a PCIe2.0 x8 5.0GT/s interface, no on-board memory (mem-free), a short PCI bracket, and RoHS R5 compliance. -
Page 11: Figure 2: Card Product Label
ConnectX-2 VPI InfiniBand and Ethernet Adapter Card User’s Manual Rev 1.0 Figure 2: Card Product Label S/N:MT0744X00012 REV: X1 P/N:MHZH29-XTR GUID: 0002C9030005646 C M AC: 0002C901122642 FC Made in IL Mellanox Technologies... -
Page 12: Chapter 2 Vpi Adapter Card Installation
2. Over-temperature This equipment should not be operated in an area with an ambient temperature exceeding the maximum recommended: 55°C (131°F). To guarantee proper air flow, allow at least 8cm (3 inches) of clearance around the ventilation openings. Mellanox Technologies... -
Page 13: Cables And Modules
IEC 60 825-1:1993 + A1:1997 + A2:2001 and EN 60825-1:1994+A1:1996+ A2:2001 Cables and Modules This card can be connected using direct copper cables or optical cables using an SFP+ transceiver module. Copper cables can be both active and passive. Mellanox Technologies... -
Page 14: Figure 3: Sfp+ Transceiver Module
When a logical connection is made the YELLOW LED will come on. When data is being transferred the YELLOW LED will blink. Mellanox Technologies... -
Page 15: Figure 6: Connector Orientation
2.4.2.2 Removing a Cable from the Adapter Card 1. Pull on the latch release mechanism thereby unlatching the connector and pull the connector out of the cage. 2. Do not apply torque to the connector when removing it from the adapter card. Mellanox Technologies... -
Page 16: Cable Lengths
Table 7 - Max LR Cable Lengths Cable Max Length of Approved Cable 10 Km These cards are able to support direct attached copper cables. Check www.mellanox.com => Prod- ucts => Cables for cable recommendations regarding direct attached copper cables. Mellanox Technologies... -
Page 17: Chapter 3 Driver Software And Firmware
Please contact Mellanox or your assigned Field Application Engineer if you cannot find the firmware binary for your adapter card. This may happen if the product is not yet available for gen- eral distribution. Mellanox Technologies... -
Page 18: Chapter 4 Adapter Card Interfaces
IEEE Std 802.3aq 10GBASE LRM. The SFP+ port has one Tx/Rx pair of SerDes. Each of the cards (listed in Table 3 on page 8) based on this device provides access to their Ethernet port by means of copper or optical cables. Mellanox Technologies... -
Page 19: Figure 8: Physical And Logical Link Indications
Note: The short bracket has the same port and LED footprint as the tall bracket. 4.1.5 I C Compatible Interface A three-pin header on the adapter card is provided as the I C compatible interface. See Figure 13,“Schematic of the ConnectX-2 MHZH Adapter Card” for the location on the board. Mellanox Technologies... -
Page 20: Power
Each board incorporates an EEPROM that is accessible through the I2C-compatible interface. The EEPROM is used for storing the Vital Product Data (VPD). The VPD format adheres to the PCI Local Bus Specification Rev 2.3 VPD definition. The EEPROM capacity is 4Kb. Mellanox Technologies... -
Page 21: Vpd Layout For These Adapter Cards
Rev 1.0 VPD Layout for these Adapter Cards The PCI VPD (Vital Product Data) layout, for each of the described Mellanox Technologies Con- nectX-2 VPI adapter cards comply with the format defined in the PCI 2.3 Specification, Appendix I. All ConnectX-2 adapter cards have the same PCI VPD layout. - Page 22 Adapter Card Interfaces Table 10 - VPD Layout for MHZH29-X[ST]R Offset (Decimal) Item Value Format Description Length 0x20 Data STR_SPC “N/A” VPD Keyword Remaining read/write area Length 0x72 Data STR_ZERO Reserved (0x00) Small Resource Type END Tag 0x78 (0x11) Mellanox Technologies...
-
Page 23: Chapter 5 Replacing A Tall Bracket With A Short Bracket
Installing the New Bracket 1. Remove the paper to expose the adhesive on the gasket. 2. Place the extra square gasket onto the new bracket. Make sure to correctly align the gasket with the hole in the bracket. Mellanox Technologies... -
Page 24: Figure 12: Placing The Bracket On The Card
Figure 12: Placing the Bracket on the Card Gasket in place on the bracket. 5. Make sure that the LEDs are aligned onto the bracket holes. 6. Use a torque driver to apply up to 2 lbs-in torque on the screws. Mellanox Technologies... -
Page 25: Appendix A Specifications
Figure 13. Note: All dimensions are in millimeters. Figure 13: Schematic of the ConnectX-2 MHZH Adapter Card J3 – Flash Jumper J1 – I2C Connector 167.65 64.40 68.90 56.97 56.12 15.00 3.65 1.90 33.35 43.13 57.13 96.30 Mellanox Technologies... -
Page 26: A.2 Emc Certification Statements
§ 15.21 Statement Warning! Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Mellanox Technologies) could void the user's authority to operate the equipment. §15.105(a) Statement NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. - Page 27 (Translation - "This is a Class A product based on the standard of the Voluntary Control Council for Interfer- ence by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio interference may occur, in which case the user may be required to take corrective actions.") Mellanox Technologies...
-
Page 28: A.3 Mhzh29-X[St]R Specifications
Environmental: IEC/EN 60950-1:2001 each port ETSI EN 300 019-2-2 IEC 60068-2- 64, 29, 32 RDMA Support: Yes, All Ports RoHS: RoHS-R6 Data Rate SFP+ Ethernet: 10 Gb/s QSFP InfiniBand: 40 Gb/s PCI Express: 2.0 SERDES @ 5.0 GT/s Mellanox Technologies... -
Page 29: Appendix B Interface Connectors Pinout
SPSDA 5 1 2 3 4 SPSCL B.2 PCI Express x8 Connector Pinout The adapter cards use a standard PCI Express x8 edge connector and the PCI Express x8 standard pinout according to the PCI Express 2.0 specification. Mellanox Technologies... -
Page 30: B.3 Qsfp Connector Pinout
ModSelL_Port0 ModSelL ResetL_Port0 ResetL VccRx RXP_3 Rx3p RXN_3 Rx3n RXP_1 Rx1p RXN_1 Rx1n RXN_2 Rx2n RXP_2 Rx2p RXN_4 Rx4n RXP_4 Rx4p ModPrsl_Port0 Mod PrsL IntL IntL VccTx Vcc1 LPMode_Port0 LPMode TXP_3 Tx3p TXN_3 Tx3n TXP_1 Tx1p TXN_1 Tx1n Mellanox Technologies... -
Page 31: Figure 15: Connector And Cage Views
ConnectX-2 VPI InfiniBand and Ethernet Adapter Card User’s Manual Rev 1.0 Figure 14: Connector and Cage Views 18.35 View into Rear of Module 8.50 18.35 View into Front of Cage 8.50 Mellanox Technologies... -
Page 32: Sfp+ Connector Pinout
Rev 1.0 B.4 SFP+ Connector Pinout Figure 15: Rear View of Module With Pin Placement 13.70 8.50 SFP+ Cage Mellanox Technologies... - Page 33 LOS is open collector output. Should be pulled up with 4.7kΩ – 10kΩ on host board to a voltage between 2.0V and 3.6V. Logic 0 indicates normal operation; logic 1 indicates loss of signal. Mellanox Technologies...
-
Page 34: Appendix C Avertissements De Sécurité D'installation (Warnings In French)
Ce matériel ne doit être installé, remplacé ou entretenu que par du personnel formé et qualifié. 6. Elimination du matériel L’élimination de ce matériel doit s’effectuer dans le respect de toutes les légis- lations et réglementations nationales en vigueur. Mellanox Technologies... - Page 35 PRODUIT LASER DE CLASSE 1 » et références aux normes laser les plus récentes CEI 60 825-1:1993 + A1:1997 + A2:2001 et NE 60825- 1:1994+A1:1996+ A2:2001 Mellanox Technologies...
-
Page 36: Appendix D Sicherheitshinweise (Warnings In German)
Anschlüsse angebracht bzw. davon getrennt werden. Lesen Sie die speziellen Warnungen und Anleitungen des Kabelherstellers. Geräteinstallation Diese Gerät sollte nur von geschultem und qualifiziertem Personal installiert, ausgetauscht oder gewartet werden. 6. Geräteentsorgung Die Entsorgung dieses Geräts sollte unter Beachtung aller nationalen Gesetze Bestimmungen erfolgen. Mellanox Technologies... - Page 37 Achtung – Nutzung von Steuerungen oder Einstellungen oder Ausführung von Prozeduren, die hier nicht spezifiziert sind, kann zu gefährlichem Strahlenkon- takt führen.. Klasse 1 Laserprodukt und Referenzen zu den aktuellsten Lasterstandards : ICE 60 825-1:1993 + A1:1997 + A2:2001 und EN 60825-1:1994+A1:1996+ A2:2001 Mellanox Technologies...
